wheelbase Citroen BERLINGO 2009 2.G Owner's Manual

123
Dimensions
TECHNICAL DATA
8

VAN (mm)
Short - L1 Long - L2
625 850 750
L Overall length 4 380 4 628
H Overall height 1 805 - 1 834
A Wheelbase 2 728
B Front overhang 925
C Rear overhang 727 975
D Width over panels: without mirrors
1 810
with mirrors 2 112
E Width of front tracks 1 505
F Width of rear tracks 1 554
G Useful length of rear fl oor 1 800 2 050
I Useful length with front passenger seat folded 3 000 3 250
DIMENSIONS
The vehicle is available in 2 lengths (L1 and L2),
refer to the tables:

126
Dimensions
PLATFORM CAB (mm)
L Overall length 4 237
H Overall height 1 821 - 1 822 A Wheelbase 2 728
B Front overhang 925
C Rear overhang 584
D
Width over panels (without mirrors) 1 810
E Width of front tracks 1 505
F Width of rear tracks 1 554
