217Driving
Parking space sensors
System which measures the parking space available between two vehicles or obstacles. It measures the size of the space and gives you information on: - the possibility of fitting into a free space,
depending on the dimensions of your vehicle and the distances needed for manoeuvring, - the level of difficulty of the manoeuvre to be per formed. The system does not measure spaces which
are clearly much smaller or larger than the size of the vehicle.
Displays in the instrument panel You have identified a parking space:  Press button A to select the function.  Operate the direction indicator on the side where the space is to be measured; a message is displayed to confirm that measurement is in progress.  During measurement, go for ward the length of the space, at a speed less than 12 mph (approx. 20 km/h), to prepare for your manoeuvre.  Once the measurement has been completed, the system informs you of the level of difficulty of the manoeuvre by a message in the multifunction screen
accompanied by an audible signal.
Operation
The parking space sensor function warning lamp can have two different states:
- on fixed: the function is selected by a press on control A . - off: the function is not selected,

Dimensions (in mm)
