Contents

6
Instruments and controls
1. Steering lock and ignition.
2. Audio system steering mounted controls.
3.
W

ipers / screenwash / trip computer control
stalk.
4.
I

nstrument panel.
5.
D

river's airbag.


Horn.
6.
G

ear lever.
7.
O

pen storage compartment.
8.
D

oor mirror controls.
E

lectric window controls.
R

ear electric windows and doors
deactivation control.
9.
P

assenger's airbag deactivation.
10.
M

anual headlamp height adjustment.
11.
F

ront side window demisting vent.
12 .
W

indscreen demisting vent.
13.
N

avigation screen and scented air
freshener.


or


Storage.
Over view

7
Instruments and controls
1. Steering wheel adjustment control.
2. Cruise control / speed limiter switches.
3.
L

ighting and direction indicator control
stalk.
4.
C

entral adjustable air vents.
5.


Storage.


or
N

avigation screen and scented air
freshener.
6.
S

unshine sensor.
7.
P

assenger's airbag.
8.
S

ide adjustable air vent.
9.
G

love box.
F

usebox.
10.
B

onnet release.
11.
D

ynamic stability control (DSC/ASR)
switch.
P

arking sensors switch.
C

entral locking switch.
H

azard warning lamps switch.
E

lectric child lock switch.
12 .
H

eating / air conditioning controls.
13.
A

udio system.
14 .
1

2 V socket (100 W max).
15.
U

SB port / auxiliary socket.
16.
C

u p h o l d e r.
17.
P

arking brake.
.
Over view

10
Petrol - Diesel instrument panel
Panel grouping together the digital indicator, the multifunction screen and the vehicle operation
indicator and warning lamps.
1.
R
ev counter.
I

ndicates the speed of rotation of the
engine (x 1000 rpm).
2.
R

ev counter zone indicating that you must
change up a gear.
3.
S

peed limiter


or
C

ruise control.
(

mph or km/h)
4.
E

lectric child lock indicator lamp.
I

ndicates, for a few seconds, the activation
of the electric child lock (deactivation of the
rear windows and doors).
Translucent digital instrument panel
This screen groups together the warning and
information messages.
Multifunction screen
Indicator lamps display zone
This zone groups together the vehicle
operation indicator lamps.
Display zero reset button
This permits resetting of the function selected
to zero (trip distance recorder or service
indicator).
Instrument panel lighting button
This adjusts the brightness of the lighting of the
instruments and controls.
5.
F

uel
gauge .
I

ndicates the quantity of fuel remaining in
the tank.
6.
S

peedometer
.
I

ndicates the current speed of the moving
vehicle (mph or km/h).
7. T
rip distance recorder.
(
miles or km)
8.
S

ervice indicator.
(

miles or km) then,
D

istance recorder.
(

miles or km)
9.
E

ngine oil level indicator. For more information, refer to the
paragraph relating to the button or
function and its associated display.
Monitoring

13
Passenger
airbag systemfixed.The control switch, located at the
passenger's end of the dashboard, is in
the
"ON " position.
The passenger's front airbag is activated.
In this case, do not install a rear ward
facing child seat on the front passenger
seat.Turn the control switch to the " OFF" position to
deactivate the front passenger's airbag.
You can install a rear ward facing child seat on the
front passenger seat, except if there is a fault with the
airbags (airbag warning lamp on).
Warning
/indicator lampis on Cause Action / Observations
Electric child
lock temporarily.
The electric child lock is activated. Displayed for a few seconds after activating the
function and every time the ignition is switched on.
For more information, refer to the "Child safety"
section.
1
Monitoring

16
Warning/indicator lampis on Cause Action / Observations
Anti-lock
Braking System
(ABS) fixed.
The anti-lock braking system has a
fault. The vehicle retains conventional braking.
Drive carefully at reduced speed and contact a
CITROËN dealer or a qualified workshop without
d e l ay.
Dynamic
stability control
(DSC/ASR) flashing.
Regulation by the system is active. The system optimises traction and improves the
directional stability of the vehicle.
fixed, associated with
illumination of the indicator
lamp in the deactivation
button, accompanied by
an audible signal and a
message.The DSC/ASR or hill start assist
system has a fault.Have it checked by a CITROËN dealer or a qualified
workshop.
Engine
autodiagnosis
system flashing.
The engine management system has
a fault. Risk of destruction of the catalytic converter.
Have it checked by a CITROËN dealer or a qualified
workshop.
fixed. The emission control system has a
fault.
The warning lamp should go off when the engine is started.
If it does not go off, contact a CITROËN dealer or qualified
workshop without delay.
Brakingfixed, associated with
the STOP warning
lamp. The braking system fluid level is too
low.
You must stop as soon as it is safe to do so.
Top up with brake fluid recommended by CITROËN.
If the problem persists, have the system checked by a
CITROËN dealer or a qualified workshop.
+ fixed, associated with
the STOP and ABS
warning lamps.The electronic brake force distribution
(EBFD) system has a fault.
You must stop as soon as it is safe to do so.
Have it checked by a CITROËN dealer or a qualified
workshop.
Monitoring

