Technical data
This section contains the specifications of your vehicle depending on its e
ngine   and   gearbox,   such   as   the   maximum   power   and   torque,   unladen
a

nd   maximum   weights,   trailer   weights,   exterior   dimensions   and   all   of   its
i

dentification
 ma
rkings.

Petrol engineVTi 82e-VTi 82 V Ti 120
Gearbox Manual
(5-speed) Electronic
(5-speed) Manual
(5-speed) Automatic
(4-speed)
Model code:
SA... HMZ0
HMZ0/PS 5FS05FS9
Cubic
  capacity   (cc) 1
  1991
  1991
  598
Bore
  x   stroke   (mm) 75
  x   90.575
  x   90.577
  x   85.8
Max
  power:   EU   standard   (kW)* 6059 88
Max
  power   engine   speed   (rpm) 5
  7505
  7506 000
Max
  torque:   EU   standard   (Nm) 118117 160
Max
  torque   engine   speed   (rpm) 2
  7502
  7504 250
Fuel UnleadedUnleaded Unleaded
Catalytic converter yesYe s yes
Engine
  oil   capacity   (in   litres)   (with   filter
r

eplacement) 3.25
3.25 4.254.25
*
  The   maximum   power   corresponds   to   the   value   type-approved   on   a   test   bed,   under   conditions   defined   in   European   legislation   (Directive   1999/99/EC).
Petrol engines
.../S: e-VTi model fitted with Stop & Start.

265
Petrol engineTHP 155
THP 15 0 **
THP 160 ***
Gearbox Manual
(6-speed)
Model code:
SA... 5FV8
5F
n
8
**
5FM8***
Cubic
  capacity   (cc) 1
  598
Bore
  x   stroke   (mm) 77
  x   85.8
Max
  power:   EU   standard   (kW)* 115
11 0 * *
120***
Max
  power   engine   speed   (rpm) 6 000
Max
  torque:   EU   standard   (Nm) 240
Max
  torque   engine   speed   (rpm) 1 400
Fuel Unleaded
Catalytic converter yes
Engine
  oil   capacity   (in   litres)   (with   filter
r

eplacement) 4.25
*
  The   maximum   power   corresponds   to   the   value   type-approved   on   a   test   bed,   under   conditions   defined   in   European   legislation   (Directive   1999/99/EC).
**
  For   Belgium   and   Russia.
***
  For   Brazil.
Petrol engines
Technical data

* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
P etrol engine
Gearbox Manual
(6-speed)
Model code: SA... 5FF85F
d8
C
ubic   capacity   (cc)
1   598
Bore   x   stroke   (mm)
77   x   85.8
Max   power:   EU   standard   (kW)*
149 152
Max   power   engine   speed   (rpm)
6 000
Max   torque:   EU   standard   (Nm)
275
Max   torque   engine   speed   (rpm)
2 000
Fuel Unleaded**
Catalytic converter Ye s
Engine   oil   capacity   (in   litres)   (with   filter
r

eplacement)
4.25
Engines - RACING
**  CITROËN
  strongly   recommends   the   use   of   98   RON   unleaded   petrol   to   ensure   optimum   operation   of   the   engine   (refer   to   the   label   inside   the  f
uel   filler   flap).

LPG EngineVTi 95
Gearbox Manual
(5-speed)
Model code:
SA... 8FR0/GPL
Cubic
  capacity   (cc) 1
  397
Bore
  x   stroke   (mm) 77
  x   75
Max.
  power:   EU   standard   (kW)* 67
Max.
  power   speed   (rpm) 5
  700
Max
  torque:   EU   standard   (Nm) 13 3
Max.
  torque   speed   (rpm) 3
  900
Fuel LPG
  /   Unleaded
Catalytic converter Ye s
Engine
  oil   capacity   (in   litres)   (with   filter
r

eplacement) 4.25
For
  more   information   on   the   operation   and   use   of   your   LPG   vehicle,   refer   to   the   specific   insert   attached   to   the   other   vehicle   documents.
*
  The   maximum   power   corresponds   to   the   value   type-approved   on   a   test   bed,   under   conditions   defined   in   European   legislation   (Directive   1999/99/EC).
LPG engine

