4
ACCESS
84















Operating fault with the
2-button remote control
Following disconnection of the vehicle
battery, replacement of the remote con-
trol battery or in the event of malfunction
of the remote control, you can no longer
unlock, lock or locate your vehicle.


)
First of all, use the key in the lock to
unlock or lock your vehicle.

)
Then, reinitialise the remote control.

Reinitialisation


)
Switch off the ignition.

)

Turn the key to position 2 (Ignition on)
.


)
Press the closed padlock immedi-
ately for a few seconds.

)
Switch off the ignition and remove
the key from the ignition switch.
The remote control is fully operational
again. Battery ref.: CR1620/3 volts.
Changing the battery

If the battery is fl at, you are in-
formed by illumination of this
warning lamp, an audible signal
and a message in the screen.


)
Unclip the casing using a coin at the
notch.

)
Slide the fl at battery out of its loca-
tion.

)
Slide the new battery into its loca-
tion observing the original direction.

)
Clip the casing.

)
Reinitialise the remote control.

If the problem persists, contact
a CITROËN dealer as soon as
possible.

10
CHECKS
186





























CHECKS

Unless otherwise indicated, check
these components in accordance with
the servicing booklet and according to
your engine.
Otherwise, have them checked by a
CITROËN dealer or a qualifi ed workshop.


Battery

The battery does not require
any maintenance.
However, check that the ter-
minals are clean and correctly
tightened, particularly in sum-
mer and winter.
When carrying out work on the battery,
refer to the "Practical information" sec-
tion for details of the precautions to be
taken before disconnecting the battery
and following its reconnection.


Air filter and passenger compartment filter

Refer to the servicing booklet
for details of the replacement
intervals for these compo-
nents.

Oil filter

Replace the oil fi lter each time
the engine oil is changed.
Refer to the servicing booklet
for details of the replacement
interval for this component.










Particle emission filter (Diesel)

According to your version of instrument
panel, the start of saturation of the par-
ticle emissions fi lter is indicated by:


- fi xed illumination of the par-
ticle emissions fi lter warning
lamp, accompanied by an au-
dible signal and a message
that there is a risk of blockage
of the particle emissions fi lter,






The presence of this label, in particular
with the Stop & Start system, indicates
the use of a specifi c 12 V lead-acid bat-
tery with special technology and speci-
fi cation, for which the involvement of a
CITROËN dealer or a qualifi ed work-
shop is required when replacing or dis-
connecting the battery.
Failure to observe this recommendation
may shorten the life of the battery.

Depending on the environment (e.g.
dusty atmosphere) and the use of the
vehicle (e.g. city driving), replace them
twice as often if necessary
(refer to
the "Engines" section).
A clogged passenger compartment fi l-
ter may have an adverse effect on the
performance of the air conditioning sys-
tem and generate undesirable odours.
As soon as the traffi c conditions per-
mit, regenerate the fi lter by driving at a
speed of at least 40 mph (60 km/h) until
the warning lamp goes off.
If the warning lamp stays on, refer to
the "Additive level" section.
On a new vehicle, the fi rst opera-
tions of regeneration of the particle
emissions fi lter may be accom-
panied by the smell of "burning",
which is perfectly normal.
Following prolonged operation
of the vehicle at very low speed
or at idle, you may, in excep-
tional circumstances, notice the
emission of water vapour at the
exhaust on acceleration. This
does not affect the behaviour of
the vehicle or the environment. or

-
temporary illumination of
the service warning lamp,
accompanied by an audible
signal and a message that
there is a risk of blockage of
the particle emissions fi lter.

323
ALPHABETICAL INDEX
L Lane Departure Warning System
(LDWS) ....................................166
Level, brake fl uid ........................184
Level, power steering fl uid .........184
Levels and checks ...............182-185
Lighting, guide-me home ....102, 103
Lighting, interior ...................111, 112
Lighting bulbs
(replacement) ...................197, 201
Lighting control stalk ............99, 102
Lighting dimmer .................28-31, 49
Loading ................................26, 210
Load reduction mode .................209
Load space cover .......................125
Locating your vehicle ...................82
Locking from the inside ................87
Locking the boot ...........................92
Long objects, transporting ..........121
LPG ............................................221
Luggage retaining strap .............122
M Main beam ...................99, 197, 199
Maintenance .................................26
Map reading lamps ..................... 111
Markings, identifi cation ...............228
Massage function .........................74
Mat .............................................120
Menu, main ................................286
Mini fuel level ...............................96
Mirror, rear view ...........................79
Mirrors, door ...................77, 78, 167
Misfuel prevention ........................98
Motorway function
(direction indicators) .................135
Mountings for ISOFIX seats .......131
MP3 CD ..............................291, 292
Music media players ..................266N Navigation ..........................237, 238
Number plate lamps ...................202
O Oil fi lter .......................................186
Oil level ................................44, 184
Opening the bonnet ....................180
Opening the boot ..........................92
Opening the doors ........................91
Opening the panoramic
sunroof blind ...............................95
Operation indicator
lamps ........................35, 40, 41, 43
P Paint colour code .......................228
Panoramic glass sunroof ..............95
Parcel shelf, rear ................123, 125
Parking brake .....................154, 187
Parking brake, electric ........147, 150
Parking lamps ............................102
Parking sensors, front ................178
Parking sensors, rear .................177
Parking space sensor .................175
Particle emission fi lter ........185, 186
Passenger compartment fi lter ....186
Personalisation .............................50
Player, CD MP3 ..................291, 292
Port, USB ........................... 115, 293
Priming the fuel system ..............181
Protecting
children ..... 126, 129, 131-133, 143
Puncture .....................................188
R Radio ..........................263, 264, 287
Radio pre-equipment ..................214
Rear screen (demisting) ...............70
Recharging the battery ...............207
Reduction of electrical load ........209R Reinitialising the electric
windows .....................................93
Reinitialising the remote
control ..................................84, 85
Remote control .................80, 82, 86
Removable screen
(snow shield) ............................210
Removing a wheel ......................195
Removing the mat ......................120
Repair kit, puncture ....................188
Replacing bulbs ..................197, 201
Replacing fuses ..........................203
Replacing the air fi lter ................186
Replacing the oil fi lter .................186
Replacing the particle
emission fi lter ...........................186
Replacing the passenger
compartment fi lter ....................186
Replacing wiper blades ...... 110, 209
Resetting the service indicator .....46
Resetting the trip recorder ............48
Rev counter .............................28-32
Reversing lamps ........................201
Risk areas (update) ....................242
Roof bars ....................................210
Roof blind .....................................95
Routine checks ...................186, 187
Running out of fuel (Diesel) ........181
S Safety for children ................93, 134
Satellite navigation system ...........56
Screen, colour and
mapping ...............56, 57, 235, 274
Screen,
monochrome ........51, 53, 286, 310
Screen, multifunction (with audio
equipment) .............51, 53, 56, 286
