Contents
Direction indicators 147
Hazard warning lamps 147
Horn 147
Braking assistance systems 148
Trajectory control systems 150
Front seat belts 152
Airbags 156
Child seats 161
Deactivating the passenger's front airbag 163
ISOFIX child seats 170
Child lock 176
Safety
Temporary puncture repair kit 177
Changing a wheel 181
Snow chains 187
Changing a bulb 188
Changing a fuse 194
12 V battery 200
Automatic power cut-off to accessories 203
Changing a wiper blade 203
Recovering the vehicle 204
Towing a trailer 207
Fitting roof bars 209
Accessories 210
Practical information
Bonnet 213
Petrol engines 214
Diesel engines 215
Fuel tank 216
Running out of fuel (Diesel) 218
Checking levels 219
Checks 222
Checks
Petrol engines 225
Petrol weights 226
Diesel engines 232
Diesel weights 233
Dimensions 239
Identifi cation markings 241
Te c h n i c a l d a t a
Bluetooth® telephone
with voice recognition 243
TOUCH SCREEN AUDIO -TELEMATIC
system 255
TOUCH SCREEN AUDIO - CD system 293
AUDIO - CD system 313
Audio and telematics
Alphabetical index
Visual search

8
Familiarisation
Interior


4-wheel drive system with
electronic control *

This system allows the selection of a
transmission mode, according to the driving
conditions.


CVT gearbox

This system offers driving combining a fully
automatic mode and a manual mode.


Digital air conditioning

This automatic air conditioning system maintains
the desired comfort level and adequate air
circulation in the passenger compartment.



Audio and communication
systems
These systems benefit from the following
technologies: radio, CD player, USB player,
Bluetooth system, satellite navigation system
with colour screen, auxiliary sockets.
124 115

Touch screen Audio- CD system


*
Depending on version.
Touch screen Audio-Telematic system


Audio- CD system

313
293
255
94

.
9
Familiarisation
Instruments and controls




1.
Door mirror controls.
Electric window controls.

2.
Bonnet release.

3.
Fusebox.

4.
Manual headlamp height adjustment.
Side switch panel.

5.
Side adjustable air vent.

6.
Instrument panel.

7.
Lighting and direction indicator control
stalk.

8.
Steering wheel adjustment control.

9.
Controls for Bluetooth system or telephone.

10.
Controls for Audio-CD, touch screen
audio- CD and touch screen Audio-
telematic systems.

11.
Driver's airbag.
Horn.

12 .
Cruise control switches.

13.
Parking brake.

195
7
Practical information

Dashboard fuses

The fusebox is located in the lower dashboard
(left-hand side).

Access to the fuses



)
Open the cover and remove it completely
by pulling it towards you.

Fuse N°



Rating



Functions




1
*

30 A

Cabin fan.


2



15 A

Brake lamps, third brake lamp.


3



10 A

Rear foglamps.


4



30 A

Windscreen wiper, screenwash.


6



20 A

Central locking, electric door mirrors.


7



15 A

Audio equipment, telematics, USB unit, Bluetooth system.


8



7.5 A

Remote control key, air conditioning control unit, instrument
panel, electric windows, rain and sunshine sensors, alarm,
switch panel, steering mounted controls.


9



15 A

Instrument panel and interior lighting.


10



15 A

Hazard warning lamps


11



15 A

Rear wiper.


12



7.5 A

Instrument panel, multifunction screen, parking sensors,
heated seats, heated rear screen, electric blind, automatic
headlamp adjustment.


13



15 A

Cigarette lighter, accessory socket.


15



20 A

Electric blind.


16



10 A

Door mirrors, audio equipment.

243

SPEAK
Press this button to activate voice recognition (" Listening
" is displayed).
During a voice recognition, press this button briefl y to put this voice recognition on hold.
Make a long press on this button to deactivate voice recognition.
Press this button briefl y to activate voice recognition, even during a call.










ANSWER A CALL
Press this button to accept an incoming call.
In the event of a 2
nd
incoming call, press
to put the 1 st call on hold and speak to the
second caller.
In this case, press briefl y to switch from one
call to the other.
To establish a three-way conversation,
press on SPEAK to change from voice
recognition and say " Incorporate the call
".

END CALL
Press this button to reject an incoming call.
During a conversation, press this button to
end the call.





BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION

244




BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION

By default, the voice recognition system is in English.

Press this button.
Say " Setup
".

Say " Language
".

Say the language of your choice in English, example: say
" French
" for French.

Say " Ye s
" to start the change of language process
Say " No
" to return to steps 4 to 7.
The system says " Select a language: English, Spanish, French,
German or Italian
".

The system then says " French selected. Is this correct?
"

The system repeats the language chosen and completes the
change of language process.

If you do not start the training procedure within around 3 minutes of
pressing SPEAK, the process is cancelled.
If you press SPEAK within 5 seconds following the play of a voice
command, this command is saved again.














