Familiarisation
Driving safely


Starting the engine

With the electronic key
)Place the gear selector lever at Nfor
vehicles with an electronic gearbox, Por Nfor vehicles with an automatic gearbox or neutral for vehicles with a manual gearbox. )Inser t the electronic key in the reader.)Press the brake pedal on vehicles withelectronic gearbox or depress the clutchpedal fully on vehicles with manualgearbox.
)Press the "START/STOP" button briefly.
The steering column unlocks and theengine star ts.
With the Keyless Entry and
Starting system
) Place the gear selector lever at N
for
vehicles with an electronic gearbox, P or Nfor vehicles with an automatic gearbox or
neutral for vehicles with a manual gearbox) With the electronic key inside the vehicle(it is not necessary to place it in thereader), press the brake pedal on vehicles
with electronic gearbox or depress the
clutch pedal fully on vehicles with manual gearbox.) Press the "STA R T/STOP" button briefly.The steering column unlocks and the engine star ts.


Switching off the engine


With the electronic key
)
Immobilise the vehicle. )
Place the gear selector lever at Nfor
vehicles with an electronic gearbox, Por Nfor vehicles with an automatic gearbox or neutral for vehicles with a manual gearbox. ) Press the "STA R T/STOP" button briefly.
The engine stops and the steering column
locks. ) Remove the electronic key from the reader.


With the Keyless Entry and
Starting system
) Immobilise the vehicle. )
Place the gear selector lever at Nfor
vehicles with an electronic gearbox, Por Nfor vehicles with an automatic gearbox or neutral for vehicles with a manual gearbox. ) With the electronic key inside the vehicle, press the "STA R T/STOP" button.
The engine stops and the steering column
l
ocks. 13
6
138
135137

Maintain pressure on the brake pedal until the engine star ts.

20
Familiarisation
Driving safely
Electric parking brake
Manual application / release
Automatic application / release


Before leaving the vehicle, check that
the brake warning lamp in the instrumentpanel and the Pwarning lamp in the control lever are on fixed (not flashing).
141
If this warning lamp is on in the instrument
panel, the automatic application /
release is deactivated
; apply and
re
lease the parking brake manually.
The parking brake is released automatically
and progressively with the movement of the
vehicle.
With the vehicle at rest, the parking brake
is applied automaticall
y on switching off the
ignition by pressing the START/STOP button.
First ensure that the engine is running and the driver's door is properly closed.
Manual applicationof the parking brake is possible by briefly pullingthe control lever.
With the ignition on or the engine running, press the brake pedal and while maintaining
this pressure, briefly pushthe control lever torelease
the parking brake.

.
21
Familiarisation
Driving safely


6-speed electronic gearbox
s
ystem

Gear selector positions
RReverse.NNeutral. AAutomated mode. M
Manual mode
Using the steering-mounted control paddles "A"Aand " B":


- changing gear in manual mode,

- temporarily taking control in automated mode.


Starting
)Check that the gear selector is in position N.)Press firmly on the brake pedal and press
the "STA R T/STOP" button.
15
0

Automatic gearbox


Gear selector positions
P
Park.RReverse.NNeutral. DAutomatic mode.M
Manual mode.
Using the steering-mounted control paddles "A
" Aand "B
":


- changing gear in manual mode,

- temporarily taking control in automaticmode.


Starting
)Check that the gear selector is in position Por N . )
Press firmly on the brake pedal and press
the "STA R T/STOP" button".
15
4

To come out of position P
, press the brakePpedal before moving the gear selector.

1
43
Monitoring
Deactivation indicator lamps
If one of the following indicator lamps comes on, this confirms that the corresponding system has been switched off intentionally.
This is may be accompanied by an audible signal and the display of a message.

Warning / indicator lampStateCauseAction / Observations
Passenger's airbag system
fixed. The control switch, located at the
right hand end of the dashboard is set
to the OFFposition.
The passen
ger's front airbag is deactivated.
Set the control to the "ON"position to activate the passenger's front airbag.
In this case, do not fit a child seat in the rear ward-
facing position.
Dynamic stability control(DSC/ASR)R

fixed. The button, located on the centre console, is pressed. Its indicator lamp is on.
The DSC/ASR is deactivated.
DSC: dynamic stability control.
ASR: anti-slip regulation. Press the button to activate the D
SC/ASR. Its indicator
lamp goes off.
The DSC/ASR system is activated automatically when
the vehicle is started.
If deactivated, the system is reactivated automaticallyfrom around 30 mph (50 km/h).
Stop & Start
fixed. The Stop & Star t has been
deactivated. R
eactivate the function via the " Driving assistance"
menu.

1
47
Monitoring
Braking
fixed. The braking system fluid level has
dropped significantly. You must stop as soon as it is safe to do so.
Top up with brake fluid listed by CITROËN.
If the problem persists, have the system checked by a
CITROËN dealer or a qualified workshop.

+
fixed
, associated
with the ABS warninglamp. Th
e electronic brake force distribution(EBFD) system has a fault. You must stop as soon as it is safe to do so.
Have it checked by a CITROËN dealer or a qualified
workshop.
Warning / indicator lampStateCauseAction / Observations
Anti-lockBraking System(ABS)
fixed. The anti-lock braking system has a fault. The vehicle retains conventional braking.
Drive carefully at reduced speed and contact aCITROËN dealer or a qualified workshop without
delay.
Dynamic stability control(DSC/ASR)
flashing. The DSC/ASR regulation is
operating. The system optimises traction and improves the
directional stability of the vehicle.

fixed. Unless it has been deactivated (button pressed and its indicator lamp
on) the DSC/ASR system has a fault. Have it checked b
y a CITROËN or a qualified
workshop.
Engine autodiagnosissystem
flashing.The engine management system hasa fault. Risk of destruction of the catalytic converter.
Have it checked by a CITROËN dealer or a qualified
workshop.

fix
ed. The emission control system has a
fault.

