Contents

7
B618_en_Chap00b_vue-ensemble_ _ed01-2016
Headlamp beam height adjustment 112
Lighting control stalk
1
05 -112
Direction indicators
1
08
Dashboard fuses
2
41-245 Central locking

7
0
Hazard warning lamps 1 18
Wiper control stalk
1
13 -116
Trip computer
5
0 -52
Speed limiter
1
75 -177
Cruise control

1
78 -181
Memorising speeds

1
70
Speed limit r e c o g n i t i o n
17

1-174
Instrument panels

1
1-14
Indicator and warning lamps
1
5 -30
Indicators
3
1-38
Distance recorders
3
9
Steering wheel adjustment
8
2
H o r n


118
Instruments and controls (cont.)
Starting - switching off the engine 15 3 -15 8
.
Over view

9
B618_en_Chap00c_eco-conduite_ed01-2016
Optimise the use of your gearbox
With a manual gearbox, move off gently and change up without waiting.
During acceleration change up early.
If your vehicle has cruise control, make use of the system at speeds
above 25 mph (40 km/h) when the traffic is flowing well.
Control the use of your electrical
equipment
Before moving off, if the passenger compartment is too warm, ventilate it
by opening the windows and air vents before using the air conditioning.
Above 30 mph (50 km/h), close the windows and leave the air vents
open.
Remember to make use of equipment that can help keep the
temperature in the passenger compartment down (sunroof and window
blinds...).
Switch off the air conditioning, unless it has automatic regulation, as
soon as the desired temperature is attained.
Switch off the demisting and defrosting controls, if not automatic.
Switch off the heated seat as soon as possible.
Switch off the headlamps and front foglamps when the ambient light
level does not require their use.
Avoid running the engine before moving off, particularly in winter; your
vehicle will warm up much faster while driving.
Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.
With an automatic gearbox, give preference to automatic mode and
avoid pressing the accelerator pedal heavily or suddenly.
The gear efficiency indicator invites you to engage the most suitable
gear: as soon as the indication is displayed in the instrument panel,
follow it straight away.
For vehicles fitted with an automatic gearbox, this indicator appears
only in manual mode.
Drive smoothly
Maintain a safe distance between vehicles, use engine braking rather
than the brake pedal, and press the accelerator progressively. These
practices contribute towards a reduction in fuel consumption and
CO
2 emissions and also help reduce the background traffic noise. A s a passenger, if you avoid connecting your multimedia devices
(film, music, video game...), you will contribute towards limiting the
consumption of electrical energy, and so of fuel.
Disconnect your portable devices before leaving the vehicle.
.
Eco-driving

11
B618_en_Chap01_Instruments-de-bord_ed01-2016
Symbols LCD instrument panel
1. Speedometer (mph or km/h).
2. Display.
3.
R

ev counter (x 1 000 rpm or tr/min).
Dials Control buttons
A. Main lighting dimmer. D
epending on version: scrolling through a
menu, a list; changing a value. B. R
ecall of the servicing information or of the
driving range with the SCR system and the
AdBlue
®. R
eset of the function selected (service
indicator or trip distance recorder).
D

epending on version: access to
the configuration menu (long press),
confirmation of a choice (short press).
1
Instruments

13
B618_en_Chap01_Instruments-de-bord_ed01-2016
Text LCD instrument panel
DialsControl buttons
1. Speedometer (mph or km/h).
2. F
uel level indicator.
3.
D

isplay.
4.
E

ngine coolant temperature gauge.
5.
R

ev counter (x 1 000 rpm or tr/min). A. R
eset of the service indicator. R
ecall of the current servicing information,
or the driving range with the SCR system
and the AdBlue
®. D
epending on version: go back a level,
abandon the operation in progress.
B.
M

ain lighting dimmer.
D

epending on version: scrolling through a
menu, a list; changing a value. C.
R

eset of the trip distance recorder and the
trip.
D
epending on version: access to
the configuration menu (long press),
confirmation of a choice (short press).
1
Instruments

