III
ACCESS
79
DOORS
From outside
)
After unlocking the vehicle using the
remote control or the key, pull the
door handle.
From inside
)
Pull the front or rear door control to
open the door.
The front passenger door or the rear
doors must fi rst be unlocked manually
using the locking control before being
opened.
Closing
If a door is not closed correctly,
this warning lamp comes on
in the instrument panel screen
until the door concerned is
closed.
Manual centralised control
System which provides full manual
locking or unlocking of the doors and
tailgate from the inside.
Locking
)
Press the front of button A
to lock
the vehicle.
If the driver's door is open when you
operate the central locking from in-
side, all of the doors lock with the ex-
ception of the driver's door.
Unlocking
)
Press the rear of button A
to unlock
the vehicle.
Opening
If the doors are locked, opening the
driver's door does not unlock the
other doors.
Page 82 of 244
III
ACCESS
80
Opening
)
After unlocking the vehicle using the
remote control or the key, press the
handle A
and raise the tailgate.
TAILGATE
Closin
g
)
Pull the handle B
downwards to
guide the tailgate,
)
release the handle and press the ex-
terior surface of the tailgate gently to
close it.
Emergency control
System which locks or unlocks mechan-
ically the driver's door only in the event
of a malfunction of the central locking.
Locking the driver's door
)
Insert the key in the lock, then turn it
to the left.
Unlocking the driver's door
)
Insert the key in the lock, then turn it
to the right.
Unlocking the front and rear doors
(from inside)
)
Tilt the interior control B
rearwards.
Using the key
Locking the front passenger door
and the rear doors (from inside)
)
Tilt the interior control B
forwards.
The other doors are not unlocked.
Page 83 of 244
III
81
"Tailgate open" warning
This warning lamp comes on on
the instrument panel screen when
the tailgate is not closed correctly.
LOWER TAILGATE
Openin
g
)
Push the handle C
to the right and
tilt the tailgate D
gently.
Closing
)
Raise the tailgate D
, push it to close
it, then check that it is secured
correctly. Before opening the tailgate, ensure
that no one is within the radius of
opening.
For reasons of safety and correct op-
eration, do not drive with the tailgate
open.
If the battery is disconnected, the
tailgate cannot be opened.
Do not climb onto the lower tailgate
and do not subject it to heavy knocks,
it may be damaged.
Always close the lower tailgate and
check that it is secured correctly be-
fore closing the main tailgate.
When closing the lower tailgate, en-
sure that no person or object is in the
proximity of the moving parts to avoid
any risk of injury or damage.
Do not open the lower tailgate when
a towbar is fi tted.
Maximum authorised weight on the
lower tailgate when open: 200 kg
.
Tailgate release
This enables the tailgate to be unlocked
in the event of a central locking fault.
- Fold back the rear seats to gain ac-
cess to the tailgate release from in-
side the boot.
- Remove the plastic cap from the
opening A
in the tailgate interior
pillar.
- Move the control B
to the right to
unlock and open the tailgate.
Page 84 of 244
III
ACCESS
82
SUNROOF
Complete closing
)
With the ignition on, push the con-
trol forwards (in the direction 2
).
The defl ector folds down gradually on
closing.
Complete opening
)
With the ignition on, push the con-
trol rearwards (in the direction 1
).
A d efl ector is deployed gradually on open-
ing to prevent unwanted gusts of air.
Temporary stop
)
To stop opening or closing, press
part 3
of the control or push the con-
trol in the opposite direction.
Partial opening
)
To open
, with the ignition on, press
part 3
of the control.
The rear part of the sunroof opens.
)
To close
, with the ignition on, press
part 3
of the control.
The rear part of the sunroof closes.
Safety anti-pinch and reinitialisation
If the roof meets an obstacle while it is
closing, it stops and opens again.
The sunroof stops automatically just
before complete opening. Push the
control again for complete opening.
Operation
In the event of unwanted opening of
the roof on closing (for example, in
the presence of ice) and immediately
after the roof has stopped, or after
the safety anti-pinch has been trig-
gered fi ve times in succession:
)
press part 3
of the control several
times to partially open the roof,
)
when the roof partially opens,
continue to press for more than
3 seconds
,
)
open and close the sunroof com-
pletely.
