IV
82
ACCESS
PANORAMIC SUNROOF (SALOON)
Sunroof closed
- Press B
to fi rst notch: tilting.
- Press B
to second notch: auto-
matic complete tilting.
- Press A
to fi rst notch: sliding to-
wards rear.
- Press A
to second notch: auto-
matic total sliding towards rear.
Sunroof open
- Press B
to fi rst notch: closure.
- Press B
to second notch: auto-
matic total closure.
Always remove the ignition key
when leaving the vehicle, even if
for a short time .
In the event of anything being
caught by the sunroof closing, you
must reverse the roof movement.
Do this by reversing the position of
the control switch .
When the driver is operating the
sunroof, they must always make
sure that the passengers are not
preventing it from closing properly.
The driver must ensure that pas-
sengers use the sunroof control
correctly.
Pay special attention to where chil-
dren are when operating the sun oof.
The fi tting of a sunroof as an ac-
cessory is prohibited
Operation
Tilted sunroof
- Press A
to fi rst notch: closure.
- Press A
to second notch: auto-
matic total closure.
Your sun roof is fi tted with a manually-
operated blind.
Anti-pinch
An anti-pinch device stops the sun
roof from closing, whether sliding or
tilting. If it meets an obstacle, it re-
opens.
Reinitialisation
After a battery disconnection or if
there has been a malfunction, you
have to re-initialise the anti-pinch
function.
)
move control B
until the roof is in
the complete tilting position,
)
keep control B
pressed down for
a minimum of 1 second.
During these operations, the anti-
pinch function does not operate
.
Page 86 of 316
IV
!
84
ACCESS
FUEL TANK
Capacity of the tank: approxi-
mately
71 litres
*
.
Low fuel level
When the minimum level
in the tank is reached, this
warning lamp comes on
in the instrument panel,
accompanied by an audible warning
and a message on the multifunction
screen. When it fi rst comes on, there
remains around 5 litres of fuel in the
tank.
You must refuel to avoid running out
of fuel.
)
Press at the top left corner, then
pull open from the left.
)
turn the key a quarter turn to lock
and unlock the fi ller cap,
)
when refuelling, place the cap on
hook A
,
)
fi ll the tank, but do not persist
after the third cut-off
; this could
cause your vehicle to malfunc-
tion.
While you are refuelling, the engine must be stopped and the ignition
switched off.
For a petrol engine with a cata-
lytic converter, unleaded fuel is
compulsory.
Opening the fuel flap
Additions of fuel must be of at least
5 litres to be taken into account by
the fuel gauge.
The fi ller neck is narrower to ensure
that only unleaded petrol nozzles
can be put in.
Opening the fi ller cap may create
a noise of an inrush of air. This
vacuum, which is entirely normal,
is caused by the sealing of the fuel
system.
Refuelling
With Stop & Start, never re-
fuel with the system in STOP
mode; you must switch off
the ignition with the key.
*
55 litres for Slovakia.
Page 96 of 316
V
94
VISIBILITY
Special position of
the windscreen wipers
This position permits release of the
windscreen wiper blades.
It is used for cleaning or replacement
of the blades. It can also be useful,
in winter, to detach the blades from
the windscreen.
To maintain the effectiveness of the
"fl at-blade" type of wiper blades, it
is advisable to:
- handle them with care,
- clean them regularly using soapy
water,
- avoid using them to retain card-
board on the windscreen,
- replace them at the fi rst signs
of wear.
COURTESY LAMPS
1.
Front courtesy lamp
2.
Map reading lamp
s
Front courtesy lamp
Rear courtesy lamp
1.
Rear courtesy lamp
2.
Map reading lamps
In this position, the courtesy
lamp comes on gradually:
Lighting off.
Lighting on.
- when the vehicle is unlocked,
- when a door is opened,
- when the key is removed from
the ignition,
- when the remote control locking
button is activated, in order to lo-
cate your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is
closed.
)
Any action on the wiper stalk in
the minute after switching off the
ignition places the blades verti-
cally on the screen.
)
To park the blades again, switch
on the ignition and operate the
wiper stalk.
Page 97 of 316
V
95
VISIBILITY
In lighting on mode, different lighting
times are available:
- with the ignition off, approxi-
mately ten minutes,
- in energy economy mode, ap-
proximately thirty seconds,
-
with the engine running, unlimited.
Map reading lamps
)
With the ignition on, press the
corresponding switch.
Panoramic sunroof rear
reading lamps (Tourer)
With the key in position or with the
ignition on:
)
Press the corresponding switch.
The reading lamp concerned comes
on for ten minutes.
The rear reading lamps come on:
- when the key is removed from
the ignition,
- when the vehicle is unlocked.
They switch off gradually:
- when the vehicle is locked,
- when the ignition is switched on.
