SAFETY
87
Parking assistance
4
FRONT AND/OR REAR
PARKING ASSISTANCE
I f fi t t e d o n y o u r v e h i c l e , t h e s y s t e m i s
audible and/or visual and consists of
four proximity sensors, located in the
f r o n t a n d / o r r e a r b u m p e r . T h e s e n s o r s
detect any obstacle which enters
t h e fi e l d : p e r s o n , v e h i c l e , t r e e , g a t e ,
located in front of or behind the vehicle
d u r i n g t h e m a n o e u v r e .
Objects the size or thickness of which
is detected at the beginning of the
manoeuvre, may no longer be detected
at the end of the manoeuvre: due to
blind spots between and below the
s e n s o r s . E x a m p l e s : s t a k e , r o a d w o r k s
c o n e , k e r b s t o n e .
This system does not take the place of
the vigilance and responsibility of the
d r i v e r . Switching the system on
The system is activated as soon as:
- reverse gear is engaged,
- the speed falls below 6 mph
( 1 0 k m / h ) i n f o r w a r d g e a r .
This is accompanied by an audible
signal and displaying of the vehicle,
d e p e n d i n g o n t h e d i s p l a y .
The proximity information is given by:
- an audible signal, which becomes more rapid as the vehicle
approaches the obstacle,
- a graphic on the display, with blocks which become progressively
c l o s e r t o t h e v e h i c l e .
The obstacle is located in relation to the
emission of the audible signal from the
s p e a k e r s , f r o n t o r r e a r a n d r i g h t o r l e f t . Switching the system off
Press the button again to re-activate
t h e s y s t e m . T h e i n d i c a t o r l i g h t o n t h e
b u t t o n s w i t c h e s o f f .
In bad or wintry weather, ensure
that the sensors are not covered
w i t h m u d , f r o s t o r s n o w .
I n t h i s c a s e ( e . g . s e n s o r s d i r t y ) , w h e n
reverse gear is engaged, the indicator
l i g h t fl a s h e s , a c c o m p a n i e d b y a n a u d i b l e
s i g n a l a n d a m e s s a g e o n t h e d i s p l a y .
C o n s u l t a C I T R O Ë N d e a l e r .
Deactivation
Press the button on the fascia
to deactivate the system
( t o a v o i d w a k i n g a c h i l d . . . ) .
The indicator light on the
b u t t o n c o m e s o n .
The system returns to the inactive
status:
- when you exit reverse gear,
- when the speed increases to above
6 mph (10 km/h),
- at the end of the manoeuvre, when the vehicle becomes stationary
( f r o n t p a r k i n g a s s i s t a n c e o n l y ) .
RE-ACTIVATION
When the distance between the vehicle
and the obstacle is less than approximately
thirty centimetres, the audible signal
becomes continuous and the "Danger"
s y m b o l a p p e a r s d e p e n d i n g o n t h e d i s p l a y .
This function will be deactivated
automatically when the vehicle is
towing a trailer or when a bicycle
c a r r i e r i s fi t t e d ( v e h i c l e fi t t e d w i t h
towing attachment or bicycle carrier
r e c o m m e n d e d b y C I T R O Ë N ) .
