Page 131 of 316
IX
!
129
DRIVING
Release
With the ignition on or the engine
running, to release the parking
brake, press on the brake pedal,
push then release
control lever A
.
The full application of the parking
brake is confi rmed by:
- warning lamp P
in the
control lever A
going off,
- display of a message "parking
brake released" in the instru-
ment panel screen.
If you push control lever A
without
pressing the brake pedal, the park-
ing brake will not be released and
the message "Foot on brake" will be
displayed in the instrument panel.
When stationary, with the en-
gine running, do not press the
accelerator pedal unneces-
sarily, as you may release the
parking brake.
Maximum application
If necessary, you can utilise maxi-
mum application
of the parking
brake. It is obtained by means of a
long pull
on control lever A
, until
you see the message "Max appli-
cation of the parking brake" and a
beep is heard.
Maximum application is essen-
tial:
- in the case of a vehicle towing
a caravan or a trailer, if the au-
tomatic functions are activated
but you are applying the parking
brake manually,
- when the effective gradient you
are parked on is variable (e.g. on
a ferry, in a lorry, during towing).
- In the case of towing, a loaded
vehicle or parking on a gradient,
turn the front wheels towards the
pavement and engage a gear
when you park.
- After a maximum application, the
release time will be longer.
Particular situations
In certain situations (starting the en-
gine...), the parking brake can auto-
matically alter its level of application.
This is normal operation.
To advance your vehicle a few cen-
timetres without starting the engine,
but with the ignition on, press on the
brake pedal and release the parking
brake by pushing
then releasing
control lever A
.
The full release of the parking brake
is confi rmed by the warning lamp P
in the control lever and the warning
lamp in the instrument panel going
off and the display of a message
"parking brake off" in the instrument
panel screen.
If the parking brake malfunctions
while applied
or if the battery is fl at,
an emergency release is still pos-
sible.
To ensure correct operation of the
parking brake and therefore your
safety, the number of successive
application/release operations is
limited to eight.
If this number is exceeded, you are
warned by the message "Parking
brake faulty" and a warning lamp
fl ashes.
- this warning lamp in the in-
strument panel going off,
Page 132 of 316
IX
!
!
130
DRIVING
Dynamic emergency braking
In the event of a failure of the ve-
hicle’s main braking system or in
an exceptional situation (e.g. driver
taken ill, under instruction, etc) pull
and hold control lever A
to stop the
vehicle.
The electronic stability programme
(ESP) provides stability during dy-
namic emergency braking.
If there is a fault with the dynamic
emergency braking, one of the fol-
lowing messages will be displayed
in the instrument panel screen:
- "Parking brake faulty".
- "Parking brake control faulty". If a failure of the ESP sys-
tem is signalled by the light-
ing of this warning lamp,
then braking stability is not
guaranteed. In this event, stability
must be assured by the driver by
repeating alternate "pull release" ac-
tions on control lever A
.
The dynamic emergency brak-
ing should only be used in ex-
ceptional circumstances.
Emergency parking brake
release
In the event of the electric parking
brake failing to release, an emergen-
cy device can be used to release the
parking brake manually, provided that
it is possible to immobilise the vehicle
while the procedure is carried out.
)
If you can start the vehicle: with
the engine running, immobilise
the vehicle by applying the foot
brake while the operation is be-
ing carried out.
)
If you are unable to start the ve-
hicle (fl at battery for example):
do not use this device and con-
tact a CITROËN dealer or a
qualifi ed workshop. However, if
you are obliged to proceed, fi rst
immobilise your vehicle securely
and then follow the instructions
below. If the vehicle cannot be im-
mobilised, do not operate
the emergency release. Your ve-
hicle may run away if on a slope.
Contact a CITROËN dealer or a
qualifi ed workshop.
Page 133 of 316
IX
!
131
DRIVING
)
On sloping ground: immobilise
the vehicle by placing the chocks
(if your vehicle has them) in front
or behind the two front wheels,
against the slope
On level ground: immobilise the
vehicle by placing the chocks
(if your vehicle has them) in
front and behind one of the front
wheels.
)
Open the lower compartment of
the centre armrest by pulling it.
)
Ensure that the cup holder B
is
folded away.
)
Remove the rubber mat covering
the base of the armrest.
This strap does not permit
application of the parking
brake.
To re-engage the electric parking
brake (after rectifying the malfunc-
tion or battery failure), give a long
pull on the control A
until the park-
ing brake warning lamp (!) fl ashes
in the instrument panel then give a
second long pull until this warning
lamp is on fi xed.