The
safety
anti
-
pinch
function is not
operational during
t
hese operations.
Page 85 of 244
III
!
!
ACCESS
83
BLIND
The blind is manual, slide it backwards
and forwards.
It opens automatically when the roof is
opened.
Check that the sunroof is not
open in tilt mode
before clos-
ing the blind.
The blind cannot be closed when the
sunroof is open in sliding mode
. Always remove the key from the
ignition when leaving the vehi-
cle, even for a short time.
If the roof meets an obstacle dur-
ing operation, you must reverse the
movement of the roof. To do this,
press the control concerned.
When the driver operates the roof
control, they must ensure that no
one is preventing the roof from clos-
ing correctly.
The driver must ensure that passen-
gers use the sunroof correctly.
Be aware of children when operating
the roof.
Page 86 of 244
III
!
ACCESS
84
FUEL TANK Opening the cap may cause an inrush
of air. This vacuum, which is completely
normal, is caused by the sealing of the
fuel system.
To fi ll the tank safely:
)
the engine must be switched off,
)
pull the control A
located at the bot-
tom right of the driver’s seat to re-
lease the fuel fi ller fl ap,
)
open the fuel fi ller fl ap B
,
)
turn the fi ller cap C
to the left,
When you have fi lled the tank:
)
refi t the fi ller cap, inserting the up-
per part fi rst,
)
screw in the fi ller cap to the right,
)
close the fl ap.
Ensure that the fuel fi ller fl ap is closed
correctly.
)
remove the fi ller cap C
,
)
fi ll the tank, but do not continue af-
ter the 3rd cut-off of the nozzle
;
this could cause malfunctions.
Low fuel level
Filling
A label, affi xed on the inside of the fl ap,
reminds you of the type of fuel to be
used according to your engine.
More than 5 litres of fuel must be add-
ed in order to be registered by the fuel
gauge. When the low fuel level is
reached, this indication ap-
pears on the instrument
panel screen. When it fi rst
comes on, approximately
10 litres of fuel remain.
The symbol fl ashes slowly
(approxi-
mately once per second).
When the symbol begins to
fl ash rapidly
(approximately
twice per second), there is not
much fuel remaining in your tank (ap-
proximately 5 litres).
You must fi ll the tank to avoid running
out of fuel.
This symbol indicates that the
fuel tank cap is located on the
left-hand side of the vehicle.
Location of the cap
1.
Opening.
2.
Closing.
Capacity of the tank: approximately
60 litres.
Page 87 of 244
III
ACCESS
85
Quality of the fuel used for Diesel engines
The Diesel engines are perfectly com-
patible with biofuels which conform to
current and future European standards
(Diesel fuel which complies with stan-
dard EN 590 mixed with a biofuel which
complies with standard EN 14214)
available at the pumps (containing up
to 7 % Fatty Acid Methyl Ester).
The B30 biofuel can be used in cer-
tain Diesel engines; however, this use
is subject to strict application of the
special servicing conditions. Contact a
CITROËN dealer or a qualifi ed work-
shop.
The use of any other type of (bio)fuel
(vegetable or animal oils, pure or dilut-
ed, domestic fuel...) is strictly prohibited
(risk of damage to the engine and fuel
system).
petrol engines
The petrol engines are perfectly compat-
ible with E10 or E24 type petrol biofuels
(containing 10 % or 24 % ethanol), con-
forming to European standards EN 228
and EN 15376.
E85 type fuels (containing up to 85 %
ethanol) are reserved exclusively for ve-
hicles marketed for the use of this type
of fuel (BioFlex vehicles). The quality of
the ethanol must comply with European
standard EN 15293.
For Brazil only, special vehicles are
marketed to run on fuels containing up
to 100 % ethanol (E100 type).
