buttons Citroen DS4 2011 1.G User Guide

294
1142
9
3
4
5
67
8
10
111213
01 FIRST STEPS


CONTROL PANEL

Buttons 2, 3, 4, 5, 6 and 12: selection of left or right of the screen, when a Menu is displayed on the screen.

295
01


1. Rotary control:


- Short press engine not running: on/off.

- Short press engine running: mute on/off.

- Rotation: volume adjustment (each source
is independant, including TA messages
and navigation information).

2. Radio source, access to the FM/AM band

menu and display the list of stations.

3. Access to the MEDIA
menu and display the
list of tracks.

4. Access to the Navigation - guidance
menu
and display the last destinations.

5. Access to the Traffi c information
menu and
display the current traffi c alerts.

6. Access to the " Telephone
" menu and display
the recent calls list.
2 - 3. Long press: access to the Audio settings
:
music ambiance, bass, treble, loudness,
left/right balance, front/rear fader, automatic
volume adjustment.
7. Access to the " Confi guration
" menu.
Long press: access to the GPS coverage and
the navigation demonstration mode.

8. MODE button:
Selection of the type of permanent display.
Long press: black screen (DARK).

9. ESC: abandon the operation in progress, up
one level in the menu.
Long press: return to permanent display.

10. CD eject.
Continuous press: reinitialisation of the system.

11. According to context:
Selection of the previous/next line in a list or
menu.
Selection of the previous/next media folder.
Step by step selection of the previous/next
radio frequency.
Move up/down in Move the map
mode.
12. According to context:
Automatic selection of the next lower/higher
radio frequency
.
Selection of the previous/next CD or media
track
.
Selection of left/right on the screen when a
menu is displayed.
Move left/right in Move the map
mode.

13. Buttons 1 to 6:
Short press: selection of the stored radio
station.
Long press: store the current radio station.

14. Dial for selection and OK confi rmation:
Selection of an item on the screen or in a
list in a menu, then confi rmation with a short
press.
Other than for menus and lists, a short press
displays a contextual menu depending on the
current screen.
Rotation with map displayed: zoom the map
scale in and out.

FIRST STEPS

302
1
04
2
1
2
33
4

Select " Select destination
" and confi rm,
then select " GPS coordinates
" and
confi rm.

Enter the GPS coordinates and confi rm
" OK
" to start the guidance.

Press NAV
to display the
" Navigation - guidance
" menu.

NAVIGATION - GUIDANCE








TOWARDS GPS COORDINATES

TOWARDS A POINT ON THE MAP

With the map displayed, press OK
to
display the contextual menu. Select
" Move the map
" and confi rm.

Press OK
to display the contextual
menu for " Move the map
" mode.

Select " Select as destination
" or
" Select as stage
" and confi rm.

Move the cursor using the screen
navigation buttons
,
,
,
to
identify the desired destination.

306
04
1
4
3
1
3
22
NAVIGATION - GUIDANCE


ADDING A STAGE


Press NAV
to display the
" Navigation - guidance
" menu.

Select " Journey leg and route
" then
confi rm.

Select " Close to
" a route passing
close to the stage or " Strict
" for a route
passing through the stage.
Confi rm " OK
" to start the guidance, and
give a general indication of the guidance
route.

Select " Add a stage
" then confi rm .
The address of the stage is entered as
a destination, by " Enter an address
",
a contact in " Directory
", or " Previous
destinations
".


ORGANISING STAGES


To organise stages, carry out
operations 1 to 2 again, then select
" Order/delete journey legs
" and
confi rm.

Select and confi rm to save the
modifi cations.
Select the stage that you want to move
in the order, using the
and
buttons
until the desired position is reached.

Select " Delete
" to delete the stage.

326
07
1a
1b
1c
1
2
RADIO


By alphabetical list
Press RADIO
or LIST
, select the station
of your choice and confi rm.

By automatic frequency search
Press
or
for the automatic search
for a lower or higher radio frequency.
Or turn the thumb wheel on the steering
mounted control.

By manual frequency search
Press
or
to adjust the radio
frequency step by step.

Press the button on the numerical
keypad to recall a preset station.
Or press then turn the thumb wheel at
the steering mounted controls.








SELECTING A STATION


The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode.
This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio
system.


PRESETTING A STATION


Press one of the buttons on the
numerical keypad for 2 seconds to
preset the current station.
An audible signal confi rms that the
station has been preset.
The quality of reception is represented
by this symbol.

346
01
1
2
7
45
6
3
8
9
10
13
1112
14
FIRST STEPS



1. On/Off and volume adjustment.

2. CD eject.

3. Selection of the display on the screen from
the following modes:
Full screen: Audio (or if a telephone call is in
progress)/
New window: Audio (or telephone if a call is
in progress) - Time or Trip computer
.
Long press: black screen (DARK).

