turn signal Citroen C4 2016 2.G Owner's Manual

22
C4-2_en_Chap01_instruments-de-bord_ed02-2015
Presence of
water in the
Diesel fuel**fixed.
The   Diesel   fuel   filter   contains   water. Risk   of   damage   to   the   injection   system   on   Diesel  e
ngines.
Contact
  a   CITROËN   dealer   or   a   qualified   workshop
w

ithout   delay.
Particle filter
(Diesel) fixed,
 a

ccompanied
 b

y   an   audible   signal
m

essage   on   the   risk
o

f   blockage   of   the
p

article   filter.This indicates that the particle filter is
starting
  to   become   saturated.As
  soon   as   driving   conditions   allow,   regenerate   the
f

ilter   by   driving   at   a   speed   of   at   least   35   mph   (60   km/h)
u

ntil   the   warning   lamp   goes   off.
fixed,
  accompanied   by
 a

n   audible   signal   and
 a

nd   a   message   that   the
 par

ticle filter additive
level
  is   too   low.This indicates the low level of the
additive
 r

eservoir.Have the reservoir topped up as soon as possible by a
CITROËN
  dealer   or   a   qualified   workshop.
Warning
/indicator lampis on Cause Action/Observations
Airbags temporarily. This   lamp   comes   on   for   a
f

ew seconds when you turn on the
ignition,   then   goes   off.
This   lamp   should   go   off   when   the   engine   is   started.
If   it   does   not   go   off,   contact   a   CITROËN   dealer   or   a
q

ualified
 w
orkshop.
fixed. One   of   the   airbag   or   seat   belt
p

retensioner   systems   has   a   fault.
Have   it   checked   by   a   CITROËN   dealer   or   a   qualified
w

orkshop.
**

Only

on   the   type   1   instrument   panel.
Instruments

24
C4-2_en_Chap01_instruments-de-bord_ed02-2015
Warning/indicator lampis on Cause Action/Observations
+
+ SCR emissions
control system

(BlueHDi Diesel) fixed,
  on   switching   on
t

he   ignition,   associated
w

ith the SERVICE and
engine
  diagnostic   warning
l

amps,   accompanied   by
a

n   audible   signal   and   a
m

essage.A
  fault   with   the   SCR   emissions
c

ontrol   system   has   been   detected.This
  alert   disappears   once   the   exhaust   emissions
r

eturn   to   normal   levels.
flashing,
  on   switching   on
t

he   ignition,   associated
w

ith the SERVICE and
engine
  diagnostic   warning
l

amps,   accompanied   by
a

n   audible   signal   and   a
m

essage   indicating   the
r

emaining
 d
riving
 r
ange.After
  confirmation   of   the   fault   with   the
e

missions   control   system,   you   can
d

rive   for   up   to   650   miles   (1   100   km)
b

efore   the   engine   starting   inhibition
s

ystem   is   triggered.Contact
  a   CITROËN   dealer   or   a   qualified
w

orkshop   without delay, to avoid a breakdown .
flashing,
  on   switching   on
t

he   ignition,   associated
w

ith the SERVICE and
engine
  diagnostic   warning
l

amps,   accompanied   by
a

n   audible   signal   and   a
m

essage.You
  have   exceeded   the   authorised
d

riving   limit   following   confirmation
o

f   a   fault   with   the   emissions   control
s

ystem:   the   engine   starting   inhibition
s

ystem   prevents   starting   of   the
e

ngine.To
  be   able   to   start   the   engine,   you   must call on a
CITROËN
  dealer   or   a   qualified   workshop.
Instruments

25
C4-2_en_Chap01_instruments-de-bord_ed02-2015
Operation indicator lamps
If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.
I t   may   be   accompanied   by   an   audible   signal   and   a   message   in   the   screen.
Warning /indicator lampis on Cause Action/Observations
Left-hand
direction indicatorflashing with buzzer.The   lighting   stalk   is   pushed   down.
Right-hand
direction indicatorflashing with buzzer.The   lighting   stalk   is   pushed   up.
Hazard warning
lamps flashing
  with   audible
s

ignal. The
  hazard   warning   lamps   switch,
 l

ocated on the dashboard, has been
operated. The
  left-hand   and   right-hand   direction   indicators   and
t

heir   associated   indicator   lamps   flash   simultaneously.
Sidelamps fixed. The
  lighting   stalk   is   in   the
"

Sidelamps"
 p
osition.
Dipped beam
headlamps fixed.
The
  lighting   stalk   is   in   the   "Dipped
b

eam   headlamps"   position   or   in   the
"

