Page 217 of 314
XII
195
T E C H N I C A L D A T A
* The weight of the braked trailer can be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced
by the same amount; warning, towing with a lightly loaded towing vehicle may have an adverse effect on its road holding.
WEIGHTS AND TOWED LOADS (SALOON) in kg
Petrol engines
1.8 litre VTi
16V 127 hp
2 litre 16V
143 hp
B i o fl e x 2 l i t r e
16V 143 hp
1.6 litre 156 hp
3 litre V6 24V
215 hp
G e a r b o x e s Manual Auto. Auto. Manual Auto.
Model codes:
RD...
6FYC RFJF RFJC/FF 5FV-5FN XFVJ
- Unladen weight 1 510 1 583 1 521 1 471 1 725
- Kerb weight 1 585 1 658 1 596 1 546 1 800
- Gross vehicle weight (GVW) 2 015 2 090 2 063 2 065 2 230
- Gross train weight (GTW) 3 315 3 590 3 563 3 565 3 630
- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient 1 300 1 500 1 50 0 1 500 1 400
- Braked trailer * (with load transfer within GTW limit) 1 530 1 720 1 720 1 730 1 650
- Unbraked trailer 750 750 750 750 75 0
- Recommended nose weight 62 69 69 70 66
The GTW and towed load values indicated apply up to a maximum altitude of 1,000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1,000 metres of a ltitude.
The speed of a towing vehicle must not exceed 100 km/h (appro x. 60 mph) (comply with the legislation in force in your
country).
High ambient temperatures may result in a reduction in the pe rformance of the vehicle in order to protect the engine; when
the ambient temperature is higher than 37 °C, limit the we ight towed.
Page 218 of 314
XII
198
T E C H N I C A L D A T A
WEIGHTS AND TOWED LOADS (SALOON) in kg
Diesel engines
1.6 litre HDi
110 hp
2 litre HDi
140 hp
2 litre HDi 163 hp
3 litre V6 HDi
240 hp
G e a r b o x e s Manual Manual Manual Auto. Auto.
Model codes:
RD...
9HZC
9HZC/1
RHF8 RHH-RHE X8ZA
- Unladen weight 1 485 1 608 1 563 1 609 1 766
- Kerb weight 1 560 1 683 1 638 1 684 1 841
- Gross vehicle weight (GVW) 2 045 2 155 2 156 2 190 2 276
- Gross train weight (GTW) 3 145 3 755 3 656 3 290 3 676
- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient 1 100 1 600 1 50 0 1 100 1 400
- Braked trailer * (with load transfer within GTW limit) 1 370 1 820 1 740 1 390 1 650
- Unbraked trailer 750 750 750 750
- Recommended nose weight 55 73 70 57 67
The GTW and towed load values indicated apply up to a maximum altitude of 1,000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1,000 metres of a ltitude.
The speed of a towing vehicle must not exceed 100 km/h (appro x. 60 mph) (comply with the legislation in force in your
country).
High ambient temperatures may result in a reduction in the pe rformance of the vehicle in order to protect the engine; when
the ambient temperature is higher than 37 °C, limit the we ight towed.
* The weight of the braked trailer can be incr
eased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced
by the same amount; warning, towing with a lightly loaded towing vehicle may have an adverse effect on its road holding.
Page 219 of 314
XII
196
T E C H N I C A L D A T A
WEIGHTS AND TOWED LOADS (TOURER) in kg
Petrol engines
1.8 litre VTi
16V 127 hp
2 litre 16V
143 hp
B i o fl e x 2 l i t r e
16V 143 hp
1.6 litre 156 hp
3 litre V6 24V
215 hp
G e a r b o x e s Manual Auto. Manual Manual Auto.
Model codes:
RW...
6FYC RFJF RFJC/FF 5FV-5FN XFVJ
- Unladen weight 1 549 1 619 1 578 1 503 1 761
- Kerb weight 1 624 1 694 1 653 1 578 1 836
- Gross vehicle weight (GVW) 2 154 2 224 2 183 2 167 2 366
- Gross train weight (GTW) 3 454 3 724 3 683 3 667 3 666
- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient 1 300 1 500 1 50 0 1 500 1 300
- Braked trailer * (with load transfer within GTW limit) 1 600 1 800 1 790 1 790 1 600
- Unbraked trailer 750 750 750 750 75 0
- Recommended nose weight 64 72 72 73 68
The GTW and towed load values indicated apply up to a maximum altitude of 1,000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1,000 metres of a ltitude.
