Contents
Conventional child seats 103
ISOFIX child seats 109
Child lock 112
Child safety
Instrument panel 22
Indicator and warning lamps 23
Indicators 31
Adjustment buttons 34
Monitoring Familiarisation
Screens with audio equipment 35
Tr i p c o m p u t e r 45
Multifunction screens
Ventilation 48
Rear screen demist/defrost 50
Heating 51
Manual air conditioning 51
Dual-zone digital air conditioning 53
Scented air freshener 56
Front seats 57
Rear seats 60
Mirrors 62
Steering wheel adjustment 63
Comfort
Remote control key 64
Window controls
69
Doors 71
Boot 74
Panoramic sunroof 75
Fuel tank 76
Misfuel prevention (Diesel) 78
Access
Lighting controls 79
LED lamps 83
Cornering lighting 84
Headlamp adjustment 85
Wiper controls 86
Courtesy lamps 89
Boot lamp 91
Visibility
Front fi ttings 92
Rear fi ttings 96
Boot fi ttings 99
Fittings Eco-driving

.Familiarisation
5

Remote control key
A.Unfolding / Folding the key.
Lockin
g(press once; fixed lighting of the
direction indicators).

Panoramic sunroof blinds

Lift the handle of the blind concerned andrelease.
Each blind is fitted with a roller in which it isstored when released.

Deadlocking(press twice in succession; fixedlighting of the direction indicators).
Unlocking the vehicle
(rapid flashing of the direction
indicators).
6
4
75

Fuel t ank
76
1.
Opening the fuel filler flap.2.Opening and hooking the fuel filler cap.

Capacity of the tank:


- approximately 50 litres (petrol),

- approximately 48 litres (Diesel),

- (depending on version: approximately 30 litres (petrol or Diesel), 33 litres (LPG)).

Access

1
Monitoring
27
Warning lamps
Warning lampis onCauseAction / Observations
STOP
fixed, alone or associated withanother warning lamp,accompanied by anaudible signal and a
message on the screen.
The illumination of this warning lamp
is related to a serious fault with thebraking system, the power steering,
the engine oil pressure or the enginecoolant temperature. Stop as soon as it is safe to do so, as the en
gine may cut out while driving.
Park, switch off the ignition and call a CITROËN
dealer or a qualified workshop.
Service
temporarily,
accompanied by an
audible signal and
a messa
ge on the
multifunction screen.
A minor fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message shown on
the screen, such as, for example:


- engine oil level,

- screenwash level,

- remote control batter
y,

- state of the bulbs,

- saturation of the par ticle emission filter on Diesel
vehicles
(see "Checks - Particle Emissions
Filter").
For any other faults, contact a CITROËN dealer or a qualified workshop.


fixed, accompanied by an
audible signal and a messageon the multifunction screen.
A major fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message shown
on the screen and contact a CITROËN dealer or a qualified workshop.
Any fault resulting in the illumination of a warning lamp must be investigated further by reading the associated message in the multifunction screen.If you encounter any problems, do not hesitate to contact a CITROËN dealer or a qualified workshop.

When the engine is running or the vehicle is
being driven, the illumination of one of the following warning lamps indicates a fault which
requires action on the par t of the driver.

Comfort
62





Mirrors
The mirror glass is electrically adjustable.
A lamp located under the mirror shell provides
lighting for the driver's and front passenger'sentry and exit.
This exterior lighting comes on when the
vehicle is unlocked or a door is opened and
stays on for a timed period.


Folding
)From outside: lock the vehicle using the
remote control or the key. )From inside: with the ignition on, pull the control A
in the central position rearwards.


Unfolding
)From outside: unlock the vehicle using theremote control or the key. )From inside: with the ignition on, pull the control A
in the central position rear wards.


Adjustment
)
Move control Ato the right or to the left to select the corresponding mirror. )
Move control Bin all four directions toadjust. )
Return control Ato the central position.

If the mirrors are folded using control A
,they will not unfold when the vehicle is unlocked. Pull again on control A.

The folding and unfolding of the door mirrors using the remote control can bedeactivated by a CITROËN dealer or a qualified workshop.
Never fold or unfold the electric foldingmirrors manually.
The objects obser ved are, in reality, closer than they appear.Take this into account in order to correctly judge the distance of vehicles
approaching from behind.

Door mirrors

Access
64















Remote control key
System which permits central unlocking or locking of the vehicle using the lock or from a distance. It is also used to locate and start the vehicle, as well as providing protection against theft.
Unfolding the key
)First press this button to unfold the key.

Unlocking the vehicle
)
Press the open padlock to unlock
the vehicle.

Unlocking using the key
)
Turn the key to the right in the driver's door lock to unlock the vehicle.
Unlocking is confirmed by rapid flashing of
the direction indicators for approximately twoseconds.
According to version, the door mirrors unfold at
the same time.
Unlocking using the remote control
Locking the vehicle
)Press the closed padlock to lock
the vehicle.



Locking using the key
)
Turn the key to the left in the driver's door lock to lock the vehicle completely.


