DRIVING
REAR PARKING SENSORS
System consisting of four proximity sen-
sors, located in the rear bumper.
Activation
This detects any obstacle (person, vehi-
cle, tree, gate, etc.) behind the vehicle,
except obstacles located just below the
bumper.
An object, such as a stake, a
roadworks cone or any other
similar object may be detected
at the beginning of the manoeu-
vre, but may no longer be de-
tected when the vehicle comes
close to it.
The parking sensor system can-
not, in any circumstances, take
the place of the vigilance and re-
sponsibility of the driver. The system is activated as soon as re-
verse gear is engaged, accompanied
by an audible signal.
On completion of the manoeuvre, when
you exit reverse gear, the system be-
comes inactive. The proximity information is given by:


- an audible signal, which becomes
more rapid as the vehicle approaches
the obstacle.

- a graphic (according to version) in
the multifunction screen, with blocks
which become increasingly closer to
the vehicle.
When the distance between the rear of
the vehicle and the obstacle is less than
thirty centimetres, the audible signal
becomes continuous and the "Danger"
symbol appears in the multifunction
screen.

9
128
DRIVING
The system will be deactivated
automatically when towing a
trailer or when a bicycle carrier is
fi tted (vehicle fi tted with a towbar
or bicycle carrier recommended
by CITROËN). In bad or wintry weather, ensure
that the sensors are not covered
with mud, frost or snow.


Programming

You can activate or deactivate the
system by means of the multifunction
screen confi guration menu. The system
state is memorised when switching off
the ignition.
For more information on access to
the parking sensors menu, refer to
"Confi guration/Vehicle parameters" in
the "Multifunction screens" section cor-
responding to your screen.
Operating faults
If there is an operating fault,
when reverse gear is en-
gaged this warning lamp
comes on in the instrument panel, ac-
companied by an audible signal (short
beep) and a message in the multifunc-
tion screen.

11
152
PRACTICAL INFORMATION

Dashboard fusebox

The fusebox is located in the lower
dashboard (left-hand side).

Access to the fuses


)
Refer to the paragraph "Access to
the tools".

Fuse tables


Fuse N°



Rating


Functions



FH36



5 A

Trailer relay unit.


FH37



-

Not used.


FH38



20 A

Hi-Fi amplifi er.


FH39



20 A

Heated seats.


FH40



40 A

Trailer relay unit.


Fuse N°



Rating


Functions



F1



15 A

Rear wiper.


F2



-

Not used.


F3



5 A

Airbags and pretensioners control unit.


F4



10 A

Air conditioning, clutch switch, electrochromatic
mirror, particle fi lter pump (Diesel), diagnostic
socket, airfl ow sensor (Diesel).


F5



30 A

Electric windows panel, passenger's electric
window control, front electric window motor.


F6



30 A

Rear electric windows motors and driver's electric
window motor.


F7



5 A

Courtesy lamp, glove box lighting, side reading
lamps.

11
153
PRACTICAL INFORMATION


Fuse N°



Rating


Functions



F8



20 A

Multifunction screen, audio system, navigation and
audio system, instrument panel with clock, alarm
control unit, alarm siren, audio system (after-market),
12 V socket, portable navigation carrier power supply.


F9



30 A

Multifunction screen, audio system, navigation and
audio system, instrument panel with clock, alarm
control unit, alarm siren, audio system (after-market),
12 V socket, portable navigation carrier power supply,
locking.


F10



15 A

Steering mounted controls.


F11



15 A

Ignition, diagnostic socket, automatic gearbox
control unit.


F12



15 A

Rain/sunshine sensor, trailer relay unit, driving
school module.


F13



5 A

Main stop switch, engine relay unit.


F14



15 A

Parking sensors control unit, airbag control unit,
instrument panel, digital air conditioning, USB Box,
HiFi amplifi er.


F15



30 A

Locking.


F16



-

Not used.


F17



40 A

Rear screen and door mirrors demisting/defrosting.


SH



-

PARC shunt.

11
PRACTICAL INFORMATION

Fuse table


Fuse N°



Rating


Functions



F1



20 A

Engine control unit supply, cooling fan unit control
relay, multifunction engine control main relay,
injection pump (Diesel).


F2



15 A

Horn.


F3



10 A

Front/rear wash-wipe.


F4



20 A

Daytime running lamps.


F5



15 A

Diesel heater (Diesel), particle fi lter additive pump
(Diesel), air fl ow sensor (Diesel), fuel pump (1.1i
and 1.4i), blow-by heater and electrovalves (VTi).


F6



10 A

ABS/ESP control unit, secondary brake lamp
switch.


F7



10 A

Electric power steering, automatic gearbox.


F8



25 A

Starter motor control.


F9



10 A

Switching and protection unit (Diesel).


