L E V E L SREFER TO THE CHAPTER: USER PRECAUTIONS
Air fi lter
Follow the requirements set out in the Maintenance Guide.
Windscreen/rear screen wash and headlamp wash fl uid
Use CITROËN-approved products wherever possible.
Capacity: See "Capacities".
Characteristics of fl uid
In order to ensure optimum clea-ning and to avoid freezing, you must never top up or replace this fl uid with water.
Engine coolant
The fl uid level should be between the marks MIN. and MAX. on the header tank.
Engine hot, wait at least 15 minutes.
Quality: See "Maintenance Guide".
Never do anything relating to the cooling system of an engine that is hot.
12 V battery
See "Starting with a slave battery".
Engine oil
Check the engine oil level on horizontal ground with the engine having been switched off for at least 10 minutes.
Quality: See "Maintenance Guide".
Pull out the manual dipstick.
The level should be between the marks MIN.and MAX. on the gauge.
It must never exceed the maximum.
MAX.
MIN.
Brake fl uid
The level of fl uid should be between the marks MIN.and MAX. on the reservoir.
Quality: See "Maintenance Guide".
If the warning lamp comes on while you are driving, stop immediately and contact a CITROËN dealer.immediately and immediately
Cabin particle fi lter/Odour fi lter
See "Maintenance Guide".
If opening the bonnet when the engine is hot, even if it is stopped and the ignition is switched off, remember that the cooling fan may operate at any moment.
Consult "User Precautions" at the end of this handbook.