The time required for the subse-
quent application may be longer
than during normal operation.
It is essential that the ignition is
not switched on until the parking
brake has re-engaged (fl ashing of
the warning lamp (!) in the instru-
ment panel then the warning lamp
on fi xed) to avoid damage to the
parking brake.
Take care not to allow moisture or
dust in the proximity of the diagnos-
tic socket D
which is essential for
the maintenance of your vehicle.
)
Release the strap from its loca-
tion C
.
)
Pull the strap to release the
brake. A loud knock confi rms the
release of the brake.
)
Take care to put the strap
back in its location C
correct-
ly. Otherwise, it will no longer
be possible to apply the brake.
Contact a CITROËN dealer or a
qualifi ed workshop.
)
Put the rubber mat back in place
on the base of the armrest.
Page 134 of 316
IX
!
132
DRIVING
If any of these instances arises, contact a CITROËN dealer or a qualifi ed workshop as soon as possible.
SITUATION
CONSEQUENCES
1
Electric parking brake problem and display
of message " Parking brake faulty
" and the
following warning lamps: If the electric parking brake problem warning lamp and the service
warning lamp come on, position the vehicle in a safe location
(on fl at ground, with a gear engaged).
2
Display of the messages " Parking brake
faulty
" and " Anti roll-back
fault
" and of the
following warning lamps:
- The automatic functions are deactivated.
- The hill start assist is not available.
- The electric parking brake is only available manually.
3
Display of messages " Parking brake faulty
"
and " Anti roll-back
fault
" and of the
following warning lamp:
- Manual release of the electric parking brake is not available.
- The hill start assist is not available.
- The automatic functions and manual application are still available.
Operating faults
Page 135 of 316
IX
133
DRIVING
SITUATION
CONSEQUENCES
4
Display of messages " Parking brake faulty
"
and " Anti roll-back
fault
" and of the
following warning lamps:
and/or
fl ashing
- The automatic functions are deactivated.
- The hill start assist is not available.
To apply the electric parking brake:
)
Immobilise the vehicle and switch off the ignition
)
Pull the control lever for at least 5 seconds or until maximum
application.
)
Switch on the ignition and check that the electric parking brake
warning lamps are on.
- Application may take longer than in normal operation.
- If warning lamp (!)
fl ashes or if the warning lamps do not come
on when the ignition is switched on, this method does not work.
Have it checked by a CITROËN dealer or a qualifi ed workshop.
To release the electric parking brake:
)
Switch on the ignition.
)
Push the control lever and hold it for approximately 3 seconds.
5
Display of message " Parking brake control
faulty – automatic mode activated
" and
the following warning lamps:
and/or
fl ashing
- Only the functions for automatic application on switching off
the engine and automatic release on acceleration are
available.
- Manual application/release of the electric parking brake and
dynamic emergency braking are unavailable.
6
Display of message " Parking brake faulty
"
and of the following warning lamp:
fl ashing
- Application of the parking brake is not guaranteed.
- The parking brake is temporarily unavailable.
It this situation arises:
)
Wait approximately 3 minutes.
)
After 3 minutes, if the warning lamp is still fl ashing, try to
reinitialise the parking brake, either by pushing and releasing
the control A
while pressing the brake pedal or by means of a
long pull on control lever A
.
7
Battery problem
-
Illumination of the battery warning lamp makes it essential to stop the
vehicle as soon as traffi c allows. Stop and immobilise your vehicle.
- Apply the electric parking brake before switching off the engine.
Page 136 of 316
IX!
134
DRIVING
HILL START ASSIST
System which keeps your vehicle
immobilised temporarily (approxi-
mately 2 seconds) when starting on
a gradient, the time to move your
foot from the brake pedal to the ac-
celerator pedal.
This function is only active when:
- the vehicle is completely station-
ary, with your foot on the brake
pedal,
- in certain conditions on a gradient,
- with the driver’s door closed.
The hill start assist function cannot
be deactivated.
Operation
On an ascending gradient, with
the vehicle stationary, the vehicle
is held for a brief moment when
you release the brake pedal:
- provided you are in fi rst gear or
neutral on a manual gearbox,
- provided you are in D
or M
on an
automatic gearbox.
On a descending gradient, with
the vehicle stationary and reverse
gear engaged, the vehicle is held
for a brief moment when you re-
lease the brake pedal.
Do not exit the vehicle while
it is being held in the hill start
assist phase.
If you need to leave the vehicle with
the engine running, apply the park-
ing brake manually and ensure that
the parking brake warning lamp (in
the instrument panel) is on fi xed
(not fl ashing).
