32
II
I N S T R U M E N T P A N E L
MAINTENANCE INDICATOR
It informs you when the next routine service is due in accordance with the vehicle servicing schedule in the Maintenance and Warranty Guide. This information is dependent on two parameters: the mileage covered, and the time elapsed since the last visit.
Operation
From switching on the ignition and for a few seconds, the span-ner symbolising maintenance operations lights up; the instru-ment panel tells you the distance remaining to the next service.
Example: there remain up to the next service:
A few seconds after this, the engine oil level indicator is displayed, then the total mileage recorder resumes its normal role. The instrument panel gives the total and trip mileages.
Operation if the distance to the next service is less than 600 miles
Each time you switch on the igni-tion and for 5 seconds, the span-ner and the distance fl ash.
Example: there remain up to the next service: 500 miles. On switch-ing on the ignition and for 5 seconds, the instrument panel indicates:
A few seconds after this, the engine oil level indicator is displayed, then the total mileage recorder resumes its normal role and the mainte-nance symbol remains lit up.
This is a warning to you that a service must be carried out at the earliest opportunity.
The instrument panel gives the total and trip mileages.
Operation if the service interval has been passed
Each time you switch on the igni-tion, the maintenance symbol and the distance covered (preceded by a minus) beyond the recom-mended interval fl ash.
Example: You have exceeded the service interval by 300 miles.
The routine service on your vehi-cle needs to be carried as soon as possible.
A few seconds after switching on the ignition, the total mile-age recorder resumes its normal role and the maintenance symbol remains lit up.
