belt Citroen C ZERO RHD 2011 1.G Owner's Manual

.
.
Contents
1
ISOFIX child seats 65
Child lock 68
Child safety
Direction indicators 69
Hazard warning lamps 69
Horn 69
Emergency or assistance call 70
Braking assistance systems 70
Tr ajectory control systems 72
Front seat belts 73
Airbags 76
Safety
Charging the main battery 80
Ancillaries battery 86
Te m p o r a ry puncture repair kit 90
Changing a wheel 94
Changing a bulb 97
Changing a fuse 105
Changing a wiper blade 110
To w i ng the vehicle 110
Precautions for washing 111
Accessories 111
Practical information
Bonnet 114
Front compartment 115
Rear compartment 116
Checking levels 117
Checks 119
Checks
Electric motor 120
Weights 121
Dimensions 122
Identifi cation markings 123
Technical data
Emergency or assistance 125
Audio system 127
Audio and telematics
Visual search
Alphabetical index

Familiarisation
10
Sitting comfortably
Door mirrors
A.
Selection of the mirror.B.Adjusting the position of the mirror glass. C.Folding/Unfolding.
42


Rear view mirror


Manual day/night type
1.Selecting the "day" position of the rear view
mirror.
2. Rear view mirror adjustment.
43
1.
Fitting the belt. 2.Fastening the buckle.3.Checking the fastening by pulling onthe belt webbing.


Seat belts
73

1
Monitoring
25
Warning/indicator lampStateCauseAction/Observations


Airbags

On temporarily. When you switch on the ignition, this
warning lamp comes on for a few seconds, then goes off. If it does not
go off, contact a CITROËN dealer or
a qualified workshop.

On fixed. Fault with one of the airbag or seat
belt pretensioner systems. Have it checked by a CITROËN dealer or a qualified
workshop.
Protection system for themain battery
On fixed. The state of charge of the main battery is too low or the temperature
of the main battery is too low... The power
from the motor is limited.
Charge the main battery as soon as possible.
If the warning lamp does not go off, contact aCITROËN dealer or qualified workshop.
Self-diagnosis system of the main electricalcircuit
On fixed. Fault in the main electrical circuit. You must stop as soon as it is safe to do so.
Have it checked by a CITROËN dealer or a qualified
workshop.
Front seat beltnot fastened/unfastened
On fixed, then
flashing, accompanied
by an audible signal.The driver and/or the front passen
ger has not fastened or has unfastenedtheir seat belt. Pull the strap, then inser t the ton
gue in the buckle.
Right hand rear seatbelt unfastened
On fixed. The right hand rear passenger hasunfastened their seat belt.
Pull the strap then inser t the ton
gue in the buckle.Left hand rear seat beltunfastened
On fixed. The left hand rear passenger hasunfastened their seat belt.

3
!
Comfort
41
Returning the seat backrest to its original position
) Push the seat backrest in position and secure it,)
refit the head restraints or put them back
in place.
1. Place the head restraints in the low position
or remove them if necessary,2.pull the control for wards to release
backrest,
3.fold the backrest forward.

Folding the backrest
When returning the backrest to itsoriginal position, take care not to trapthe seat belts.

6
i
Child safety
61











General points relating to child seats

For maximum safety, please obser ve the following recommendations:


- in accordance with European regulations,
all children under the age of 12 or less
than one and a half metres tall must
travel in a
pproved child seats suited to
their weight , on seats fitted with a seat
belt or ISOFIX mountings * ,-statistically, the safest seats in your
vehicle for carrying children are the rear seats, -
a child weighing less than 9 kg must
travel in the "rearwards-facing" position both in the front and in the rear.
CITROËN recommendsthat children should travel in the rear seats of your vehicle: -"rearwards-facing"
up to the age of 2, -
"forwards-facing"
over the age of 2.
Although one of CITROËN's main criteria when designing your vehicle, the safety of your children
also depends on you.

*

The rules for carrying children are specific to each country. Refer to the current legislation
in your country.

6
Child safety
63


Passenger airbag OFF


Child seats recommended by CITROËN
CITROËN offers a complete range of recommended child seats which are secured using ay
three point seat belt:
Group 0+: from bir th to 13 kg
L1"RÖMER Baby-Safe Plus"
Installed in the rear wards-facing position.
Groups 2 and 3: from 15 to 36 kg
L3"RECARO Start''
L4"KLIPPAN Optima"From the age of 6 years(approximately 22 kg),
the booster is used on its own.
L5"RÖMER KIDFIX" Can be fitted to the vehicle's ISOFIX mountings.
The child is restrained by the seat belt.

