These have one position for use (up) and a
stowed position (down).
They can also be removed.
To remove a head restraint:
)
release the backrest using control 1
,
)
tilt the backrest 2
slightly forwards,
)
pull the head restraint upwards to the stop,
)
then, press the lug A
.
Rear head restraints
Never drive with the head restraints
removed; they must be in place and
correctly adjusted.
Steering wheel
adjustment
)
When stationary
, pull the control lever to
release the adjustment mechanism.
)
Adjust the height and reach to suit your
driving position.
)
Push the control lever to lock the
adjustment mechanism.
As a safety precaution, these
operations should only be carried out
while the vehicle is stationary.
Page 104 of 396
Locking the vehicle
Normal locking using the remote
control
Normal locking using the key
)
Turn the key towards the rear in the driver's
door lock to lock the vehicle.
)
Press the closed padlock to lock
the vehicle.
If one of the doors or the boot is still
open, the central locking does not
take place; the vehicle locks itself then
unlocks straight away, identifiable by
the sound of the locks rebounding.
When the vehicle is locked, if it is
unlocked inadvertently, it will lock itself
again automatically after thir ty seconds
unless a door or the boot is opened.
The folding and unfolding of the door
mirrors using the remote control can be
deactivated by a CITROËN dealer or a
qualified workshop.
Locking is confirmed by fixed lighting of the
direction indicators for approximately
two seconds.
According to version, the door mirrors fold at
the same time.
depending on the level of ambient light, it also
brings on of the timed operation of the welcome
and guide-me-home lighting, if this is activated
(see "Visibility - Automatic welcome lighting/
Guide-me-home lighting").
Closing the windows using the
remote control
)
Press and hold down the closed
padlock until the desired position
is obtained. The windows stop
when you release the button.
When closing the windows using the
remote control you must ensure that
nothing prevents them from closing
correctly.
If you want to leave the windows
partly open, you must deactivate the
volumetric alarm monitoring.
Page 106 of 396
Starting the vehicle
)
Inser t the key in the ignition switch.
The system recognises the star ting code.
)
Turn the key fully towards the dashboard to
position 3 (Star ting)
.
)
When the engine star ts, release the key.
)
Immobilise the vehicle.
)
Turn the key fully towards you to
position 1 (Stop)
.
)
Remove the key from the ignition switch.
Switching the vehicle off
A heavy object (key fob...), attached to
the key and weighing down on its shaft
in the ignition switch, could cause a
malfunction.
Key left in the "Ignition on"
position
On opening the driver's door, an aler t
message is displayed, accompanied
by an audible signal, to remind you that
the key is still in the ignition switch at
position 1 (Stop)
.
If the key has been left in the ignition
switch at position 2 (Ignition on)
,
the ignition will be switched off
automatically after one hour.
To switch the ignition back on, turn the
key to position 1 (Stop)
, then back to
position 2 (Ignition on)
.
Page 112 of 396
Deactivate the interior volumetric and anti-tilt
monitoring to avoid unwanted triggering of the
alarm in cer tain cases such as:
- leaving a pet in the vehicle,
- leaving a window par tially open,
- washing your vehicle,
- changing a wheel,
- having your vehicle towed,
- transpor t by sea.
Locking the vehicle
with exterior perimeter
monitoring only
Deactivation of the interior
volumetric and anti-tilt
monitoring
)
Switch off the ignition.
)
Within ten seconds, press the button until
the indicator lamp is on continuously.
)
Get out of the vehicle.
)
Press the locking button on the remote
control immediately.
The exterior perimeter monitoring alone is
activated: the indicator lamp in the button
flashes once per second. To be effective, this deactivation must
be carried out each time the ignition is
switched off.
Reactivation of the interior
volumetric and anti-tilt
monitoring
)
Press the unlocking button on the remote
control to deactivate the exterior perimeter
monitoring.
)
Press the locking button on the remote
control to activate all the monitoring
functions.
The indicator lamp in the button again flashes
once per second.
Page 115 of 396
11 3Access
System allowing the doors to be locked and
unlocked manually in the event of a malfunction
of the central locking system or battery failure.
Emergency control
Locking the driver's door
)
Inser t the key in the door lock, then turn it
to the rear.
You can also apply the procedure described
for the passenger doors.
Unlocking the driver's door
)
Inser t the key in the door lock, then turn it
to the front.
Locking the front and rear
passenger doors
)
Open the doors.
)
On the rear doors, check that the child lock
is not on (see Child Safety).
)
Remove the black cap, located on the edge
of the door, using the key.
)
Insert the key in the socket without forcing
it, then without turning it, move the latch
sideways towards the inside of the door.
)
Remove the key and refit the cap.
)
Close the doors and check that the vehicle
has locked correctly from the outside.
Unlocking the front and rear
passenger doors
)
Pull the interior door opening control.
