Page 3 of 185
8
Interior
INSTRUMENTS AND CONTROLS
1. Lights and direction indicators
stalk.
2. I n s t r u m e n t p a n e l w i t h d i s p l a y .
3. Wipers, wash-wipe, trip
computer controls.
4. I g n i t i o n .
5. Audio equipment.
6. Driver's airbag, horn.
7. Steering wheel height and depth
adjustment.
8. Cruise control, speed limiter
switch.
9. Control pad, parking assistance,
headlamp beam adjustment,
ESP.
10. Bonnet release.
11. Electric exterior mirror
adjustment.
Page 5 of 185
3
43
2
3
10
Interior
1. Forwards-backwards
adjustment.
2. Angle.
3. Height. 4. Head restraint
height and
angle.
Driver's seat
57 63
38
71
82
SIT COMFORTABLY
Steering wheel
Adjust the height and depth of the
steering wheel. Storage compartments
These are placed under the front seats.
For greater ease, reach behind the seat
to access them.
The tools are stored under the right-hand
seat and can be accessed from the rear.
Seat belts
Height adjustment.
Fastening. Mirrors
Manual adjustments.
Electric adjustments.
Page 40 of 185
41
Steering wheel controls
EASE OF USE and COMFORT
3
Daytime lights
Depending on the country in which the
v e h i c l e i s s o l d , t h e v e h i c l e m a y b e e q u i p p e d
w i t h d a y t i m e l i g h t s . T h e d i p p e d h e a d l a m p s
c o m e o n w h e n t h e v e h i c l e i s s t a r t e d .
R e a r f o g l a m p s ( a m b e r ,
2 n d r o t a t i o n o f t h e r i n g
f o r w a r d s ) .
F r o n t f o g l a m p s ( g r e e n ,
1 s t r o t a t i o n o f t h e r i n g
f o r w a r d s ) .
Front and rear foglamps
R o t a t e r i n g
B f o r w a r d s t o s w i t c h o n
a n d r e a r w a r d s t o s w i t c h o f f . T h e
s t a t u s i s c o n fi r m e d b y t h e l a m p o n t h e
i n s t r u m e n t p a n e l .
T h e s e o p e r a t e w i t h t h e s i d e l a m p s a n d
t h e d i p p e d b e a m h e a d l a m p s .
Do not forget to switch them off
w h e n t h e y a r e n o l o n g e r n e e d e d .
O p e r a t i o n o f t h e u t o m a t i c l i g h t i n g
s w i t c h e s o f f t h e r e a r f o g l a m p s , b u t t h e
f r o n t f o g l a m p s r e m a i n o n . T h i s w a r n i n g l i g h t c o m e s o n
o n t h e i n s t r u m e n t p a n e l .
T h e i n s t r u m e n t s a n d c o n t r o l s
( i n s t r u m e n t p a n e l , d i s p l a y , a i r
c o n d i t i o n i n g c o n t r o l p a n e l , . . . ) a r e
o n l y l i t o n s w i t c h i n g t o t h e a u t o m a t i c
switching on of the lights mode or
w h e n t h e l i g h t s a r e s w i t c h e d o n
m a n u a l l y .
T o s w i t c h o f f t h e f r o n t a n d r e a r
f o g l a m p s , t u r n t h e r i n g r e a r w a r d s t w i c e
in succession.
I n c l e a r w e a t h e r o r i n r a i n , b o t h d a y
a n d n i g h t , r e a r f o g l a m p s d a z z l e a n d
their use is prohibited.
Automatic switching on of the lights
I n f o g g y w e a t h e r o r i n s n o w ,
t h e b r i g h t n e s s s e n s o r c a n
d e t e c t s u f fi c i e n t l i g h t . A s a
consequence, the lights will not come
o n a u t o m a t i c a l l y . I f n e c e s s a r y , y o u
m u s t s w i t c h o n t h e d i p p e d h e a d l a m p s
m a n u a l l y .
D o n o t c o v e r t h e b r i g h t n e s s
s e n s o r l o c a t e d o n t h e w i n d s c r e e n ,
behind the mirror. It is used for
t h e a u t o m a t i c s w i t c h i n g o n o f t h e l i g h t s
a n d f o r t h e a u t o m a t i c w i p e r s .
Activation
Turn the ring to the AUTO position.
T h e a c t i v a t i o n o f t h i s f u n c t i o n i s
a c c o m p a n i e d b y a m e s s a g e o n t h e
d i s p l a y .
Deactivation
T u r n t h e r i n g f o r w a r d s o r r e a r w a r d s .
