remote control CITROEN DS4 2010 Owners Manual

01
02
03
04
05
2
AccessSafety
64 Remote control key
70
"
Keyless Entry and Starting"
80


Doors
81
Boo

t
83
A

larm
87
E

lectric windows
92
F

ront seats
98
R

ear seats
99
S

teering wheel adjustment
100


Mirrors
104
M

anual air conditioning
106
D

ual-zone digital air conditioning
110
F

ront demist - defrost
111
R

ear screen demist - defrost
112
F

ront fittings
114
P

anoramic windscreen
115
C

entre consoles
117
F

ront armrest
121
R

ear fittings
122
B

oot fittings 128 L
ighting control
132
A

utomatic illumination of headlamps
133
W

elcome lighting
13 4
H

eadlamp beam height adjustment
135
D

irectional lighting
137
W

iper control
138
A

utomatic rain sensitive wipers
142
C

ourtesy lamps
14 3
I

nterior mood lighting
14 4
B

oot lamp
Overview
Eco-drivingInstruments Lighting and visibility
Ease of use and comfort
14 Instrument panels
16
R
ev counter
17
I

ndicator and warning lamps
33
I

ndicators
43
M

anual test
46
C

ustomising the instrument panel colours
47
M

onochrome screen C
51
T

ouch screen tablet
56
T

rip computer 14 8
G

eneral safety recommendations
14 9
H

azard warning lamps
14 9


Horn
15 0
E

mergency or assistance
15 4
B

raking assistance systems
155
T

rajectory control systems
157
F

ront seat belts
161
A

irbags
166
C

hild seats
168
D

eactivating the passenger's front airbag
175
I

SOFIX child seats
180
C

hild lock
Contents

4
Exterior
Keyless Entry and Starting 70 -77
Remote control 6 4- 69, 77
-

o
pening / closing
-

b
ack-up control
-


battery
Alarm
8

3-86 Lighting control

1
28 -132
Headlamp adjustment
1

34
Guide-me-home lighting

1
31, 132
Welcome lighting

1
33
Directional lighting systems

1
35 -136
Changing bulbs
2

79-284
-

f
ront lamps
-

f
ront foglamps
-

s
ide repeaters
Wiper control

1
37-141
Changing a wiper blade

2
41 Door mirrors
1 00 -101
Blind spot sensors

2
10 -212
Doors

7
8 -79, 80
Keyless Entry and Starting

7
0 -77
-

o
pening / closing
-

b
ack-up control
Manual child lock

1
80
Electric windows

87
- 88
Fuel tank

2
27-230
Misfuel prevention

2
29
Roof bars

2
40
Braking assistance

1
54-155
Trajectory control

1
55 -156
Tyre under-inflation detection

2
04-205
Tyre pressures

2
04, 266, 270, 308
Snow chains

2
31
Temporary puncture
repair kit

2
60 -270
Changing a wheel

2
71-278
-
tools
-

r
emoving / refitting
Boot

6
5, 70, 81- 82
Reversing camera

2
23
AdBlue, topping up

3
7- 42, 254-256
Changing bulbs
2

85-287
-

r
ear lamps
-

3
rd brake lamp
-

n
umber plate lamp
Parking sensors

2
21-222
Towbar

1
85, 238
Quickly detachable towball

2
33 -237
Towing
29

6-297
Over view

64
Remote control keySystem which permits central unlocking or locking of the vehicle using the door lock or from a distance. It is also used to locate and start the vehicle,
as well as providing protection against theft.
Unlocking the vehicle
F Press this button to unfold the key.
Complete unlocking using
the remote control
Selective unlocking using
the remote control
F Press the open padlock to unlock the vehicle completely.
F

P
ress the open padlock once to
unlock the driver's door only.
F

P
ress the open padlock again to
unlock the other doors and the
boot.
Unlocking using the key
F Turn the key for wards in the driver's door lock to unlock the vehicle completely.
Opening the windows using
the remote control
F Maintain the press on the open padlock until the desired position
is obtained. The windows stop as
soon as you release the button.
The direction indicators flash for a
few
seconds.
The spotlamps in the door mirrors
come on.
Depending on version, the door mirrors
unfold, the welcome lighting comes on,
the alarm is deactivated.
The complete or selective door
unlocking parameter is set via the
vehicle configuration menu.
Unfolding the key
02
Access

65
Selective unlocking of the boot
F Press the central button on the remote control to unlock the
boot. The doors remain locked.
If selective unlocking of the boot is deactivated,
pressing this button also unlocks the doors.
Don't forget to lock the boot again by
pressing the closed padlock button.
The complete or selective boot
unlocking parameter is set via the
vehicle configuration menu.
Selective unlocking of the boot is
activated by default.
Locking the vehicle
Normal locking using the remote
control
Normal locking using the key
F Turn the key towards the rear in the driver's door lock to lock the vehicle. F

P
ress the closed padlock to lock
the vehicle. If one of the doors or the boot is still
open, the central locking does not take
place.
However, the alarm (if present) will
be completely activated after about
45 seconds.
If the vehicle is unlocked inadvertently
and with no action on the doors or
boot, the vehicle will lock itself again
automatically after about 30 seconds.
If the alarm had previously been
activated, it will not be reactivated
automatically.
The folding and unfolding of the door
mirrors using the remote control can be
deactivated by a CITROËN dealer or a
qualified workshop.
The direction indicators flash for a
few
seconds.
Depending on version, the door mirrors fold,
the alarm is activated.
02
Access

