cHAnGInG A FuSE
The fuseboxes are located:
-
in the lower dashboard on the left-
hand side (behind the cover),
-


under
  the   bonnet   (near   the   battery).
The
  information   given   concerns   only
those fuses which can be changed by
the user using the tweezer

, located
behind the dashboard storage
compartment
  on   the   right-hand   side.
For

  any   other   work,   visit   a   CITROËN
dealer

  or   a   qualified   workshop.
removing and fitting a fuse
Always replace a failed fuse with
a fuse of the same rating.
Motor

trade

technicians:

for

complete


information

on

the

fuses

and relays, refer to the "Repair
Manual"


diagrams

via

the

dealer
 network.
CITR
o
Ë
n
will not accept responsibility
for the cost incurred in repairing
your vehicle or for rectifying the
malfunctions

resulting

from

the

installation of accessories not
supplied


and

not

recommended

by

the

CITROËN


network

and

not

installed

in accordance with its instructions,
in


particular

when

the

combined

consumption


of

all

of

the

additional

equipment


connected

exceeds

10 millia

mperes. Before replacing a fuse, the cause of
the

incident

must

be

identified

and

rectified.
●


Use


the

tweezer.
Changing a fuse
