Page 1 of 314
4
F A M I L I A R I S A T I O N
E X T E R I O R
Xenon dual-function directional headlamps
This function automatically provides you with
extra visibility on bends. This lighting is linked
with the cornering lighting which maximises
the area lit at intersections and when parking.
Lane departure warning system
This driving aid warns you when
you unwittingly cross a lane
marking.
Parking
sensors
(visual + audible)
This function warns you if an
obstacle is detected in front of or
behind the vehicle.
Tyre
u n d e r - i n fl a t i o n
detection
This function checks the pressure
of the tyres automatically while
driving.
Panoramic sunroof
(Tourer)
This provides you with perfect brightness in the
passenger compartment.
Sunroof
(Saloon)
This also provides you with improved ventilation in the
passenger compartment.
87
80-81
144 147 112
Page 12 of 314
15
F A M I L I A R I S A T I O N
M O N I T O R I N G
Instrument panel T h e h a z a r d w a r n i n g l a m p s
can also be used with the
ignition switched off.
A. Fuel gauge and low fuel warning lamp.
B. Cruise control/speed limiter information.
C. Coolant temperature.
D. Speedometer.
E. Instrument panel.
F. Mileage recorder.
G. Trip mileage recorder reset button.
H. Rev counter.
I. Engine oil temperature.
J. D i s p l a y o f a u t o m a t i c g e a r b o x i n f o r m a t i o n .
- W h e n t h e i g n i t i o n i s s w i t c h e d o n , t h e o r a n g e a n d red warning lamps light up.
- W h e n t h e e n g i n e i s r u n n i n g , t h e s e w a r n i n g l a m p s should go out .
- I f a n y w a r n i n g l a m p s r e m a i n o n , r e f e r t o t h e "Monitoring" section.
Hazard warning lamps
22
111
Page 14 of 314
17
F A M I L I A R I S A T I O N
P A S S E N G E R S A F E T Y
Front passenger’s airbag
deactivation Child safety
Seat belts and front
passenger’s airbag
The seat belt fastened/unfastened
status for each seat category is indicated
b y t h e l i g h t i n g o r fl a s h i n g o f t h e w a r n i n g
lamps linked to each position:
A. Non-fastened/unfastened front and/
or rear seat belts warning lamp.
B. Front left-hand seat belt warning
lamp.
C. Front right-hand seat belt warning
lamp.
D. Rear right-hand seat belt warning
lamp.
E. Central rear seat belt warning
lamp.
F. Rear left-hand seat belt warning
lamp.
G. Front passenger’s airbag deactivation
warning lamp.
H. Front passenger’s airbag activation
warning lamp.
2 9 - 3 0 , 3 4 To use a rear facing child seat in the
f r o n t p a s s e n g e r ' s s e a t p o s i t i o n , t h e
p a s s e n g e r ' s a i r b a g m u s t fi r s t b e
deactivated.
To do this:
W i t h t h e i g n i t i o n s w i t c h e d o f f , i n s e r t
the key into the switch I .
Turn the key to the "OFF" p o s i t i o n , t h e
passenger’s airbag is deactivated.
The front passenger’s airbag deactiva-
tion warning lamp G lights up when the
ignition is switched on.
120 This deactivates the controls in the rear
o f t h e v e h i c l e , b o t h f o r t h e r e a r w i n d o w s
and for opening the rear doors from the
inside. The electric child safety device
is activated by pressing button
J .
The activation of the function is indicated
by a message on the instrument panel
screen and the lamp on button J .
110
Page 18 of 314
21
F A M I L I A R I S A T I O N
Y o u c a n a c t i v a t e / d e a c t i v a t e t h e p a r k i n g
sensors by pressing button B . When
t h e p a r k i n g s e n s o r s a r e i n a c t i v e , t h e
warning lamp on button B comes on.
Parking sensors
(visual and audible)
Parking space sensor
Y o u c a n s e l e c t t h e " P a r k i n g s p a c e
sensor" by pressing button
A , d i r e c t i o n
indicator activated on the side of the
s p a c e t o b e m e a s u r e d , w i t h a s p e e d
lower than 12 mph (20 km/h) and at
a distance of less than 1.5 m from the
space.
T h e fi x e d l i g h t i n g o f t h e w a r n i n g l a m p
indicates that this function is selected.
D R I V I N G
145
147 Lane departure warning system
This device is recommended on motor-
w a y s a n d d u a l c a r r i a g e w a y s , a n d
operates only at speeds above 50 mph
(80 km/h).
A press on button
C activates the
f u n c t i o n , t h e w a r n i n g l a m p o n t h e b u t t o n
lights up.
The system does not alert you if one
of your direction indicators is operating
and for approx. 20 seconds after the
direction indicator has stopped.
144
Page 26 of 314
I!
28M O N I T O R I N G
Indicator and warning lamps
V i s u a l i n d i c a t o r s i n f o r m i n g t h e d r i v e r t h a t a s y s t e m i s i n o p e r a t
i o n ( o p e r a t i o n o r
deactivation indicator lamps) or of the occurrence of a fault (wa rning lamp).