T h e d e a c t i v a t i o n o f t h i s f u n c t i o n i s
a c c o m p a n i e d b y a m e s s a g e o n t h e
d i s p l a y .
T h e f u n c t i o n i s d e a c t i v a t e d t e m p o r a r i l y
w h e n y o u u s e t h e m a n u a l l i g h t s s t a l k . The side lights
a n d d i p p e d b e a m
h e a d l a m p s s w i t c h
o n a u t o m a t i c a l l y i f
the light is poor, or
d u r i n g o p e r a t i o n o f t h e w i n d s c r e e n
w i p e r s . T h e y s w i t c h o f f a s s o o n a s t h e
light becomes bright enough or the
windscreen wipers stop.
T h i s f u n c t i o n i s n o t c o m p a t i b l e w i t h t h e
d a y t i m e l i g h t s .
Page 43 of 185
43
Steering wheel controls
EASE OF USE and COMFORT
3
2 F a s t w i p e ( h e a v y r a i n ) .
1 N o r m a l w i p e ( m o d e r a t e r a i n ) .
l Intermittent wipe.
0 Off.
Single wipe
( p r e s s d o w n w a r d s ) .
In the I ntermittent position, the wiping
s p e e d i s i n p r o p o r t i o n t o t h e v e h i c l e
speed.
WINDSCREEN WIPER STALK
Manual windscreen wipers W h e n e v e r t h e i g n i t i o n h a s b e e n
s w i t c h e d o f f f o r m o r e t h a n o n e m i n u t e ,
w i t h t h e w i n d s c r e e n w i p e r s t a l k i n
p o s i t i o n 2 , 1 o r I , t h e s t a l k m u s t b e
r e a c t i v a t e d :
- m o v e t h e s t a l k t o a n y p o s i t i o n ,
- t h e n m o v e i t b a c k t o t h e r e q u i r e d
position.
D o n o t c o v e r t h e r a i n s e n s o r ,
l o c a t e d i n t h e c e n t r e o f t h e
windscreen, behind the mirror. Activation
P r e s s t h e c o n t r o l d o w n w a r d s .
A c t i v a t i o n o f t h e f u n c t i o n i s
a c c o m p a n i e d b y a m e s s a g e o n t h e
d i s p l a y .
Deactivation/Switching off
P l a c e t h e w i n d s c r e e n w i p e r s s t a l k i n
position
I , 1 or 2 . D e a c t i v a t i o n o f t h e
f u n c t i o n i s a c c o m p a n i e d b y a m e s s a g e
o n t h e d i s p l a y .
I n t h e e v e n t o f m a l f u n c t i o n o f t h e
a u t o m a t i c w i n d s c r e e n w i p e r s , t h e
w i n d s c r e e n w i p e r s w i l l o p e r a t e i n
intermittent mode.
C o n t a c t a C I T R O Ë N d e a l e r t o h a v e t h e
s y s t e m c h e c k e d .
In the
AUTO position, the windscreen
w i p e r s o p e r a t e a u t o m a t i c a l l y a n d
a d a p t t h e i r s p e e d t o t h e i n t e n s i t y o f t h e
r a i n f a l l .
W h e n n o t i n AUTO mode, for the
o t h e r p o s i t i o n s , r e f e r t o t h e m a n u a l
windscreen wipers section.
T h e a u t o m a t i c w i n d s c r e e n w i p e r s
f u n c t i o n m u s t b e r e a c t i v a t e d i f t h e
i g n i t i o n h a s b e e n s w i t c h e d o f f f o r m o r e
t h a n o n e m i n u t e , b y p r e s s i n g t h e s t a l k
d o w n w a r d s .
W h e n u s i n g a n a u t o m a t i c c a r
w a s h , s w i t c h o f f t h e i g n i t i o n t o
a v o i d t r i g g e r i n g o f t h e a u t o m a t i c
wiping.
I n w i n t e r , i t i s a d v i s a b l e t o w a i t f o r t h e
w i n d s c r e e n t o c o m p l e t e l y c l e a r o f i c e
b e f o r e o p e r a t i n g t h e a u t o m a t i c w i p e .
Automatic windscreen wipers
Page 55 of 185
55
EASE OF USE and COMFORT
33
Ventilation
DE-ICING AND DEMISTING
Manual mode Direct the control to this
t e m p e r a t u r e s e t t i n g .
I n c r e a s e t h e a i r fl o w s e t t i n g . P r e s s t h e a i r c o n d i t i o n i n g .
R e t u r n i n g t o e x t e r i o r a i r
i n t a k e o p e n p e r m i t s r e n e w a l
o f t h e a i r i n t h e p a s s e n g e r
c o m p a r t m e n t ( d i o d e o f f ) .