15
B618_en_Chap01_Instruments-de-bord_ed01-2016
Visual indicators informing the driver that a system is in operation, switched off or has a fault.
Indicator and warning lamps
When the ignition is switched on
Certain warning lamps come on for a few
seconds in the instrument panel when the
vehicle's ignition is switched on.
When the engine is started, these same
warning lamps should go off.
If they remain on, before moving off, refer to the
information on the warning lamp concerned.
Associated warnings
The switching on of certain warning lamps may
be accompanied by an audible signal and a
message.
The warning lamps may come on continuously
(fixed) or flash.Certain warning lamps may come on in
one of two modes: fixed (continuous) or
flashing.
Only by relating the type of illumination
to the operation of the vehicle can it
be determined whether the situation is
normal or a fault has occurred. In the
event of a fault, the illumination of the
warning lamp may be accompanied by
a message.
Refer to the tables in the following
pages for more information.
When switching on the ignition, the
displays in the instrument panel appear
dynamically and progressively. This is
normal operation.
1
Instruments

18
Warning / indicator lampStateCause Action / Observations
Stop & Star t fixed.
When the vehicle stops (red lights,
traffic jams,...) the Stop & Start system
has put the engine into STOP mode.The warning lamp goes off and the engine restarts
automatically in START mode, as soon as you want to
move off.
flashes for a few
seconds, then goes
of f. STOP mode is temporarily
unavailable,
or
START mode is invoked
automatically. For more information on Stop & Star t
, refer to the
corresponding section.
Blind spot
monitoring
system
* fixed.
The system has been activated. For more information on the Blind spot monitoring
system, refer to the corresponding section.
*

Only on the Text LCD instrument panel.
Instruments

21
B618_en_Chap01_Instruments-de-bord_ed01-2016
Warning / indicator lampStateCause Action / Observations
or Service
temporarily,
accompanied by the
display of a message. One or more minor faults for which
there is no specific warning lamp
have been detected. Identify the cause of the fault using the message
displayed in the instrument panel.
You can deal with some problems yourself, such as a
door open or the start of saturation of the particle filter
(as soon as the traffic conditions allow, regenerate
the filter by driving at a speed of at least 40 mph
(60
km/h), until the warning lamp goes off).
For any other problems, such as a fault with the tyre
under inflation detection system, contact a CITROËN
dealer or a qualified workshop.
fixed, accompanied
by the display of a
message. One or more major faults for which
there is no specific warning lamp
have been detected. Identify the cause of the fault using the message
displayed in the instrument panel; you must then
contact a CITROËN dealer or a qualified workshop.
fixed, associated with the
flashing and then fixed
display of the service
indicator spanner.The servicing interval has been
exceeded.
Only on BlueHDi Diesel versions.
Your vehicle must be serviced as soon as possible.
1
Instruments

23
B618_en_Chap01_Instruments-de-bord_ed01-2016
Warning / indicator lampStateCause Action / Observations
Engine
diagnostic
system fixed.
The emission control system has a
fault.
The warning lamp should go off when the engine is started.
If it does not go off, contact a CITROËN dealer or qualified
workshop without delay.
flashing.The engine management system has
a fault. Risk of destruction of the catalytic converter.
Have it checked by a CITROËN dealer or a qualified
workshop.
fixed, associated with the
SERVICE warning lamp.A minor engine fault has been
detected.Have it checked by a CITROËN dealer or a qualified
workshop.
fixed, associated with
the STOP warning
lamp. A major engine fault has been
detected.
You must stop as soon as it is safe to do so.
Park, switch off the ignition and contact a CITROËN
dealer or a qualified workshop.
Power steering *fixed. Major power steering fault. Drive carefully at reduced speed.
Have it checked by a CITROËN dealer or a qualified
workshop.
* Only on the Symbols LCD instrument panel.
1
Instruments

24
Warning / indicator lampStateCause Action / Observations
Door(s) open fixed, associated with
a message identifying
the door. Speed below 6 mph (10 km/h), a door
or the boot is not properly closed.
Close the door or boot.
fixed, associated with
a message identifying
the door, together with
an audible signal. Speed above 6 mph (10 km/h), a door
or the boot is not properly closed.
Foot on the
clutch
* fixed.
In the STOP mode of Stop & Start,
changing to START mode is denied
because the clutch pedal is not fully
down. You must declutch fully to allow the change to engine
START mode.
*
Only on the Symbols LCD instrument panel.
Instruments
