remote control Citroen C5 DAG 2009.5 (RD/TD) / 2.G User Guide

IV
75
O P E N I N G S
DOORS
Opening
From outside When the selective unlocking is acti-
vated, the fi rst press of the remote
control unlocking button permits
unlocking of the driver's door only.
 Pull on the front door control to
open the door; this unlocks the
vehicle completely.

 Pull on the rear door control to
open the door; this unlocks the
door concerned only.
With the selective unlocking acti-
vated:
- the driver's door control unlocks the driver's door only.
- the other door controls unlock the other doors and the boot.
The interior door controls do not
operate when the vehicle is dead-
locked. Manual centralised control
System which provides full manual
locking or unlocking of the doors
and boot from the inside.
Locking

 Press button A to lock the vehicle.
The red indicator lamp on the button
comes on. It fl ashes when the doors
are locked while stationary with the
engine off.
If one of the doors is open, the cen-
tral locking from the inside does not
take place.

 After unlocking the vehicle com-
pletely using the remote control
or the key, pull the door handle. From inside

IV
76
O P E N I N G S
Unlocking

 Press button A again to unlock
the vehicle.
The red indicator lamp on the button
switches off.
If the vehicle is locked or dead-
locked from the outside, the red in-
dicator lamp fl ashes and button A
is inactive.

 In this case, use the remote
control or the key to unlock the
vehicle.
Automatic central locking
System which provides full automatic locking or unlocking of the doors and
the boot while driving.
You can activate or deactivate this
function. Locking
When the speed exceeds 6 mph
(10 km/h), the doors and the boot
lock automatically.
If one of the doors is open, the auto-
matic central locking does not take
place.
If the boot is open, the automatic
central locking of the doors is active.
Unlocking

 Above 6 mph (10 km/h), press
button A to unlock the doors and
the boot temporarily.
Activation

 Press button A for more than
two seconds.
A confi rmation message appears on
the instrument panel screen, accom-
panied by an audible signal.
Deactivation

 Press button A again for more
than two seconds.
A confi rmation message appears on
the instrument panel screen, accom-
panied by an audible signal. Emergency control
System which locks or unlocks the
doors mechanically in the event of
a malfunction of the battery or of the
central locking.
Locking the driver's door

 Insert the key in the lock, then
turn it to the right.
Unlocking the driver's door

 Insert the key in the lock, then
turn it to the left.
Locking the front and rear
passenger doors

 Insert the key in the lock, located
on the edge of the door, then turn
it one eighth of a turn .
Unlocking the front and rear
passenger doors

 Pull the interior door opening
control.

IV
77
O P E N I N G S
BOOT (SALOON)

 Press upwards on lever 1 and lift
up the boot lid. With the vehicle stationary, this is
carried out using:
- The remote control.
- The key in a door lock.
- The interior central locking/un-
locking control.
The boot automatically locks when
the vehicle is moving at a speed of
over 6 mph (10 km/h), even if auto-
matic central locking is deactivated.
It is unlocked when a door is opened
or when the central locking button is
pressed (speed lower than 6 mph
(10 km/h)).
Opening
Locking/unlocking Emergency tailgate release
System for mechanical unlocking of
the boot in the event of a battery or
central locking malfunction.
Unlocking

 Fold back the rear seats to gain
access to the lock from inside
the boot.

 Insert a small screwdriver into
hole A of the lock to unlock the
tailgate.

 Push the white part, located in-
side the lock, to the left to unlock
the boot.

IV
78
O P E N I N G S
Electric opening
BOOT (TOURER)
Manual opening

 Press upwards on lever A and lift
up the tailgate.

 Press upwards on lever A , or
press button B of the remote
control. Do not attempt to help the opening
of the tailgate manually after press-
ing the control
A .
Manual closing

 Lower the tailgate using the inte-
rior handle C .
Electric closing

 Press the push-button D to close
the tailgate.
Do not interrupt the closing of the
tailgate; if any obstacle prevents it
closing, the operation will stop and
the tailgate will automatically rise
by a few centimetres.
Locking/unlocking
With the vehicle stationary, this is
carried out using:
- The remote control.
- The key in a door lock.
- The interior central locking/un- locking control. Interrupting the opening/
closing of the tailgate
When the tailgate is being opened or
closed electrically, you can interrupt
its movement at any point by press-
ing push-button
D , the control A or
button B .
You can then open or close the tail-
gate electrically or manually, if nec-
essary moving it in the opposite
direction to release it.
The boot automatically locks when
the vehicle is moving at a speed of
over 6 mph (10 km/h), even if auto-
matic central locking is deactivated.
It is unlocked when a door is opened
or when the central locking button
is pressed (at a speed of less than
6 mph (10 km/h)).
Memorisation of an
intermediate position
You can store an opening angle for
the tailgate:

 Manually or automatically move
the tailgate to the required posi-
tion.

