Instruments and controls
1. Lighting and direction indicator stalk
2. Steering mounted controls for the audio
system or the touch screen tablet
A

ctivation / deactivation of the lane
departure warning system
3.
S

teering mounted controls for the ETG
electronic gearbox
4.
S

peed limiter control
5.
S

creen wash/wipe control stalk
6.
E

lectric window controls
7.
B

onnet release
8.
F

uel filler flap release
9.
D

eactivation of Stop & Start
o

r Activation / deactivation of Active City
Brake
H

eadlamp height adjustment 10. D
oor mirror adjustment controls
11. D eactivation of VSC / TRC systems
12 .
S

teering wheel adjustment control
13.
D

river's front airbag


Horn
14 .
S

ide air vents
15.
I

nstrument panel
16.
C

ourtesy lamp
E

lectric fabric roof control
17.
P

assenger's front airbag
18.
G

love box /
D

eactivation of the passenger's front
airbag /
R

einitialisation of the tyre under-inflation
detection system
19.
A

udio system, touch screen tablet or open
storage 20. S
TART/STOP button
21. H azard warning lamps
22.
M

anual or automatic air conditioning
controls
23.
A

uxiliary sockets for portable devices
24.
G

ear lever
25.
C

up holder and storage
26.
P

arking brake
2 7.
C

up holder
.
Over view

156
C1_en_Chap09_info-pratiques_ed01-2015
Dashboard fuses
The fusebox is located below the dashboard
(driver's side).
F
U
nclip the plastic cover for access to the
fuses.
When you have finished, carefully refit the
c ove r. Fuse

N° Rating

(A) Functions
1 5Fuel injection system - Audio system - VSC system
2 15Front and rear screenwash
3 5Main distribution unit - Instrument panel - Display screen -
Air conditioning - Heated rear screen and door mirror heating -
Heated seats - Electric fabric roof - Audio system
4 5Electric power steering - Stop & Start
5 15Rear wiper
6 5Cooling fan - ABS system ESP - VSC system
7 25Front wiper
8 10Heated door mirrors
9 1512 V socket (120 W max)
10 7. 5Door mirrors - Audio system - Stop & Start - Instrument panel -
Display screen
Practical information

157
C1_en_Chap09_info-pratiques_ed01-2015
FuseN° Rating
(A) Functions
11 5Steering lock - Fuel injection system - Electronic gearbox
12 7. 5Airbags
13 5Instrument panel - Display Screen - Stop & Start
14 15
**
Steering - Fuel injection system - Brake lamps
7. 5 *
15 7. 5 * *
Fuel injection system - Stop & Start
10*
16 7. 5Engine diagnosis
17 10Brake lamps - Third brake lamp - Fuel injection system -
ABS system - VSC system - Electronic gearbox - Keyless Entry
and Starting system
18 10Sidelamps - Number plate lamps - Rear foglamp - Front
foglamps - Rear lamps - Lighting dimmer
19 40Air conditioning
* PureTech 82 engine.
** VTi 68 engine.
9
Practical information

158
C1_en_Chap09_info-pratiques_ed01-2015
FuseN° Rating
(A) Functions
20 40Air conditioning - Engine self-diagnosis - Sidelamps - Number
plate lamps - Rear foglamp - Front foglamps - Rear lamps
-
Lighting dimmer - Brake lamps - Third brake lamp - Fuel
injection system - ABS system - VSC system - Electronic
gearbox - Keyless Entry and Starting system - Electric windows
21 30Fuel injection system - Stop & Start - Main distribution unit
22** 7. 5Fuel injection system
23** 20Fuel injection system - Stop & Start
24 25Main distribution unit
25 30Electric windows
26 25Electric windows
27 10Air conditioning
28 5Rear foglamp
** VTi 68 engine.
Practical information

161
C1_en_Chap09_info-pratiques_ed01-2015
FuseN° Rating
(A) Functions
27 7. 5VSC system
28 60Passenger compartment fusebox
29** 125***Heated rear screen and door mirror heating - Heated seats
-
Electric fabric roof - ABS system - VSC system - Cooling fan
-
Front foglamps - LED daytime running lamps
30 50
Electronic gearbox
40 Stop & Start
31 50Power steering
32 50*
Cooling fan
30
40
33 50ABS system - VSC system
34 10Spare fuse
* PureTech 82 engine.
** VTi 68 engine.
***

T

his fuse must be replaced only by a
CITROËN dealer or a qualified workshop.
9
Practical information

162
C1_en_Chap09_info-pratiques_ed01-2015
FuseN° Rating
(A) Functions
35 20Spare fuse
36 30Spare fuse
37 20Heated rear screen and door mirror heating
38 30ABS system - VSC system
39 7. 5Front foglamps - Instrument panel - Display screen
40 7. 5LED daytime running lamps
41 15Right hand heated seat
42 20Electric fabric roof
43 15Left hand heated seat
