Dashboard fuses
2
36 -240
O
Page 238 of 442
236
To replace a fuse, you must:
F u se the special tweezer to extract the fuse
from its housing and check the condition of
its filament.
F
a
lways replace the failed fuse with a fuse
of the same rating (same colour); using a
different rating could cause faults (risk of
f i r e).
If the fuse fails again soon after replacement,
have the vehicle's electrical system checked by
a CITROËN dealer or a qualified workshop. Good
Failed
The replacement of a fuse not shown in
the tables below may cause a serious
malfunction of your vehicle. Contact
a CITROËN dealer or a qualified
workshop. Tw e e z e r
Changing a fuse
Changing a fuse
Before changing a fuse:
F
t he cause of the failure must be identified
and rectified,
F
a
ll electrical consumers must be switched
of f,
F
t
he vehicle must be immobilised with the
ignition off,
F
i
dentify the failed fuse using the tables and
layout drawings in the following pages.
The extraction tweezer is fitted to the back of
the cover of the dashboard fuseboxes.
Access to the tools
F Open the glove box lid.
F U nclip the fuse boxes protection cover.
F
D
isengage the cover completely and turn it
ove r,
F
R
emove the tweezer from the back of the
c ove r.
In the event of a breakdown
Page 240 of 442
238
Dashboard fuses
The 2 fuseboxes are placed in the lower
dashboard, in the glove box.Fuse
N° Rating
(A) Functions
F29 -Not used.
F30 30Heated rear screen.
F31 10Heated mirrors.
F32 -Not used.
F33 40Front electric windows.
F34 40Rear electric windows.
F35 30Not used.
F36 -Not used.
F37 -Not used.
F38 -Not used.
F39 -Not used.
F40 -Not used.
Access to the fuses
F Open the glove box.
F
U nclip the fuse boxes protection cover.
Upper fusebox
In the event of a breakdown
Page 241 of 442
239
Lower fusebox
FuseN° Rating
(A) Functions
F1 10Electrochromatic interior mirror, heated rear screen, particle
filter pump (Diesel), parking sensors, power steering, LPG
system, clutch pedal switch, exterior mirror adjustment.
F10(+) -
F11(Gnd) 30Locking / unlocking of the doors and fuel filler flap (depending
on engine).
F13 10Rain and sunshine sensor, air conditioning, front camera.
F14 5Alarm, telematic unit.
F16 3Automatic gearbox gear selector, brake pedal switch,
Stop & Start system.
F17 5Instrument panel, driving school module.
F18 5Air conditioning, gear selector position indicator (automatic
gearbox).
F19 3Steering mounted controls.
F21 3START/STOP switch or button.
F23 5Seat belts not fastened warning lamps display.
8
In the event of a breakdown
Page 243 of 442
241
Engine compartment fuses
Access to the fuses
F Unclip the cover.
F C hange the fuse.
F
W
hen you have finished, close the cover
carefully to ensure correct sealing of the
fusebox. Fuse
N° Rating
(A) Functions
F1 40Air conditioning.
F10 15Engine management.
F11 20Engine management.
F12 5Engine management.
F13 5Engine management.
F14 5Battery charge status unit (depending on engine).
F15 5Not used.
F16 20Front foglamp.
F17 5Engine management.
F18 10Right-hand main beam headlamp.
F19 10Left-hand main beam headlamp.
F2 60A B S / E S P.
F20 30Engine management.
F21 30Starter motor (depending on engine).
F22 30Not used.
F23 40Starter unit (with Stop & Start and depending on engine).
F24 40Passenger compartment fusebox.
The fusebox is placed in the engine
compartment near the battery.
8
In the event of a breakdown
Page 244 of 442
242
FuseN° Rating
(A) Functions
F25 40Towbar pre-equipment.
F26 15Automatic gearbox or LPG system.
F27 25Built-in systems inter face (BSI).
F28 30Diesel emissions control system (AdBlue
®).
F29 40Windscreen wipers.
F3 50Passenger compartment fusebox.
F30 40Diesel pre-heating unit.
F31 80Additional heating (depending on equipment).
F32 80Power steering.
F4 30A B S / E S P.
F5 70Built-in systems inter face (BSI).
F6 60Cooling fan assembly.
F7 80Built-in systems inter face (BSI).
F8 15Engine management.
F9 15Engine management.
In the event of a breakdown
