Foglamps selection ring.
The foglamps operate with the side-
lamps and the dipped and main
beam headlamps.


-
1 st turn forwards: rear foglamps on.


- 1 st turn rearwards: rear foglamps off.




- 1st turn forwards: front foglamps on.


- 2nd turn forwards: rear foglamps on.


- 1st turn rearwards: rear foglamps off.


- 2nd turn rearwards: front foglamps
off.



Model with rear foglamps
only
Model with front and rear
foglamps





In good or rainy weather, both day
and night, use of the front foglamps
and the rear foglamps is prohibited.
In these situations, the power of their
beams may dazzle other drivers.
They should only be used in fog or
falling snow.
In these weather conditions, it is
your responsibility to switch on the
foglamps and dipped headlamps
manually as the sunshine sensor
may detect suffi cient light.
Do not forget to switch off the front
and rear foglamps when they are
no longer needed.

Lighting left on
When a front door is opened with
the ignition off and in manual ligh-
ting mode, an audible signal warns
the driver if the vehicle's lighting is
still on.
In this case, switching off the ligh-
ting stops the audible signal.
With the ignition off, if the dipped
headlamps remain on, they will
switch off automatically after thirty
minutes to prevent discharging of
the battery.

V
91
VISIBILITY

Linked with the automatic
"Guide-me-home" lighting
The link with the automatic illumi-
nation of headlamps provides the
"guide-me-home" lighting with the
following additional options:


- selection of the duration of ligh-
ting for 15, 30 or 60 seconds in
the vehicle parameters on the in-
strument panel screen confi gu-
ration menu,

- automatic activation of "guide-
me-home" lighting when auto-
matic illumination of headlamps
is in operation.


Operating fault
In the event of a fault with the sun-
shine sensor, the lighting comes on
and a message appears in the instru-
ment panel screen, accompanied by
an audible signal.
Contact a CITROËN dealer or a
qualifi ed workshop.
In fog or snow, the sunshine sen-
sor may detect suffi cient light.
Therefore, the lighting will not
come on automatically.
Do not cover the sunshine sen-
sor, linked with the rain sensor and
located in the centre of the wind-
screen behind the rear view mirror;
the associated functions would no
longer operate.







MANUAL HEADLAMP
ADJUSTMENT
To avoid dazzling other road users,
the height of the halogen bulb head-
lamps must be adjusted according
to the load in the vehicle.

0.
1 or 2 people in the front seats.

-. 3 people.

1.
5 people.

-. Intermediate setting.

2.
5 people + maximum authorised
loads.

-. Intermediate setting.

3.
Driver + maximum authorised
loads.
Initial setting is position "0"
.












AUTOMATIC ADJUSTMENT
OF DIRECTIONAL
HEADLAMPS
Do not touch the xenon bulbs.
Contact a CITROËN dealer or a
qualifi ed workshop. If a fault occurs, this
warning lamp comes
on in the instrument
panel, accompanied by an audible signal and a
message in the instru-
ment panel screen.
The system then places your head-
lamps in the lowest position. To avoid causing a nuisance to other
road users, this system corrects
the height of the xenon headlamp
beams automatically and when sta-
tionary, depending on the load in the
vehicle.

V
95
VISIBILITY

Reverse gear
When reverse gear is engaged, the
rear wiper operates if the windscreen
wipers are operating.

Programming
The function is activated or deac-
tivated via the instrument panel
screen confi guration menu.
This function is activated by default.











Windscreen and headlamp
wash


)
Pull the windscreen wiper stalk
towards you. The windscreen
wash then the windscreen wip-
ers operate for a fi xed period.
The headlamp washers only operate
when the dipped beam headlamps
are on
.













Automatic rain sensitive
windscreen wipers
The windscreen wipers operate au-
tomatically, without any action on the
part of the driver, if rain is detected
(sensor behind the rear view mirror),
adapting their speed to the intensity
of the rainfall.

Activation
This is controlled manually by the
driver by moving stalk A
to the
"AUTO"
position.
It is accompanied by a message in
the instrument panel screen.
Switching off
This is controlled manually by the
driver by moving stalk A
upwards
and returning it to position "0"
.
It is accompanied by a message in
the instrument panel screen.
The automatic wiping must be reac-
tivated if the ignition has been off for
more than one minute, by pushing
stalk A
downwards.

Operating fault
If an automatic wiping malfunction
occurs, the wipers will operate in in-
termittent mode.
Have it checked by a CITROËN
dealer or a qualifi ed workshop.
Do not cover the rain sensor, linked
with the sunshine sensor and loca-
ted in the centre of the windscreen
behind the rear view mirror.
Switch off the automatic wip-
ing when using an automatic car
wash.
In winter, it is advisable to wait until
the windscreen is completely clear
of ice before activating the auto-
matic wiping.

VIII
11 7
SAFETY








TYRE UNDER-INFLATION
DETECTION
System which automatically checks
the pressures of the tyres while
driving.

