Engine Citroen C3 2004 1.G Workshop Manual

Downloaded from www.Manualslib.com manuals search engine 97
ENGINE
CYLINDER HEAD
Engines: HFX KFV NFU
Cylinder head tightening (m.daN) Cylinder head bolts
X =MAX. reusable length
Tightening : 2 ± 0,2
Angular tightening: 240° ± 5°
Tightening :2,5 ±0,2Angular tightening:200 ±5°
(In the order 1 to 10)
B1BP1DVC
KFU HFX KFV
HFX KFV
175,5 ± 0,5 122 ± 0,3NFU
B1BP10KC
NOTE:Retightening of the cylinder head
after a completed repair is prohibited.
C2 C3 C3 PLURIEL
NOTE:Oil the threads and under the heads of
the bolts (use engine oil or Molykote G Rapid
Plus).
Tightening
: 2 ± 0,2Angular tightening:260° ± 5°
(In the order 1 to 10)
NFU
KFV
119

Downloaded from www.Manualslib.com manuals search engine 98
ENGINECYLINDER HEAD
Engines: KFW NFV NFU
Identification of cylinder head gasket
B1BP10KC
XSARA XSARA PICASSO
Engine type KFW NFV NFU
Identification marks
(Notch on cylinder head gasket) *
11 1 1
20 0 1
Thickness 3 0 0 1
40 1 1
A0
CURTY B 0
D0
A1
Suppliers MEILLOR B 1
D0
A
ELRING B
D
A1
REINZ B 0
D0
Material C 0 (With asbestos) – 1 (Without asbestos)
Repair R 0 (Standard gasket) – 1 (Repair gasket)
0 = Without notch
1 = One notch

Downloaded from www.Manualslib.com manuals search engine 99
ENGINE
CYLINDER HEAD (Continued)
Engines: KFW NFV NFU
Cylinder head tightening (m.daN) One Cylinder head bolts
X =MAX. reusable length
Pretightening :2
Angular tightening: 240 ± 5°
XSARA XSARA PICASSO
NOTE:Oil the threads and under the heads of the bolts (use
engine oil or Molykote G Rapid Plus).
B1DP13NC

Downloaded from www.Manualslib.com manuals search engine ENGINECYLINDER HEAD
Engine: 6FZ
Identification of cylinder head gasket
B1DP183D
Nominal
dimensionRepair dimension
2 – 4 – 5
4 – 5
R1 R2 R3
1 1,1
0,8 Gasket thickness
(mm)
Supplier MEILLOR Marking zone
"e" Identification zone
"d"
1,3
100
Identification marks
“d”
= Identification zone.
“e”= Marking zone.
NOTE:3 layer metallic gasket
XSARA XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 101
ENGINE
CYLINDER HEAD
Engine: 6FZ
X =MAX. reusable length NOTE:
Oil the threads and
under the heads of the bolts
(use engine oil or Molykote G
Rapid Plus)
. Pretightening
: 1,5 ± 0,2
Tightening: 5 ± 0,2
Destightening: 360 ° (1 turn)
Tightening: 2 ± 0,2
Angular tightening: 285° ± 5°
B1DP16FC
A = Washer thickness:4 ± 0,2 mm.X= Length under heads of new bolts = 144,5 ±0,5 mm.
XSARA XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 102
ENGINE
102
XSARA XSARA PICASSO
CYLINDER HEAD
Engine: RFN
Identification of cylinder head gasket
B1DP183D
Nominal
dimensionRepair dimension
2 – 4 – 5
4 – 5
R1 R2
1,1
0,8 Gasket thickness
(mm)
Supplier MEILLOR Marking zone
"e" Identification zone
"d"
1,4
Multilayer metallic gasket

Downloaded from www.Manualslib.com manuals search engine 103
ENGINE
CYLINDER HEAD
Engine: RFN
X =MAX. reusable length NOTE:
Oil the threads and
under the heads of the bolts
(use engine oil or Molykote G
Rapid Plus)
. Pretightening
: 1,5 ± 0,2
Tightening: 5 ± 0,2
Destightening: 360 ° (1 turn)
Tightening: 2 ± 0,2
Angular tightening: 285° ± 5°
B1DP16FC
A = Washer thickness:4 ± 0,2 mm.X= Length under heads of new bolts = 144,5 ±0,5 mm.
XSARA XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 104
ENGINECYLINDER HEAD
Engine: RFS
Identification of cylinder head gasket
Engine type
Identification marks
(Notch on cylinder head gasket) *
RFS
A
B
C
D
E
MEILLOR Suppliers
*0 = Without notch
1 = One notch
B1BP004C
1
0
1
0
0
XSARA

Downloaded from www.Manualslib.com manuals search engine 105
ENGINE
CYLINDER HEAD
Engine: RFS
X =MAX. reusable length NOTE:
Oil the threads and
under the heads of the bolts
(use engine oil or Molykote G
Rapid Plus). Pretightening
: 3,5
Slackening:NO
Tightening:7
Angular tightening: 160°
B1DP13PC
B1DP05BC
RFS
RFS
112 mm Cylinder head tightening (m.daN) One Cylinder head bolts
XSARA

Downloaded from www.Manualslib.com manuals search engine 106
ENGINECYLINDER HEAD
Identification of cylinder head gasket
Engine types SupplierPiston
standproud
(mm)Thicknesss
(mm)No. of notches at
“d “No. of notches at
“e”
0,771 to 0,820 1,35 1
0,611 to 0,720 1,25 2
8HY 8HV ELRING 0,721 to 0,770 1,30 3 1
0,821 to 0,870 1,40 4
0,871 to 0,977 1,45 5
B1DP1CMD
Engines: 8HX 8HW 8HZ
Type of gasket:Metallic multilayer
«d»Thickness reference.
«e»Engine reference.
C2 C3 C3 PLURIEL XSARA