AUTO"   position   in   conditions   of   low
l

ight.
Main beam
headlamps fixed.
The
  lighting   stalk   is   pulled   towards
yo

u. Pull
  the   stalk   again   to   return   to   dipped   beam
h

eadlamps.
Front foglamps fixed. The
  front   foglamps   are   switched   on
u

sing   the   ring   on   the   lighting   control
st

alk. Turn
  the   ring   on   the   lighting   control   stalk   rear ward
t

wice   to   switch   off   the   front   foglamps.
Rear foglamps fixed. The
  rear   foglamps   are   on.Turn
  the   ring   on   the   stalk   rear ward   to   switch   off   the
r

ear
 fo
glamps.
1
Instruments

66
C4-2_en_Chap02_ouvertures_ed02-2015
Locking the passenger doors
F Open  the   doors.
F  O n   the   rear   doors,   check   that   the   child   lock
i

s   not   on.
For
  more   information   on   the   child   lock,   refer   to
t

he   corresponding   section.
F

R
emove   the   black   cap,   located   on   the   edge
o

f   the   door,   using   the   integral   key.
F

I
nsert   the   integral   key   in   the   socket   without
f

orcing   it,   then   without   turning   it,   move   the
l

atch sideways towards the inside of the
d o o r.
F

R
emove   the   integral   key   and   refit   the   cap.
F

C
lose   the   doors   and   check   that   the   vehicle
h

as   locked   correctly   from   the   outside.
Unlocking the passenger doors
F Pull  the   interior   door   opening   control.
Changing the battery
Battery ref.: CR2032 / 3 volts.
B attery   replacement   is   signalled   by   the   display
o

f   a   message.
F

U
nclip   the   cover   using   a   small   screwdriver
a

t   the   cutout.
F

L
ift   off   the   cover.
F

R
emove   the   flat   battery   from   its   location.
F

F
it the new battery into its location
observing
  the   original   direction   of   fitment.
F

C
lip   the   cover   onto   the   casing.
Access

127
C4-2_en_Chap04_eclairage-et-visibilite_ed02-2015
In good or rainy weather, by both day and   night,   the   front   foglamps   and   the
r

ear   foglamps   are   prohibited.   In   these
s

ituations,   the   power   of   their   beams
m

ay   dazzle   other   drivers.   They   should
o

nly   be   used   in   fog   or   falling   snow.
In these weather conditions, you should
switch
  on   the   foglamps   and   dipped
b

eam   headlamps   manually,   as   the
s

unshine   sensor   may   detect   sufficient
l

ight.
Do
  not   forget   to   switch   off   the   front   and
r

ear   foglamps   when   they   are   no   longer
n

ecessary.Switching off the lighting when
switching off the ignition
When the ignition is switched off, all of the lamps   switch   off   immediately,   except   for t

he   dipped   beam   headlamps   if   automatic
 g

uide-me-home   lighting   is   activated.
Switching on the lighting
when switching on the
ignition
To reactivate the lighting control stalk, turn   the   ring   A to position "0"  -   lighting
o

ff,   then   to   the   position   of   your   choice.
When
  the   driver's   door   is   opened,   a
t

emporary   audible   signal   warns   you   that
t

he   vehicle's   lighting   is   on.
They
  switch   off   automatically   after   a
p

eriod which depends on the state of
charge
  of   the   battery   (entry   to   energy
ec

onomy
 mo
de).
4
Lighting and visibility

128
C4-2_en_Chap04_eclairage-et-visibilite_ed02-2015
Parking lamps
F Depending  on   version,   within   one   minute  o
f   switching   off   the   ignition,   operate   the
l

ighting   control   stalk   up   or   down   depending
o

n   the   traffic   side   (for   example:   when
p

arking   on   the   left;   lighting   control   stalk
u

pwards;   the   right   hand   sidelamps   are   on).
This
  is   confirmed   by   an   audible   signal   and
i

llumination   of   the   corresponding   direction
i

ndicator   warning   lamp   in   the   instrument   panel.
To
  switch   off   the   parking   lamps,   return   the
l

ighting   control   stalk   to   the   central   position.
Manual guide-me-home
lighting
The temporary illumination of the dipped beam headlamps   after   the   vehicle's   ignition   has   been
s

witched   off   makes   the   driver's   exit   easier
w

hen   the   light   is   poor.
Switching on
F With  the   ignition   off,   "flash"   the   headlamps  u
sing   the   lighting   stalk.
F

A
  further   "headlamp   flash"   switches   the
f

unction   off.
Switching off
The manual guide-me-home lighting switches off   automatically   after   a   set   time.Side
  markers   for   the   vehicle   by   illumination   of
t

he   sidelamps   on   the   traffic   side   only.
Daytime running lamps
Daytime lighting which comes on automatically w
hen   the   engine   is   started   making   the   vehicle
m

ore   visible   to   other   users.
This
  function   is   assured   by   dedicated   lamps.
Lighting and visibility