The warning lamp should go off when the engine is started.
If it does not
go off, contact a CITROËN dealer or qualified
workshop without delay.

60
Monitoring
Tr ip computer, a few definitions

Range
(miles or km)
The distance which can still be
travelled with the fuel remainingin the tank (related to the average fuel consumption over the last few miles (kilometres) travelled).


This value may vary following a changein the style of driving or the relief,resulting in a significant change in thecurrent fuel consumption.
When the ran
ge falls below 20 miles (30 km),
dashes are displayed. After filling with at least 5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (10 0 km).

If dashes are displayed continuously while driving in place of the digits,
contact a CITROËN dealer or a qualified workshop.
This function is only displayed from 20 mph (30 km/h).
Current fuel consumption
(mpg or l/100 km or km/l) Calculated over the last few seconds.
Average fuel consumption
(mpg or l/100 km or km/l) Calculated since the last trip computer reset.
Average speed
(mph or km/h)Calculated since the last trip computer reset.


Distance travelled
(miles or km)
Calculated since the last trip
computer reset.

Stop & Start time counter
(minutes / seconds or hours /
minutes)
If your vehicle is fitted with Stop & Star t, a timecounter calculates the time spent in STOP mode during a journey.
It resets to zero every time the ignition isswitched on with the STA R T/STOP button.

77
2
Access

Motorised opening


Unlocking and opening the tailgate with the electronic key /
remote control

Unlocking and opening the tailgate with the Keyless Entryand Starting system

Openin
g the tailgate
)
Make a long press on this button.
)Press button Aon the tailgate, with theelectronic key in the area of coverage.



When selective locking is activated, the electronic key must be near the rear of the vehicle.


By default, the tailgate openscompletely or alternatively to the
memorised position.

)After complete unlocking of the vehicle, press control Aon the tailgate.
The instruction is confirmed by an audiblesignal.
Motorised closing
There are two possibilities:)
Press and release the exterior
control A.or
- by pressing one of thesetwo buttons,

The motorised tailgate has an anti-pinch system that interrupts closing if it encounters an obstacle.
Operation of the tailgate can be interrupted at any time:

After interruption of an operation,another press on one of the controlsresumes the movement, with the exception of a press on the remote control button, which only allows opening.

or
- by pressing the exterior control A.
Memorising an opening
position

Where height is restricted (garage with a low
ceiling, ...) it is possible to limit and memorise
the opening angle of the tailgate.
Thi
s memorisation is done as follows:


- open the tailgate to the desired position,

- press button
B
or the exterior control A
for more than 3 seconds.
Memorisation of the maximum opening position of the tailgate is confirmed by an audible signal.
To cancel the memorised position:


- stop t
he tailgate in an intermediate position,

- press button B
or the exterior control A
for more than 3 seconds.
)
Press and then release button B.

81
2
Access

Reactivation of the interior volumetric monitoring
)Deactivate the exterior perimeter monitoring by unlocking the vehicle usingthe remote control or the Keyless Entry andStarting system.
The indicator lamp in the button goes off.
)Reactivate the full alarm system by locking
the vehicle using the remote control or the
"Keyless Entry and Star ting" system.
The indicator lamp in the button flashes once
per second again.
Tr iggering of the alarm
This is indicated by sounding of the siren and flashing of the direction indicators for
thirty seconds.
The monitoring functions remain active until
the alarm has been triggered eleven times in
succession.When the vehicle is unlocked using the remotecontrol or the Keyless Entry and Startingsystem, rapid flashing of the indicator lampin the button informs you that the alarm was
triggered during your absence. When the
ignition is switched on, this flashing stops immediately.
Failure of the remote control
To deactivate the monitoring functions:
) Unlock the vehicle using the key (integral
with the remote control) in the driver's door lock. ) Open the door; the alarm is triggered. )
Switch on the ignition; the alarm stops. The
indicator lamp in the button goes off.




Locking the vehicle without
activating the alarm
)
Lock or deadlock the vehicle using the key (integral with the remote control) in thedriver's door lock.




Operating fault


When the ignition is switched on, fixed
illumination of the indicator lamp in the button
indicates a fault in the system.
Have it checked by a CITROËN dealer or a qualified workshop.



Automatic activation *



2 minutes after the last door or the boot is closed, the system is activated automatically. )
To avoid triggering the alarm on enteringthe vehicle, first press the unlocking button on the remote control or unlock the vehicleusing the Keyless Entry and Starting system.

* Accordin
g to country.

89
3
Comfort
)Press the control to obtain the desired lumbar support.




Electric lumbar adjustment
You can deactivate the massage
function at any time by pressing this
switch, its indicator lamp goes off.



DeactivationActivation
Massage function
This function provides the front occupants
with a lumbar massage. It only operates when
the engine is running or in STOP mode of the Stop & Start system.
)
Press this switch.




Adjustment of intensity
Press this button to select one of
the two levels of massage intensityoffered.

Its indicator lamp comes on and the massagefunction is activated for a period of 1 hour.
During this time, massage is performed in6 cycles of 10 minutes (6 minutes of massage followed by 4 minutes break).
After one hour, the function is deactivated, the
indicator lamp goes off.
