battery CITROEN DS3 CABRIO 2013 Handbook (in English)

CHECKS PRACTICAL
INFORMATIONTECHNICAL DATA AUDIO AND
TELEMATICS
187 Bonnet
188 Running out of fuel (Diesel)
189Petrol engines
190Diesel engines
191Checking levels
194 Checks
198 Temporary puncture repair kit
204 Changing a wheel
211 Changing a bulb
218 Changing a fuse
225 Battery
227Energy economy mode
228Changing a wiper blade
229Towing the vehicle
231To w i ng a trailer
233Advice on care andmaintenance
234 Accessories
238Petrol engines
240Petrol weights
242 LPG engines
243 LPG weights
244Diesel engines
245Diesel weights
246 Dimensions
248 Identifi cation markings
253Emergency or assistance
255 MyWay
287 Audio system
012012013013010010011011

Warning lampis onCauseAction/Observations
Engine oil pressure
fixed. There is a fault with the enginelubrication system. You must stop as soon it is safe to do so.
Park, switch off the ignition and contact a CITROËN
dealer or a qualified workshop.
Battery charge fixed. The battery charging circuit has a fault(dirty or loose terminals, slack or cut
alternator belt, ...). The warnin
g lamp should go off when the engine isstarted.
If it does not go off, contact a CITROËN dealer or aqualified workshop.
Door(s) open
fixed if the speed isbelow 6 mph (10 km/h).

A door or the boot is still open. Close the door or boot.
fixed and accompanied by an audible signal
if the speed is above6 mph (10 km/h).

A few seconds after the ignition is switched
on, the distance recorder resumes its normal
operation.
The spanner remainson.
The distance remaining may be weighted by the time factor, depending on the driver's driving habits.
Therefore, the spanner may also comeon if you have exceeded the two year service interval.
Service indicator zero reset

After each ser vice, the ser vice indicator mustbe reset to zero.
The procedure for resetting to zero is as
follows: ) switch off the ignition,)
press and hold the trip distance recorder
zero reset button,) switch on the ignition; the distance recorder
display begins a countdown,
) when the display indicates "=0", release
the button; the spanner disappears.
Following this operation, if you wish todisconnect the battery, lock the vehicleand wait at least five minutes for thezero reset to be taken into account.


Retrieving the service information

You can access the ser vice information at anytime. )Press the trip distance recorder zero reset button.
The ser vice information is displayed for afew seconds, then disappears.
Service overdue
For a few seconds after the ignition is switched on,the spanner flashes to indicate that the
service must be carried out as soon as possible.Example:the ser vice is overdue by 180 miles(300 km).
For a few seconds after the ignition is switched
on, the display indicates:

Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction, you can no longer unlock, lock or locate your
vehicle.)First of all, use the key in the lock to unlock
or lock your vehicle.
)Then, reinitialise the remote control.
If the problem persists, contact a CITROËN
dealer as soon as possible.
Remote control problem
Reinitialisation
)Switch off the ignition.)Turn the key to position 2 (Ignition).)Press the closed padlock immediately for afew seconds.)Switch off the ignition and remove the keyfrom the ignition switch.
The remote control is fully operational again.

Changing the battery

Battery ref.: CR1620/3 volts.)Unclip the casing by inserting a coin at the notch and rotating.
)Slide the flat battery out of its location.)Slide the new battery into its location
observing the original direction.
)Clip the casing in place, then the chrome
finisher. )Reinitialise the remote control.

If the batter
y is flat, you are
informed by lighting of this warninglamp in the instrument panel, an audible signal
and a message in the multifunction screen.
) Unfold the key.)
Release the chrome finisher by pressing on lug A.)
Maintain pressure on lug A
and remove thechrome finisher by sliding it off at 45°.

Alarm System which protects and provides a deterrent against the theft of your vehicle. It provides two types of protection, exterior and interior, as well as aself-protection function.
Exterior perimeter
protection
The system detects opening of the vehicle.
The alarm is triggered if anyone tries to enter
the vehicle by forcing a door, the boot or
the bonnet.
Interior volumetric
protection

The system detects any variation in the volume
in the passenger compartment.
The alarm is triggered if anyone breaks a
window or moves inside the vehicle.
If you wish to leave a pet in the vehicle or a
window partially open, deactivate the interior
volumetric protection.

Self-protection function

The system detects the putting out of ser vice of its components.
The alarm is triggered if anyone tries to put
the wires of the siren, the central control or the
battery out of ser vice.
Do not make any modifications to the alarmsystem, this could cause malfunctions.

Activation
)Press button Afor more than two seconds.
A confirmation message appears on themultifunction screen, accompanied by an audible signal.
Deactivation
)Press button Aagain for more than
two seconds.
A confirmation message appears on themultifunction screen, accompanied by an
audible signal.
To lock or unlock the doors mechanicall
y in the event of a central locking system failure or flatbattery.
Emergency control


Locking the driver’s door
)
Inser t the key in the lock, then turn it to theleft.


Unlocking the driver’s door
)
Inser t the key in the lock, then turn it to the
right.

Locking the passenger’s door
)Remove the black cap, on the edge of the
door, using the key. )Inser t the key in the cavity, then turn it fully. )Remove the key and refit the cap.



Unlocking the passenger’s door
)Pull the interior door opening control.
In the event of a fault with the central locking system, you must disconnectthe battery to lock the boot and so ensure the complete locking of the vehicle.

