ECU Citroen C ZERO 2010.5 1.G Owner's Manual

.Familiarisation
13
Passenger safety
1.
Inser t the key. 2.Select position: "ON"(activation), with front passenger or
"for wards facing" child seat, "OFF"
(deactivation), with "rear facing" child seat.


Front passenger’s airbag

Two rings A
, located between the seat cushion
and backrest are used to secure an ISOFIXchild seat.
A ring B is used to secure an upper strap called
the TOP TETHER.

ISOFIX mountings
77
Child lock
A.
Child lock on.
B. Child lock off.
6
8
65

3
!
Comfort
41
Returning the seat backrest to its original position
) Push the seat backrest in position and secure it,)
refit the head restraints or put them back
in place.
1. Place the head restraints in the low position
or remove them if necessary,2.pull the control for wards to release
backrest,
3.fold the backrest forward.

Folding the backrest
When returning the backrest to itsoriginal position, take care not to trapthe seat belts.

3
!
Comfort
45





12 V accessory
socket
) To connect a 12 V accessory (max power:
120 W), lift the cover and connect
a suitable adaptor.












Mat

To prevent any risk of jamming under the pedals:


- only use mats suited to the fixings already present in the vehicle; it is imperative that these fixings are used.

- never fit one mat on top of another.

When removin
g the mat on the driver's side,
move back the seat as far as possible and
remove the fixin
gs.
When refitting, position the mat correctly on
the pins and clip the fixings. Check that the mat
is secured firmly. The sun visors fold for wards
, and to the side
when they are unhooked.
They are fitted with a cour tesy mirror anda ticket holder.






Sun visor

6
Child safety
63


Passenger airbag OFF


Child seats recommended by CITROËN
CITROËN offers a complete range of recommended child seats which are secured using ay
three point seat belt:
Group 0+: from bir th to 13 kg
L1"RÖMER Baby-Safe Plus"
Installed in the rear wards-facing position.
Groups 2 and 3: from 15 to 36 kg
L3"RECARO Start''
L4"KLIPPAN Optima"From the age of 6 years(approximately 22 kg),
the booster is used on its own.
L5"RÖMER KIDFIX" Can be fitted to the vehicle's ISOFIX mountings.
The child is restrained by the seat belt.

Child safety
64














Installing child seats using the seat belt In accordance with European regulations, this table indicates the options for installing child seats secured using a seat belt and universally approved (a)in accordance with the weight of the child and the seat in the vehicle.
Weight of the child and indicative age
SeatUnder 13 kg(groups 0(
b )and 0+)
Up to approx 1 year

From 9 to 18 kg(group 1)1 to 3 years approx
From 15 to 25 kg(group 2)3 to 6 years approx
From 22 to 36 kg(group 3)
6 to 10 years approx

Front passenger seat ( c )L1
ISOFIX ROMERDuo Plus (secured with
the seat belt)
XX
Outer rear seatsUUUU
(a) Universal child seat: child seat that can be installed in all vehicles using a seat belt.(b)
Group 0: from bir th to 10 kg. Shells seats and baby carriers cannot be installed in the front passenger seat.(c)Consult the legislation in force in your country before installing your child on this seat.
U : Seat suitable for the installation of a child seat secured using a seat belt and universally approved, "rear wards-facing" and/or "forwards-facing". X:
Seat not suitable for the installation of a child seat of the indicated weight group.

6!
Child safety
65
Your vehicle has been approved in accordance
with the newISOFIX regulation .
The seats, represented below, are fitted with
re
gulation ISOFIX mountings:


















"ISOFIX" mountings
There are three rings for each seat:
- two rings A
located in the angle between
the vehicle seat's cushion and backrest,
indicated by a label. This IS
OFIX mounting system provides fast,
reliable and safe fitting of the child seat in your
vehicle.
The ISOFIX child seats
are fitted with
two latches which are secured on the tworings A. Some seats also have an upper strapwhich is secured to the ring B
.
To attach this strap, remove the head restraint
from the vehicle's seat. Attach the hook to the
ring B
, then tighten the upper strap.

The incorrect installation of a child seatin a vehicle compromises the child's protection in the event of an accident.
For information re
garding the ISOFIX child seats which can be installed in your vehicle,
refer to the table showing the locations for
installing ISOFIX child seats. - a rin
g B
for securing the upper strap called
the TOP TETHER, located in the boot.

i
Child safety
66












ISOFIX child seat recommended by CITROËN and approved for
your vehicle

ISOFIXRÖMER Duo Plus
(size category B1)
Group 1: from 9 to 18 kg


Installed in the forward facing position.
Fitted with an upper strap to be secured on the ISOFIX upper ring, referred to as the TOP TETHER.
Three seat body angles: sitting, reclining, lying.
This child seat can also be used on seats which are not fitted with ISOFIX mountings. In this case, it must be attached to the vehicle seat using the three point seat belt.Follow the instructions for fitting the child seat given in the seat manufacturer's installation guide.

