Page 10 of 153
33
5
5
3
14
Interior VENTILATION
Heating Automatic air
conditioning
51 53
Air conditioning
CHILD SAFETY
Child seats
103
102
Air bag disarming
Recommended settings for the Manual Air Conditioning
For optimum use of the system, we recommend:
If
I require... Air
distribution
Temperature A i r fl o w Air
recirculation AC
Heating -
Cooling
De-icing
Demisting 55
With Automatic Air Conditioning, operation in AUTO mode is recommended
irrespective of the requirement.
Remember to switch the system off when the ambient air suits
your requirements.
Page 29 of 153
READY TO SET OFF
33 33
22
Instruments and controls
FUEL GAUGE COOLANT TEMPERATURE
The needle is positioned between
the blue zone and the red zone:
normal operation.
In arduous conditions of use or hot
climatic conditions, the needle may
move close to the red graduations.
What you should do if the needle
enters the red zone:
Reduce your speed or let the engine
run at idle.
What you should do if the warning
light comes on:
- stop immediately, switch off the ignition. The fan may continue to
operate for a certain time up to
a p p r o x i m a t e l y 1 0 m i n u t e s .
- wait for the engine to cool down in order to check the coolant level and
top it up if necessary.
As the cooling system is pressurised,
follow this advice in order to avoid any
risk of scalding:
- wait at least one hour after switching off the engine before
carrying out any work,
- unscrew the cap by 1/4 turn to allow the pressure to drop,
- when the pressure has dropped, c h e c k t h e l e v e l o n t h e e x p a n s i o n
bottle,
-
if necessary, remove the cap to top up.
If the needle remains in the red
zone, have the system checked by a
CITROËN dealer.
Refer to the "Levels" section of
chapter 7.
Refer to the "Fuel" section of
chapter 7.
The fuel level is tested each time the
key is turned to the "running" position.
The gauge is positioned on:
-
1: the fuel tank is full,
a p p r o x i m a t e l y 6 0 l i t r e s .
- 0: the reserve is now being
used, the warning light comes on
continuously. The reserve when
t h e w a r n i n g fi r s t c o m e s o n i s
a p p r o x i m a t e l y 8 l i t r e s .
Page 114 of 153
109
Towing a trailer
ACCESSORIES
6
For more information about
weights, refer to the administrative
documents (V5 registration
document, ...) or to the "Weights"
section of chapter 9.
TOWING A TRAILER, CARAVAN, BOAT, ETC...
Distribution of loads
Distribute the load in the trailer so
that the heaviest objects are as
close as possible to the axle and
the nose weight is close to the
maximum authorised without, however,
exceeding it.
Cooling
Towing a trailer on a slope increases
the coolant temperature. As the fan is electrically controlled, its
cooling capacity is not dependent on
the engine speed.
On the contrary, use a high gear to
lower the engine speed and reduce
your speed.
In all cases, pay attention to the
coolant temperature.
Driving advice
A towed vehicle must free wheel:
gearbox in neutral.
Page 122 of 153
117
CHECKS
77
Levels
Cooling system
O n l y u s e t h e fl u i d r e c o m m e n d e d b y t h e
m a n u f a c t u r e r .
O t h e r w i s e , y o u r i s k s e r i o u s l y d a m a g i n g
y o u r e n g i n e .
W h e n t h e e n g i n e i s w a r m , t h e
t e m p e r a t u r e o f t h e c o o l a n t i s c o n t r o l l e d
b y t h e e n g i n e f a n . A s t h i s f a n c a n
o p e r a t e w i t h t h e i g n i t i o n k e y r e m o v e d
a n d b e c a u s e t h e c o o l i n g s y s t e m i s
p r e s s u r i s e d , w a i t f o r a t l e a s t o n e h o u r
a f t e r t h e e n g i n e h a s s t o p p e d b e f o r e
c a r r y i n g o u t a n y w o r k .
S l a c k e n t h e c a p b y 1 / 4 o f a t u r n t o
r e l e a s e t h e p r e s s u r e t o p r e v e n t a n y
r i s k o f s c a l d i n g . W h e n t h e p r e s s u r e
h a s d r o p p e d , r e m o v e t h e c a p a n d t o p
u p t h e l e v e l w i t h c o o l a n t .
