11
PRACTICAL INFORMATION
204








VERY COLD CLIMATE SCREEN *


*
According to country.


Fitting



)
Offer up the very cold climate screen
to the front of the lower section of
the front bumper.

)
Press around its edge to engage its
fi xing clips one by one.



Removal



)
Use a screwdriver as a lever to
release each fi xing clip in turn.
Do not forget to remove the very
cold climate screen:


- when the ambient temperature
exceeds 10 °C,

- when towing,

- at speeds above 75 mph
(120 km/h).
Removable protective screen which
prevents the accumulation of snow at
the radiator cooling fan.











FITTING ROOF BARS


For safety reasons and to avoid dam-
aging the roof, it is essential to use the
transverse bars approved for your ve-
hicle.

When fi tting roof bars, use only the four
fi xing points located in the roof frame.
The points are masked by the vehicle
doors when closed.
The roof bar fi xings include a stud to be
fi tted to the hole at each fi xing point.
Observe the fi tting instructions and the
conditions of use in the guide supplied
with the bars.
Maximum authorised weight on
the roof rack, for a loading height
not exceeding 40 cm (with the ex-
ception of bicycle carriers): 55 kg.
As this value is subject to change,
check the maximum load fi gure
given in the guide provide d with
the roof bars.
If the height exceeds 40 cm,
adapt the speed of the vehicle
to the profi le of the road to avoid
damaging the roof bars and the
fi xings on the vehicle.
Be sure to refer to national legis-
lation in order to comply with the
regulations for transporting ob-
jects which are longer than the
vehicle.