F10



30 A

Fuel heater (Diesel), blow-by heater (1.1i, 1.4i and
Diesel), fuel pump (VTi), injectors and ignition coils
(petrol), electronic thermostat and canister purge
electrovalve (1.1i and 1.4i).


F11



40 A

Heater blower.

11
156
PRACTICAL INFORMATION


Fuse N°



Rating


Functions



F12



30 A

Windscreen wipers slow/fast speed.


F13



40 A

Built-in systems interface supply (ignition positive).


F14



30 A

Valvetronic supply (VTi).


F15



10 A

Right-hand main beam headlamps.


F16



10 A

Left-hand main beam headlamps.


F17



15 A

Left-hand dipped beam headlamps.


F18



15 A

Right-hand dipped beam headlamps.


F19



15 A

Oxygen sensors and electrovalves (VTi),
electrovalves (Diesel), EGR electrovalve (Diesel).


F20



10 A

Pumps, electronic thermostat (VTi), water in fuel
sensor (Diesel).


F21



5 A

Fan assembly control supply, ABS/ESP.

11
163
PRACTICAL INFORMATION
We recommend the use of genu-
ine CITROËN towbars and their
harnesses that have been tested
and approved from the design
stage of your vehicle, and that
the fi tting of the towbar is en-
trusted to a CITROËN dealer or
a qualifi ed workshop.
If the towbar is not fi tted by a
CITROËN dealer, it is impera-
tive that it is fi tted in accordance
with the vehicle manufacturer's
instructions.
TOWING A TRAILER, ...
The rear parking sensors will
be deactivated automatically if
a genuine CITROËN towbar is
used.

Towbar suitable for the attachment of a
trailer with additional lighting and sig-
nalling.
Your vehicle is primarily designed for
transporting people and luggage, but it
may also be used for towing a trailer. Driving with a trailer places greater de-
mands on the towing vehicle and the
driver must take particular care.
Driving advice


Distribution of loads


)
Distribute the load in the trailer so
that the heaviest items are as close
as possible to the axle and the nose
weight approaches the maximum
permitted without exceeding it.
Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towed load
must be reduced by 10 % for every
1 000 metres of altitude.
Refer to the "Technical Data" section for
details of the weights and towed loads
which apply to your vehicle.

Side wind


)
Take into account the increased
sensitivity to side wind.


Cooling
Towing a trailer on a slope increases
the temperature of the coolant.
As the fan is electrically controlled, its
cooling capacity is not dependent on
the engine speed.


)
To lower the engine speed, reduce
your speed. The maximum towed load on a long in-
cline depends on the gradient and the
ambient temperature.
In all cases, keep a check on the coolant
temperature.


)
If the warning lamp and the
STOP
warning lamp come
on, stop the vehicle and
switch off the engine as
soon as possible.


Braking
Towing a trailer increases the braking
distance.
To avoid overheating of the brakes on a
long mountain type of descent, the use
of engine braking is recommended.

Tyres


)
Check the tyre pressures of the towing
vehicle and of the trailer, observing the
recommended pressures.


Lighting


)
Check the electrical lighting and sig-
nalling on the trailer.

11
PRACTICAL INFORMATION

*
To avoid any risk of jamming of the
pedals:

-
ensure that the mat is positioned and
secured correctly,

-
never fi t one mat on top of another.

ACCESSORIES

They are all adapted to your vehicle and
benefi t from CITROËN's recommenda-
tion and warranty.

"Comfort"

sun blinds, door defl ectors, isotherm
module, smoking kit, fragrance cartridg-
es, front centre armrest, moveable mirror,
reading lamp...
"Style":

leather steering wheel, gear lever knobs,
front spoiler, rear diffuser, bumper trims,
front foglamp trims, parking brake lever
trims, aluminium footrest, alloy wheels,
wheel trims, chrome tailgate fi nisher,
chrome tailpipe fi nisher, chrome mirror
shells, chrome door handles... A wide range of accessories and genu-
ine parts is available from the CITROËN
dealer network.
These accessories and parts have been
tested and approved for reliability and
safety.


Conversion kits
You can obtain an "Enterprise" kit to
convert a trade vehicle to a private car
and vice-versa.

"Transport solutions":

child seats and booster cushions, boot
tray, boot carpet, boot net, boot contain-
ers, transverse roof bars, bicycle carrier,
ski carrier, roof boxes, towbars, towbar
wiring harnesses...
"Safety":

anti-theft alarm, wheel security bolts,
stolen vehicle tracking system, breath-
alyser, fi rst aid kit, warning triangle, high
visibility vest, dog guard, snow chains,
non-slip covers, foglamps kit, parking
sensors, bumper protection strips (trans-
lucent, gloss black, chrome fi nish)...