I f fl u i d h a s t o b e a d d e d f r e q u e n t l y ,
t h i s i n d i c a t e s a f a i l u r e w h i c h m u s t b e
c h e c k e d b y a C I T R O Ë N d e a l e r a s
s o o n a s p o s s i b l e . Power steering fluid level
T h e v e h i c l e m u s t b e p a r k e d o n l e v e l
g r o u n d w i t h t h e e n g i n e c o l d . U n s c r e w
t h e c a p i n t e g r a t e d w i t h t h e g a u g e a n d
c h e c k t h e l e v e l w h i c h m u s t b e b e t w e e n
t h e M I N a n d M A X m a r k s .
I n o r d e r t o r e g e n e r a t e t h e fi l t e r , y o u
a r e a d v i s e d t o d r i v e a t a s p e e d h i g h e r
t h a n 4 0 m p h ( 6 0 k m / h ) f o r a t l e a s t fi v e
m i n u t e s a s s o o n a s p o s s i b l e , w h e n
t r a f fi c c o n d i t i o n s p e r m i t ( u n t i l t h e
m e s s a g e d i s a p p e a r s a n d t h e s e r v i c e
w a r n i n g l i g h t i s s w i t c h e d o f f ) .
D u r i n g r e g e n e r a t i o n o f t h e p a r t i c l e
e m i s s i o n fi l t e r , r e l a y n o i s e m a y b e
h e a r d u n d e r t h e f a s c i a .
I f t h e m e s s a g e i s s t i l l d i s p l a y e d a n d i f
t h e s e r v i c e w a r n i n g l i g h t r e m a i n s o n ,
c o n s u l t a C I T R O Ë N d e a l e r .
Topping up
T h e l e v e l m u s t b e b e t w e e n t h e M I N
a n d M A X m a r k s o n t h e e x p a n s i o n
b o t t l e . I f m o r e t h a n 1 l i t r e o f fl u i d i s
r e q u i r e d t o t o p u p t h e l e v e l , h a v e t h e
s y s t e m c h e c k e d b y a C I T R O Ë N d e a l e r . Windscreen wash and headlamp
wash level
F o r b e s t q u a l i t y c l e a n i n g a n d f o r y o u r
s a f e t y , w e w o u l d a d v i s e t h a t y o u u s e
p r o d u c t s o f t h e C I T R O Ë N r a n g e .
F o r o p t i m u m c l e a n i n g a n d t o a v o i d
f r e e z i n g , t h i s fl u i d m u s t n o t b e t o p p e d
u p o r r e p l a c e d w i t h w a t e r .
C a p a c i t y o f t h e s c r e e n w a s h r e s e r v o i r :
a p p r o x i m a t e l y 4 . 5 l i t r e s .
I f y o u r v e h i c l e i s fi t t e d w i t h h e a d l a m p
w a s h e r s , t h e c a p a c i t y o f t h e r e s e r v o i r
i s 7 . 5 l i t r e s .
Diesel additive level
(Diesel with particle
emission filter)
T h e m i n i m u m l e v e l o f t h i s
a d d i t i v e i s i n d i c a t e d b y l i g h t i n g o f t h e
s e r v i c e w a r n i n g l i g h t , a c c o m p a n i e d b y
a n a u d i b l e s i g n a l a n d a m e s s a g e o n
t h e d i s p l a y .
W h e n t h i s o c c u r s w i t h t h e e n g i n e
r u n n i n g i t i s d u e t o t h e s t a r t o f
s a t u r a t i o n o f t h e p a r t i c l e e m i s s i o n fi l t e r
( e x c e p t i o n a l l y p r o l o n g e d u r b a n t y p e
d r i v i n g c o n d i t i o n s : l o w s p e e d , l o n g
t r a f fi c j a m s , . . . ) . Topping up
I t i s i m p e r a t i v e t h a t t h i s a d d i t i v e i s
t o p p e d u p b y a C I T R O Ë N d e a l e r
w i t h o u t d e l a y .
Used oil
A v o i d p r o l o n g e d c o n t a c t o f u s e d o i l
w i t h t h e s k i n .
B r a k e fl u i d i s h a r m f u l t o h e a l t h a n d
v e r y c o r r o s i v e .
D o n o t d i s p o s e o f u s e d o i l , b r a k e fl u i d
o r c o o l a n t i n t o d r a i n s o r i n t o t h e g r o u n d
b u t i n t o t h e c o n t a i n e r s d e d i c a t e d t o t h i s
u s e a t C I T R O Ë N d e a l e r .
Page 131 of 153
126
Snow screen
6. REFITTING THE REPAIRED WHEEL
T h e w h e e l i s r e fi t t e d a s d e s c r i b e d i n
s t e p 5 , n o t f o r g e t t i n g t o r e fi t t h e w h e e l
trim.