24
Resetting the service indicator
After each service, the service indicator must
be reset to zero.
If you have carried out the service on your
vehicle yourself:
F
s
witch off the ignition,
F

p
ress and hold the trip distance recorder
zero reset button,
F

s
witch on the ignition; the distance recorder
display begins a countdown,
F

w
hen the display indicates "=0" , release
the button; the spanner disappears.
Retrieving the service
information
You can access the service information at any
time.
F

P
ress the trip distance recorder zero reset
button.
T

he service information is displayed for a
few seconds, then disappears. If you have to disconnect the battery
following this operation, lock the vehicle
and wait at least five minutes for the
reset to be registered.
Monitoring

26
Distance recordersLighting dimmer
The total and trip distances are displayed for
thirty seconds when the ignition is switched off,
when the driver's door is opened and when the
vehicle is locked or unlocked.It measures the total distance travelled by the
vehicle since its first registration.
Activation
When the lighting is on:
F
p ress the button to change the brightness
of the instruments and controls,
F

w
hen the level of brightness required is
reached, release the button.
Deactivation
When the lighting is off, or in day mode on
vehicles fitted with daytime running lamps,
pressing the button does not have any effect.
Total distance recorder
When travelling abroad, you may
have to change the units of distance:
the display of road speed must be in
the official units (miles or km) for the
country. The change of units is done via
the screen configuration menu, with the
vehicle stationary. System for manual adjustment of the
brightness of the instruments and controls to
suit the ambient light level.
Trip distance recorder
It measures the distance travelled since it was
reset to zero by the driver.
F

W
ith the ignition on, press the button until
zeros appear.
Monitoring

49
Scented air freshenerSystem permitting the diffusion of a fragrance in the passenger compartment in accordance with
your requirements, by means of the adjustment dial and the various fragrance cartridges available.
Fitting the cartridge
F Remove the cartridge from the sealing case.
F

I
nstall the cartridge (flower at top right).
F

P
ress the dial and turn it a quarter of a turn
clockwise.
This dial is located on the dashboard.
It allows you to adjust the intensity of diffusion
of the fragrance.
F

T

urn the dial to the right to permit diffusion
of the fragrance.
F

T

urn the dial to the left to stop diffusion of
the fragrance.
Fragrance cartridge
Removing the cartridge
F Press the dial and turn it a quarter of a turn anti-clockwise.
F

R
emove the cartridge.
F

R
efit its sealing case.
As a safety precaution, do not carry
out any action on the cartridge while
driving.
Do not dismantle the cartridges.
Do not attempt to refill the fragrance
diffuser or the cartridges.
Avoid all contact with the skin and eyes.
Keep out of reach of children and
animals. Do not discard the original cartridge as
this serves as a plug when no fragrance
cartridge is in use.
In order to preserve the service life of
the cartridge, turn the dial to the left
when you no longer wish to diffuse the
fragrance in the passenger compartment.
Leave the central vents open.
The intensity of diffusion of the
fragrance may depend on the
ventilation or air conditioning settings.
Adjustment dial
This cartridge can be removed easily.
You can change it at any time and store it in the
sealed case which keeps it closed once it has
been opened.
You can obtain different fragrance cartridges
from a CITROËN dealer or a qualified
workshop.
3
Comfort

52
Table position of the front
passenger seat
Placing this seat in the table position, with the
rear benchseat also in the table position, allows
you to transport long objects.
F
P
ush the control upwards and guide the
seat back for wards to fold it onto the seat
cushion.
F

T
o put it back in place, lift up the seat back
and guide it rear wards until it locks in. Do not forget to fold the "aircraft" type
table fixed on the back of the seat first.
For safety reasons, a passenger sat in
the rear of the vehicle must not place
his feet on the front seat in the table
position.
Comfort
