Page 157 of 259
Downloaded from www.Manualslib.com manuals search engine 154
INJECTION
Component (diagr.) Supplier Reference Observations
Diagnostic warning lamp31Incorporated in the dashboard instrument panel.
Central diagnostic socket32In the passenger compartment.
Electronic immobiliser33
Consumption information 34Incorporated in the dashboard instrument panel.
Rev counter35Incorporated in the dashboard instrument panel.
Preheater warning lamp36Incorporated in the dashboard instrument panel.
Pre-postheating unit37NAGARES 960411P
CARTIER 735068
Preheater plugs38CHAMPION CH170
BOSCH0250202032
Cruise control switch39
Automatic gearbox ECU
40
Air conditioning compressor41SANDEN SD7V16
Additional heating by heating
42 a
elements in boiler42 b
Additional heating control
relay43
FEATURES OF BOSCH HDi DIRECT INJECTION SYSTEM
Electrical circuit (continued)
Page 161 of 259
Downloaded from www.Manualslib.com manuals search engine 158
INJECTION
FEATURES OF BOSCH HDi DIRECT INJECTION SYSTEM
Component (diagr.) Supplier Reference Observations
88 way connector. Flash eprom type sequential
Ignition injection ECU1BOSCHEDC 15C2 injection (reprogrammable eprom). Installed in the
ECU compartment.
FIRST3 way black connector. Installed in the front RH
Inertia switch34INERTIA Type 505wheelarch, fixed on the suspension mounting.
SWITCHManual rearming in the event of the cut-out system
being activated.
Injection double relay15BITRON 240 10915 way black connector. Installed in the ECU
compartment.
Battery14VA R TAL2 – 12 volts
400 ampsEngine compartment..
Atmospheric pressure sensor13BOSCHIncorporated in the injection ECU.
Central diagnostic socket36In the passenger compartment.
Diagnostic warning lamp35Incorporated in the dashboard instrument panel.
Vehicle speed sensor10EATON On the gearbox.
Preheater warning lamp40Incorporated in the dashboard instrument panel.
Rev counter39Incorporated in the dashboard instrument panel.
Consumption information 38Incorporated in the dashboard instrument panel.
Engine speed sensor2ELECTRIFIL
Camshaft position sensor3ELECTRIFIL Airgap value : 1,2 mm.
Electrical circuit
Page 166 of 259
Downloaded from www.Manualslib.com manuals search engine 163
INJECTION
FEATURES OF BOSCH HDi DIRECT INJECTION SYSTEM
Component (diagr.) Supplier Reference Observations
88 way connector. Flash eprom type sequential
Ignition injection ECU19BOSCHEDC 15C2 injection (reprogrammable eprom). Installed in the
electronic ECUs compartment.
Injection double relay52BITRON 240 10915 way black connector. Installed in the electronic
ECUs compartment.
Battery51VA R TAL2 – 12 volts
Engine compartment.
400 amps
Atmospheric pressure sensor18BOSCHIncorporated in the injection ECU.
Central diagnostic socket50In the passenger compartment.
Diagnostic warning lamp27Incorporated in the dashboard instrument panel.
Vehicle speed sensor53EATON On the gearbox.
Preheater warning lamp26Incorporated in the dashboard instrument panel.
Rev counter24Incorporated in the dashboard instrument panel.
Trip computer23Incorporated in the dashboard instrument panel.
Engine speed sensor60ELECTRIFIL
Camshaft position sensor61ELECTRIFIL Airgap value : 1,2 mm.
Preheater unit57NAGARES 960411P
CARTIER 51299011
Preheater plug62CHAMPION CH170
BERU 0100226344
Electrical circuit
Page 249 of 259
Downloaded from www.Manualslib.com manuals search engine C5FPOC5CC5FPOC6D
AIR
CONDITIONING
SPECIAL FEATURES : AIR CONDITIONING SYSTEM (R 134.a)
Pollen filter
Remove :
- The trim(1) under the dashboard (driver’s side).
- The cover (2).
- Unclip at «a» and pull out the pollen filter (3).
- Remove the pollen filter(3).
246