"Protection" :

mats * , mudfl aps, seat covers, door sill
protectors... If a towbar and wiring are fi tted
outside the CITROËN dealer
network, this must be done
making use of the vehicle's
electrical pre-equipment and
following the manufacturer's
recommendations.

235
VISUAL SEARCH
Remote control key............... 64-67


- opening/closing

- anti-theft protection

- starting

- battery

EXTERIOR

Lighting controls ................... 77-80
Headlamp adjustment................ 80
Changing bulbs................. 145-147


- front lamps

- foglamps

- direction indicator repeaters Door mirrors ............................... 62
Doors .................................... 70-73


- opening/closing

- central locking

- emergency control
Child lock ................................. 100
Electric windows ................... 68-69 Accessories ...................... 165-166 Wiper controls....................... 81-83
Changing a wiper blade ........... 160
Boot ........................................... 73
Temporary puncture
repair kit ..................... 136-140
Changing a wheel ............. 141-144


- tools

- removing/refi tting
Changing bulbs................. 148-149


- rear lamps

- 3rd brake lamp

- number plate lamps
Rear parking sensors ....... 127-128
Towbar ..................................... 163
Towing .............................. 161-162
Hill start assist ......................... 122
Braking assistance .................. 102
Trajectory control ..................... 103
Tyre pressures ................. 140, 177 Fuel tank ............................... 74-75
Misfuel prevention ..................... 76

241
ALPHABETICAL INDEX
R Resetting the trip recorder ............ 38
Rev counter ............................ 23, 24
Reversing lamp .......................... 148
Risk areas (update) .................... 194
Routine checks ................... 134, 135
Running out of fuel (Diesel) ........ 130
S Safety
for children ..........92-100, 105, 107
Scented air freshener ................... 58
Screen, colour 16/9 ...... 48, 184, 205
Screen,
monochrome ............ 216, 228, 230
Screen, multifunction
(with audio equipment) ... 43, 45, 48
Screen-wash reservoir ............... 133
Screen menu map ...... 205, 228, 230
Screenwash ................................. 82
Screenwash fluid level ............... 133
Seat, rear bench ........................... 61
Seat adjustment ........................... 59
Seat belts ........................... 104, 105
Seats, rear .................................... 61
Serial number, vehicle ................ 177
Service indicator ........................... 35
Servicing ...................................... 21
Setting
the clock ............. 38, 204, 226, 227
Short-cut menus ................. 185, 186
Sidelamps .................... 77, 146, 148
Side repeater .............................. 146
Spare wheel ............................... 141
Speakers (fitting) ........................ 164
Speed limiter .............................. 123
Speedometer .......................... 23, 24 P Paint colour code ....................... 177
Parcel shelf, rear .......................... 91
Parking brake ..................... 110, 135
Parking sensors, rear ................. 127
Particle emission filter ........ 134, 135
Passenger compartment filter ...... 134
Player, CD MP3 ................. 199, 219
Port, USB ..................... 88, 220, 222
Priming the fuel system .............. 130
Protecting
children ................92-100, 105, 107
Puncture ..................................... 136
R Radio .................................. 197, 217
Radio pre-equipment .................. 164
Rear foglamp ........................ 78, 148
Rear screen (demisting) ............... 57
Recharging the battery ............... 159
Reduction of electrical load ........ 159
Regeneration of the particle
emissions filter ......................... 135
Reinitialising the electric windows .... 69
Reinitialising the remote control ..... 66
Remote control ....................... 64, 67
Removing a wheel ...................... 143
Removing the mat ........................ 89
Repair kit, puncture .................... 136
Replacing bulbs ...................145-150
Replacing fuses ...................151-157
Replacing the air filter ................ 134
Replacing the oil filter ................. 134
Replacing the passenger
compartment filter .................... 134
Replacing wiper blades ........ 83, 160
Resetting the service indicator ..... 36 L Locating your vehicle ................... 65
Locking from the inside ................ 71
Low fuel level ............................... 74
LPG ............................................ 170
M Main beam ........................... 77, 146
Maintenance ................................. 21
Markings,
identification ............................. 177
Mat ............................................... 89
Menu, main ................................ 216
Mirror, rear view ........................... 63
Mirrors, door ................................. 62
Misfuel prevention ........................ 76
Motorway function
(direction indicators) ................. 101
Mountings for ISOFIX
seats ..................................... 97, 99
MP3 CD .............................. 199, 219
Music media players .................. 198
MyWay ..........................48, 181-212
N Navigation .................................. 187
Number plate lamps ................... 148
O Oil filter ....................................... 134
Oil level ................................ 37, 133
Opening the bonnet .................... 130
Opening the boot .................... 64, 73
Opening the doors .................. 64, 70
Opening the fuel filler flap ............ 74
Operation indicator
lamps .....................................25-34