The speed of a towing vehicle must not exceed 100 km/h (appro x. 60 mph) (comply with the legislation in force in your
country).
High ambient temperatures may result in a reduction in the pe rformance of the vehicle in order to protect the engine; when
the ambient temperature is higher than 37 °C, limit the we ight towed.
* The weight of the braked trailer can be increa
sed, within the GTW limit, on condition that the GV W of the towing vehicle is reduced
by the same amount; warning, towing with a lightly loaded towing vehicle may have an adverse effect on its road holding.
Page 220 of 314
XII
199
T E C H N I C A L D A T A
The GTW and towed load values indicated apply up to a maximum altitude of 1,000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1,000 metres of a ltitude.
The speed of a towing vehicle must not exceed 100 km/h (appro x. 60 mph) (comply with the legislation in force in your
country).
High ambient temperatures may result in a reduction in the pe rformance of the vehicle in order to protect the engine; when
the ambient temperature is higher than 37 °C, limit the we ight towed.
WEIGHTS AND TOWED LOADS (TOURER) in kg
Diesel engines
1.6 litre HDi
110 hp
2 litre HDi
140 hp
2 litre HDi 163 hp
3 litre V6 HDi
240 hp
G e a r b o x e s Manual Manual Manual Auto. Auto.
Model codes:
RW...
9HZC
9HZC/1
RHF8 RHH-RHE X8ZA
- Unladen weight 1 573 1 655 1 595 1 642 1 802
- Kerb weight 1 612 1 730 1 670 1 717 1 877
- Gross vehicle weight (GVW) 2 178 2 276 2 238 2 286 2 373
- Gross train weight (GTW) 3 178 3 776 3 638 3 286 3 676
- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient 1 000 1 500 1 40 0 1 000 1 300
- Braked trailer * (with load transfer within GTW limit) 1 300 1 800 1 670 1 290 1 600
- Unbraked trailer 750 750 750 750
- Recommended nose weight 52 72 67 53 64
* The weight of the braked trailer can be increa sed, within the GTW limit, on condition that the GV W of the towing vehicle is reduced
by the same amount; warning, towing with a lightly loaded towing vehicle may have an adverse effect on its road holding.
Page 259 of 314
239
5
6
SETUPSETUP 1
2
3
4
0 9 CONFIGURATION
SETTING THE DATE AND TIME
Set the parameters using the ring and move on to the next using the 4-direction navigator. P r e s s O K t o c o n fi r m .
Select the "Date format" function and p r e s s O K t o c o n fi r m . Select the format required using the r i n g a n d p r e s s O K t o c o n fi r m .
Select the "Set date & time" function a n d p r e s s O K t o c o n fi r m .
Pressing the SETUP button for more than 2 seconds permits access t o :
This setting operation must be carried out if the battery has been disconnected.
Press the SETUP button.
Select the "Time format" function and p r e s s O K t o c o n fi r m . Select the format required using the r i n g a n d p r e s s O K t o c o n fi r m .
SET DATE & TIME
Select the "Date & Time" function and p r e s s O K t o c o n fi r m .
DESCRIPTION OF THE UNIT
G P S C O V E R A G E
DEMO MODE
DATE & TIME
P r i n c i p l e o f t h e G P S s y n c h r o ( G M T ) :
1 . C o n fi r m t h e " S y n c h r o n i s e w i t h G P S " s e l e c t i o n , t h e t i m e i s t h e n s e t t o G M T u n i v e r s a l t i m e , the date is also updated. 2 . U s i n g t h e 4 - d i r e c t i o n n a v i g a t o r , m o v e t h e c u r s o r t o t h e t i m e fi e l d s a n d p r e s s O K . 3 . Y o u c a n t h e n u s e t h e r i n g t o s e t t h e t i m e t o t h e t i m e z o n e o f y o u r c h o i c e . T a k e c a r e w h e n c h a n g i n g b e t w e e n s u m m e r / w i n t e r t i m e , t h e t i m e z o n e m u s t b e c h a n g e d a g a i n manually.
This function provides access to the options in the SETUP menu.
Page 264 of 314
244
There is a difference in sound quality between the different audio s o u r c e s ( r a d i o , C D . . . ) .