Child safety
64














Installing child seats using the seat belt In accordance with European regulations, this table indicates the options for installing child seats secured using a seat belt and universally approved (a)in accordance with the weight of the child and the seat in the vehicle.
Weight of the child and indicative age
SeatUnder 13 kg(groups 0(
b )and 0+)
Up to approx 1 year

From 9 to 18 kg(group 1)1 to 3 years approx
From 15 to 25 kg(group 2)3 to 6 years approx
From 22 to 36 kg(group 3)
6 to 10 years approx

Front passenger seat ( c )L1
ISOFIX ROMERDuo Plus (secured with
the seat belt)
XX
Outer rear seatsUUUU
(a) Universal child seat: child seat that can be installed in all vehicles using a seat belt.(b)
Group 0: from bir th to 10 kg. Shells seats and baby carriers cannot be installed in the front passenger seat.(c)Consult the legislation in force in your country before installing your child on this seat.
U : Seat suitable for the installation of a child seat secured using a seat belt and universally approved, "rear wards-facing" and/or "forwards-facing". X:
Seat not suitable for the installation of a child seat of the indicated weight group.

i
Child safety
66












ISOFIX child seat recommended by CITROËN and approved for
your vehicle

ISOFIXRÖMER Duo Plus
(size category B1)
Group 1: from 9 to 18 kg


Installed in the forward facing position.
Fitted with an upper strap to be secured on the ISOFIX upper ring, referred to as the TOP TETHER.
Three seat body angles: sitting, reclining, lying.
This child seat can also be used on seats which are not fitted with ISOFIX mountings. In this case, it must be attached to the vehicle seat using the three point seat belt.Follow the instructions for fitting the child seat given in the seat manufacturer's installation guide.

!
Child safety
68
The incorrect installation of a child seat in a vehicle compromises the child'sprotection in the event of an accident. When installing a child seat using the seat belt, check that the seat belt is tightenedcorrectly on the child seat and that it secures the child seat firmly on the seat of your vehicle. Remember to fasten the seat belts or the child seat harnesses keeping the slackinrelation to the child's body to a minimum, even for short journeys.
For optimum installation of the "forwards-facing" child seat, ensure that the back of the child seat is in contact with the backof the vehicle's seat and that the head restraint does not cause any discomfort.
If the head restraint has to be removed,ensure that it is stored or attached securelyto prevent it from being thrown around the vehicle in the event of sharp braking. Children under the age of 10 must not travel in the "for wards-facing" position on the frontpassenger seat, unless the rear seats arealready occupied by other children, cannot be used or are absent.
Deactivate the passenger airbag *
when a"rearwards-facing" child seat is installed onthe front seat. Other wise, the child would risk being seriously injured or killed ifthe airbag were to inflate.

Advice on child seats
Installing a booster seat
The chest par t of the seat belt must bepositioned on the child's shoulder without
touching the neck.Ensure that the lap part of the seat beltpasses correctly over the child's thighs.CITROËN recommends the use of a booster seat which has a back, fitted witha seat belt guide at shoulder level.
As a safety precaution, do not leave: - one or more children alone andunsuper vised in a vehicle, - a child or an animal in a vehicle whichis exposed to the sun, with the windows closed, - the keys within reach of children inside the vehicle. To prevent accidental opening of the doors, use the "Child lock". Take care not to open the rear windows bymore than one third.To protect young children from the rays of the sun, fit side blinds on the rear windows.


*
According to country and current local legislation.








Child lock

Mechanical system to prevent opening of
the rear doors using their interior controls.
The control is located on the edge of each rear door.


Child lock on
)Lower the control Ato position 1.


Child lock off
)Raise the control Ato position 2.

7
Safety
73
Seat belts


Front seat belts
Fastening
)
Pull the strap, then inser t the tongue inthe buckle A.)
Check that the seat belt is fastened correctly by pulling the strap.



Front seat belt not fastened/
unfastened warning lamp

If the driver does not fasten their seat
belt within one minute after switching on
the ignition, the warning lamp flashes
accompanied by an intermittent audible signal.
After about 90 seconds, the warning lamp, the
audible signal and the display stop, and then
return until the driver fastens their seat belt.
If the seat belt is unfastened while the vehicle is moving
, you are warned by the same alerts.

Th
e front seat belts are fitted with a
pretensioning and force limiting system.
This system improves safety in the frontseats in the event of a front or side impact.
Depending on the severity of the impact,
the pretensioning system instantly tightens
the seat belts against the body of the
occupants.

The pretensioning seat belts are active when
the ignition is on.
The force limiter reduces the pressure of
the seat belt on the chest of the occupant,so improving their protection.

Unfastening
)
Press the red button on the buckle A
.

When the ignition is switched on, this
warning lamp comes on accompanied
by an audible signal for a few secondsif the driver and/or passenger has notfastened their seat belt.
