Page 37 of 230
I
I N S T R U M E N T S a n d C O N T R O L S
38
MONOCHROME DISPLAY
This provides the following information:
- the time,
- t h e a u d i o e q u i p m e n t d i s p l a y s ( r e f e r t o the "Audio and Telematics" section).
Setting the time
The digital clock can be set in automatic
mode or in manual mode .
Selecting the Setting
Select the automatic mode or the
manual mode as follows:
Press button A "PWR" to switch on
the audio system.
Access the setting mode by pressing
button B "TUNE" for approximately
2 seconds.
Press button B "TUNE" several
times to scroll through the various
menus and select the CT menu
(clock time).
The order of the menus is the follow-
ing: AF/CT/REG/TP-S/PTY display
l a n g u a g e / S C V / P H O N E / F u n c t i o n s
setting mode OFF.
Automatic mode
This mode permits automatic setting of
the local time using the signal from the
RDS stations.
The symbol
"CT" appears on the display.
Manual mode
This mode permits manual setting of
t h e t i m e u s i n g t h e a u d i o e q u i p m e n t b u t -
tons.
It can also be used when the "Automat-
ic mode" displays an inaccurate time,
when the local RDS stations are broad-
casting from a different time zone.
Page 38 of 230
I
I N S T R U M E N T S a n d C O N T R O L S
39
Set the time using the buttons as indi-
cated below:
with the ignition on or in the ACC
(Accessories) position, press and
hold the CLOCK button until the
t i m e d i s p l a y fl a s h e s .
Press the appropriate button to set
the time:
Button
H : setting of the hours
The hours digits scroll when you press
this button.
B u t t o n M : setting of the minutes
The minutes digits scroll when you
press this button.
B u t t o n 0 0 : resetting of the minutes to
zero.
- from 1 to 29 min
: rounded down to
the previous hour,
- from 3 0 t o 5 9 m i n : rounded up to
the next hour.
Manual mode
Automatic mode
In this mode, setting is automatic using
the signal from the RDS radio stations.
After setting the time, press the
DISP button; the time display stops
fl a s h i n g .
The digital clock does not display
seconds.
When the "minutes" display is set or
reset to zero, the clock starts at the
zero second of the minute selected.
The time setting is lost if the battery
is disconnected.
Turn button B "TUNE" to the left or
to the right to select "CT ON" (auto-
matic mode) or "CT OFF" (manual
mode).
After selecting the mode, you can
exit the "Functions setting mode"
menu by pressing button B "TUNE"
for approximately 2 seconds.
If no action is carried out within
10 seconds, the system will exit the
"functions setting mode" menu auto-
matically.
Page 40 of 230
I
41
Setting the time
The digital clock is set a u t o m a t i c a l l y .
This mode enables the system to set
the local time automatically using the
signal from the RDS stations.
On the control panel, press button A
(SET) to access the "Settings"
menu.
On the touch screen, press button B
to access the " S y s t e m " menu.
The system settings screen is dis-
played.
" I n f o r m a t i o n " m e n u
On the control panel, press button
D
(INFO) to access the " I n f o " screen and
consult:
- " S u p p o r t i n f o " to display the soft-
ware and data versions,
- " V e h i c l e p o s i t i o n " to display the
GPS location of the vehicle,
- "Calendar" to make a note of
events, birthdays, etc.,
- " J o u r n e y " to display the average
speed, the consumption, the dis-
tances and the duration of driving,
- "Environment" to display the alti-
tude, the atmospheric pressure, the
exterior temperature (the ice symbol
is displayed if there is a risk of ice),
- "Air conditioning" to display the
information relating to the air condi-
tioning,
- " M o b i l e t e l e p h o n e " to enter a
number, delete a character, make
or receive a call. "Route" menu
On the control panel, press button E
(NAVI) to access the "Route Menu"
screen and select:
- "Detour" to make a detour through
a s p e c i fi e d r e g i o n ,
- "Route" to change the route,
- " D i s p l a y a r o u t e " to display a route
in different ways,
- "Delete a route" to delete a route,
- "Local POI" to search for the POIs
in the surrounding area.
Page 154 of 230
IX
P R A C T I C A L I N F O R M A T I O N
146
INTERIOR BULBS
Front and rear courtesy lights
I n s e r t a s c r e w d r i v e r t o r e m o v e t h e c o u r t e s y l i g h t c o v e r .
R e m o v e t h e b u l b w h i l e p r e s s i n g t h e t a b A .
T o r e fi t t h e c o v e r , a l i g n t h e h o o k s o n t h e h o l e s l o c a t e d i n t h e b o d y o f t h e v e h i c l e .
Glove box light
T u r n t h e p i n B anticlockwise and
remove it.
R e m o v e t h e b u l b .
Low level light
Insert a screwdriver to remove the
l i g h t c o v e r .
R e m o v e t h e b u l b .