R e f e r t o t h e " I n s t r u m e n t s a n d
c o n t r o l s " s e c t i o n o f c h a p t e r 2 ,
" T y r e u n d e r - i n fl a t i o n d e t e c t i o n "
p a r t , f o r r e c o m m e n d a t i o n s a f t e r
c h a n g i n g a w h e e l fi t t e d w i t h a t y r e
u n d e r - i n fl a t i o n d e t e c t i o n s e n s o r . R e f e r t o t h e " I d e n t i fi c a t i o n
f e a t u r e s " s e c t i o n o f c h a p t e r 9 t o
locate the tyre label.
REMOVABLE SNOW SCREEN
According to country, the removable
snow screen is installed on the lower
p a r t o f t h e f r o n t b u m p e r t o p r e v e n t t h e
accumulation of snow at the radiator
cooling fan.
Do not forget to remove the snow
s c r e e n w h e n t h e e x t e r i o r t e m p e r a t u r e
i s h i g h e r t h a n 1 0 ° C ( n o r i s k o f
snowfall) and when towing.
FITTING
REMOVAL
- Pass a screwdriver into the hole
l o c a t e d n e a r e a c h o f t h e c l i p s .
- Use the screwdriver as a lever to u n c l i p t h e f o u r c l i p s B in turn.
- O f f e r u p t h e s n o w s c r e e n f a c i n g i t s
c e n t r i n g p i n A o n t h e f r o n t b u m p e r .
- P u t i t i n p l a c e b y p r e s s i n g a t e a c h c l i p B located in the four corners.
T h e s p a r e w h e e l i s n o t d e s i g n e d
to be used over long distances.
Have the tightening of the bolts
a n d t h e t y r e p r e s s u r e c h e c k e d b y a
C I T R O Ë N d e a l e r a s s o o n a s p o s s i b l e .
A l s o , h a v e t h e o r i g i n a l w h e e l r e p a i r e d
a n d r e fi t t e d b y a C I T R O Ë N d e a l e r a s
s o o n a s p o s s i b l e .
Page 132 of 153
126
Snow screen
6. REFITTING THE REPAIRED WHEEL
T h e w h e e l i s r e fi t t e d a s d e s c r i b e d i n
s t e p 5 , n o t f o r g e t t i n g t o r e fi t t h e w h e e l
trim.
R e f e r t o t h e " I n s t r u m e n t s a n d
c o n t r o l s " s e c t i o n o f c h a p t e r 2 ,
" T y r e u n d e r - i n fl a t i o n d e t e c t i o n "
p a r t , f o r r e c o m m e n d a t i o n s a f t e r
c h a n g i n g a w h e e l fi t t e d w i t h a t y r e
u n d e r - i n fl a t i o n d e t e c t i o n s e n s o r . R e f e r t o t h e " I d e n t i fi c a t i o n
f e a t u r e s " s e c t i o n o f c h a p t e r 9 t o
locate the tyre label.
REMOVABLE SNOW SCREEN
According to country, the removable
snow screen is installed on the lower
p a r t o f t h e f r o n t b u m p e r t o p r e v e n t t h e
accumulation of snow at the radiator
cooling fan.
Do not forget to remove the snow
s c r e e n w h e n t h e e x t e r i o r t e m p e r a t u r e
i s h i g h e r t h a n 1 0 ° C ( n o r i s k o f
snowfall) and when towing.
FITTING
REMOVAL
- Pass a screwdriver into the hole
l o c a t e d n e a r e a c h o f t h e c l i p s .
- Use the screwdriver as a lever to u n c l i p t h e f o u r c l i p s B in turn.
- O f f e r u p t h e s n o w s c r e e n f a c i n g i t s
c e n t r i n g p i n A o n t h e f r o n t b u m p e r .
- P u t i t i n p l a c e b y p r e s s i n g a t e a c h c l i p B located in the four corners.
T h e s p a r e w h e e l i s n o t d e s i g n e d
to be used over long distances.
Have the tightening of the bolts
a n d t h e t y r e p r e s s u r e c h e c k e d b y a
C I T R O Ë N d e a l e r a s s o o n a s p o s s i b l e .
A l s o , h a v e t h e o r i g i n a l w h e e l r e p a i r e d
a n d r e fi t t e d b y a C I T R O Ë N d e a l e r a s
s o o n a s p o s s i b l e .