D i r e c t t h e c o n t r o l t o t h i s a i r
distribution setting.
De-icing the rear screen and/or
mirrors
Pressing this button, with the
e n g i n e r u n n i n g , a c t i v a t e s t h e
r a p i d d e m i s t i n g - d e - i c i n g o f
t h e r e a r s c r e e n a n d / o r e l e c t r i c
mirrors.
This function switches off:
- w h e n t h e b u t t o n i s p r e s s e d ,
- w h e n t h e e n g i n e i s s w i t c h e d o f f ,
- a u t o m a t i c a l l y t o p r e v e n t e x c e s s i v e energy consumption.
Page 73 of 185
Mirrors and windows
71
EASE OF USE and COMFORT
33
Electric exterior mirrors
- M o v e t h e c o n t r o l t o t h e r i g h t o r t o the left to select the corresponding
mirror.
- M o v e t h e c o n t r o l i n a l l f o u r d i r e c t i o n s t o a d j u s t .
- R e t u r n t h e c o n t r o l t o t h e c e n t r a l position. Electric folding/unfolding
T h e m i r r o r s c a n b e f o l d e d o r u n f o l d e d
e l e c t r i c a l l y f r o m t h e i n s i d e , w i t h t h e
v e h i c l e p a r k e d a n d t h e i g n i t i o n o n :
- P l a c e t h e c o n t r o l i n t h e c e n t r a l
position.
- T u r n t h e c o n t r o l d o w n w a r d s .
MIRRORS
Heated mirrors
Manual exterior mirrors
M o v e t h e l e v e r i n a l l f o u r d i r e c t i o n s t o
a d j u s t .
W h e n t h e v e h i c l e i s p a r k e d , t h e
e x t e r i o r m i r r o r s c a n b e f o l d e d b a c k
m a n u a l l y .
T h e m i r r o r s a r e n o t e q u i p p e d w i t h
a u t o m a t i c d e - i c i n g .
T h e e l e c t r i c m i r r o r s c a n b e
h e a t e d . P r e s s t h e r e a r s c r e e n
d e - i c i n g b u t t o n .
Page 74 of 185
Mirrors and windows
7 2
Forced folding
I f t h e m i r r o r c a s i n g h a s c o m e o u t o f
i t s i n i t i a l l o c a t i o n , w i t h t h e v e h i c l e
s t a t i o n a r y r e p o s i t i o n t h e m i r r o r c a s i n g
m a n u a l l y o r u s e t h e e l e c t r i c f o l d i n g
control. Manual interior mirror
T h e i n t e r i o r m i r r o r h a s t w o p o s i t i o n s :
- d a y ( n o r m a l ) ,
- n i g h t ( a n t i - d a z z l e ) .
T o c h a n g e f r o m o n e t o t h e o t h e r , p u s h
o r p u l l t h e l e v e r o n t h e l o w e r e d g e o f
the mirror. Areas for toll cards/car park
tickets
T h e a t h e r m i c w i n d s c r e e n h a s t w o n o n -
r e fl e c t i v e z o n e s l o c a t e d e i t h e r s i d e o f
t h e b a s e o f t h e i n t e r i o r m i r r o r .
T h e y a r e i n t e n d e d f o r a f fi x i n g t o l l c a r d s
a n d / o r c a r p a r k t i c k e t s .
Page 75 of 185
Mirrors and windows
73
EASE OF USE and COMFORT
33
ELECTRIC WINDOWS
1. D r i v e r ' s e l e c t r i c w i n d o w c o n t r o l
2. P a s s e n g e r e l e c t r i c w i n d o w c o n t r o l
T h e r e a r e t w o o p e r a t i n g m o d e s :
Safety auto-reverse
W h e n t h e w i n d o w r i s e s a n d m e e t s a n
o b s t a c l e , i t s t o p s a n d p a r t i a l l y l o w e r s .
Automatic mode
Press or pull the control, beyond the
p o i n t o f r e s i s t a n c e . T h e w i n d o w o p e n s
or closes fully when the control is
r e l e a s e d . P r e s s i n g t h e c o n t r o l a g a i n
s t o p s t h e m o v e m e n t o f t h e w i n d o w .
T h e e l e c t r i c a l f u n c t i o n s o f t h e e l e c t r i c
w i n d o w s a r e d e a c t i v a t e d :
- a p p r o x i m a t e l y 4 5 s e c o n d s a f t e r t h e
ignition is switched off,
- a f t e r o n e o f t h e f r o n t d o o r s i s opened, if the ignition is off.