When the ignition is switched on
C e r t a i n w a r n i n g l a m p s c o m e o n f o r a f e w s e c o n d s w h e n t h e v e h i c l e ' s i g n i t i o n
is switched on.
W h e n t h e e n g i n e i s s t a r t e d , t h e s e s a m e w a r n i n g l a m p s s h o u l d s w i t c h o f f .
I f t h e y r e m a i n o n , b e f o r e m o v i n g o f f , r e f e r t o t h e i n f o r m a t i o n o n t h e w a r n i n g l a m p c o n c e r n e d .
Associated warnings
T h e s w i t c h i n g o n o f c e r t a i n w a r n i n g l a m p s m a y b e a c c o m p a n i e d b y a n a u d i b l e
signal and a message on the multifunction screen.
Operation indicator lamps
I f o n e o f t h e f o l l o w i n g i n d i c a t o r l a m p s c o m e s o n , t h i s c o n fi r m s t h a t t h e c o r r e -
s p o n d i n g s y s t e m h a s c o m e i n t o o p e r a t i o n .
T h e w a r n i n g l a m p s m a y c o m e
o n c o n t i n u o u s l y ( fi x e d ) o r fl a s h .
C e r t a i n w a r n i n g l a m p s m a y c o m e
o n i n t w o d i f f e r e n t m o d e s . O n l y
b y r e l a t i n g t h e t y p e o f l i g h t i n g t o
the operating status of the vehicle
can it be ascertained whether the
situation is normal or whether a
fault has occurred.
Warning lamp is on Cause Action/Observations
Left-hand
direction
indicato
r fl a s h i n g w i t h
b u z z e r . The lighting stalk is pushed down.
Right-hand
direction
indicator fl a s h i n g w i t h
b u z z e r . The lighting stalk is pushed up.
Sidelamps fi x e d . The lighting stalk is in the
" S i d e l a m p s " p o s i t i o n . Turn the control to the desired
position.
Dipped beam
headlamps fi x e d . T h e l i g h t i n g s t a l k i s i n t h e " D i p p e d
beam headlamps" position. Turn the control to the desired
position.
Main beam
headlamps fi x e d . The lighting stalk is pulled towards
y o u . Pull the stalk to return to dipped
beam headlamps.
Page 36 of 314
I
37
M O N I T O R I N G
Engine oil temperature gauge
U n d e r n o r m a l o p e r a t i n g c o n d i t i o n s ,
the bars should be within section
1 .
I n s e v e r e o p e r a t i n g c o n d i t i o n s , t h e
b a r s m a y e x t e n d i n t o s e c t i o n 2 .
I n t h i s e v e n t , s l o w d o w n , a n d i f n e c e s -
s a r y , s t o p t h e e n g i n e a n d c h e c k t h e
levels (see corresponding chapter). Coolant temperature
indicator
U n d e r n o r m a l o p e r a t i n g c o n d i t i o n s ,
the bars should be within section
1 .
I n s e v e r e o p e r a t i n g c o n d i t i o n s , t h e
b a r s m a y e x t e n d i n t o s e c t i o n 2 , t h e
engine coolant temperature warning
lamp A and the STOP warning lamp
w i l l l i g h t u p , stop immediately .
S w i t c h o f f t h e i g n i t i o n . The cooling
fan may continue to operate for a
certain time .
C o n s u l t a C I T R O Ë N d e a l e r .
If the SERVICE warning lamp lights
u p , c h e c k t h e l e v e l s ( s e e c o r r e s p o n d -
ing chapter). O n h o r i z o n t a l g r o u n d , t h e l i g h t i n g o f
t h e f u e l l o w w a r n i n g l a m p w a r n s y o u
t h a t y o u a r e a t t h e r e s e r v e l e v e l .
A m e s s a g e a l e r t i s d i s p l a y e d o n t h e
instrument panel.
Fuel gauge indicator
Page 67 of 314
IV
67
O P E N I N G S
First press button A to fold
the key.
Locating your vehicle
Press the closed padlock to locate
your locked vehicle in a car park.
This is indicated by switching on of the
i n t e r i o r l i g h t i n g a n d fl a s h i n g o f t h e d i -
rection indicators for a few seconds.
The vehicle remains locked. Guide-me-home lighting Anti-theft protecti
on
Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the
ignition is switched on, this code
must be recognised in order for
starting to be possible.
This electronic engine immobiliser
locks the engine management sys-
tem a few minutes after the ignition
is switched off and prevents starting
of the engine by anyone who does
not have the key.
In the event of a mal-
function, you are in-
formed by lighting of
this warning lamp, an
audible signal and a message on
the multifunction screen.
In this case, your vehicle does not
start; contact a CITROËN dealer as
soon as possible.
Folding the key
A press on button B oper-
ates the guide-me-home
lighting (lighting of the
sidelamps, dipped beams
and number plate lamps).
A second press before the end of
the timing cancels the guide-me-
home lighting.
The timed duration can be set via the
"Lighting" menu on the "Main Menu"
of the instrument panel screen.
Page 71 of 314
IV
67
O P E N I N G S
First press button A to fold
the key.