Page 125 of 396
123Visibility
Model without AUTO lighting
Model with AUTO lighting
Manual controls
The lighting commands are issued directly
by the driver by means of the ring A
and the
stalk B
.
Sidelamps (luminous signature).
Automatic illumination of headlamps.
B.
Stalk for switching headlamps: pull the stalk
towards you to switch the lighting between
dipped and main beam headlamps.
In the lamps off and sidelamps modes, the
driver can switch on the main beam headlamps
temporarily ("headlamp flash") by maintaining a
pull on the stalk.
A.
Main lighting mode selection ring: turn it
to position the symbol required facing the
mark.
Lamps off.
Sidelamps.
Dipped headlamps or main beam
headlamps.
Displays
Illumination of the corresponding indicator
lamp in the instrument panel confirms that the
lighting selected is on. Daytime lighting, compulsory in cer tain
countries, which comes on automatically when
the engine is star ted making the vehicle more
visible to other users.
This function is assured:
- in countries where it is imposed by
regulations,
by illumination of the dipped beam
headlamps associated with illumination of
the sidelamps and number plate lamps; this
function cannot be deactivated.
- for other countries where it is provided,
by illumination of dedicated lamps
associated with illumination of the
sidelamps and number plate lamps; this
function can be activated or deactivated via
the vehicle configuration menu.
The instruments and controls (multifunction
screen, air conditioning control panel, ...) are
not illuminated, except in night mode with
manual or automatic illumination of headlamps.
Daytime running lamps
The lighting control must be in position "0"
or
"AU TO "
(day mode).
Page 133 of 396
131Visibility
System for selection and control of the various
front and rear wiping modes for the elimination
of rain and cleaning the screens.
The vehicle's front and rear wipers are
designed to improve the driver's visibility
according to the climatic conditions.
The wipers are controlled by means of stalk A
for the front and the ring B
for the rear.
Wiper controls
Programming
Model without AUTO wiping
Various automatic wiper control modes are also
available depending on whether the following
options are fitted:
- automatic rain sensitive windscreen wipers,
- rear wiping on engaging reverse gear.
Model with AUTO wiping
Windscreen wiper
A.
Wiping speed control stalk: raise or lower
the stalk to the desired position.
Single wipe (press downwards or pull
towards you, then release).
Automatic wiping (press down,
then release).
Single wipe (pull the stalk briefly
towards you). Fast wiping (heavy rain).
Normal wiping (moderate rain).
Intermittent wiping (proportional to
the speed of the vehicle).
Park.
or
Page 135 of 396
133Visibility
Windscreen and headlamp
wash
)
Pull the windscreen wiper stalk towards
you. The windscreen wash then the
windscreen wipers operate for a fixed
period.
The headlamp washers only operate when the
dipped beam headlamps are on
.
Low screenwash/headlamp
wash level
On vehicle fitted with headlamp washers, the
low level of this fluid is indicated by gauge in
the reser voir filler neck under the bonnet.
Checking and topping up this fluid can only be
done when stationary with the engine off.
The driver should check the level of
this fluid regularly, par ticularly during
winter.
Refer to "Checks - § Screenwash/headlamp
wash level" for the procedure on checking the
level.
Page 150 of 396
Longitudinal adjustment
Front armrest
Comfor t and storage device for the driver and front passenger.
The length of the armrest cover can be adjusted.
The armrest's compar tment can hold up to
6 CDs.
)
Raise the cover fully.
Storage
)
To move for wards, raise the lever.
The armrest slides for wards to its stop.
)
To stow it, slide it fully back and press
down to lock it.
Page 168 of 396
Your vehicle has been approved in accordance
with the new
ISOFIX regulation
.
The seats, represented below, are fitted with
regulation ISOFIX mountings:
"ISOFIX" mountings
There are three rings for each seat:
- two rings A
, located between the vehicle
seat back and cushion, indicated by a label,
- a ring B
behind the seat for fixing the upper
strap, referred to as the To p Te t h e r
. This ISOFIX mounting system provides fast,
reliable and safe fitting of the child seat in your
vehicle.
The incorrect installation of a child seat
in a vehicle compromises the child's
protection in the event of an accident.
For information regarding the ISOFIX child
seats which can be installed in your vehicle,
refer to the table showing the locations for
installing ISOFIX child seats. When fitting an ISOFIX child seat to
the left hand rear seat, before fitting
the seat, first move the centre rear seat
belt towards the middle of the vehicle,
so as to avoid the seat inter fering with
the operation of the seat belt.
The ISOFIX child seats
are fitted with two
latches which are secured on the two rings A
.
Some seats also have an upper strap
, known
as the Top Tether, which is attached to ring B
.
To attach this strap, raise the vehicle seat's
head restraint then pass the hook between its
rods. Then fix the hook on ring B
and tighten
the upper strap.
