Driving
141





Reversing camera

A reversing camera is activated automatically
when reverse gear is engaged.
The colour image is provided in the navigationscreen.
The space between the blue lines represents thewidth of your vehicle except for the door mirrors.
The blue lines represent the general direction of the vehicle.
The red lines represent a distance of about
30 cm beyond the edge of your vehicle's
rear bumper. The audible signal becomes
continuous from this limit.
The green lines represent distances of
about 1 and 2 metres beyond the edge of your
vehicle's rear bumper.


Clean the reversing camera regularly using a soft, dry cloth.



The reversing camera cannot in any circumstances be a substitute for thevigilance and responsibility of the driver.