diesel engineH d i 70 FA P e- Hdi 7 0 FAPe-Hdi 9 0 FAP
Gearbox Manual
(5-speed) Electronic
(5-speed) Manual
(5-speed) Electronic
(6-speed)
Model code:
SA... 8HR4
8HP4/PS 9HPK /S9HP8/PS
Cubic
  capacity   (cc) 1
  3981 560
Bore
  x   stroke   (mm) 73.7
  x   8275
  x   88.3
Max
  power:   EU   standard   (kW)* 50 68
Max
  power   engine   speed   (rpm) 4 000 4 000
Max
  torque:   EU   standard   (Nm) 160 230
Max
  torque   engine   speed   (rpm) 2 000 1
  750
Fuel
die

sel
die
sel
Catalytic converter yesyes
Particle
  filter   (FAP) yesyes
Engine
  oil   capacity   (in   litres)   (with   filter
r

eplacement) 3.75
3.75
.../S:


e-HDi   model   fitted   with   Stop   &   Start
Diesel engines
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).

273
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
* *   For   Belgium.
Diesel engines
diesel engine BlueH d i 100BlueH d i 120
BlueH d i 115**
Gearbox Manual
(5-speed) Manual
(6-speed)
Model code:
SA... BHY0/SBHZ8/S
-**
Cubic
  capacity   (cc) 1 5601 560
Bore
  x   stroke   (mm) 75
  x   88.375
  x   88.3
Max
  power:   EU   standard   (kW)* 73 88
Max
  power   engine   speed   (rpm) 3 500 3 500
Max
  torque:   EU   standard   (Nm) 254 300
Max
  torque   engine   speed   (rpm) 1
  7501
  750
Fuel
die

sel
die
sel
Catalytic converter Ye sYe s
Particle
  filter   (FAP) Ye sYe s
Engine
  oil   capacity   (in   litres)   (with   filter
r

eplacement) 3.75
3.75
Technical data

17Technical data
Petrol enginePureTech 82V Ti 120THP 155THP 150 ** PureTech 110 S&S
THP 165 S&STHP 150 S&S **
Gearbox Manual (5-speed) Manual (5-speed) Automatic (4-speed) Manual (6-speed) Manual (5-speed) Manual (6-speed)
Model code: SB... HMZ6 5FS0 5FS9 5FV8 5FV8 ** HNZ6/S 5GZM/S 5GWM/S **
Cubic capacity (cc) 1 199 1 598 1 598 1 199 1 598
Bore x stroke (mm) 75 x 90.5 77 x 85.8 77 x 85.8 75 x 90.5 77 x 85.8
Max power: EU standard (kW) * 60 88 115 11 0 * * 81 120 11 0 * *
Max power engine speed (rpm) 5 750 6 000 6 000 5 500 6 000
Max torque: EU standard (Nm) 118 160 240 205 240
Max torque engine speed (rpm) 2 750 4 250 1 400 1 500 1 750
Fuel Unleaded Unleaded Unleaded Unleaded Unleaded
Catalytic converter Ye s Ye s Ye s Ye s Ye s
Engine oil capacity (in litres) (with filter replacement) 3.25 4.25 4.25 3.25 4.25
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC). ** For Belgium.
Petrol engines

19Technical data
Diesel enginee-HDi 90BlueHDi 100BlueHDi 120BlueHDi 115 **
Gearbox Manual (5-speed) ETG6 electronic (6-speed) Manual (5-speed) Manual (6-speed)
Model code: SB... 9HPK /S 9HP8/PS BHY6/S BHZM/S BHXM/S **
Cubic capacity (cc) 1 560 1 560 1 560
Bore x stroke (mm) 75 x 88.3 75 x 88.3 75 x 88.3
Max power: EU standard (kW)* 68 73 88 85 **
Max power engine speed (rpm) 4 000 3 750 3 500
Max torque: EU standard (Nm) 230 254 300
Max torque engine speed (rpm) 1 750 1 750 1 750
Fuel Diesel Diesel Diesel
Catalytic converter Ye s Ye s Ye s
Particle filter (FAP) Ye s Ye s Ye s
Engine oil capacity (in litres) (with filter replacement) 3.75 3.75 3.75
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC). ** For Belgium.
Diesel engines
.../S : model fitted with Stop & Start