Page 88 of 244
IV
VISIBILITY
86
LIGHTING STALK
Additional lighting
Other lamps are installed to fulfi l the re-
quirements of particular driving conditions:
-
rear foglamps to be seen from a distance,
- front foglamps for even better visibility,
- daytime running lamps to be seen
during the day.
Certain functions of the lighting stalk
(automatic illumination of headlam-
ps, sensitivity) can be confi gured
via the colour screen "Equipment"
menu.
Manual controls
The lighting is controlled directly by the
driver by means of the ring A
and the
stalk B
. Lamps off.
Automatic illumination of head-
lamps.
Sidelamps.
B.
Stalk for switching headlamps: pull
the stalk towards you to switch the
lighting between dipped and main
beam headlamps.
In the lamps off and sidelamps modes,
the driver can switch on the main beam
headlamps temporarily ("headlamp
fl ash") by maintaining a pull on the
stalk.
Displays
Illumination of the corresponding indica-
tor lamp in the instrument panel confi rms
that the lighting selected is on.
A.
Main lighting mode selection ring:
turn it to position the symbol re-
quired facing the mark.
Dipped headlamps or main
beam headlamps.
Main lighting
The various front and rear lamps of the
vehicle are designed to adapt the driv-
er's visibility progressively in relation to
the climatic conditions:
- sidelamps, to be seen,
- dipped beam headlamps to see
without dazzling other drivers,
- main beam headlamps to see clearly
when the road is clear.
Page 89 of 244
IV
!
VISIBILITY
87
Front and rear foglamps
C.
foglamps selection ring.
The foglamps operate with the dipped
and main beam headlamps.
front and rear foglamps
)
To switch on the front foglamps, turn
the ring C
forwards once.
)
To switch on the rear foglamps, turn
the ring C
forwards twice.
)
To switch off the rear foglamps, turn
the ring C
rearwards once.
)
To switch off the front foglamps, turn
the ring C
rearwards twice.
The ring C
returns to its initial position
automatically.
The front foglamps are switched on au-
tomatically when you switch on the rear
foglamps.
The rear foglamps are switched off
automatically when you switch off the
dipped/main beam headlamps or the
front foglamps.
On vehicles fi tted with daytime run-
ning lamps, the rear foglamps can be
switched on even if the lighting stalk is
in the "OFF" position.
In good or rainy weather, both
day and night, the front fo-
glamps and the rear foglamps
are prohibited. In these situations,
the power of their beams may dazzle
other drivers.
Do not forget to switch off the front fo-
glamps and the rear foglamps when
they are no longer necessary.
Lighting on reminder
An audible signal when the driver's door
is opened warns the driver if the vehicle
lighting is on, with the ignition off.
Switching off the lighting stops the
audible signal.
If condensation is present, switch the
headlamps on for a few minutes in
order to clear it.
Page 90 of 244
IV
!
VISIBILITY
88
Automatic illumination of headlamps
Daytime running lamps *
*
According to country.
Automatic switching off
When the lights stalk is at "dipped head-
lamps or main beam headlamps", if the
ignition switch is at "LOCK" or "ACC" or
if the key has been removed from the
ignition switch, the lights switch off auto-
matically when the driver's door is
opened
.
On vehicles which are equipped with day-
time running lamps, the dipped beam head-
lamps come on when the vehicle is started.
This warning lamp comes on
in the instrument panel.
The instruments and controls (instrument
panel, multifunction screen, air condition-
ing control panel, ...) are illuminated. The sidelamps and the dipped beam
headlamps come on automatically, with-
out any action on the part of the driver,
if a low level of exterior light is detected
or if the wipers are switched on.
When the light returns to a suffi cient
level or the wipers are switched off, the
lighting is switched off automatically.
The sensor is located at the base of the
windscreen.
Contact a CITROËN dealer or a qualifi ed work-
shop to adjust the sensitivity of the sensor.
In foggy weather or in snow, the
sunshine sensor may detect suf-
fi cient light. The lighting will not
come on automatically.
Do not cover the sunshine sensor, the
associated functions will no longer be
controlled.
The sensitivity of the automatic illumina-
tion of headlamps can be confi gured via
the colour screen "Equipment" menu.