Manual mode
Press or pull the control, without
p a s s i n g t h e p o i n t o f r e s i s t a n c e .
T h e w i n d o w s t o p s w h e n y o u r e l e a s e
the control.
Reinitialisation
F o l l o w i n g r e c o n n e c t i o n o f t h e b a t t e r y ,
o r i n t h e e v e n t o f a m a l f u n c t i o n , t h e
s a f e t y a u t o - r e v e r s e f u n c t i o n m u s t b e
r e i n i t i a l i s e d . Good practice
I f t h e e l e c t r i c w i n d o w s m e e t a n
o b s t a c l e d u r i n g o p e r a t i o n , y o u m u s t
r e v e r s e t h e m o v e m e n t o f t h e w i n d o w .
To do this, press the control concerned.
W h e n t h e d r i v e r o p e r a t e s t h e
p a s s e n g e r e l e c t r i c w i n d o w c o n t r o l s , h e
m u s t e n s u r e t h a t n o o n e i s p r e v e n t i n g
correct closing of the windows.
T h e d r i v e r m u s t e n s u r e t h a t t h e
p a s s e n g e r s u s e t h e e l e c t r i c w i n d o w s
correctly.
B e a w a r e o f c h i l d r e n w h e n o p e r a t i n g
the windows.
F o l l o w i n g s e v e r a l c o n s e c u t i v e c l o s i n g /
o p e n i n g o p e r a t i o n s o f t h e e l e c t r i c
w i n d o w c o n t r o l , a p r o t e c t i o n s y s t e m i s
t r i g g e r e d w h i c h o n l y a u t h o r i s e s c l o s i n g
o f t h e w i n d o w . A f t e r c l o s i n g , w a i t
a p p r o x i m a t e l y 4 0 m i n u t e s . O n c e t h i s
t i m e h a s e l a p s e d , t h e c o n t r o l b e c o m e s
o p e r a t i o n a l a g a i n .
L o w e r t h e w i n d o w f u l l y , t h e n r a i s e i t , i t
w i l l r i s e i n s t e p s o f a f e w c e n t i m e t r e s
e a c h t i m e t h e c o n t r o l i s p r e s s e d .
R e p e a t t h e o p e r a t i o n u n t i l t h e w i n d o w
is fully closed.
C o n t i n u e t o p r e s s t h e c o n t r o l f o r a t
l e a s t o n e s e c o n d a f t e r t h e w i n d o w
c l o s e d p o s i t i o n h a s b e e n r e a c h e d .
T h e s a f e t y a u t o - r e v e r s e d o e s n o t
o p e r a t e d u r i n g t h e s e o p e r a t i o n s .
Page 125 of 185
Changing a fuse
118
PASSENGER COMPARTMENT FUSES
Fuses
F A m p e r e s
A Allocation
1 - S p a r e
2 20 Heated seats
3 - S p a r e
4 15 Folding mirrors relay
5 15 R e f r i g e r a t i o n e q u i p m e n t s o c k e t r e l a y
TOWING/TOWBAR/
COACHBUILDERS/PLATFORM
CAB FUSES
T h e d e s i g n a t i o n s c o m m u n i c a t e d a r e
an indication only as this additional
b o x r e l a t e s t o o t h e r i n f o r m a t i o n w h i c h
d e p e n d s o n t h e m o d i fi e r - c o a c h b u i l d e r
f o r w h i c h t h e h a n d b o o k c a n n o t b e
u s e d a s a t e c h n i c a l s u p p o r t . Fuses
F A m p e r e s
A Allocation
1 15 S p a r e
2 15 I g n i t i o n , g e n e r a t o r o p e r a t i n g r e l a y
3 15 T r a i l e r 1 2 V s u p p l y
4 15 P e r m a n e n t s u p p l y f o r t h e m o d i fi e r s
5 40 H a z a r d w a r n i n g l i g h t s
Page 130 of 185
123
Dimensions
TECHNICAL DATA
8
VAN (mm)
Short - L1 Long - L2
625 850 750
L Overall length 4 380 4 628
H Overall height 1 805-1 834
A Wheelbase 2 728
B Front overhang 925
C Rear overhang 727 975
D Width over panels: without mirrors
1 810
with mirrors 2 112
E Width of front tracks 1 505
F Width of rear tracks 1 554
G U s e f u l l e n g t h o f r e a r fl o o r 1 800 2 050
I Useful length with front passenger seat
folded 3 000 3 250 DIMENSIONS DIMENSIONS
The vehicle is available in 2 lengths (L1 and L2),
refer to the tables:
