5FAMILIARISATION-
INSTRUMENTS AND CONTROLS
13. Audio equipment steering wheel
control.
14. Steering lock and ignition.
15. Fuse box.
16. Passenger air bag disarming
control.
17. Alarm.
18. Steering wheel adjustment
control.
19. Passenger’s electric mirror
control.
20. Headlamp height adjustment.
21. Heated seats control.
22. Handbrake.
23. Lighter.
24. Movable ashtray.
25. Gear lever.
26. Storage compartment.
27. Heating/air conditioning controls.
28. RD3 audio equipment.
29. Lower glove box.
30. Upper glove box or passenger
air bag.
31. Bonnet release.
32. Side adjustable heating/
ventilation vents.
33. Door window demisting vents.
1. Speaker (tweeter).
2. Windscreen demisting vents.
3. Controls:
- Electric windows.
- Rear door windows demisting.
- Air conditioning.
4. Central locking button.
5. Multifunction display or clock.
6. Hazard warning lights switch.
7. Central adjustable heating/
ventilation vents.
8. Lights and direction indicators
controls.
9. Speed limiter/cruise control
switch.
10. Instrument panel.
11. Driver’s air bag.
Horn.
12. Wipers/wash-wipe controls.
Page 8 of 118
11FAMILIARISATION-
SPEED LIMITER * CRUISE CONTROL *
73
71 I f t h e v e h i c l e i s fi t t e d w i t h
a speed limiter and cruise
control, these functions can-
not be activated at the same
time.
This limiter indicates the status of
selection of the function on the in-
strument panel and displays the
programmed speed. The minimum
speed which can be programmed is
at least 18 mph (30 km/h).
It prevents exceeding of the speed
programmed by the driver, this func-
tion remains active regardless of any
action on the brake or clutch pedals.
On the other hand, pressing the ac-
celerator pedal to the point of resist-
ance does not have any effect.
It is possible to exceed the pro-
grammed speed temporarily by
p r e s s i n g t h e a c c e l e r a t o r fi r m l y b e -
yond this point of resistance.
The operating actions must be car-
ried out with the engine running. The cruise control has a display on
the instrument panel to indicate the
programmed reference speed.
It enables the vehicle to maintain the
reference speed programmed by the
driver.
In order for it to be programmed or
activated, the vehicle speed must be
greater than 25 mph (40 km/h) with
at least fourth gear engaged.
* According to version.
Page 14 of 118
MONITORING and DISPLAY SCREENS18 -
1. Seat belt not fastened warning
light
2. Passenger air bag disarmed
warning light
3. Front and side air bags warning
light
4. Front fog lamps indicator light
5. Anti-lock braking system (ABS)
warning light
6. Rear fog lamp indicator light
7. Diesel pre-heat warning light
8. Left hand direction indicator
9. Total distance recorder, service
indicator and engine oil level
indicator
10. Right hand direction indicator
11. Emission control system warning
light
12. Main beam headlamps indicator
light
13. H a n d b r a k e , l o w b r a k e fl u i d
level and electronic brake force
d i s t r i b u t i o n w a r n i n g l i g h t
14. Dipped beam headlamps
indicator light
15. Battery charge warning light
16. E n g i n e o i l p r e s s u r e a n d
t e m p e r a t u r e w a r n i n g l i g h t
17. W a t e r i n d i e s e l fi l t e r w a r n i n g l i g h t
18. Low coolant level warning light
19. C o o l a n t t e m p e r a t u r e i n d i c a t o r
20. T o t a l d i s t a n c e r e c o r d e r b u t t o n
21. Central (STOP) warning light
22. Speedometer *
23. R e v c o u n t e r
24. L i g h t i n g r h e o s t a t b u t t o n
25. F u e l l e v e l i n d i c a t o r
26. L o w f u e l l e v e l w a r n i n g l i g h t
27. S p e e d l i m i t e r / c r u i s e c o n t r o l
display
INSTRUMENT PANEL: PETROL - DIESEL
* Version indicating kilometres, ac- c o r d i n g t o c o u n t r y .