Locking using the remotecontrol

If one of the doors or the boot is stillopen, the central locking does not takeplace.
When the vehicle is locked, if it isunlocked inadvertently, it will relock automatically after thir ty secondsunless a door or the boot is open.

The folding and unfolding of the door mirrors using the remote control can bedeactivated by a CITROËN dealer or a qualified workshop.
Lockin
g is confirmed by fixed lighting of the
direction indicators for approximately twoseconds.
According to version, the door mirrors fold at
the same time.

4
Access
65
Deadlocking using the
remote controlDeadlockin
g using the key
) Turn the key to the left in the driver's door lock to lock the vehicle completely.)
Turn the key to the left again within fiveseconds to deadlock the vehicle.
)
Press the closed padlock to lock
the vehicle.) Press the closed padlock again
within five seconds to deadlock
the vehicle.
Deadlocking is confirmed by fixed lighting of the direction indicators for approximately two seconds. According to version, the door mirrors fold at the same time.Deadlocking renders the exterior and interior door controls inoperative. It also deactivates the manual central control button. Therefore, never leave anyone inside the vehicle when it is deadlocked.

4
Access
67
Remote control problem
Following disconnection of the vehicle battery,replacement of the remote control battery or in the event of a remote control malfunction, you can no longer unlock, lock or locate your
vehicle.) First of all, use the key in the lock to unlock
or lock your vehicle.) Then, reinitialise the remote control.
If the problem persists, contact a CITROËN
dealer as soon as possible.

Changing the battery

Battery ref.: CR1620 / 3 volts. Reinitialisation
)
Switch off the ignition.)
Turn the key to position 2 (Ignition on).)
Press the closed padlock immediately for afew seconds.)
Switch off the ignition and remove the key from the ignition switch.
The remote control is fully operational again. I
f the battery is flat, you are
informed by illumination of
this warnin
g lamp, an audible
signal and a message in the
multifunction screen.

Key reminder


Switching the vehicle off
)Immobilise the vehicle. )Turn the key fully towards you toposition 1 (Stop)
. )Remove the key from the ignition switch.
)
Unclip the casing using a coin at the notch. )
Slide the flat battery out of its location.)
Slide the new battery into its location
observing the original direction. ) Clip the casing.)
Reinitialise the remote control.


Do not attach any heavy objects to the key as this could weigh down on it whenin the ignition switch and cause a fault.

If the key is left in the ignition switch, anaudible signal sounds when the driver's door is opened.

Access
68

Remote control

The high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of your vehicle. You run the risk of stopping it from working and the remote control would haveto be reinitialised.
No remote control can operate when the key is in the ignition switch, even when the ignition is switched off, except for reinitialisation.


Locking the vehicle

Driving with the doors locked may make access to the passenger compar tment by theemergency services more difficult in an emergency.
However, the vehicle unlocks automatically in the event of a serious impact causing airbag deployment. As a safety precaution, never leave children alone in the vehicle, except for a very shor t period.
In all cases, it is essential to remove the key from the ignition switch when leaving the vehicle.


Anti-theft protection

Do not make any modifications to the electronic engine immobiliser system; this could cause malfunctions.


When purchasing a second-hand vehicle

Have the pairing of all of the keys in your possession checked by a CITROËN dealer, to ensure that only your keys can be used to open and start the vehicle.
Lost keys

Visit a CITROËN dealer with the vehicle's registration document, your personal identification documents and if possible the key code label.
The CITROËN dealer will be able to look up the key code and the transponder coderequired to order a new key.
Do not throw the remote controlbatteries away, they contain metals which are harmful to the environment.
Take them to an approved collectionpoint.

4
Access
71











Doors


From outside
)After unlocking the vehicle using theremote control or the key, pull the door handle.
From inside
)
Pull the front door control to open the door;
this unlocks the vehicle completely. ) Pull the rear door control to open the door;
this unlocks only the door opened.

Closing
-when the engine is running
, this
warnin
g lamp comes on, accompanied
by a message in the multifunction screen for a few seconds,

Opening

When a door is not closed correctly:

- when the vehicle is movin
g
(speed higher than 6 mph (10 km/h)), this warning
lamp comes on, accompanied by an
audible signal and a message in the multifunction screen for a few seconds.

Access
72
Manual centralised control
Locking
)Press button Ato lock the vehicle.
The red indicator lamp on the button comes on.

Automatic centralised
control

Unlocking
)Above 6 mph (10 km/h), press button Ato
unlock the doors and the boot temporarily.

Unlocking
)
Press button A
again to unlock the vehicle.
The red indicator lamp on the button switches
off.


Locking

When the speed exceeds 6 mph (10 km/h), the doors and the boot lock automatically.
If the vehicle is locked from the outside,the red indicator lamp flashes andbutton A
is inactive. )In this case, use the remote controlor the key to unlock the vehicle.

If one of the doors is open, centrallocking from the inside does not takeplace.

If one of the doors is open, theautomatic central locking does not take place.
If the boot is open, the automatic centrallocking of the doors is active.
System which provides full manual locking or
unlocking of the doors from the inside. System which provides full automatic locking
or unlocking of the doors and the boot while
driving.
You can activate or deactivate this function.