66
F Press the closed padlock to lock the vehicle completely.
Deadlocking using the remote
control
F Press the closed padlock again within five seconds to deadlock
the vehicle. F

T
urn the key to the rear in the driver's door
lock to lock the vehicle completely.
F
T
urn the key to the rear again within five
seconds to deadlock the vehicle.
Deadlocking using the key
Deadlocking is confirmed by fixed lighting
of the direction indicators for approximately
two
seconds.
According to version, the door mirrors fold at
the same time.
In low light, deadlocking also brings on the
guide-me-home lighting.
For more information on the guide-me-home
lighting, refer to the corresponding section. Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the central locking
control button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.
02
Access

67
F Press this button.
Locating your vehicle
This function allows you to identify your vehicle
from a distance, particularly in poor light. Your
vehicle must be locked.
Folding the key
Closing the windows using
the remote control
F Press and hold the closed padlock button until the desired
position is obtained. The
windows stop when you release
the button.
When closing the windows using the
remote control you must ensure that
nothing prevents them from closing
c o r r e c t l y.
If you want to leave the windows
partly open, you must deactivate the
volumetric alarm monitoring. If you do not press the button, there is a
risk of damaging the remote control.
F

P
ress this button before folding the key.This will switch on the courtesy lamps and
the direction indicators will flash for around
ten
se

conds.
02
Access

69
In the event of a malfunction with the remote
control, you can no longer unlock, lock or
locate your vehicle.
F
F
irst of all, use the key in the lock to unlock
or lock your vehicle.
F

T
hen, reinitialise the remote control.
Fault with the remote control
Reinitialisation
F Switch off the ignition and remove the ignition key.
F

P
ress the closed padlock immediately for a
few seconds.
F

T
urn the key to position 2 (Ignition on) .
F

S
witch off the ignition and remove the key
from the ignition switch.
The remote control is fully operational again.
Changing the battery
Battery ref.: CR2032/3 volts.
F
U
nclip the cover using a small screwdriver
at the two cutouts.
F

L
ift off the cover.
F

R
emove the flat battery from its location.
F

F
it the new battery into its location
observing the original direction of fitment.
F

C
lip the cover onto the casing.
If the battery is flat, you are informed
by illumination of this warning lamp,
an audible signal and a message in
the screen.
If the problem persists, contact a
CITROËN dealer as soon as possible.
02
Access

70
"Keyless Entry and Starting"
System which permits the unlocking, locking
and starting of the vehicle while keeping the
electronic key on your person.The electronic key can also be used as
a remote control.
For more information on the Remote
control key , refer to the corresponding
section.
The direction indicators flash for a few
seconds.
Depending on version, the door mirrors
unfold, the welcome lighting comes on,
the alarm is deactivated.
Unlocking the vehicle
The vehicle or just the driver's door is unlocked,
depending on the setting.
F

W
ith the electronic key on your person and
in the recognition zone A , pass your hand
behind the door handle of one of the front
doors to unlock the vehicle or press the
tailgate opening control.Selective unlocking
F To unlock only the drivers door, with the electronic key on your person, pass your
hand behind the driver's door handle.
F

T
o unlock the complete vehicle, pass your
hand behind one of the door handle of the
front passenger door with the electronic
key close to the passenger door, or
press the tailgate opening control with
the electronic key close to the rear of the
vehicle.
Activation or deactivation of the selective
unlocking is done in the " Driving" menu, then
" Vehicle settings ".
By default, complete unlocking is activated.
Complete unlocking
02
Access

71
If one of the doors or the boot is still
open or if the electronic key for the
Keyless Entry and Starting system has
been left inside the vehicle, the central
locking does not take place.
However, the alarm (if fitted) will be
fully activated after about 45 seconds.As a safety measure (children on
board), never leave the vehicle without
taking the electronic key for the Keyless
Entry and Starting system with you,
even for a short period.
Be aware of the risk of theft when the
electronic key for the Keyless Entry and
Starting system is in one of the defined
zones with the vehicle unlocked.
In order to preserve the battery in the
electronic key and the vehicle's battery,
the "hands-free" functions are put into
long-term standby after 21 days without
use. To restore these functions, press
one of the remote control buttons or
start the engine with the electronic key
in the reader.
For more information on starting with
Keyless Entr y and Star ting
, refer to
the corresponding section.
If the vehicle is unlocked by mistake
and with no action on the doors or boot,
the vehicle will lock again automatically
after about 30 seconds.
If fitted to your vehicle, the alarm will
also be reactivated automatically.
The automatic folding and unfolding
of the door mirrors can be deactivated
by a CITROËN dealer or a qualified
workshop.
02
Access

74
Back-up key integrated in the Keyless Entry and Starting
The integral key is used to lock and unlock the
vehicle when the electronic key cannot operate:
-

b
attery flat, vehicle battery discharged or
disconnected,
.

..
-

v
ehicle located in an area with strong
electromagnetic signals. If the alarm is activated, the audible
signal triggered on opening a door
with the key (integral with the remote
control) will stop when the ignition is
switched on.
F

I
nsert the integral key in the door lock, then
turn it to the rear.
Unlocking the driver's door
F Insert the integral key in the door lock, then turn it to the front.
Locking the driver's door
F Maintain a pull on button 1 , to extract the
integral key 2 .
02
Access