Page 15 of 118
19MONITORING and DISPLAY SCREENS-
INSTRUMENTS AND CONTROLS
A permanently lit warning light or
o n e fl a s h i n g , w i t h t h e e n g i n e r u n -
n i n g , i n d i c a t e s a n o p e r a t i n g f a u l t
o f t h e u n i t c o n c e r n e d . T h e i l l u m i -
n a t i o n o f c e r t a i n w a r n i n g l i g h t s
m a y b e a c c o m p a n i e d b y a n a u d i -
b l e s i g n a l a n d a m e s s a g e o n t h e
d i s p l a y . D o n o t i g n o r e t h i s w a r n -
i n g : c o n s u l t a CITROËN d e a l e r a s
s o o n a s p o s s i b l e .
I f t h e c e n t r a l S T O P w a r n i n g l i g h t
c o m e s o n w h e n y o u a r e d r i v i n g ,
s t o p y o u r v e h i c l e i m m e d i a t e l y ,
w h e r e i t i s s a f e t o d o s o .
Central (STOP)
warning light
Linked to the warning
lights:
- ' ' e n g i n e o i l p r e s s u r e a n d t e m p e - r a t u r e ' ' ,
- ''low coolant level'',
- 'handbrake'',
- ' ' l o w b r a k e fl u i d l e v e l ' ' ,
- ' ' e l e c t r o n i c b r a k e f o r c e d i s t r i b u t i o n s y s t e m f a u l t ' ' .
L i n k e d w i t h t h e " c o o l a n t t e m p e r a t u r e "
i n d i c a t o r .
Y o u m u s t s t o p i f t h e l i g h t fl a s h e s
w i t h t h e e n g i n e r u n n i n g .
C o n s u l t a C I T R O Ë N d e a l e r . E n g i n e o i l p r e s s u r e
a n d t e m p e r a t u r e
warning light
Linked to the central (STOP) warning
l i g h t .
Y o u m u s t s t o p .
This warning light indicates one of
the following:
- i n s u f fi c i e n t o i l p r e s s u r e i n d i c a t e d by the message " O i l p r e s s u r e
i n s u f fi c i e n t " o n t h e d i s p l a y .
- a l a c k o f o i l i n t h e l u b r i c a t i o n c i r c u i t . T o p u p t h e l e v e l .
- a n o i l t e m p e r a t u r e w h i c h i s t o o h i g h . T o l o w e r t h e o i l t e m p e r a t u r e ,
r e d u c e y o u r s p e e d .
Lighting of the warning light is ac-
c o m p a n i e d b y a n a u d i b l e s i g n a l .
C o n s u l t a C I T R O Ë N d e a l e r .
L o w e n g i n e c o o l a n t
l e v e l w a r n i n g l i g h t
Linked to the central (STOP)
w a r n i n g l i g h t .
This comes on for a few seconds
w h e n t h e i g n i t i o n i s s w i t c h e d o n .
Lighting of this warning light is ac-
c o m p a n i e d b y a n a u d i b l e s i g n a l a n d
the message " T o p u p e n g i n e fl u i d
l e v e l " o n t h e d i s p l a y .
Y o u m u s t s t o p .
Wait for the engine to cool before
t o p p i n g u p t h e l e v e l .
T h e c o o l i n g c i r c u i t i s p r e s s u r i s e d . H a n d b r a k e , l o w
b r a k e f l u i d l e v e l a n d
E l e c t r o n i c B r a k e F o r c e
D i s t r i b u t i o n s y s t e m
f a u l t w a r n i n g l i g h t
Linked to the central (STOP) warning
l i g h t .
This comes on each time the ignition
i s s w i t c h e d o n .
Lighting of this warning light is ac-
c o m p a n i e d b y a n a u d i b l e s i g n a l a n d
a message on the display indicating
t h e c a u s e o f t h e w a r n i n g :
- " H a n d b r a k e o n " , if the handbrake
i s a p p l i e d o r n o t f u l l y r e l e a s e d .
- " B r a k e fl u i d l e v e l l o w " if there is
a n e x c e s s i v e d r o p i n b r a k e fl u i d
level (if the warning light remains
on even when the handbrake is
r e l e a s e d ) .
- " B r a k i n g f a u l t " is displayed to-
gether with the ABS warning
l i g h t , i n d i c a t i n g a m a l f u n c t i o n o f
the Electronic Brake Force Distri-
b u t i o n s y s t e m . Y o u m u s t s t o p .
C o n s u l t a C I T R O Ë N d e a l e r .
In the event of breakdown and to
p r e v e n t a n y r i s k o f b u r n s , u n -
s c r e w t h e c a p b y t w o t u r n s t o a l l o w
t h e p r e s s u r e t o d r o p .
W h e n t h e p r e s s u r e h a s d r o p p e d , r e -
m o v e t h e c a p a n d t o p u p t h e l e v e l .
C o n s u l t a C I T R O Ë N d e a l e r .
Page 16 of 118
MONITORING and DISPLAY SCREENS20 - B a t t e r y c h a r g e w a r n i n g
light
This comes on for a few se conds
w h e n t h e i g n i t i o n i s s w i t c h e d o n .
Lighting of this warning light, when the
e n g i n e i s r u n n i n g , a c c o m p a n i e d b y a n
a u d i b l e s i g n a l a n d t h e m e s s a g e " B a t t e r y
c h a r g e f a u l t " on the display, indicates
one of the following:
- f a u l t y o p e r a t i o n o f t h e c h a r g i n g c i r c u i t ,
- slack battery or starter terminals,
- a c u t o r s l a c k a l t e r n a t o r b e l t ,
- a n a l t e r n a t o r f a i l u r e .
C o n s u l t a C I T R O Ë N d e a l e r . E m i s s i o n c o n t r o l
s y s t e m w a r n i n g l i g h t
This comes on for a few
seconds each time the igni-
t i o n i s s w i t c h e d o n .
I f i t c o m e s o n w i t h t h e e n g i n e r u n n i n g ,
a c c o m p a n i e d b y a n a u d i b l e s i g n a l
and the message on the display:
- " A n t i p o l l u t i o n f a u l t " , this indi-
c a t e s a f a i l u r e o f t h e e m i s s i o n
c o n t r o l s y s t e m .
- " C a t a l y t i c c o n v e r t e r f a u l t " , this
i n d i c a t e s a m a l f u n c t i o n o f t h e i n -
j e c t i o n o r i g n i t i o n s y s t e m . T h e r e
is a risk of damage to the catalytic
c o n v e r t e r ( p e t r o l e n g i n e o n l y ) .
C o n s u l t a C I T R O Ë N d e a l e r .
D i e s e l e n g i n e
pre-heat warning
light
W a i t u n t i l t h e w a r n i n g l i g h t g o e s o u t
b e f o r e s t a r t i n g t h e e n g i n e .
I f t h e t e m p e r a t u r e i s h i g h e n o u g h ,
the warning light comes on for less
t h a n o n e s e c o n d . Y o u c a n s t a r t t h e
e n g i n e w i t h o u t w a i t i n g . L o w f u e l l e v e l
warning light
This comes on for a few
seconds when the igni-
t i o n i s s w i t c h e d o n .
When the ignition is on, it is accom-
p a n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " F u e l l e v e l l o w " on the
d i s p l a y .
I f i t fl a s h e s w i t h t h e f u e l g a u g e n e e d l e
in the lowest position, when the igni-
t i o n i s o n , t h i s i n d i c a t e s a m a l f u n c t i o n
o f t h e f u e l g a u g e .
W h e n t h i s w a r n i n g l i g h t fi r s t c o m e s
o n , y o u h a v e e n o u g h f u e l l e f t t o d r i v e
a p p r o x i m a t e l y 3 0 m i l e s ( 5 0 k m ) .
Capacity of the tank:
- approximately 55 litres for petrol engines,
- approximately 60 litres for Diesel e n g i n e s .
W a t e r i n d i e s e l f i l t e r
i n d i c a t o r *
There is a risk of damage to the
i n j e c t i o n s y s t e m .
C o n s u l t a C I T R O Ë N d e a l e r a s s o o n
a s p o s s i b l e .
A n t i - l o c k b r a k i n g
s y s t e m ( A B S ) w a r n i n g
light
This comes on for a few seconds each
t i m e t h e i g n i t i o n i s s w i t c h e d o n .
If the warning light remains on or
comes on above 8 mph (12 km/h),
t h i s i n d i c a t e s a n A B S m a l f u n c t i o n .
However, the vehicle retains conven-
t i o n a l s e r v o - a s s i s t e d b r a k i n g .
Lighting of this warning light, accom-
p a n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " A B S f a u l t " on the display,
i n d i c a t e s a n A B S f a u l t .
C o n s u l t a C I T R O Ë N d e a l e r .
* A c c o r d i n g t o c o u n t r y .
Page 17 of 118
21MONITORING and DISPLAY SCREENS-
S e a t b e l t n o t f a s t e n e d
w a r n i n g l i g h t *
When the ignition is switched
on, this indicator light comes
on if the driver has not fastened his
s e a t b e l t .
Above 12 mph (20 km/h), the warn-
i n g l i g h t fl a s h e s f o r t w o m i n u t e s .
O n c e t h e t w o m i n u t e s h a v e e l a p s e d ,
t h e w a r n i n g l i g h t r e m a i n s o n u n t i l t h e
d r i v e r f a s t e n s h i s s e a t b e l t . C o o l a n t t e m p e r a t u r e i n d i c a t o r
- needle in zone (A) , the tempera-
t u r e i s c o r r e c t ,
- needle in zone ( B ) , the tempera-
t u r e i s t o o h i g h . T h e c e n t r a l STOP
w a r n i n g l i g h t fl a s h e s , a c c o m p a -
n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " E n g i n e c o o l a n t t e m p .
too high" o n t h e d i s p l a y .
Y o u m u s t s t o p .
C o n s u l t a C I T R O Ë N d e a l e r .
* A c c o r d i n g t o c o u n t r y . P a s s e n g e r a i r b a g
d i s a r m e d w a r n i n g
l i g h t *
Lighting of this warning light is accom-
panied by the message " P a s s e n g e r
a i r b a g d e a c t i v a t e d " o n t h e d i s p l a y .
If the passenger air bag is disarmed,
the warning light comes on when
the ignition is switched on and it re-
m a i n s o n .
A l w a y s c o n s u l t a C I T R O Ë N d e a l e r i f
t h e w a r n i n g l i g h t fl a s h e s . F r o n t a n d s i d e a i r b a g s
warning light
This comes on for a few
seconds when the ignition is
s w i t c h e d o n .
W i t h t h e e n g i n e r u n n i n g , i l l u m i n a t i o n
of this warning light accompanied by
a n a u d i b l e s i g n a l a n d t h e m e s s a g e
" A i r b a g f a u l t " o n t h e m u l t i f u n c t i o n
d i s p l a y , i n d i c a t e s a f a u l t i n t h e a i r
b a g s .
C o n s u l t a C I T R O Ë N d e a l e r .
Page 18 of 118
21MONITORING and DISPLAY SCREENS-
S e a t b e l t n o t f a s t e n e d
w a r n i n g l i g h t *
When the ignition is switched
on, this indicator light comes
on if the driver has not fastened his
s e a t b e l t .
Above 12 mph (20 km/h), the warn-
i n g l i g h t fl a s h e s f o r t w o m i n u t e s .
O n c e t h e t w o m i n u t e s h a v e e l a p s e d ,
t h e w a r n i n g l i g h t r e m a i n s o n u n t i l t h e
d r i v e r f a s t e n s h i s s e a t b e l t . C o o l a n t t e m p e r a t u r e i n d i c a t o r
- needle in zone (A) , the tempera-
t u r e i s c o r r e c t ,
- needle in zone ( B ) , the tempera-
t u r e i s t o o h i g h . T h e c e n t r a l STOP
w a r n i n g l i g h t fl a s h e s , a c c o m p a -
n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " E n g i n e c o o l a n t t e m p .
too high" o n t h e d i s p l a y .
Y o u m u s t s t o p .
C o n s u l t a C I T R O Ë N d e a l e r .
* A c c o r d i n g t o c o u n t r y . P a s s e n g e r a i r b a g
d i s a r m e d w a r n i n g
l i g h t *
Lighting of this warning light is accom-
panied by the message " P a s s e n g e r
a i r b a g d e a c t i v a t e d " o n t h e d i s p l a y .
If the passenger air bag is disarmed,
the warning light comes on when
the ignition is switched on and it re-
m a i n s o n .
A l w a y s c o n s u l t a C I T R O Ë N d e a l e r i f
t h e w a r n i n g l i g h t fl a s h e s . F r o n t a n d s i d e a i r b a g s
warning light
This comes on for a few
seconds when the ignition is
s w i t c h e d o n .
W i t h t h e e n g i n e r u n n i n g , i l l u m i n a t i o n
of this warning light accompanied by
a n a u d i b l e s i g n a l a n d t h e m e s s a g e
" A i r b a g f a u l t " o n t h e m u l t i f u n c t i o n
d i s p l a y , i n d i c a t e s a f a u l t i n t h e a i r
b a g s .
C o n s u l t a C I T R O Ë N d e a l e r .
Page 19 of 118
MONITORING and DISPLAY SCREENS22 - S e r v i c e i n d i c a t o r
T h i s i s a v i s u a l r e m i n d e r o f w h e n t h e
n e x t s e r v i c e i s d u e . T h i s s e r v i c e i s t o
b e c a r r i e d o u t a c c o r d i n g t o t h e m a n u -
f a c t u r e r ' s s e r v i c i n g s c h e d u l e . 5 seconds after the ignition is switched
o n , t h e t o t a l d i s t a n c e r e c o r d e r r e s u m e s
normal operation and the display shows
t h e t o t a l o r t r i p d i s t a n c e s .
T h e d i s t a n c e r e m a i n i n g b e f o r e t h e n e x t
s e r v i c e i s l e s s t h a n 5 0 0 m i l e s ( 1 , 0 0 0 k m ) .
Example: 400 miles (900 km) remain
b e f o r e t h e n e x t s e r v i c e i s d u e .
When switching on the ignition and
for 5 seconds, the display shows:
5 seconds after the ignition is
switched on, the total distance re-
c o r d e r r e s u m e s n o r m a l o p e r a t i o n
a n d t h e s y m b o l r e m a i n s l i t .
T h i s i n d i c a t e s t h a t a s e r v i c e s h o u l d
b e c a r r i e d o u t s h o r t l y . T h e d i s p l a y
s h o w s t h e t o t a l o r t r i p d i s t a n c e s . T h e s e r v i c e i s o v e r d u e .
Each time the ignition is switched on
and for 5 seconds, the symbol and
t h e e x c e s s d i s t a n c e fl a s h .
Example: t h e s e r v i c e i s o v e r d u e b y
3 0 0 m i l e s / k m . T h e s e r v i c e s h o u l d b e
c a r r i e d o u t v e r y s h o r t l y .
When the ignition is switched on and
for 5 seconds, the display shows:
5 seconds after the ignition is
switched on, the total distance re-
c o r d e r r e s u m e s n o r m a l o p e r a t i o n a n d
t h e s y m b o l r e m a i n s l i t . T h e d i s p l a y
s h o w s t h e t o t a l o r t r i p d i s t a n c e s .
Note: the spanner lights if the two year
i n t e r v a l h a s b e e n e x c e e d e d .
INSTRUMENT PANEL DISPLAY
After switching on the ignition, three
f u n c t i o n s a r e s h o w n i n s u c c e s s i o n :
- service indicator,
- engine oil level indicator,
- total distance recorder/total and t r i p d i s t a n c e s .
Note
: the total and trip distances are
displayed for 30 seconds when the
ignition is switched off, on opening
the driver's door, as well as on lock-
i n g a n d u n l o c k i n g t h e v e h i c l e .
Example: 4,800 miles/km remain be-
f o r e t h e n e x t s e r v i c e i s d u e . W h e n t h e
ignition comes on and for 5 seconds
the display shows:
Operation
As soon as the ignition is switched
on and for 5 seconds, the spanner
s y m b o l i s i n g ' ' s e r v i c e o p e r a t i o n ' ' i s l i t .