 Make a long press on push-but-
ton D . The system emits a short
audible beep.

 Release the push-button D .

V
92
V I S I B I L I T Y
Special position of the
windscreen wipers
This position permits release of the
windscreen wiper blades.
It is used for cleaning or replacement
of the blades. It can also be useful,
in winter, to detach the blades from
the windscreen.
In the moment following switching
off of the ignition, any action on the
stalk positions the wipers vertically
on the windscreen. To park the wipers after this has
been done, switch on the ignition
and operate the stalk.
For maintain the effectiveness of
the "fl at-blade" wiper blades, it is
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- avoid using them to retain card- board on the windscreen.
- replace them at the fi rst signs of wear.
COURTESY LAMPS

1. Front courtesy lamp

2. Map reading lamp s
Front courtesy lamp
Rear courtesy lamp

1. Rear courtesy lamp

2. Map reading lamps In this position, the courtesy
lamp comes on gradually:
Permanently off.
Permanent lighting.
- when the vehicle is unlocked,
- when a door is opened,
- when the key is removed from
the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is closed.

V
92
V I S I B I L I T Y
Special position of the
windscreen wipers
This position permits release of the
windscreen wiper blades.
It is used for cleaning or replacement
of the blades. It can also be useful,
in winter, to detach the blades from
the windscreen.
In the moment following switching
off of the ignition, any action on the
stalk positions the wipers vertically
on the windscreen. To park the wipers after this has
been done, switch on the ignition
and operate the stalk.
For maintain the effectiveness of
the "fl at-blade" wiper blades, it is
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- avoid using them to retain card- board on the windscreen.
- replace them at the fi rst signs of wear.
COURTESY LAMPS

1. Front courtesy lamp

2. Map reading lamp s
Front courtesy lamp
Rear courtesy lamp

1. Rear courtesy lamp

2. Map reading lamps In this position, the courtesy
lamp comes on gradually:
Permanently off.
Permanent lighting.
- when the vehicle is unlocked,
- when a door is opened,
- when the key is removed from
the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is closed.

V
92
V I S I B I L I T Y
Special position of the
windscreen wipers
This position permits release of the
windscreen wiper blades.
It is used for cleaning or replacement
of the blades. It can also be useful,
in winter, to detach the blades from
the windscreen.
In the moment following switching
off of the ignition, any action on the
stalk positions the wipers vertically
on the windscreen. To park the wipers after this has
been done, switch on the ignition
and operate the stalk.
For maintain the effectiveness of
the "fl at-blade" wiper blades, it is
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- avoid using them to retain card- board on the windscreen.
- replace them at the fi rst signs of wear.
COURTESY LAMPS

1. Front courtesy lamp

2. Map reading lamp s
Front courtesy lamp
Rear courtesy lamp

1. Rear courtesy lamp

2. Map reading lamps In this position, the courtesy
lamp comes on gradually:
Permanently off.
Permanent lighting.
- when the vehicle is unlocked,
- when a door is opened,
- when the key is removed from
the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is closed.

IV
76
A C C E S S
Unlocking

 Press button A again to unlock
the vehicle.
The red indicator lamp on the button
switches off.
If the vehicle is locked or deadloc-
ked from the outside, the red indi-
cator lamp fl ashes and button A is
inactive.

 In this case, use the remote
control or the key to unlock the
vehicle.
Automatic central locking
System which provides full automa-
tic locking or unlocking of the doors
and the boot while driving.
You can activate or deactivate this
function. Locking
When the speed exceeds 6 mph
(10 km/h), the doors and the boot
lock automatically.
If one of the doors is open, the auto-
matic central locking does not take
place.
If the boot is open, the automatic
central locking of the doors is ac-
tive.
Unlocking

 Above 6 mph (10 km/h), press
button A to unlock the doors and
the boot temporarily.
Activation

 Press button A for more than two
seconds.
A confi rmation message appears on
the instrument panel screen, accom-
panied by an audible signal.
Deactivation

 Press button A again for more
than two seconds.
A confi rmation message appears on
the instrument panel screen, accom-
panied by an audible signal.
Emergency control
To lock or unlock the doors manually
in the event of a malfunction of the
central locking system or battery
failure. Locking the driver's door

 Insert the key in the lock, then
turn it to the right.
Unlocking the driver's door

 Insert the key in the lock, then
turn it to the left.
Locking the front and rear
passenger doors

 Remove the black cap, located
on the edge of the door, using
the key.

 Insert the key in the socket, then
turn it as far as it will go.

 Remove the key and refi t the
cap.

 On the rear doors, check that the
child lock is not activated.
Unlocking the front and rear
passenger doors

 Pull the interior door opening
control.
