ESP CITROEN DS3 CABRIO DAG 2015 Handbook (in English)

17Technical data
DS3-Cabrio_en_Chap12_caracteristiques_ed02-2014
Petrol enginePureTech 82V Ti 120THP 155THP 150 ** PureTech 110 S&S
THP 165 S&STHP 150 S&S **
Gearbox Manual (5-speed) Manual (5-speed) Automatic (4-speed) Manual (6-speed) Manual (5-speed) Manual (6-speed)
Model code: SB... HMZ6 5FS0 5FS9 5FV8 5FN8 ** HNZ6/S 5GZM/S 5GWM/S **
Cubic capacity (cc) 1 199 1 598 1 598 1 199 1 598
Bore x stroke (mm) 75 x 90.5 77 x 85.8 77 x 85.8 75 x 90.5 77 x 85.8
Max power: EU standard (kW) * 60 88 115 11 0 * * 81 120 11 0 * *
Max power engine speed (rpm) 5 750 6 000 6 000 5 500 6 000
Max torque: EU standard (Nm) 118 160 240 205 240
Max torque engine speed (rpm) 2 750 4 250 1 400 1 500 1 750
Fuel Unleaded Unleaded Unleaded Unleaded Unleaded
Catalytic converter Ye s Ye s Ye s Ye s Ye s
Engine oil capacity (in litres) (with filter replacement) 3.25 4.25 4.25 3.25 4.25
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC). ** For Belgium.
Petrol engines

19Technical data
DS3-Cabrio_en_Chap12_caracteristiques_ed02-2014
Diesel enginee-HDi 90BlueHDi 100BlueHDi 120BlueHDi 115 **
Gearbox Manual (5-speed) ETG6 electronic (6-speed) Manual (5-speed) Manual (6-speed)
Model code: SB... 9HPK /S 9HP8/PS BHY6/S BHZM/S BHXM/S **
Cubic capacity (cc) 1 560 1 560 1 560
Bore x stroke (mm) 75 x 88.3 75 x 88.3 75 x 88.3
Max power: EU standard (kW) * 68 73 88 85 **
Max power engine speed (rpm) 4 000 3 750 3 500
Max torque: EU standard (Nm) 230 254 300
Max torque engine speed (rpm) 1 750 1 750 1 750
Fuel Diesel Diesel Diesel
Catalytic converter Ye s Ye s Ye s
Particle filter (FAP) Ye s Ye s Ye s
Engine oil capacity (in litres)(with filter replacement) 3.75 3.75 3.75
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC). ** For Belgium.
Diesel engines
.../S: model fitted with Stop & Start