6
Child safety
67
















Installing ISOFIX child seats
In accordance with European regulations, this table indicates the options for the installation of ISOFIX child seats on the vehicle seats fitted with
ISOFIX mountings.
In the case of the universal and semi-universal ISOFIX child seats, the child seat's ISOFIX size category, determined by a letter between A
and G
, is
indicated on the child seat next to the ISOFIX logo.
IUF:seat suitable for the installation of an Isofix U niversal seat, "F
orward facing" and secured using the "Top Tether" upper strap.X:seat which is not suitable for the installation of an ISOFIX seat of the size category indicated.
Weight of the child
/indicative age
Less than 10 kg (group 0)Up to 6 months approx
Less than 10 kg(group 0)Less than 13 kg (group 0+)Up to 1 year approx
From 9 to 18 kg (group 1)From 1 to 3 years approx
Type of ISOFIX child seatInfant car seat*"rear facing""rear facing" "for ward facing"
ISOFIX size categoryFGCDECDABB1
Universal and semi-universal ISOFIX child
seats which can be installed on the outer rear seatsXXXXXIUF

*
Infant car seats and "car cots" cannot be installed on the front passenger seat.

!
Child safety
68
The incorrect installation of a child seat in a vehicle compromises the child'sprotection in the event of an accident. When installing a child seat using the seat belt, check that the seat belt is tightenedcorrectly on the child seat and that it secures the child seat firmly on the seat of your vehicle. Remember to fasten the seat belts or the child seat harnesses keeping the slackinrelation to the child's body to a minimum, even for short journeys.
For optimum installation of the "forwards-facing" child seat, ensure that the back of the child seat is in contact with the backof the vehicle's seat and that the head restraint does not cause any discomfort.
If the head restraint has to be removed,ensure that it is stored or attached securelyto prevent it from being thrown around the vehicle in the event of sharp braking. Children under the age of 10 must not travel in the "for wards-facing" position on the frontpassenger seat, unless the rear seats arealready occupied by other children, cannot be used or are absent.
Deactivate the passenger airbag *
when a"rearwards-facing" child seat is installed onthe front seat. Other wise, the child would risk being seriously injured or killed ifthe airbag were to inflate.

Advice on child seats
Installing a booster seat
The chest par t of the seat belt must bepositioned on the child's shoulder without
touching the neck.Ensure that the lap part of the seat beltpasses correctly over the child's thighs.CITROËN recommends the use of a booster seat which has a back, fitted witha seat belt guide at shoulder level.
As a safety precaution, do not leave: - one or more children alone andunsuper vised in a vehicle, - a child or an animal in a vehicle whichis exposed to the sun, with the windows closed, - the keys within reach of children inside the vehicle. To prevent accidental opening of the doors, use the "Child lock". Take care not to open the rear windows bymore than one third.To protect young children from the rays of the sun, fit side blinds on the rear windows.


*
According to country and current local legislation.








Child lock

Mechanical system to prevent opening of
the rear doors using their interior controls.
The control is located on the edge of each rear door.


Child lock on
)Lower the control Ato position 1.


Child lock off
)Raise the control Ato position 2.

7
i
Safety
75




The driver must ensure that passengers usethe seat belts correctly and that they are allrestrained securely before setting off.
Wherever you are seated in the vehicle, always fasten your seat belt, even for short journeys.
Do not interchange the seat belt buckles asthey will not fulfil their role fully.
The seat belts are fitted with an inertia reel permitting automatic adjustment of the length of the strap to your size. The seat belt isstowed automatically when not in use.
Before and after use, ensure that the seatbelt is reeled in correctly.
The lower par t of the strap must bepositioned as low as possible on the pelvis.
The upper par t must be positioned inthe hollow of the shoulder.
The inertia reels are fitted with an automatic locking device which comes into operation inthe event of a collision, emergency braking or if the vehicle rolls over. You can releasethe device by pulling firmly on the strap and releasing it so that it reels in slightly.
Recommendations for children
Use a suitable child seat if the passenger isless than 12 years old or shor ter than one and a half metres. Never use the same seat belt to secure morethan one person. Never allow a child to travel on your lap.

In order to be effective, a seat belt must:


- be tightened as close to the body as possible,


- be pulled in front of you with a smooth movement, checking that it does nottwist,

- be used to restrain only one person,

- not bear any trace of cuts or fraying,

- not be converted or modified to avoid affecting its per formance.
In accordance with current safety regulations, for all repairs on your vehicle, go to a qualified workshop with the skills and equipment needed, which a CITROËN dealer is able to provide.
Have your seat belts checked regularly by a CITROËN dealer or a qualified workshop, particularly if the straps show signs of damage.
Clean the seat belt straps with soapywater or a textile cleaning product, sold by CITROËN dealers.
After folding or moving a seat or rear bench seat, ensure that the seat belt is positioned and reeled in correctly.
In the event of an impact
Depending on the nature and seriousness of the impact
, thepretensioning device may be deployedbefore and independently of the airbags.Deployment of the pretensioners isaccompanied by a slight discharge of harmless smoke and a noise, due to the activation of the pyrotechnic cartridge incorporated in the system.In all cases, the airbag warning lampcomes on.Following an impact, have the seat belts system checked, and if necessary replaced,by a CITROËN dealer or a qualified workshop.
