Citroen DS3 2010 1.G Owners Manual

113Visibility
Interior mood lighting
The dimmed passenger compartment lighting improves visibility in the vehicle when the light is poor.
Switching on
At night, the illumination of footwells and the central dashboard storage compar tment comes on automatically when the sidelamps are switched on.
Switching off
The interior mood lighting switches off automatically when the sidelamps are switched off. It can be switched off manually using the instrument panel lighting rheostat button.  With the lighting on, press several times on the left hand button of the instrument panel to progressively reduce the dashboard lighting level.  Press again to reduce the lighting level to the minimum and switch off the interior mood lighting.
This comes on automatically when the boot is opened and switches off automatically when the boot is closed.
Boot lamp
Different lighting times are provided: - when the ignition is off,
approximately ten minutes, - in energy economy mode, approximately thir ty seconds, - when the engine is running, no limit.

Interior fi ttings
1. Sun visor (see details on the following page) 2. Glove box (see details on the following page) 3. Oddments storage4. Door tray5. Upper storage compar tment6. Lower storage compar tment with non-slip mat7. USB por t/auxiliar y socket (see details on the following pages) 8. 12 V accessories socket (see details on following pages) 9. Centre armrest with storage (see details on the following page) or Cup/bottle holder

Fittings
Component which protects against sunlight from the front or the side, also equipped with an illuminated cour tesy mirror.  With the ignition on, raise the concealing flap; the mirror is lit automatically. This sun visor is also equipped with a ticket holder.
Sun visor Glove box
 To open the glove box, raise the handle. It houses the front passenger airbag deactivation switch A . It gives access to the dashboard fusebox (see the "Practical information - § Changing a fuse" section).
Centre armrest
Storage
 For access to the closed storage box, lift the lever to open the lid.  For access to the open storage box below
the armrest, lift the complete armrest towards the rear. These can be used for por table devices (mobile phone, MP3 player...) which can be connected to the USB por t /auxiliary socket or charged from the 12 V socket in the centre console.
Comfor t and storage system for the driver and front passenger.

Auxiliary socket
The auxiliary socket is located in the " AUX "box on the centre console. It permits the connection of a por table device, such as a digital audio player of the iPod ® type, to listen to your music files using the vehicle's speakers.
USB Player
For more information on the use of this equipment, refer to the MyWay or Audio system
par t of the "Audio and Telematics" section.
When it is in use, the por table device charges automatically.
The USB por t is located in the "AUX" box on the centre console. It permits the connection of a por table device, such as a digital audio player of the iPod ®
generation 5 and later type or USB memory stick type. It reads the audio file formats (mp3, ogg, wma, wav...) which are transmitted to your audio equipment and played via the vehicle's speakers. You can manage these files using the steering mounted controls or the audio equipment control panel and display them on the multifunction screen.
For more information on the use of this equipment, refer to the Audio system par t of the "Audio and Telematics" section.
12 V accessory
socket
 To connect a 12 V accessory (max power: 120 W), lift the cover and connect a suitable adaptor.
The management of the files is done using your por table device.

Fittings
Mats
Removable carpet protection.
When fitting the mat for the first time, on the driver's side use only the fixings provided in the wallet attached. The other mats are simply placed on the carpet.
Fitting Removal
To remove the mat on the driver's side:  move the seat as far back as possible,
 unclip the fixings,  remove the mat.
Refitting
To refit the mat on the driver's side:  position the mat correctly,  refit the fixings by pressing,  check that the mat is secured correctly.
To avoid any risk of jamming of the pedals: - only use mats which are suited to the fixings already present in the vehicle; it is imperative that these are used, - never fit one mat on top of another.

Fittings
Component which protects against sunlight from the front or the side, also equipped with an illuminated cour tesy mirror.  With the ignition on, raise the concealing flap; the mirror is lit automatically. This sun visor is also equipped with a ticket holder.
Sun visor Glove box
 To open the glove box, raise the handle. It houses the front passenger airbag deactivation switch A . It gives access to the dashboard fusebox (see the "Practical information - § Changing a fuse" section).
Centre armrest
Storage
 For access to the closed storage box, lift the lever to open the lid.  For access to the open storage box below
the armrest, lift the complete armrest towards the rear. These can be used for por table devices (mobile phone, MP3 player...) which can be connected to the USB por t /auxiliary socket or charged from the 12 V socket in the centre console.
Comfor t and storage system for the driver and front passenger.

Auxiliary socket
The auxiliary socket is located in the " AUX "box on the centre console. It permits the connection of a por table device, such as a digital audio player of the iPod ® type, to listen to your music files using the vehicle's speakers.
USB Player
For more information on the use of this equipment, refer to the MyWay or Audio system
par t of the "Audio and Telematics" section.
When it is in use, the por table device charges automatically.
The USB por t is located in the "AUX" box on the centre console. It permits the connection of a por table device, such as a digital audio player of the iPod ®
generation 5 and later type or USB memory stick type. It reads the audio file formats (mp3, ogg, wma, wav...) which are transmitted to your audio equipment and played via the vehicle's speakers. You can manage these files using the steering mounted controls or the audio equipment control panel and display them on the multifunction screen.
For more information on the use of this equipment, refer to the Audio system par t of the "Audio and Telematics" section.
12 V accessory
socket
 To connect a 12 V accessory (max power: 120 W), lift the cover and connect a suitable adaptor.
The management of the files is done using your por table device.

Fittings
Mats
Removable carpet protection.
When fitting the mat for the first time, on the driver's side use only the fixings provided in the wallet attached. The other mats are simply placed on the carpet.
Fitting Removal
To remove the mat on the driver's side:  move the seat as far back as possible,
 unclip the fixings,  remove the mat.
Refitting
To refit the mat on the driver's side:  position the mat correctly,  refit the fixings by pressing,  check that the mat is secured correctly.
To avoid any risk of jamming of the pedals: - only use mats which are suited to the fixings already present in the vehicle; it is imperative that these are used, - never fit one mat on top of another.

1. Rear parcel shelf (see the following page for details) 2. Retaining strap3. Location for Hi- Fi amplifier4. Stowing rings5. Storage box (version equipped with a temporar y puncture repair kit) (see the following page for details) or Tool box (version equipped with a spare wheel) (refer to section "Practical Information - § Changing a wheel")

Boot fi ttings

Fittings
To remove the shelf:  unhook the two cords,  raise the shelf slightly, then unclip it on each side.
Rear parcel shelf
 Raise the boot carpet by pulling the strap upwards to gain access to the storage box. This has areas for storing a temporary puncture repair kit, a box of spare bulbs, a first aid kit,
two warning triangles, ...
Storage box
 refit the boot floor carpet by folding it slightly in the middle.
