23

Limit the causes of excess
consumption

Spread loads throughout the vehicle; place the
heaviest items in the bottom of the boot, as
close as possible to the rear seats.
Limit the loads carried in the vehicle and
reduce wind resistance (roof bars, roof rack,
bicycle carrier, trailer...). Use a roof box in
preference.
Remove roof bars and roof racks after use.

At the end of winter, remove snow tyres and
refit your summer tyres.



Observe the recommendations
on maintenance

Check the tyre pressures regularly, when
cold, referring to the label in the door
aperture, driver's side.
Carry out this check in par ticular:


- before a long journey,

- at each change of season,

- after a long period out of use.
Don't forget the spare wheel and the tyres on
any trailer or caravan.

Have your vehicle ser viced regularly (engine
oil, oil filter, air filter...) and obser ve the
schedule of operations recommended by the
manufacturer.



When refuelling, do not continue after the 3 rd
cut-off of the nozzle to avoid any over flow.

At the wheel of your new vehicle, it is only
after the first 1 800 miles (3 000 kilometres)
that you will see the fuel consumption settle
down to a consistent average.

Switch off the headlamps and front foglamps
when the level of light does not require their
use.

Avoid running the engine before moving off,
particularly in winter; your vehicle will warm
up much faster while driving.

As a passenger, if you avoid connecting
your multimedia devices (film, music, video
game...), you will contribute towards limiting
the consumption of electrical energy, and so
of fuel.
Disconnect your portable devices before
leaving the vehicle.

35Monitoring










Warning lamps

When the engine is running or the vehicle is
being driven, the illumination of one of the
following warning lamps indicates a fault which
requires action on the par t of the driver. Any fault resulting in the illumination of a warning lamp must be investigated fur ther by
reading the associated message in the multifunction screen.
If you encounter any problems, do not hesitate to contact a CITROËN dealer or a qualified
workshop.



Warning lamp



is on



Cause



Action/Observations








STOP


fixed, alone or
associated with
another warning lamp,
accompanied by an
audible signal and
a message on the
screen. Illumination of the warning lamp is
associated with a serious braking
system or engine coolant temperature
problem. Stop as soon as it is safe to do so as the engine may
cut out when driving.
Park, switch off the ignition and call a CITROËN dealer
or a qualified workshop.





Service


temporarily. Minor problems have occurred for
which there is no specific warning
lamp. Identify the problem by reading the message shown in
the screen, such as, for example:


- the engine oil level,

- the screenwash level,

- the remote control battery,

- saturation of the par ticle emission filter on Diesel
vehicles (see "Checks - § par ticle emissions
filter").
For any other faults, contact a CITROËN dealer or a
qualified workshop.

fixed. Major problems have occurred for
which there is no specific warning
lamp. Identify the problem by reading the message shown
in the screen and contact a CITROËN dealer or a
qualified workshop.

181Checks














Petrol engines



1.
Screenwash fluid reservoir.

2.
Coolant header tank.

3.
Air filter.

4.
Brake fluid reser voir.

5.
Battery.

6.
Fusebox.

7.
Engine oil dipstick.

8.
Engine oil filler cap.

Diesel engines



1.
Screenwash fluid reservoir.

2.
Coolant header tank.

3.
Air filter.

4.
Brake fluid reser voir.

5.
Battery.

6.
Fusebox.

7.
Engine oil dipstick.

8.
Engine oil filler cap.

9.
Priming pump (on fuel filter).

185Checks









Diesel additive level
(Diesel engine with particle
emission filter)

Topping up

This additive must be topped up by a CITROËN
dealer or a qualified workshop without delay.











Used products

Avoid prolonged contact of used oil or
fluids with the skin.
Most of these fluids are harmful to
health or indeed very corrosive.
Do not discard used oil or fluids into
sewers or onto the ground.
Take used oil to a CITROËN dealer or
a qualified workshop (France) or to an
authorised waste disposal site. A additive reser voir low level is
indicated by fixed illumination of
this warning lamp, accompanied by an audible
warning and a message in the multifunction
screen.

Checks


Battery Air filter and passenger compartment filter


Oil filter








Par ticle emission filter (Diesel)

Unless other wise indicated, check these components in accordance with the Warranty and Maintenance Record and according to your engine.
Other wise, have them checked by a CITROËN dealer or a qualified workshop.
The battery does not require any
maintenance.
However, check that the terminals
are clean and correctly tightened,
particularly in summer and winter.
When carrying out work on the battery, refer to
the "Practical information" section for details of
the precautions to be taken before disconnecting
the battery and following its reconnection.