105
Access











Boot


Opening
)After unlocking the vehicle using theremote control or the key, pull the handleand raise the tailgate.
Closing
)
Lower the tailgate using the interior grab
handle.
If the tail
gate is not closed correctly:
-when the engine is running ,
this warning lamp comes on,
accompanied by a messageon the multifunction screen for a few seconds,
-when the vehicle is moving (speed above6 mph (10 km/h)), this warning lamp comes
on, accompanied by an audible signal and
a message on the multifunction screen for a few seconds.
System for mechanical unlocking of the boot
in the event of a battery or central lockingmalfunction.
Tailgate release

Unlocking
)
Fold back the rear benchseat to gainaccess to the lock from inside the boot.)
Insert a small screwdriver into hole Aof thelock to unlock the tailgate.

169Driving

Operating fault
With the ignition on, if this warninglamp comes on and AUTOflashes,
accompanied by an audible signal and a
message in the multifunction screen, this
indicates a gearbox fault. Have it checked by a CITROËN dealer or a qualified workshop.


Reinitialisation
(5-speed electronic
gearbox)
In exceptional circumstances, thegearbox may need an automatic reinitialisation: starting and gear changing are no longer possible.
AUTO
and - -appear in theinstrument panel. AUTO

and - -
appear in the instrument panel.
)Select position N.)Press the brake pedal.)Wait for around 30 seconds until Nor a gear appears in the instrument panel. )Move the gear lever to position A, then toposition N . )With your foot still on the brake pedal, start
the engine.
The gearbox is operational again. Followin
g disconnection of the battery, it is necessary to reinitialise the gearbox. )Switch on the ignition.
Follow the procedure described above.

173Driving

Manual operation
Ddisappears and the gears engaged appear in succession on the
instrument panel.
If the en
gine speed is too low or
too high, the gear selected flashes for a fewseconds, then the actual gear engaged isdisplayed.
It is possible to change from position D(automatic) to position M
(manual) at any time.
When the vehicle is stationary or moving
ver
y slowly, the gearbox selects gear M1automatically.
The spor t and snow programmes do not
operate in manual mode.
Invalid value during manualoperation
)Select position M for sequential
changing
of the four gears. )Push the lever towards the + sign
to change up a gear.)Pull the lever towards the - sign to changedown a gear.
It is only possible to change from one gear to
another if the vehicle speed and engine speedpermit; other wise, the gearbox will operate
temporarily in automatic mode. This s
ymbol is displayed if a gear
is not engaged correctly (selector
between two positions).
Stopping the vehicle
Before switching off the engine, you can engageposition Por Nto place the gearbox in neutral. In both cases, apply the parking brake
to immobilise the vehicle. When the i
gnition is on, the lighting
of this warning lamp, accompanied
by an audible signal and a message in the
multifunction screen, indicates a gearbox fault.
In this case, the gearbox switches to back-up
mode and is locked in 3rd gear. You may feel
a substantial knock when changing from Pto R
and from N
to R
. This will not cause any
damage to the gearbox.
Do not exceed 60 mph (10 0 km/h), local speed
restrictions permitting.
Contact a CITROËN dealer or a qualified
wor
kshop as soon as possible.

Operating fault
If the lever is not in position P,P
when the driver's door is opened or approximately 45 seconds after the ignition is switched off, a message appears in the multifunction screen. )Return the lever to position P
; the message disappears.

There is a risk of damage to thegearbox:


- if you press the accelerator and brake pedals at the same time,

- if you force the movement of the gear lever from the Pposition to another position when the battery is flat.
To r e d u c e fuel consumption when at a prolonged standstill with the enginerunning (traffic jam...), put the gear lever in the Nposition and apply the parking brake.

Stop & Start The Stop & Start system puts the engine temporarily into standby - STOP mode - during stops in the traffic (red lights, traffic jams, or other...).
The engine restar ts automatically - START mode - as soon as you want to move off. The restar t takes place instantly, quickly and silently.
Per
fect for urban use, the Stop & Start system reduces fuel consumption and exhaust emissions as well as the noise level when stationary.
Operation
Going into engine STOP mode
For your comfor t, during parkingmanoeuvres, STOP mode is not available for a few seconds after coming out of reverse gear.STOP mode does not affect the functionality of the vehicle, such as for example, braking, power steering...
Never refuel with the engine in STOPmode; you must switch off the ignition with the key. Th
e "ECO"warning lamp comes
on in the instrument panel and the engine goes into standby:
- with a manual gearbox
, at speeds below
12 mph (20 km/h), when you put the gear lever into neutral, and you release theclutch pedal. -with a 5 or 6-speed electronic gearbox ,
at speeds below 5 mph (8 km/h), when you press the brake pedal or put the gear lever in position N.
A time counter calculates the sum
of the periods in STOP mode
during a journey. It rests itself
to zero every time the ignition is switched on with the key.
STOP mode is not invoked when:


- the driver's door is open,

- the driver's seat belt is not fastened,

- the vehicle has not exceeded 6 mph(10 km/h) since the last engine star t using
the key,

- the engine is needed to maintain acomfortable temperature in the passenger compartment,

- demisting is active,

- some special conditions (battery charge, engine temperature, braking assistance,ambient temperature...) where the engine isneeded to assure control of a system.


Special cases: STOP mode not available

The "ECO"warning lamp flashes for
a few seconds then goes off.
This operation is per fectly normal.