Check that the audio settings (Volume, Bass, T r e b l e , A m b i e n c e , L o u d n e s s ) a r e a d a p t e d t o the sources listened to. It is advisable to set the AUDIO functions (Bass, Treble, Front-Rear B a l a n c e , L e f t - R i g h t B a l a n c e ) t o t h e m i d d l e position, select the musical ambience "Linear" and set the loudness correction to the "Active" position in CD mode or to the "Inactive" position in radio mode.
For optimum sound quality, the audio settings (Volume, Bass, Treble, A m b i e n c e , L o u d n e s s ) c a n b e a d a p t e d t o t h e d i f f e r e n t s o u n d s o u r c e s , which may result in audible differences when changing source ( r a d i o , C D . . . ) .
The CD is ejected automatically or is not played by the player.
- Check that the CD is inserted in the player the right way up. - C h e c k t h e c o n d i t i o n o f t h e C D : t h e C D c a n n o t be played if it is too damaged. - Check the content in the case of a recorded C D : c o n s u l t t h e a d v i c e i n t h e " A u d i o " s e c t i o n . - The audio equipment's CD player does not play DVDs. - Due to inadequate quality, certain recorded CDs will not be played by the audio system.
The CD is inserted upside down, is unplayable, doe s not contain any audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not recognised by the audio equipment.
The CD player sound is poor. Insert good quality CDs and store them in suitable conditions. The CD used is scratched or of poor quality.
T h e a u d i o e q u i p m e n t s e t t i n g s ( b a s s , t r e b l e , a m b i e n c e s ) a r e u n s u i t a b l e . Set the treble or bass level to 0, without selecting an ambience.
The table below groups together the answers to th e most frequently asked questions concerning the Na viDrive 3D.
QUESTION SOLUTION ANSWER
FREQUENTLY ASKED QUESTIONS
Page 265 of 314
245
SOLUTION ANSWER
The stored stations do not function ( n o s o u n d , 8 7 . 5 M h z i s d i s p l a y e d . . . ) .
An incorrect waveband is selected.
The quality of reception of the radio station listened to gradually deteriorates or the stored stations do not function (no s o u n d , 8 7 . 5 M h z i s d i s p l a y e d . . . ) .
Activate the "RDS" function by means of the short-cut menu to enable the system to check whether there is a more powerful transmitter in the geographical area.
Press RADIO, select Radio Menu then "Waveband" to return to the waveband on which the stations are stored.
The vehicle is too far from the transmitter used by the station listened to or there is no transmitter in the geographical area through which the vehicle is travelling.
T h e e n v i r o n m e n t ( h i l l s , b u i l d i n g s , t u n n e l s , b a s e m e n t c a r p a r k s . . . ) b l o c k reception, including in RDS mode.
Sound cut-outs of 1 to 2 seconds in radio mode.
During this brief sound cut-out, the RDS searches for any frequency permitting better reception of the station. Deactivate the "RDS" function by means of the short-cut menu if the phenomenon is too frequent and always on the same route.
With the engine off, the system switches off after a few minutes of use.
When the engine is switched off, the system's oper ating time depends on the battery charge.
T h e s w i t c h - o f f i s n o r m a l : t h e s y s t e m s w i t c h e s t o e c o n o m y m o d e a n d switches off to prevent discharging of the vehicle's battery.
Start the vehicle's engine to increase the battery charge.
This phenomenon is normal and does not indicate a failure of the audio equipment.
Have the aerial checked by a CITROËN dealer. The aerial is absent or has been damaged (for exam ple when going through a c a r w a s h o r i n t o a n u n d e r g r o u n d c a r p a r k ) .
Page 293 of 314
273
There is a difference in sound quality between the different audio s o u r c e s ( r a d i o , C D . . . ) .
C h e c k t h a t t h e a u d i o s e t t i n g s ( V o l u m e , B a s s , T r e b l e , A m b i e n c e , L o u d n e s s ) a r e a d a p t e d t o the sources listened to. It is advisable to set t h e A U D I O f u n c t i o n s ( B a s s , T r e b l e , F r o n t - R e a r B a l a n c e , L e f t - R i g h t B a l a n c e ) t o t h e m i d d l e position, select the Linear musical ambience and set the loudness correction to the "Active" p o s i t i o n i n C D m o d e o r t o t h e " I n a c t i v e " p o s i t i o n in radio mode.