4. Selection of source:
Radio, CD, AUX, USB, Streaming.
Accept an incoming call.

5. Selection of FM1, FM2, DAB and AM
wavebands.

6. Buttons 1 to 6:
Selection of a preset radio station.
Long press: preset a station.
7. Display the list of stations received,
the CD/MP3 tracks or folders.
Long press: MP3/WMA fi le order/update
the list of stations received.

8. TA (Traffi c Announcement) function on/off.
Long press: access to the type of
information.

9. Confi rmation or display of contextual menu.

10. Abandon current operation.
Up one level (menu or folder).

11 . Automatic search for a lower/higher radio
frequency.
Selection of previous/next CD, USB,
streaming track.
Navigation in a list.
12. Manual step by step search for a lower/
higher radio frequency.
Selection of the previous/next MP3 folder.
Selection of the previous/next USB device
folder/genre/artist/playlist.
Navigation in a list.

13. Main menu.

14. Audio settings:
equalizer, treble, bass, loudness,
distribution, left/right balance, front/rear,
automatic volume.

352
04
1
2
3
AUDIO







AUDIO CD


Insert 12 cm diameter circular compact discs only.
Some anti-pirating systems, on original discs or CDs copied using a
personal recorder, may cause faults which are no refl ection on the
quality of the original player.
Without pressing the EJECT
button, insert a CD in the player,
play begins automatically.

To play a disc which has already been
inserted, press the SOURCE
button several
times in succession and select " CD
".


Press one of the buttons to select a
track on the CD.
PLAYING A CD

Press LIST
to display the list of tracks
on the CD.

Press and hold one of the buttons for
fast forward or backward.

354
04
1
3
2
4
5












CD, USB

AUDIO


PLAYING A COMPILATION

Insert an MP3 compilation in the CD player or
connect a memory stick to the USB port, directly or
via an extension lead.

The system creates playlists (temporary memory) the creation time
for which can take from a few seconds to several minutes.
The playlists are updated every time the ignition is switched off or a
USB memory stick is connected.
Play starts automatically after a period which depends on the
capacity of the USB memory stick.

At a fi rst connection, the order suggested is by folder.
When connecting again, the order previously chosen is
retained.

To play a disc or memory stick which
has already been inserted, press
SOURCE
several times in succession
and select " CD
" or " USB
".


Press one of the buttons to select the
next or previous track.

Press one of the buttons to select the
next or previous folder in the order
chosen.

Press and hold one of the buttons for
fast forwards or backwards.

Press LIST
to display the menu of
folders in the compilation.

363


1
2
1
4
2
33
05 USING THE TELEPHONE


To display the " TELEPHONE
" menu:


- Make along press on SOURCE
.

- Or, press OK
to display the contextual
menu. Select " Call
" and confi rm.



- Or, press MENU
, select " Telephone
"
and confi rm. Select " Call
" and
confi rm.


Select " Dial
" to enter a number and
confi rm.
Repeat the previous step 1
to display
the " TELEPHONE
" menu.

Select OK
and confi rm to start the
call.

Select " Calls list
" and confi rm.


MAKING A CALL - DIALLING


Select numbers one at a time using
the
and
buttons and confi rm.


MAKING A CALL - RECENTLY CALLED
NUMBERS *


Select the number and confi rm
to start the call.

The calls list includes calls sent and received in the vehicle using
the connected telephone.


*

Depending on the compatibility of the telephone.

Correction allows numbers to be deleted one at a time.

Instruments and controls

Instrument panels 38 - 40
Warning lamps 41-51
Indicators 52-54
Manual test 55
Setting buttons 56 -59


- trip distance recorder

- lighting dimmer/black panel

- customisation of dials and screens


Stop & Star t 212-214
Lane depar ture warning system 215
Lighting c ontrols 12 2-126
Adjusting headlamps 128

Door mirrors 95 -96
Electric windows 115 -116

Dashboard fuses 263 -266

Opening the bonnet 231

Adjusting the steering wheel 94
Horn 173
Multifunction screens 62- 69
Seat belt and front passenger
airbag warning display screen 180 -181

Manual gearbox 201-202
6 -speed electronic gearbox
system 203-206
Automatic gearbox 207-210
Parking brake 192-199, 200
Rear view mirror 97
Emergency or
assistance call 173, 291
Cour tesy lamps 136
Wiper controls 131-135
Trip computer 70 -74

Ventilation 78 -79
Manual air conditioning 80 - 81, 86
Digital air conditioning 82- 86
Demisting/Defrosting
the rear screen 87
Audio system 345 -377
Setting the date/time 369

eMyWay satellite navigation system 293-344
Setting the date/time 335
Interior mood lighting 137


Hazard warning lamps 172-173
Central locking 107-108
Black panel 58
Memorising speeds 219
Speed limiter 220 -221
Cruise control 222-223