129
C4-2_en_Chap04_eclairage-et-visibilite_ed02-2015
Automatic illumination of
headlamps
The sidelamps and dipped beam headlamps are   switched   on   automatically,   without   any
a

ction on the part of the driver, when a low level
of
  external   light   is   detected   or   in   certain   cases
o

f   activation   of   the   windscreen   wipers.
As
  soon   as   the   brightness   returns   to   an
a

dequate   level   or   after   the   windscreen   wipers
a

re   switched   off,   these   lamps   are   switched   off
a

utomatically   and   the   daytime   running   lamps
c

ome   on.
Activation
F Turn   ring   A to the "AUTO"  position.   The  a
ctivation   of   the   function   is   confirmed   by
t

he   display   of   a   message.
Deactivation
F Turn  ring   A to a position other than
"AUTO" .
  The   deactivation   of   the   function   is
c

onfirmed   by   the   display   of   a   message.
Operating fault
In the event of a fault with the
sunshine  sensor,   the   lighting   come
o

n,   this   warning   lamp   is   displayed
o

n   the   instrument   panel   and/or   a
m

essage   appears   in   the   screen,
a

ccompanied   by   an   audible   signal.
Contact
  a   CITROËN   or   a   qualified
w

orkshop   workshop.
In

fog   or   snow,   the   sunshine   sensor
m

ay

detect   sufficient   light.   Therefore,
t

he

lighting   will   not   come   on
au

tomatically.
Do not cover the sunshine sensor,
coupled with the rain sensor and
located in the centre of the windscreen
behind
  the   rear   view   mirror;   the
a

ssociated   functions   would   no   longer
be c

ontrolled.
4
Lighting and visibility

176
C4-2_en_Chap06_conduite_ed02-2015
With the vehicle stationary, to apply the parking brake   whether   the   engine   is   running   or   off,   pull
control lever A .
The
  application   of   the   parking   brake   is
c

onfirmed   by:
-
 i

llumination
 o
f
 t
he
 b
raking
 w
arning
 l

amp   and   of   the   P

warning   lamp   in
 t

he control lever A ,
-

d
isplay   of   the   message   "Parking
b

rake   on".
When
  the   driver’s   door   is   opened   with   the
e

ngine   running,   a   message   is   displayed
a

ccompanied   by   an   audible   signal   if   the   parking
b

rake   has   not   been   applied,   except   in   the   case
o

f   an   automatic   gearbox   with   the   gear   selector
i

n position P .
Before
  leaving   the   vehicle,   ensure
 t

hat   parking   brake   warning   lamp   in   the
 i

nstrument   panel   is   on   fixed,   not   flashing.
Manual applicationManual release
The full application of the parking brake is c
onfirmed   by:
-

t
he   braking   warning   lamp   and
t

he P   warning   lamp   in   the   control
l

ever A   going   off,
-

d
isplay   of   the   message   "Parking
b

rake   off ".
If you pull control lever A  without  pressing t
he   brake   pedal,   the   parking   brake   will n

ot   be   released   and   a   warning   lamp   will
 c

ome   on   in   the   instrument   panel.
With the ignition on or the engine running, to release   the   parking   brake,   press on the brake
pedal or the accelerator, pull then release
control A . If
  necessary,   you   can   make   a   maximum
application

of   the   parking   brake.   This   is
o

btained
 by m
eans
 o
f
 a long
pull
on the control
lever A ,   until   you   see   the   message   "Parking
b

rake   on   maximum"   and   a   beep   is   heard.
In   the   case   of   towing,   a   loaded   vehicle   or
p

arking   on   a   gradient,   make   a   maximum
a

pplication   of   the   parking   brake   then   turn   the
f

ront   wheels   towards   the   pavement   and   engage
a

  gear   when   you   park.
After
  a   maximum   application,   the   release   time
w

ill   be   longer.
Maximum application
Maximum application is essential:
- i n   the   case   of   a   vehicle   towing   a   caravan
o

r   a   trailer,   if   the   automatic   functions   are
a

ctivated   but   you   are   applying   the   parking
b

rake
 m
anually,
-

w
hen   the   gradient   you   are   parked   on   may
v

ary   (e.g.   on   a   ferry,   on   a   lorry,   during
tow

ing).
Driving

177
C4-2_en_Chap06_conduite_ed02-2015
Automatic release
Full release of the parking brake is confirmed by:
-

t
he   braking   warning   lamp   and
t

he P   warning   lamp   in   the   control
l

ever A   going   off,
-

d
isplay   of   the   message   "Parking
b

rake   off ".
Automatic application,
engine off
- illumination of t he b raking w arning l
amp   and   of   the   P  warning   lamp   in t

