jump start Citroen C4 2016 2.G Owner's Manual

266
C4-2_en_Chap08_en-cas-de-panne_ed02-2015
When your vehicle's battery is discharged, the engine   can   be   started   using   a   slave   battery
(

external   or   on   another   vehicle)   and   jump   lead
c

ables.
Starting using another
battery
First check that the slave battery has a n ominal   voltage   of   12   V   and   a   capacity
a

t   least   equal   to   that   of   the   discharged
b

attery.
Do
  not   try   to   start   the   engine   by
c

onnecting   a   battery   charger.
Do
  not   disconnect   the   (+)   terminal   when
t

he   engine   is   running. F

S
tart   the   engine   of   the   vehicle   with   the
g

ood   battery   and   leave   it   running   for   a   few
m

inutes.
F
O
perate   the   starter   on   the   broken   down
v

ehicle   and   let   the   engine   run. I
f   the   engine   does   not   start   straight   away,  s
witch   off   the   ignition   and   wait   a   few
m

oments   before   trying   again.
F

R
emove   the   plastic   cover   from
the
  (+)   terminal,   if   your   vehicle   has   one.
F

C
onnect the red cable to the positive
terminal
  (+)   of   the   flat   battery   A, then to the
positive
  terminal   (+)   of   the   slave   battery   B.
F

C
onnect   one   end   of   the   green   or   black
c

able   to   the   negative   terminal   (-)   of   the
s

lave battery B   (or   earth   point   on   the   other
v

ehicle).
F

C
onnect
t
he
o
ther
e
nd
o
f
t
he
g
reen
o
r
b
lack
c

able to the earth point C   on   the   broken
d

own   vehicle   (or   on   the   engine   mounting).F

W
ait   until   the   engine   returns   to   idle   then
d

isconnect   the   jump   lead   cables   in   the
r

everse
 o
rder.
F

R
efit   the   plastic   cover   to   the   (+)   terminal,   if
y

our   vehicle   has   one.
In the event of a breakdown