Tyre pressures OK display

Choice of detection

This function provides warning of
tyres that are under-infl ated or punc-
tured.

Automatic detection
Sensors monitor the tyre pressures.
In the event of an anomaly, a mes-
sage will appear in the instrument
panel screen.

Driver request detection
You can check the tyre pressures at
any time.


)
Press on button A
(CHECK); the
information will be displayed in
the instrument panel screen.



)
Press on button A
(CHECK).
The system indicates to you that the
tyres are correctly infl ated.
This information is only available on
request by the driver.


Under-inflated tyre


automatic detection


detection on request


Automatic detection:
A message indicates which tyre is
under-infl ated.

Driver request detection:
The vehicle outline indicates the un-
der-infl ated tyre(s).
The message is accompanied by il-
lumination of the SERVICE
warning
lamp and an audible beep.


)
Check the tyre pressures as
soon as possible.

VIII
118
SAFETY

Punctured tyre


automatic detection


detection on request


Automatic detection:
A message indicates which tyre is
punctured.

Driver request detection:
The vehicle outline indicates the
punctured tyre(s).
The message is accompanied by
illumination of the STOP
warning
lamp and an audible beep.



Wheel not monitored


automatic detection


detection on request


Automatic detection:
A message indicates to you which
wheel is not monitored.

Driver request detection:
The vehicle outline indicates the
wheel(s) which is/are not monitored.


)
The message is accompanied
by illumination of the SERVICE

warning lamp and an audible
beep. have it checked by a
CITROËN dealer or a qualifi ed
workshop. The defl ation detection system is a
driving aid, but which does not ab-
solve the driver from the need to be
vigilant and responsible.
This system does not dispense
with the requirement to check
the tyres on a regular basis (see
"Identifi cation markings") to ensure
optimum vehicle behaviour and to
avoid premature tyre wear under
certain conditions (high load, high
speed).
Do not forget to check the tyre
pressure of the spare wheel .
Any repair or replacement of a tyre
on a wheel that is equipped with
a sensor must be carried out by
a CITROËN dealer or a qualifi ed
workshop.
The system may suffer from tem-
porary interference caused by
electro-magnetic transmissions on
frequencies close to that use by
the system .




)
If you have fi tted wheels that
are not equipped with tyre defl a-
tion detection (wheels with snow
tyres, etc.), contact a CITROËN
dealer or a qualifi ed workshop.

IX
156
DRIVING





LANE DEPARTURE
WARNING SYSTEM
System which detects the involun-
tary crossing of longitudinal traffi c
lane markings on the ground (solid
or broken line).
Sensors, fi tted below the front
bumper, trigger a warning if the vehi-
cle drifts over a lane marking (speed
higher than 50 mph (80 km/h)).
This system is particularly useful on
motorways and main roads.

Activation



)
Press this button, the indicator
lamp comes on.



Deactivation



)
Press this button again, the indi-
cator lamp goes off.
The status of the system remains
in the memory when the ignition is
switched off.


Detection

You are warned by the vibration of
the driver’s seat cushion:


- on the right-hand side, if the
marking on the ground has been
crossed on the right,

- on the left-hand side, if the mark-
ing on the ground has been
crossed on the left.
No warning is transmitted while the
direction indicator is active and for
approximately 20 seconds after the
direction indicator is switched off.
A warning may be transmitted if a direc-
tion marking (e.g. arrow) or non-standard
marking (e.g. graffi ti) is crossed.


Operating fault

In the event of a malfunction, the
service warning lamp comes on, ac-
companied by an audible signal and
a message in the screen.
Contact a CITROËN dealer or a
qualifi ed workshop. The lane departure warning sys-
tem cannot, in any circumstances,
replace the need for vigilance and
responsibility on the part of the
driver.

The detection may be impeded:


- if the sensors are dirty (mud,
snow...),

- if the markings on the ground
are worn,

- if there is little contrast between
the markings on the ground and
the road surface.

IX
157
DRIVING





PARKING SPACE SENSOR

System which measures the parking
space available between two vehi-
cles or obstacles. It measures the
size of the space and gives you in-
formation on:


- the possibility of fi tting into a
free space, depending on the
dimensions of your vehicle and
the distances necessary for your
manoeuvring,

- the level of diffi culty of the ma-
noeuvre to be performed.
The system does not measure spac-
es which are clearly much smaller or
larger than the size of the vehicle.

Displays in the instrument panel

The parking space sensor function
warning lamp can have three different
states:


- off:
the function is not selected,

- on fi xed:
the function is selected
but the conditions for measuring
are not yet met (direction indi-
cator not operating, speed too
high) or the measurement is ter-
minated.

- fl ashing:
measurement is in
progress or the message is be-
ing displayed. You can select the "parking space
sensor" function by pressing but-
ton A.
The fi xed illumination of the
warning lamp indicates that the
function is selected.
During the measurement, the mes-
sage "Measurement in progress -
Vmax 20 km/h (12 mph)" is displayed in the instrument panel screen.

