traction control Citroen C4 2012 2.G Owner's Manual

I
39
MONITORING




Deactivation of
the automatic
functions of the
electric parking
brake



fi xed. The "automatic application"
(on switching off the engine)
and "automatic release"
functions are deactivated or
faulty. Activate the function (according to country)
via the vehicle confi guration menu or
contact a CITROËN dealer or a qualifi ed
workshop if automatic application/release
is not possible.
The parking brake can be released
manually using the emergency release
procedure.
For more information on the electric
parking brake, refer to the "Driving"
section.

Warning lamp


is on


Cause


Action/Observations





Dynamic
stability
control
(ESP/ASR)


fl ashing. The ESP/ASR regulation is
active. The system optimises traction and
improves the directional stability of the
vehicle.

fi xed. Unless it has been
deactivated (button pressed
and its indicator lamp on) the
ESP/ASR system has a fault. Have it checked by a CITROËN or a
qualifi ed workshop.


Engine
autodiagnosis
system


fl ashing. The engine management
system has a fault. Risk of destruction of the catalytic converter.
Have it checked by a CITROËN dealer or
a qualifi ed workshop.

fi xed. The emission control system
has a fault. The warning lamp should go off when the
engine is started.
If it does not go off, contact a CITROËN
dealer or qualifi ed workshop without delay.





Airbags


temporarily. This lamp comes on for a few
seconds when you turn on the
ignition, then goes off.
This lamp should go off when the engine is started.

If it does not go off, contact a CITROËN
dealer or a qualifi ed workshop.

fi xed. One of the airbag or seat belt
pretensioner systems has a
fault. Have it checked by a CITROËN dealer or
a qualifi ed workshop.

VIII
129
SAFETY
TRAJECTORY CONTROL
SYSTEMS

Anti-slip regulation (ASR)
and electronic stability
programme (ESP)

The anti-slip regulation (also known
as Traction Control) optimises trac-
tion to prevent skidding of the wheels,
by acting on the brakes of the driving
wheels and on the engine.
The electronic stability programme acts
on the brake of one or more wheels
and on the engine to keep the vehicle
on the trajectory required by the driver,
within the limits of the laws of physics.

Deactivation
In exceptional conditions (starting a
vehicle which is bogged down, stuck
in snow, on soft ground...), it may be
advisable to deactivate the ASR and
ESP systems, so that the wheels
can move freely and regain grip.


)
Press the "ESP OFF"
button, lo-
cated in the centre of the dash-
board.
If this warning lamp comes
on in the instrument panel
and the indicator lamp on the
button comes on, this indi-
cates that the ASR and ESP
systems are deactivated. This is indicated by fl ashing
of this warning lamp in the
instrument panel.

Activation
These systems are activated auto-
matically each time the vehicle is
started.
They come into operation in the event
of a grip or trajectory problem.

Intelligent Traction Control
system *

Your vehicle has a system to help
driving on snow.
This automatic system continuously
checks for situations of diffi cult sur-
face adhesion that could make it dif-
fi cult to move off or make progress
on deep fresh snow or compacted
snow.
In these situations, the system takes
over from the ASR
system by opti-
mising the amount of wheel slip to
provide the best traction and trajec-
tory control, even without snow tyres
and with or without chains.
In extremely severe conditions (snow
on top of ice, sand, deep mud…), it
can be useful to deactivate the ESP/
ASR
systems to allow a degree of
wheel spin and so recover grip.

*
Depending on engine type.

346
ALPHABETICAL INDEX
Warning lamps ....................37-39Wash-wipe, rear.....................r100Weights..................213,215, 221Welcome lighting...................104Wheel, changing....................186Window controls ......................86Windscreen zones for toll/car park cards ............................105Wiper, rear.............................r100Wiper control stalk .........100, 101Wipers............................100, 101
Under-inflation
(detection)............................127
Unlocking .................................78
Unlocking from
th
e inside .........................88,89
Update risk areas...........244,288
Updating the date..........320,321
Updating the time...........320,321
USB Box................................108
USB Reader...................r253,314
Xenon headlamps ..................190
Temperature adjustment....58,60Temperature controlfor heated seats.....................68Temporary tyre repair kit ........ 183Third brake lamp .................... 196TMC (Traffic info) ........... 249,289Toll/car park cards .................. 105Tools...................................... 186Torch.............................. 116,196Total distance recorder............r44Towbar...................................r209Towing another vehicle.......... 207Traction control (ASR) ........... 129Traffic information (TA) ......................290, 291,312
Traffic information (TMC) ..................249, 289,290Trip computer......................r53-55Trip distance recorder..............r44Tyre pressures ....................... 226Tyres ........................................29Tyre under-inflationdetection .............................. 127
Vehicle identification..............226Ventilation ................................56Video......................................259Video menu ............................259Video pack .............................329
TV
X
U
W