F o r o p t i m u m s o u n d q u a l i t y , t h e a u d i o s e t t i n g s ( V o l u m e , B a s s , T r e b l e , A m b i e n c e , L o u d n e s s ) c a n b e a d a p t e d t o t h e d i f f e r e n t s o u n d s o u r c e s , w h i c h m a y r e s u l t i n a u d i b l e d i f f e r e n c e s w h e n c h a n g i n g s o u r c e ( r a d i o , C D . . . ) .
T h e C D i s e j e c t e d automatically or is not played by the player.
- C h e c k t h a t t h e C D i s i n s e r t e d i n t h e p l a y e r t h e r i g h t w a y u p . - C h e c k t h e c o n d i t i o n o f t h e C D : t h e C D c a n n o t b e p l a y e d i f i t i s t o o d a m a g e d . - Check the content in the case of a recorded C D : c o n s u l t t h e a d v i c e i n t h e A u d i o s e c t i o n . - T h e a u d i o e q u i p m e n t ' s C D p l a y e r d o e s n o t p l a y D V D s . - Because of their quality level, certain writeable C D s w i l l n o t b e p l a y e d b y t h e a u d i o s y s t e m .
T h e C D i s i n s e r t e d u p s i d e d o w n , i s u n p l a y a b l e , d o e s n o t c o n t a i n a n y a u d i o data or contains an audio format which the player cannot play.
T h e C D i s p r o t e c t e d b y a n a n t i - p i r a t i n g p r o t e c t i o n s y s t e m w h i c h i s n o t r e c o g n i s e d b y t h e a u d i o e q u i p m e n t .
T h e C D p l a y e r s o u n d is poor. I n s e r t g o o d q u a l i t y C D s a n d s t o r e t h e m i n suitable conditions. T h e C D u s e d i s s c r a t c h e d o r o f p o o r q u a l i t y .
T h e a u d i o e q u i p m e n t s e t t i n g s ( b a s s , t r e b l e , a m b i e n c e s ) a r e u n s u i t a b l e . S e t t h e t r e b l e o r b a s s l e v e l t o 0 , w i t h o u t s e l e c t i n g an ambience.
Q U E S T I O N S O L U T I O N A N S W E R
F R E Q U E N T L Y A S K E D Q U E S T I O N S
Page 294 of 314
274
S O L U T I O N A N S W E R
The quality of reception of the radio station l i s t e n e d t o g r a d u a l l y deteriorates or the stored stations do not function ( n o s o u n d , 8 7 . 5 M h z i s d i s p l a y e d . . . ) .
The vehicle is too far from the transmitter used by the station listened to or t h e r e i s n o t r a n s m i t t e r i n t h e g e o g r a p h i c a l a r e a t h r o u g h w h i c h t h e v e h i c l e i s t r a v e l l i n g .
T h e e n v i r o n m e n t ( h i l l s , b u i l d i n g s , t u n n e l s , b a s e m e n t c a r p a r k s . . . ) b l o c k r e c e p t i o n , i n c l u d i n g i n R D S m o d e .
T h e a e r i a l i s a b s e n t o r h a s b e e n d a m a g e d ( f o r e x a m p l e w h e n g o i n g t h r o u g h a c a r w a s h o r i n t o a n u n d e r g r o u n d c a r p a r k ) .
A c t i v a t e t h e R D S f u n c t i o n t o e n a b l e t h e s y s t e m to check whether there is a more powerful t r a n s m i t t e r i n t h e g e o g r a p h i c a l a r e a .
This phenomenon is normal and does not indicate a failure of the audio equipment.
Have the aerial checked by a CITROËN dealer.
Sound cut-outs of 1 to 2 seconds in radio mode. D u r i n g t h i s b r i e f s o u n d c u t - o u t , t h e R D S s e a r c h e s f o r a n y f r e q u e n c y p e r m i t t i n g b e t t e r r e c e p t i o n o f t h e s t a t i o n . D e a c t i v a t e t h e R D S f u n c t i o n i f t h e p h e n o m e n o n is too frequent and always on the same route.
W i t h t h e e n g i n e o f f , the audio equipment switches off after a few minutes of use.
W h e n t h e e n g i n e i s s w i t c h e d o f f , t h e a u d i o e q u i p m e n t o p e r a t i n g t i m e d e p e n d s o n t h e b a t t e r y c h a r g e . The switch-off is normal: the audio equipment switches to economy mode a n d s w i t c h e s o f f t o p r e v e n t d i s c h a r g i n g o f t h e v e h i c l e ' s b a t t e r y .