The trip recorder display shows the
d i s t a n c e r e m a i n i n g ( i n r o u n d fi g u r e s )
b e f o r e t h e n e x t s e r v i c e .
Page 20 of 118
23MONITORING and DISPLAY SCREENS-
E n g i n e o i l l e v e l i n d i c a t o r
When the ignition is switched on,
the engine oil level is indicated for
approximately 10 seconds, after the
s e r v i c e i n f o r m a t i o n .
F l a s h i n g o f t h e s i x s q u a r e s a n d d i s -
p l a y i n g o f " m a x " i n d i c a t e a s u r p l u s o f
o i l w h i c h c o u l d d a m a g e t h e e n g i n e .
I f t h e s u r p l u s o f o i l i s c o n fi r m e d b y
a c h e c k u s i n g t h e d i p s t i c k , c o n t a c t a
C I T R O Ë N d e a l e r w i t h o u t d e l a y .
Y o u r C I T R O Ë N d e a l e r c a r r i e s o u t
t h i s o p e r a t i o n a f t e r e a c h s e r v i c e .
T h e r e s e t p r o c e d u r e i s a s f o l l o w s :
- S w i t c h o f f t h e i g n i t i o n .
- P r e s s a n d h o l d b u t t o n
1 .
- S w i t c h o n t h e i g n i t i o n .
T h e d i s p l a y b e g i n s a 1 0 s e c o n d c o u n t -
d o w n .
-
K e e p b u t t o n 1 p r e s s e d f o r 1 0 s e c o n d s .
The display shows [=0] and the spanner
d i s a p p e a r s .
Flashing of the six segments and dis-
playing of "min" indicate a lack of oil
w h i c h c o u l d d a m a g e t h e e n g i n e .
I f t h e l a c k o f o i l i s c o n fi r m e d b y a
c h e c k u s i n g t h e d i p s t i c k , i t i s e s s e n t i a l
t h a t t h e l e v e l i s t o p p e d u p . Flashing of the six segments indi-
c a t e s a m a l f u n c t i o n o f t h e o i l l e v e l
i n d i c a t o r .
There is a risk of damage to the
e n g i n e .
C o n s u l t a C I T R O Ë N d e a l e r .
T h e l e v e l r e a d o n t h e d i p s t i c k o r o n
t h e i n d i c a t o r w i l l o n l y b e c o r r e c t i f
t h e v e h i c l e i s o n l e v e l g r o u n d a n d
t h e e n g i n e h a s b e e n o f f f o r m o r e
t h a n 1 5 m i n u t e s .
R e s e t t i n g t h e s e r v i c e i n d i c a t o r
S u r p l u s o f o i l
L a c k o f o i l O i l l e v e l i n d i c a t o r f a u l t
Page 21 of 118
MONITORING and DISPLAY SCREENS24 - B r i e fl y p r e s s i n g b u t t o n 1 alternates
between the total and trip distance
d i s p l a y s .
To reset the trip recorder to zero,
w h e n i t i s d i s p l a y e d p r e s s b u t t o n 1
u n t i l z e r o s a p p e a r .
T o t a l d i s t a n c e r e c o r d e r
W i t h t h e l i g h t s o n , p r e s s t h e b u t t o n
to vary the intensity of the lighting of
t h e i n s t r u m e n t s a n d c o n t r o l s . W h e n
t h e l i g h t i n g r e a c h e s t h e m i n i m u m ( o r
m a x i m u m ) s e t t i n g , r e l e a s e t h e b u t t o n
then press it again to increase (or re-
d u c e ) t h e b r i g h t n e s s .
As soon as the lighting is of the re-
q u i r e d b r i g h t n e s s , r e l e a s e t h e b u t t o n .
LIGHTING RHEOSTAT CLOCK
B u t t o n 1 : h o u r a d j u s t m e n t
B u t t o n 2 : m i n u t e a d j u s t m e n t
P r e s s a n d h o l d t h e b u t t o n f o r r a p i d
a d v a n c e .