Locating your vehicle
Press the closed padlock to locate
your locked vehicle in a car park.
This is indicated by switching on of the
i n t e r i o r l i g h t i n g a n d fl a s h i n g o f t h e d i -
rection indicators for a few seconds.
The vehicle remains locked. Guide-me-home lighting Anti-theft protecti
on
Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the
ignition is switched on, this code
must be recognised in order for
starting to be possible.
This electronic engine immobiliser
locks the engine management sys-
tem a few minutes after the ignition
is switched off and prevents starting
of the engine by anyone who does
not have the key.
In the event of a mal-
function, you are in-
formed by lighting of
this warning lamp, an
audible signal and a message on
the multifunction screen.
In this case, your vehicle does not
start; contact a CITROËN dealer as
soon as possible.
Folding the key
A press on button B oper-
ates the guide-me-home
lighting (lighting of the
sidelamps, dipped beams
and number plate lamps).
A second press before the end of
the timing cancels the guide-me-
home lighting.
The timed duration can be set via the
"Lighting" menu on the "Main Menu"
of the instrument panel screen.
Page 90 of 314
V
87
V I S I B I L I T Y
Linked with the automatic
"Guide-me-home" lighting
Link with the automatic illumination
of headlamps provides the "guide-
me-home" lighting with the following
additional options:
- selection of the duration of light- ing for 15, 30 or 60 seconds in
the vehicle parameters on the in-
s t r u m e n t p a n e l s c r e e n c o n fi g u -
ration menu,
- automatic activation of "guide- me-home" lighting when auto-
matic illumination of headlamps
is in operation.
Operating fault
In the event of a malfunction of the
brightness sensor, the lamps come
on and a message appears on the
instrument panel screen, accompa-
nied by an audible signal.
Consult a CITROËN dealer.
In fog or snow, the brightness
s e n s o r m a y d e t e c t s u f fi c i e n t l i g h t .
Therefore, the lamps will not come
on automatically.
Do not cover the brightness sen-
sor, linked with the rain sensor and
located in the centre of the wind-
screen behind the rear view mirror;
the associated functions would no
longer operate.
MANUAL HEADLAMP ADJUSTMENT
To avoid dazzling other road users,
the height of the halogen bulb head-
lamps must be adjusted according
to the load in the vehicle.
0. 1 or 2 people in the front seats.
-. 3 people.
1. 5 people.
-. Intermediate setting.
2. 5 people + maximum authorised
loads.
-. Intermediate setting.
3. Driver + maximum authorised
loads.
Initial setting is position "0".
AUTOMATIC ADJUSTMENT OF DIRECTIONAL HEADLAMPS
Do not touch the xenon bulbs.
Consult a CITROËN dealer.
If a malfunction occurs,
this warning lamp is dis-
played on the instrument
panel, accompanied by
an audible signal and a
message on the instru-
ment panel screen.
The system then places your head-
lamps in the lowest position.
To avoid causing a nuisance to oth-
er road users, this system corrects
the height of the xenon headlamp
beams automatically and when sta-
tionary, depending on the load in the
vehicle.
Page 92 of 314
V
87
V I S I B I L I T Y
Linked with the automatic
"Guide-me-home" lighting
Link with the automatic illumination
of headlamps provides the "guide-
me-home" lighting with the following
additional options:
- selection of the duration of light- ing for 15, 30 or 60 seconds in
the vehicle parameters on the in-
s t r u m e n t p a n e l s c r e e n c o n fi g u -
ration menu,
- automatic activation of "guide- me-home" lighting when auto-
matic illumination of headlamps
is in operation.
Operating fault
In the event of a malfunction of the
brightness sensor, the lamps come
on and a message appears on the
instrument panel screen, accompa-
nied by an audible signal.
Consult a CITROËN dealer.
In fog or snow, the brightness
s e n s o r m a y d e t e c t s u f fi c i e n t l i g h t .
Therefore, the lamps will not come
on automatically.
Do not cover the brightness sen-
sor, linked with the rain sensor and
located in the centre of the wind-
screen behind the rear view mirror;
the associated functions would no
longer operate.
MANUAL HEADLAMP ADJUSTMENT
To avoid dazzling other road users,
the height of the halogen bulb head-
lamps must be adjusted according
to the load in the vehicle.
0. 1 or 2 people in the front seats.
-. 3 people.
1. 5 people.
-. Intermediate setting.
2. 5 people + maximum authorised
loads.
-. Intermediate setting.
3. Driver + maximum authorised
loads.
Initial setting is position "0".
AUTOMATIC ADJUSTMENT OF DIRECTIONAL HEADLAMPS
Do not touch the xenon bulbs.
Consult a CITROËN dealer.
If a malfunction occurs,
this warning lamp is dis-
played on the instrument
panel, accompanied by
an audible signal and a
message on the instru-
ment panel screen.
The system then places your head-
lamps in the lowest position.
To avoid causing a nuisance to oth-
er road users, this system corrects
the height of the xenon headlamp
beams automatically and when sta-
tionary, depending on the load in the
vehicle.