Page 112 of 316
VII
110
CHILD SAFETY
ADVICE ON CHILD SEATS
Installing a booster seat
The chest part of the seat belt must
be positioned on the child's shoulder
without touching the neck.
Ensure that the lap part of the seat
belt passes correctly over the child's
thighs.
CITROËN recommends the use of a
booster seat which has a back, fi t-
ted with a seat belt guide at shoulder
level.
As a safety precaution, do not leave:
- one or more children alone and
unsupervised in a vehicle,
- a child or an animal in a vehicle
which is exposed to the sun, with
the windows closed,
- the keys within reach of children
inside the vehicle.
To prevent accidental opening of the
doors, use the "Child lock".
Take care not to open the rear win-
dows by more than one third.
To protect young children from the
rays of the sun, fi t side blinds on the
rear windows.
The incorrect installation of a child
seat in a vehicle compromises the
child's protection in the event of an
accident.
When installing a child seat using the
seat belt, check that the seat belt is
tightened correctly on the child seat
and that it secures the child seat
fi rmly on the seat of your vehicle.
Remember to fasten the seat belts
or the child seat harnesses keeping
the slack
in relation to the child's
body to a minimum, even for short
journeys.
For optimum installation of the "for-
wards-facing" child seat, ensure that
the back of the child seat is in con-
tact with the back of the vehicle's
seat and that the head restraint does
not cause any discomfort.
If the head restraint has to be re-
moved, ensure that it is stored or
attached securely to prevent it from
being thrown around the vehicle in
the event of sharp braking.
Children under the age of 10 must
not travel in the "forwards-facing"
position on the front passenger seat,
unless the rear seats are already oc-
cupied by other children, cannot be
used or are absent.
Deactivate the passenger airbag *
when a "rearwards-facing" child
seat is installed on the front seat.
Otherwise, the child would risk be-
ing seriously injured or killed if the
airbag were to infl ate.
*
According to country and current
local legislation.
Page 115 of 316
VII
11 3
CHILD SAFETY
ELECTRICCHILD LOCK
Activation
)
Press button A
.
The indicator lamp in button A
comes
on, accompanied by a message in
the instrument panel screen. Remote control system to prevent
opening of the rear doors using their
interior controls and use of the rear
electric windows.
Deactivation
)
Press button A
again.
The indicator lamp in button A
goes
off, accompanied by a message in
the instrument panel screen.
This indicator lamp remains off until
the child lock is activated.
This system is independent and in
no circumstances does it take the
place of the central locking control.
Check the status of the child lock
each time you switch on the ignition.
Always remove the key from the
ignition when leaving the vehicle,
even for a short time.
In the event of a serious impact,
the electric child lock is deactivated
automatically to permit the exit of
the rear passengers.
Any other status of the indicator
lamp indicates a fault with the elec-
tric child lock. Have it checked by a
CITROËN or a qualifi ed workshop.
The control is located on the driver's
door, with the electric window controls.
Page 125 of 316
VIII
123
SAFETY
Front airbags
System which protects the head and
chest of the driver and front passen-
ger in the event of a front impact.
The driver's airbag is fi tted in the
centre of the steering wheel; the
front passenger's airbag is fi tted in
the dashboard above the glove box.
Deployment
The airbags are deployed simultane-
ously, unless the passenger's front
airbag is deactivated, in the event of
a serious front impact to all or part of
the front impact zone A
, in the lon-
gitudinal centreline of the vehicle on
a horizontal plane and directed from
the front to the rear of the vehicle.
The front airbag infl ates between the
front occupant of the vehicle and the
dashboard to cushion their forward
movement.
Deactivation
This warning lamp comes on
in the roof console screen
when the ignition is on and
until the airbag is reactivated.
To assure the safety of your child,
the passenger's airbag must be
deactivated when you install a
"rearwards-facing" child seat on
the front passenger seat.
Otherwise, the child would risk be-
ing seriously injured or killed if the
airbag were deployed.
Activation
When you remove the child seat,
turn switch 1
to the "ON"
position to
reactivate the airbag and so assure
the safety of your front passenger in
the event of an impact.
Operating fault
If this symbol appears in the
instrument panel screen,
accompanied by an audible
warning and a message,
contact a CITROËN dealer or a
qualifi ed workshop to have the sys-
tem checked. The airbags may no
longer be deployed in the event of a
serious impact. Only the front passenger's airbag
can be deactivated:
)
with the ignition off
, insert the
key in the passenger airbag de-
activation switch 1
,
)
turn it to the "OFF"
position,
)
then, remove the key keeping
the switch in this position. If this warning lamp fl ashes,
contact a CITROËN dealer
or a qualifi ed workshop.
If both airbag warning lamps come
on continuously, do not install a
"rearwards-facing" child seat on
the front passenger seat.
Have it checked by a CITROËN
dealer or a qualifi ed workshop.
Page 130 of 316
IX!
!
