Remote control key System which permits central unlocking or locking of the vehicle using the lock or from a distance. It is also used to locate and start the vehicle, as well as providing protection against theft.
Unlocking the vehicle
Unfolding the key
)First press this button to unfold the key.


Unlocking using the remote
control


Unlocking using the key
)Press the open padlock to unlockthe vehicle.

)
Turn the key to the left in the driver's door lock to unlock the vehicle.
Unlockin
g is confirmed by rapid flashing of
the direction indicators for approximately
two seconds.
Accordin
g to version, the door mirrors unfoldat the same time.

221Practical information











Battery
Procedure for charging your battery when it is flat or for starting the engine using another battery.
The battery is located under the bonnet.To gain access to it:
)
open the bonnet using the interior releaselever, then the exterior safety catch,)
secure the bonnet stay, )
lift the plastic cover on the (+) terminal.


Access to the battery
)
Connect the red cable to the positive
terminal (+) of the flat battery A, then to the
positive terminal (+) of the slave battery B.

Starting using another
batter
y
After refitting the battery by a CITROËN dealer or a qualifiedworkshop, the Stop & Star t system will only be active after a continuousperiod of immobilisation of the vehicle,a period which depends on the climaticconditions and the state of charge of
the battery (up to about 8 hours).
The presence of this label, in particular with the Stop & Start system, indicatesthe use of a 12 V lead-acid battery withspecial technology and specification;
the involvement of a CITROËN dealer or a qualified workshop is essential when replacing or disconnecting the battery.
Failure to observe this recommendation may cause premature wear of the battery.
)
Connect one end of the green or blackcable to the negative terminal (-) of the slave battery B
. )
Connect the other end of the green or black cable to the remote negative terminal (-) of your vehicle

)Start the slave vehicle.)Operate the star ter of the broken down
vehicle and let the engine run.)Wait until the engine returns to idle anddisconnect the cables.

Charging the battery using
a battery charger

Batteries contain harmful substancessuch as sulphuric acid and lead. Theymust be disposed of in accordancewith regulations and must not, in anycircumstances, be discarded with household waste. Ta k e used remote control batteries andvehicle batteries to a special collectionpoint.
)
Follow the instructions for use provided bythe manufacturer of the charger.
Do not disconnect the battery tocharge it.
Do not push the vehicle to star tthe engine if your vehicle is fitted with an electronic gearbox.

315
Alphabetical index
Replacing the air filter...................................r190Replacing the oil filter...................................r190Replacing the passenger compartment filter......................................r190Replacing wiper blades.........................117, 224Resetting the service indicator.......................r44Resetting the trip recorder..............................r46Rev counter...............................................r28,30Reversing lamp.............................................211Risk areas (update).......................................264Routine checks.....................................190, 191Running out of fuel (Diesel)..........................184
Safety for children..................128 -138, 149, 152Scented air freshener.....................................r77Screen, colour 16/9.........................61,254, 275Screen, monochrome..................286,298, 300Screen, multifunction(with audio equipment) .....................54,57, 61Screen-wash reservoir..................................187Screen menu map........................275,298, 300Screenwash..................................................115Screenwash fluid level..................................188Seat, rear bench .............................................84Seat adjustment........................................79,82Seat belts ...............................................147-149Seats, rear.......................................................r84Serial number, vehicle..................................244Ser vice indicator.............................................r43
S
Servicing.........................................................24Setting the clock...........................274, 296, 297Short-cut menus...................................255,256Sidelamps.....................................108, 209, 211Side repeater.................................................209Spare wheel..................................................200Speed limiter.................................................r174Speedometer............................................r28, 30Stability control (ESP)...................................145Starting the vehicle.........................92, 161,166Steering mounted controls, audio.........253,285Stopping the vehicle .......................92, 161,166Stop & Start .......50, 73, 102, 170, 183, 190, 221Storage ..................................................122, 123Storage box...................................................127Stowing rings ................................................ 126Sun visor.......................................................r123Synchronising the remote control...................94System, navigation........................................257Systems, ASR and ESP................................145U
Temporary tyre repair kit...............................194Third brake lamp...........................................212TMC (Tr a f f i c i n f o) ..........................................265Tools ..............................................................200Total distance recorder...................................r46To w b a r...........................................................r227Towed loads ..........................236, 237, 239, 241Towing another vehicle.................................225Tr a c t i o n c o n t r o l (ASR)..................................145Tr affic information (TA).................266, 267, 288Traffic information (TMC).....................265, 266Tr i p c o m p u t e r......................................r48-50,57Tr i p d i s t a n c e r e c o r d e r.....................................r46Tyre pressures ..............................................244
Tyres ........................................................24, 244
Unlocking........................................................90Unlocking from the inside...............................99Update risk areas..........................................264Updating the date ..........................274,296,297Updating the time..........................274 ,296,297USB Box ........................................................124USB Reader..........................................r124, 290
T
Table of weights....................236, 237, 239, 241Ta b l e s of engines .................234, 235,238, 240Tables of fuses..............................................214Ta n k, fuel...............................................102,104Technical data.......................................234-242Telephone.............................................271, 293Temperature adjustment...........................70,73Temperature control for heated seats............80
V
Ventilation .....................................66,67, 70, 73