Refer to the Warranty and
Maintenance Record for details of
the replacement inter vals for these
components.
Depending on the environment (e.g. dusty
atmosphere) and the use of the vehicle (e.g.
city driving), replace them twice as often if
necessary
(refer to the "Engines" section).
A clogged passenger compar tment filter may
have an adverse effect on the per formance
of the air conditioning system and generate
undesirable odours.


Replace the oil filter each time the
engine oil is changed.
Refer to the Warranty and
Maintenance Record for details of
the replacement inter val for this
component.





The presence of this label, in particular with
the Stop & Star t system, indicates the use of
a specific 12 V lead-acid battery with special
technology and specification, for which the
involvement of a CITROËN dealer or a qualified
workshop is required when replacing or
disconnecting the battery.
Failure to obser ve this recommendation may
shor ten the life of the battery. The star t of saturation of the
par ticle filter is indicated by the
temporary illumination of this warning lamp
accompanied by a message in the multi-
function screen.
As soon as the traffic conditions permit,
regenerate the filter by driving at a speed of at
least 40 mph (60 km/h) until the warning lamp
goes off.
If the warning lamp stays on, this indicates a
low additive level.

On a new vehicle, the first par ticle
filter regeneration operations may be
accompanied by a "burning" smell,
which is per fectly normal.
Following prolonged operation of the
vehicle at very low speed or at idle,
you may, in exceptional circumstances,
notice the emission of water vapour at
the exhaust on acceleration. This does
not affect the behaviour of the vehicle
or the environment.

Fuse table



Fuse N°



Rating


Functions



F1



20 A

Engine control unit supply, cooling fan unit control relay, multifunction engine control main relay, injection pump
(Diesel).


F2



15 A

Horn.


F3



10 A

Front/rear screenwash.


F4



20 A

LED lamps.


F5



15 A

Diesel heater (Diesel), par ticle filter additive pump (Diesel), air flow sensor (Diesel), blow-by heater and
electrovalves (VTi).


F6



10 A

ABS/ESP control unit, secondary stop switch.


F7



10 A

Electric power steering, automatic gearbox.


F8



25 A

Starter control.


F9



10 A

Switching and protection unit (Diesel).


F10



30 A

Fuel heater (Diesel), blow-by heater (Diesel), fuel pump (VTi), injectors and ignition coils (petrol).


F11



40 A

Heater blower.

MODELS:



ENGINES AND GEARBOXES



Model codes:


SA...


8FR0



8FR0/P



5FS0



5FS9



5FR8

5FX8 *



PETROL ENGINES


VTi 95



VTi 120



THP 150


Cubic capacity (cc)
1 397
1 598
1 598
Bore x stroke (mm)
77 x 75
77 x 85.8
77 x 85.8
Max power: EU standard (kW)
70
88
115
11 0 *

Max power engine speed (rpm)
6 000
6 000
6 000
Max torque: EU standard (Nm)
13 6
160
240
Max torque engine speed (rpm)
4 000
4 250
1 400
Fuel
Unleaded
Unleaded
Unleaded
Catalytic conver ter
yes

yes
yes

GEARBOX

Manual
(5 -speed)
Electronic
(5 -speed)
Manual
(5 -speed)
Auto
(4 - speed)
Manual
(6 -speed)

OIL CAPACITIES (in litres)




Engine (with filter replacement)
4.25
4.25
4.25
4.25

*
Belgium and Russia only.

231Technical data


ENGINE AND GEARBOX
- R ACING



MODELS:
Model codes: SA...


5FF8



5FD8



PETROL ENGINE








Cubic capacity (cm 3
)

1 598
Bore x stroke (mm)

77 x 85.8
Max power: EU standard (kW)
149
152
Max power engine speed (rpm)
6 000
Max torque: EU standard (Nm)
275
Max torque engine speed (rpm)
2 000
Fuel

Unleaded **

Catalytic conver ter

Ye s

GEARBOX

Manual
(6 -speed)

OIL CAPACITY (in litres)






Engine (with filter replacement)
4.25

**
CITROËN recommends the use of 98 RON unleaded petrol to ensure optimum engine per formance.

MODELS:



ENGINE AND GEARBOX



Model codes:
SA...


8FR0/GPL



LPG ENGINE



VTi 95


Cubic capacity (cc)

1 397
Bore x stroke (mm)

77 x 75
Max. power: EU standard (kW)
70
Max. power speed (rpm)

6 000
Max torque: EU standard (Nm)
13 6
Max. torque speed (rpm)

4 000
Fuel

LPG/Unleaded
Catalytic conver ter

Ye s

GEARBOX

Manual
(5 -speed)

OIL CAPACITY (in litres)




Engine (with filter replacement)
4.25
For more information on the operation and use of your LPG vehicle, refer to the specific inser t attached to the other vehicle documents.