S t a r t t h e v e h i c l e ' s e n g i n e t o i n c r e a s e t h e b a t t e r y c h a r g e .
The stored stations do not function (no sound, 8 7 . 5 M h z i s d i s p l a y e d . . . ) .
An incorrect waveband is selected. P r e s s t h e B A N D A S T b u t t o n t o r e t u r n t o t h e w a v e b a n d ( A M , F M 1 , F M 2 , F M A S T ) o n w h i c h the stations are stored.
Page 314 of 314
293
T h e t r a f fi c a n n o u n c e m e n t ( T A ) i s d i s p l a y e d . I d o n o t r e c e i v e a n y t r a f fi c information.
T u n e t o a r a d i o s t a t i o n w h i c h b r o a d c a s t s t r a f fi c information. T h e r a d i o s t a t i o n i s n o t p a r t o f t h e r e g i o n a l t r a f fi c i n f o r m a t i o n n e t w o r k .
Q U E S T I O N S O L U T I O N A N S W E R
The quality of reception of the radio station l i s t e n e d t o g r a d u a l l y deteriorates or the stored stations do not function (no s o u n d , 8 7 . 5 M h z i s d i s p l a y e d . . . ) .
The vehicle is too far from the transmitter used b y the station listened to or t h e r e i s n o t r a n s m i t t e r i n t h e g e o g r a p h i c a l a r e a t h r o u g h w h i c h t h e v e h i c l e i s t r a v e l l i n g .
T h e e n v i r o n m e n t ( h i l l s , b u i l d i n g s , t u n n e l s , b a s e m e n t c a r p a r k s . . . ) b l o c k r e c e p t i o n , i n c l u d i n g i n R D S m o d e .
T h e a e r i a l i s a b s e n t o r h a s b e e n d a m a g e d ( f o r e x a m p l e w h e n g o i n g t h r o u g h a c a r w a s h o r i n t o a n u n d e r g r o u n d c a r p a r k ) .
A c t i v a t e t h e R D S f u n c t i o n t o e n a b l e t h e s y s t e m to check whether there is a more powerful t r a n s m i t t e r i n t h e g e o g r a p h i c a l a r e a .
This phenomenon is normal and does not indicate a failure of the audio equipment.
Have the aerial checked by a CITROËN dealer.
Sound cut-outs of 1 to 2 seconds in radio mode.
D u r i n g t h i s b r i e f s o u n d c u t - o u t , t h e R D S s e a r c h e s f o r a n y f r e q u e n c y p e r m i t t i n g b e t t e r r e c e p t i o n o f t h e s t a t i o n . D e a c t i v a t e t h e R D S f u n c t i o n i f t h e p h e n o m e n o n is too frequent and always on the same route.
W i t h t h e e n g i n e o f f , the audio equipment switches off after a few minutes of use.
W h e n t h e e n g i n e i s s w i t c h e d o f f , t h e a u d i o e q u i p m e n t o p e r a t i n g t i m e d e p e n d s o n t h e b a t t e r y c h a r g e . The switch-off is normal: the audio equipment switches to economy mode a n d s w i t c h e s o f f t o p r e v e n t d i s c h a r g i n g o f t h e v e h i c l e ' s b a t t e r y .
S t a r t t h e v e h i c l e ' s e n g i n e t o i n c r e a s e t h e b a t t e r y c h a r g e .
The stored stations do not function (no sound, 8 7 . 5 M h z i s d i s p l a y e d . . . ) .
An incorrect waveband is selected. P r e s s t h e B A N D A S T b u t t o n t o r e t u r n t o t h e w a v e b a n d ( A M , F M 1 , F M 2 , F M A S T ) o n w h i c h t h e stations are stored.
T h e m e s s a g e " t h e a u d i o system is overheated" appears on the display.
Switch the audio system off for a few minutes to allow the system to cool. I n o r d e r t o p r o t e c t t h e i n s t a l l a t i o n i f t h e s u r r o u n d i n g t e m p e r a t u r e i s t o o h i g h , the audio equipment switches to an automatic therma l protection mode l e a d i n g t o a r e d u c t i o n o f t h e v o l u m e o r s t o p p i n g o f t h e p l a y i n g o f t h e C D .