he control lever A ,
-

d
isplay   of   the   message   "Parking
b

rake   on".
The

application   of   the   parking   brake   is
c

onfirmed   by:
With

the

vehicle   stationary,   the   parking   brake
i

s automatically applied when the engine is
switched off .
Before   leaving   the   vehicle,   ensure
t

hat   parking   brake   warning   lamp   in
t

he
  instrument   panel   is   on   fixed   (not
f

lashing).
Never leave a child alone inside the
vehicle
  with   the   ignition   on,   as   they
c

ould   release   the   parking   brake.
When stationary, with the engine running, do not press the accelerator pedal unnecessarily,
as
  you   may   release   the   parking   brake.
In the case of towing, a loaded vehicle or   parking   on   a   gradient,   turn   the   front
w

heels   towards   the   pavement   and
e

ngage   a   gear   when   you   park.The
  electric   parking   brake   releases
automatically and progressively when you
press   the   accelerator:
F
M
anual gearbox:
press down fully on the
clutch   pedal,   engage   first   gear   or   reverse,
p

ress on the accelerator pedal and
move off.
F
A
utomatic gearbox
:   select   position   D
, M
or R   then   press   the   accelerator   pedal.
Immobilising the vehicle,
engine running
- illumination
  of   the   braking  w
arning   lamp   and   the   P   warning
l

amp   in   the   control   lever   A,
-

d
isplay   of   the   message   "Parking
b

rake   on".
When

the
  driver’s   door   is   opened,   a   message   is
d

isplayed
  accompanied   by   an   audible   signal,   if
t

he

parking   brake   has   not   been   applied,   except
i

n

the

case   of   an   automatic   gearbox   with   the
g

ear

selector   in   position   P.
The

application   of   the   parking   brake   is
c

onfirmed   by:
With

the

engine   running   and   the   vehicle
s

tationary,   in   order   to   immobilise   the   vehicle
i

t is essential to manually

apply   the   parking
b

rake

by

pulling
control lever A .
Before   leaving   the   vehicle,   ensure
 t

hat   parking   brake   warning   lamp   in   the
 i

nstrument   panel   is   on   fixed,   not   flashing.
6
Driving

183
C4-2_en_Chap06_conduite_ed02-2015
Moving off
If position N is engaged inadvertently while   driving,   allow   the   engine   to
r

eturn   to   idle   then   engage   position   D to
accelerate. F

Sel
ect position D for automatic
 c
hanging
 o

f   the   six   gears.
The   gearbox   then   operates   in   auto-adaptive
m

ode,   without   any   intervention   on   the   part
o

f   the   driver.   It   continuously   selects   the   most
s

uitable   gear   according   to   the   style   of   driving,  t
he profile of the road and the load in the
vehicle.
For
  maximum   acceleration   without   touching
t

he selector, press the accelerator pedal down
fully
  (kick   down).   The   gearbox   changes   down
a

utomatically   or   maintains   the   gear   selected
u

ntil   the   maximum   engine   speed   is   reached.
On
  braking,   the   gearbox   changes   down
a

utomatically   to   provide   effective   engine
b

raking.
If you release the accelerator sharply, the
gearbox
  will   not   change   to   a   higher   gear   for
s

afety   reasons.
When
  the   engine   is   running   at   idle,   with
t

he   brakes   released,   if   position   R,
D
or
M   is   selected,   the   vehicle   moves
e

ven   without   the   accelerator   being
p

ressed.
Never leave children unsupervised in
the
  vehicle   when   the   engine   is   running.
When
  carrying   out   maintenance   with
t

he   engine   running,   apply   the   parking
b

rake   and   select   position   P.
Never select position N while the
vehicle
  is   moving.
Never select positions P or R unless the
vehicle
  is   completely   stationary.
If
  the   parking   brake   does   not   release
a

utomatically,   check   that   the   front   doors
a

re   fully   closed.
F

W

ith

your

foot

on

the

brake,

select

p

osition


P or N
.
F

S

tart

the

engine.
If this procedure is not followed, an audible
signal

is

heard,

accompanied

by

a

message

in

t

he

instrument

panel

screen.
F
 W
ith

the

engine

running,

press

the

brake
 ped
al.
F

Sel

ect position R , D or M.
Automatic operation
The parking brake is released manually, the v
ehicle   moves   off.
If
  the   parking   brake   is   on   and   automatic   mode
i

s   activated,   accelerate   progressively.
If you do not press the brake pedal when trying   to   move   the   gear   selector   out o

f position P ,
  this   warning   lamp   or   this
 s

ymbol
 ap

pears
 in t
he
 in
strument
 pan
el
 a
ccompanied
 b

y

a

message,   flashing   of   the   P

symbol,   the   display   of
 a


message
  and   an   audible   signal.
F Check  that   the   display   in   the   instrument  p
anel   agrees   with   the   position   engaged.
F

G
radually   release   the   brake   pedal.
6
Driving