What is the Bluetooth
®
hands-free telephone with voice
recognition?
The system uses wireless communication technology known as
Bluetooth
®
which allows you to make hands-free telephone calls in
your vehicle via your Bluetooth ® compatible mobile telephone.
You can make telephone calls using a microphone located in
the courtesy lamp, making use of the simple steering mounted
controls or by the voice recognition function with voice commands.
Five languages are available: English (the default), Spanish,
French, German and Italian.










Change the voice command language

245




BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION








Training the user's voice


You can use the user voice training function to create a voice model
for one person per language.
The characteristics of your voice and your pronunciation are saved
in this model to provide the best voice recognition.
The vehicle must be stationary with the parking brake applied.
Switch off your telephone during the operation to avoid any
interruption.

Press this button.
The system says the fi rst of 45 standard phrases.

Say " Word training
".
When you are ready to start, press and
hold this button.

Repeat each of the phrases in the table on the following
page.
The system saves your voice and moves on to the next
command.
Continue the process until all of the phrases have been
saved.

An explanation message is given.
After playing all the voice commands, the system says " The word

training
is complete
" and ends the process.

If you do not start the programming process within approximately
3 minutes after pressing the SPEAK button, the process is
cancelled.
If you press the SPEAK button within 5 seconds of the play of a
voice command, this command is saved again.

246




BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION

Voice training commands

1 # 790 (for # = "Hash")
2 * 671 (for * = "Star")
3 212 - 4 903
4 235 - 3 494
5 315- 5 657
6 456 - 7 930
7 793 - 5 462
8 794 - 1 826
9 826 - 3 145
10 962 - 7 305
11 (531) 742 - 9 860
12 (632) 807 - 4 591
13 (800) 222 - 5 015
14 (888) 555 - 1 212
15 0 123 456 789 16 55 66 77 88 99
17 44 33 22 11 00
18 Call 293 - 5804
19 Call * 350
20 Call 1 (234) 567 - 8 901
21 Dial 639 - 1542
22 Dial # 780
23 Dial (987) 654 - 3210
24 1058# 3794# Send
25 27643# 4321# Send
26 Cancel
27 Continue
28 Emergency number
29 Clear all
30 Help 31 Home, Work, Mobile, Pager
32 List of names
33 No
34 Phone book: Delete

35 Phone book: New entry
36 Previous
37 Phone book: Clear all
38 Redial
39 Repeat the training
40 Confi gure the confi rmation requests
41 Confi gure the language
42 Confi gure the matching options
43 Match a telephone
44 Transfer the call
45 Yes

247




BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION

For reasons of safety and because the sustained attention of the
driver is needed, operations of matching a Bluetooth ® mobile phone
with the audio system's hands-free function must be done with the
vehicle stationary
.

The systems says " Please say the 4 digits of a pairing cod

e
".

Press this button.

The system confi rms the validity of the number spoken,
answer " Ye s
".
Say " No
" to return to step 7.

Say " Pairing options
".










Pairing a Bluetooth ®
telephone
First connection


Say " Pair a telephone
".

Say " Confi gure
".
The system can register up to 7 Bluetooth
®
compatible mobile
telephones.
The telephone which has the highest level of priority is connected
automatically.

The system says " Do you wish to
pair
a telephone, delete a
telephone or obtain the list of paired telephones?
".
Say a 4-digit number which will be recorded as the pairing
code.

Remember this pairing code as you must enter it in the telephone in
one of the following steps of the matching procedure.

248

Consult your mobile telephone's user manual and enter
the pairing code recorded in step 7 in the telephone.





BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION

The system says " Start the
pairing
procedure on the telephone.
Consult the instructions in the telephone manual
".

If the code is incorrect, the system locks. To clear the code:


- check that the telephone's voice recognition is not activated,

- with the ignition on and the audio system active, press the END
CALL button for 2 seconds, 3 times in succession.


When it detects a Bluetooth
®
compatible mobile telephone,
the system says " Please say the name of the telephone after
the beep
".

After the audible signal, allocate a name to the telephone
by saying the name of your choice.
The system says " Allocate an order of priority between 1 and 7.
One is the highest level of priority
".

Give a number between 1 and 7 to establish the level of
priority of the mobile telephone.

The system says and confi rms the " name of the telephone
" and
the " number
" of its priority.

Answer " Ye s
".
Say " No
" to return to step 13.

The systems says " Pairing complete
" then emits an audible signal
and deactivates the voice recognition.
The services available depend on the network, the SIM card and the compatibility of the Bluetooth
®
telephone used. Check in your telephone
user manual and with your service provider for the services you have access to.

If the system does not detect the Bluetooth
®
compatible mobile
telephone, the matching process stops ands is accompanied by an
audible signal.
If you select a level of priority which has already been allocated to
another telephone, the system asks you if you wish to replace this
level of priority.