Page 137 of 316
IX
135
DRIVING
5-SPEED MANUAL GEARBOX
Starting the vehicle
)
Check that the gear lever is in
neutral.
)
Do not touch the accelerator.
)
For Diesel engines: turn the
key to position M
and wait until
the pre-heating warning lamp
switches off if it has come on.
)
Operate the starter, turning the
key until the engine starts (no
more than ten seconds).
)
In temperatures lower than 0°C,
declutch while operating the
starter to facilitate starting.
Engaging reverse gear
)
Move the gear lever to the right
then back.
Only engage reverse gear when the
vehicle is stationary with the engine
at idle.
6-SPEED MANUAL GEARBOX
Engaging reverse gear
)
Raise the ring under the knob
(indicated by the arrow) and
push the gear lever to the left
then forwards.
Only engage reverse gear when the
vehicle is stationary with the engine
at idle.
As a safety precaution and to facili-
tate starting of the engine:
- always select neutral,
- press the clutch pedal.
Page 138 of 316
IX
!
136
DRIVING
GEAR EFFICIENCY
INDICATOR *
System which reduces fuel con-
sumption by advising the driver to
change up on vehicles fi tted with a
manual gearbox.
Operation
The system intervenes only when
driving economically.
Depending on the driving situation
and your vehicle's equipment, the
system may advise you to skip one
or more gears. You can follow this
instruction without engaging the in-
termediate gears.
The gear engagement recommen-
dations must not be considered
compulsory. In fact, the confi gu-
ration of the road, the amount of
traffi c and safety remain determin-
ing factors when choosing the best
gear. Therefore, the driver remains
responsible for deciding whether or
not to follow the advice given by the
system.
This function cannot be deactivated.
*
According to engine.
Example:
- You are in third gear.
- You press the accelerator pedal
moderately.
- The system may suggest that
you engage a higher gear, if ap-
propriate.
The information appears in the in-
strument panel in the form of an ar-
row accompanied by the suggested
gear.
In the case of driving which
makes particular demands on
the performance of the engine
(fi rm pressure on the accelerator
pedal, for example, when overtak-
ing...), the system will not recom-
mend a gear change.
The system never suggests:
- engaging fi rst gear,
- engaging reverse gear,
- engaging a lower gear.
Page 139 of 316
IX
137
DRIVING
6-SPEED ELECTRONIC GEARBOX SYSTEM
)
automatic mode: gear lever in
position A
,
)
manual mode: gear lever in posi-
tion M
,
)
SPORT
mode: gear lever in po-
sition A
and a press on button 1
.
Six-speed electronic gearbox sys-
tem which offers a choice between
the comfort of fully automatic opera-
tion or the pleasure of manual gear
changing.
There are two driving modes:
- automatic
operation for elec-
tronic control of the gears by the
gearbox,
- manual
operation for sequential
gear changing by the driver,
In automated mode, it remains pos-
sible to change gear manually by
using the steering mounted control
paddles, when overtaking, for ex-
ample.
A SPORT
programme is available in
automated mode, providing a more
dynamic driving style.
Mode selection
The steering mounted paddles
cannot be used to select neutral
or to engage or disengage reverse
gear.
+.
Change up paddle to the right of
the steering wheel.
)
Press the back of the "+"
steer-
ing mounted paddle to change
up a gear.
-.
Change down paddle to the left of
the steering wheel.
)
Press the back of the "-"
steering
mounted paddle to change down
a gear.
Steering mounted control paddles
Page 140 of 316
IX
138
DRIVING
The position of the gear lever the the
driving mode are displayed in dial C
of the instrument panel.
A selection grille alongside the gear
lever also allows you to see the se-
lected position.
Displays in the instrument panel
Moving off
)
To start the engine, the gear le-
ver must be in position N
.
)
Press the brake pedal down fully.
)
Operate the starter
.
N
appears in the instrument panel
screen.
N
fl ashes in the instrument panel,
accompanied by an audible signal
and a message in the multifunction
screen, if the gear lever is not in
position N
on starting.
)
Select fi rst gear (position M
or A
)
or reverse (position R
).
)
Release the parking brake un-
less it is programmed in auto-
matic mode.
)
Release the brake pedal, then
accelerate.
)
With your foot on the brake, push
the lever forwards.
Reverse
Only engage reverse with
the vehicle immobilised.
To avoid any jerking, wait a
moment before accelerating.
Neutral
Never select position N
with
the vehicle moving.