IX
158
DRIVING

Operation

You have identifi ed a parking space:


)

Press button A
to select the function.


)
Activate the direction indicator
on the side where the space is to
be measured.

)
During measurement, go forward
the length of the space, at a speed
less than 12 mph (approx. 20 km/h),
to prepare for your manoeuvre.
The system then measures the size
of the space.

)

The system informs you of the level of
diffi culty of the manoeuvre via a mes-
sage in the instrument panel screen
accompanied by an audible signal.

)
Depending on the message issued
by the system, you may or may not
be able to perform the manoeuvre.
The function displays the following
types of message:

Parking YES


Parking
DIFFICULT


Parking NO
The function deselects itself auto-
matically:


- when you engage reverse gear,

- when you switch off the ignition,

- if measurement is not requested,

- within fi ve minutes of selection of
the function,

- if the vehicle speed exceeds the
threshold of 45 mph (approx.
70 km/h) for one minute.
If the lateral distance between your
vehicle and the parking space is too
large, the system may not be able to
measure the space.
The function remains available af-
ter each measurement and thus can
measure more than one space during
your search.
In bad weather conditions or in
winter, make sure that the sensors
are not covered by dirt, or by ice or
snow.
The parking space sensor function
deactivates the front parking sensors
during space measurement when
you are in forward gear.
If there is a fault, have the system
checked by a CITROËN dealer or
a qualifi ed workshop.

IX
159
DRIVING
The parking sensors system cannot,
in any circumstances, replace the
need for vigilance and responsibility
on the part of the driver.





VISUAL AND AUDIBLE
FRONT AND/OR REAR
PARKING SENSORS
System consisting of proximity sensors,
installed in the front and/or rear bumper.
It detects any obstacle (person, ve-
hicle, tree, barrier...) located in front of
or behind the vehicle, however, it will
not be able to detect obstacles located
immediately below the bumper.
An object, such as a stake, a road-
works cone or any other similar ob-
ject may be detected at the start of
the manoeuvre but may no longer
be detected when the vehicle moves
nearer to it. The parking sensors are switched on
:


- by engaging reverse gear,

- at a speed below 6 mph (10 km/h)
in forward gear.
This is accompanied by an audible
signal and/or displaying of the vehi-
cle on the multifunction screen.
The proximity information is indicated by:



- an audible signal which be-
comes more rapid as the vehicle
approaches the obstacle,

- a diagram on the multifunction
display, with blocks which move
closer to the vehicle.
The obstacle is located in relation to
the emission of the audible signal by
the speakers; front or rear and right
or left.
When the distance between the ve-
hicle and the obstacle is less than
approximately thirty centimetres,
the audible signal becomes con-
tinuous and/or the "Danger" symbol
appears, depending on the multi-
function screen version.
The parking sensors are switched off
:



- when you exit reverse gear,

- when the speed is higher than
6 mph (10 km/h) in forward gear,

- when the vehicle has been station-
ary for more than three seconds in
forward gear.
Deactivation


)
Press button A
, the warning lamp
comes on, the system is fully de-
activated.
The system will be deactivated au-
tomatically when a trailer is being
towed or when a bicycle carrier is
fi tted (vehicle fi tted with a towbar
or bicycle carrier recommended by
CITROËN).

IX
160
DRIVING

Reactivation

In bad weather or in winter, ensure
that the sensors are not covered
with mud, ice or snow. When re-
verse gear is engaged, an audible
signal (long beep) indicates that the
sensors may be dirty.
When the speed of the vehicle is
below about 6 mph (10 km/h), some
sources of noise (motorcycle, lorry,
pneumatic drill, ...) may trigger the
audible parking sensor signals.


)
Press button A
again, the warning
lamp switches off, the system is
reactivated.









"HYDRACTIVE III +"
ELECTRONIC SUSPENSION
The suspension automatically and
instantly adjusts to different driving
styles and to the profi le of the road,
providing the best compromise be-
tween occupant comfort and vehicle
road holding.
The system alternates between soft
and fi rm suspension settings, maxi-
mising comfort at the same time as
constantly ensuring the highest level
of safety. It also automatically cor-
rects ride height, according to the
vehicle load and driving conditions.
In addition, the "Hydractive III +" sys-
tem allows you to choose between
two modes of suspension.
A change of suspension mode can
be made either when the vehicle is
moving or when stationary, by press-
ing button A
.


Display in the instrument
panel
The suspension mode selected is
displayed in the instrument panel
screen.

Normal mode
This mode favours soft
damping for maximum com-
fort.
If the speed authorised for a
particular position is exceeded,
the vehicle reverts automatically to the
normal road position.


SPORT mode
This mode favours dynamic
driving.

The warning lamp on button A

comes on in addition to the
message in the instrument
panel screen.

SPORT
mode is retained when you
switch off the engine.
