Automobiles CITROËN declares, by application of the
provisions of the European regulation (Directive 2000/53)
relating to End of Life Vehicles, that it achieves the objectives
set by this regulation and that recycled materials are used in
the manufacture of the products that it sells.
We draw your attention to the following
points:
- The fitting of electrical equipment or accessories not
listed by CITROËN may cause faults and failures with the
electrical system of your vehicle. Contact a CITROËN
dealer for information on the range of recommended
accessories.
- As a safety measure, access to the diagnostic socket,
used for the vehicle's electronic systems, is reserved
strictly for CITROËN dealers or qualified workshops,
equipped with the special diagnostic tool required (risk
of malfunctions of the vehicle's electronic systems that
could cause breakdowns or serious accidents). The
manufacturer cannot be held responsible if this advice is
not followed.
- Any modification or adaptation not intended or authorised
by Automobiles CITROËN or carried out without meeting
the technical requirements defined by the manufacturer
would lead to the suspension of the legal and contractual
warranty.
Reproduction or translation of all or part of this document is
prohibited without written authorisation from Automobiles
CITROËN. Labels are fitted in various areas of your vehicle. They carry
safety warnings as well as vehicle identification information.
Do not remove them: they form an integral part of your
vehicle.
Printed in the EU
Anglais
For any work on your vehicle, use a qualified workshop that
has the technical information, competence and equipment
required, which a CITROËN dealer is able to provide.
8
Practical information
1
Temporary puncture repair kit
All versions * , except BlueHDi
Diesel
BlueHDi Diesel versions
*
Depending on the country of sale.
Access to the kit
This kit is installed in the storage box, under the
boot floor.
This kit consists of a compressor and a sealant
cartridge.
It allows the temporary repair
of a tyre.
You are then able to go to the nearest garage.
It is designed to repair most punctures
which could affect the tyre, located on
the tyre tread or shoulder.
Its compressor can be used to check
and adjust the pressure of the tyre.
Practical information
2
Description of the kit
A.
"Sealant" or "Air" position selector.
B.
On "I"
/ off "O"
switch.
C.
Deflation button.
D.
Pressure gauge (in bar and psi).
E.
Compar tment housing:
- a cable with adaptor for 12 V socket,
- various inflation adaptors for
accessories, such as balls, bicycle
tyres...
F.
Sealant cartridge.
G.
White pipe with cap for repair.
H.
Black pipe for inflation.
I.
Speed limit sticker.
The speed limit sticker I
must be affixed
to the vehicle's steering wheel to remind
you that a wheel is in temporary use.
Do not exceed a speed of 50 mph
(80 km/h) when driving with a tyre
repaired using this type of kit.
The vehicle's electric system allows the
connection of a compressor for long
enough to inflate a tyre after a puncture
repair or for inflating a small inflatable
accessory.
