bonnet Citroen C ZERO 2012 1.G Owner's Manual

.
.
Contents
2
ISOFIX child seats 67
Child lock 70
Child safety
Direction indicators 71
Hazard warning lamps 71
Horn 71
Emergency or assistance call 72
Braking assistance systems 72
Tr ajectory control systems 74
Fr
ont seat belts 75
Airbags 78
Safety
Charging the main battery 82
Ancillaries battery 88
Te m p o r a ry puncture repair kit 92
Changing a wheel 96
Changing a bulb 99
Changing a fuse 107
Changing a wiper blade 112
To w i ng the vehicle 112
Precautions for washing 113
Accessories 113
Practical information
Bonnet 116
Front compartment 117
Rear compartment 118
Checking levels 119
Checks 121
Checks
Motor and main battery 122
Weights 123
Dimensions 124
Identifi cation markings 125
Technical data
Emergency or assistance 127
Audio system 129
Audio and telematics
Visual search
Alphabetical index

.Familiarisation
5
31
Access
A.Unfolding / Folding the key.
B.Locking the vehicle. C.Unlocking the vehicle.

Remote control key
Bonnet
116
Electric windows
A.Release lever.
B. Safety catch. C.
Bonnet stay.
A.
Driver's electric window.
B. Passenger's electric window. C.
Right hand rear electric window.D.
Left hand rear electric window.E.
Deactivating the passenger and rear electric window switches.
34

.Familiarisation
7
Instruments and controls
1.
Driver's airbag.
Horn. 2.Instrument panel.
3.Wiper stalk. 4. Side vents.
5. Window demisting vent.
6.Electric window switches and switch for deactivating the the front and rear passenger electric window controls.
7. Opening control for the fast charging flap (vehicle left hand side).8.Bonnet release lever.9.
Opening control for the normal charging flap (vehicle right hand side). 10.Fusebox.11.
Door mirror controls.12.
Headlamp height adjustment.
ASR/ESP deactivation switch.13.Steering lock and ignition switch.

Practical information
88





Ancillaries battery
(other than the electric motor, the heating and
the air conditioning) are powered by this 12 V
ancillaries battery.
It is located in the front compartment and isrecharged by the main battery, during phases
of operation ("Ready" lamp on in the instrument
panel) and charging.

If the ancillaries battery is discharged,it will not be possible to star t the motor and the main battery cannot becharged.
)Open the front bonnet using the interior release lever, then the exterior safety catch. )Secure the bonnet stay.)Slacken nut 1.)Remove the battery protective cover for access to the two terminals.



Access to the battery
Disconnecting the battery is not recommended.However, if the vehicle is not to be used for a prolonged period of more than a month, it may be necessary todisconnect and store it to avoid theelectrolyte freezing.


After prolonged disconnection of the battery, you must contact a CITROËNdealer or a qualified workshop to havethe electronic control unit reinitialised.

Practical information
100
) Lift the cover B
, using a screwdriver
protected by a cloth.) Slacken fixing screw C
until the head of the screw touches the trim.
)Remove the bumper retaining clips, using ascrewdriver. )Carefully lift the bumper. To replace a failed bulb,
you must first remove
the lamp. To remove the lamp:)Open the bonnet. )Press tab A to release the connector.
Access to bulbs

8
Practical information
111

Access to the fuses
)Open the bonnet (refer to the "Checks" section),)Unclip the cover and remove it completely
by pulling towards you. )Change the fuse (refer to the corresponding paragraph).)When you have finished, close the cover carefully to ensure sealing of the fusebox.
Fuse N°RatingFunctions
1110 A On-board charger.
12 10 A
Dir
ection indicator.
1
310 A Horn.
1410 A Daytime running lamps.
1515 A
Battery fan.
1610 A
Air conditioning compressor.
1720 A Right hand dipped beam.
1820 A
Left hand dipped beam, headlamp adjusters.
1
910 A
Right hand main beam.
20 10 A
Left hand main beam.

8
Practical information
113





Accessories

A wide range of accessories and genuine par ts is available from the CITROËN dealer network.
These accessories and par ts have been tested and approved for reliability and safety.
They are all adapted to your vehicle and benefit from CITROËN's recommendation and warranty.
Conversion kits
You can obtain an "Enterprise" kit to conver t a
trade vehicle to a private car and vice-versa.
"Comfort":
black armrest, reading lamp, insulated
modules, rear parking sensors, cigarette lighter,ashtray with base, head restraint mounted coathanger...

"Transport solutions":

boot liner, boot carpet, rear parcel shelf, boot dividers...


"Security and safety":

alarm, wheel security bolts, child seats,
breathalyzer, warning triangle, high visibility
vest, first aid kit, snow chains, non-slip covers,
pet transpor t ca
ge, pet safety belt...
Precautions for
washing
To avoid damaging the electrical components, the use of a high pressure jet wash is strictly prohibited:


- in the front compar tment (under thebonnet),

- under the body.

For washing the body, do not use a pressure greater than 80 bars.
Check - before washing the vehicle -that the charging flaps and the charging socket covers (normal and fast charge) are properly closed.


Do not wash the vehicle while the
battery is being recharged.

Checks
116











Bonnet Protects the components in the front compartment and provides access for checking levels, charging the 12 V ancillaries battery, changing fuses, ...
)Push the exterior safety catch Bto the left and raise the bonnet.

)
Open the bonnet fully and on the right,unclip the stay Cfrom its holder.)
Fit the stay Cin one of the two notches to
hold the bonnet open.
)Open the front right door.)Pull the interior release lever A , located at
the bottom of the door aper ture.
Opening
Closing
)Take the stay out of the support notch.)Clip the stay in its housing. )Lower the bonnet and release it at the end of its travel. )Pull on the bonnet to check that it is fully latched.


Do not press down on the middle of the bonnet if it does not fully close, as there is a risk of deforming it. Open the bonnet fully and close it again.
The location of the interior release lever prevents opening of the bonnet while the front right door is closed.

10
Technical data
125














Identifi cation markings
Various visible markings for the identification of your vehicle.
A. Ser vice - Replacement Par ts
identification plate.
This plate is riveted to the underside of thebonnet.
Tyre pressures must be checkedwhen the tyres are cold, at least oncea month.

Low tyre pressures increase the
electrical power consumption of your vehicle, which reduces its range. B. Tyre identification label
.This label is affixed to the driver's centre pillar.
It bears the
following information:
- the tyre pressures (in bars),
- the tyre specification,
- the type of tyre.C. Manufacturer's
plate This plate is riveted to the left hand centre pillar.
D. Vehicle identification number (VIN).
This number is is engraved on the inner wheel
arch, inside the boot, right hand side.
For information on fitting snowchains, contact a CITROËN dealer or a qualified workshop.
It bears in par ticular the
following information:


- the vehicle model,

- the paint code,

- the type, variant, version.

.
Visual search
155
Electric windows 34
Dashboard fuses 108-109
Ventilation 47Heating 49-51 Air conditioning 49-51Demisting / defrosting 52
12 V accessory socket 45Manual parking brake 54
Rear view mirror 43
USB Player 46
Opening the bonnet 116

Instruments
and controls
Opening the charging flaps 37

Audio system 129-152
Drive selector 55-56