128
DRIVING
Release
The electric parking brake releases
automatically and progressively
when you press the accelerator:
)
with a manual gearbox
(fi rst
gear or reverse gear engaged),
press down fully on the clutch
pedal then press on the accele-
rator pedal and move off.
)
with an automatic gearbox
, ac-
celerate with the selector in posi-
tion D
, M
or R
.
Full release of the parking brake is
confi rmed by:
- warning lamp P
in the
control lever A
going off,
- display of a message "parking
brake off" in the instrument panel
screen.
When stationary, with the engine
running, do not press the accelera-
tor pedal unnecessarily (particularly
when starting the engine, including
in neutral), as you may release the
parking brake.
Do not place any object (packet of
cigarettes, telephone...) between
the gear lever and the electric park-
ing brake control.
Activation / Deactivation of the
automatic functions
Depending on the country of sale,
automatic application when switch-
ing off the engine and automatic
release when moving off can be de-
activated. The activation / deactiva-
tion is done in the instrument panel
screen confi guration menu. Select
"Vehicle parameters / Comfort / Auto
parking brake".
Deactivation of these func-
tions is signalled by this
warning lamp in the instru-
ment panel.
With the automatic functions deac-
tivated, the parking brake must be
applied and released manually.
In some special circumstanc-
es, with the engine not run-
ning, (towing, icy conditions...) the
automatic parking brake can be
released manually, with the key in
the running position.
Manual operation
Manual application / release of the
parking brake is always possible.
Application
With the vehicle stationary, to apply the
parking brake whether the engine is
running or off, pull
on control lever A
.
The application of the parking brake
is confi rmed by:
- warning lamp P
in the con-
trol lever A
coming on,
- display of a message "parking
brake on" in the instrument panel
screen.
When the driver’s door is opened
with the engine running, a mes-
sage is displayed accompanied
by an audible signal if the parking
brake has not been applied.
-
this warning lamp in the in-
strument panel coming on,
- this warning lamp in the in-
strument panel going off,
If the confi guration menu does not
have the option to activate / deac-
tivate the automatic functions, this
can be done by a CITROËN dealer
or a qualifi ed workshop.
Page 137 of 316
IX
135
DRIVING
5-SPEED MANUAL GEARBOX
Starting the vehicle
)
Check that the gear lever is in
neutral.
)
Do not touch the accelerator.
)
For Diesel engines: turn the
key to position M
and wait until
the pre-heating warning lamp
switches off if it has come on.
)
Operate the starter, turning the
key until the engine starts (no
more than ten seconds).
)
In temperatures lower than 0°C,
declutch while operating the
starter to facilitate starting.
Engaging reverse gear
)
Move the gear lever to the right
then back.
Only engage reverse gear when the
vehicle is stationary with the engine
at idle.
6-SPEED MANUAL GEARBOX
Engaging reverse gear
)
Raise the ring under the knob
(indicated by the arrow) and
push the gear lever to the left
then forwards.
Only engage reverse gear when the
vehicle is stationary with the engine
at idle.
As a safety precaution and to facili-
tate starting of the engine:
- always select neutral,
- press the clutch pedal.
Page 143 of 316
IX!
141
DRIVING
STOP & START
The Stop & Start system puts the en-
gine temporarily into standby - STOP
mode - during stops in the traffi c
(red lights, traffi c jams, or other...).
The engine restarts automatically -
START mode - as soon as you want
to move off. The restart takes place
instantly, quickly and silently.
Perfect for urban use, the Stop &
Start system reduces fuel consump-
tion and exhaust emissions as well
as the noise level when stationary.
Operation
- with the electronic gearbox
system
, at speeds below 4 mph
(6 km/h), press the brake pedal or
put the gear lever in position N
.
Going into engine STOP mode
The "ECO"
warning lamp comes
on in the instrument panel and
the engine goes into standby:
If your vehicle is fi tted
with the system, a time
counter calculates the
sum of the periods in
STOP mode during a journey. It rests
itself to zero every time the ignition
is switched on with the key.
For your comfort, during parking
maoeuvres, STOP mode is not
available for a few seconds after
coming out of reverse gear.
STOP mode does not affect the func-
tionality of the vehicle, such as for ex-
ample, braking, power steering...
Never refuel with the engine
in STOP mode; you must
switch off the ignition with the
key.
Special cases: STOP mode not
available
In this case, the "ECO"
warning lamp fl ashes for a
few seconds then goes off.
This operation is perfectly normal.
STOP mode is not invoked when:
- the driver's door is open,
- the driver's seat belt is not fas-
tened,
- the vehicle has not exceeded
6 mph (10 km/h) since the last
engine start using the key,
- the electric parking brake is ap-
plied or being applied,
- the engine is needed to maintain
a comfortable temperature in the
passenger compartment,
- demisting is active,
- some special conditions (battery
charge, engine temperature,
braking assistance, ambient
temperature...) where the engine
is needed to assure control of a
system.
