279Practical information

"Multimedia":

audio systems, steering mounted audio controls,
speakers, Hi-Fi module, Bluetooth hands-free
system, por table satellite navigation system,
semi-integral support bracket for portable
navigation system, speed camera detector, USB
Box, reversing camera, por table video screen,
por table video suppor t bracket, 230 V/50 Hz
socket, 230 V/12 V adaptor, Wi-Fi on board...
By visiting a CITROËN dealer you can also
obtain cleaning and maintenance products
(interior and exterior) - including ecological
products in the "TECHNATURE" range,
products for topping up (screenwash...), paint
touch-up pens and aerosols for the exact colour
of your vehicle, refills (sealant cartridge for the
temporar y puncture repair kit...), ...



Installation of radio
communication
transmitters
Before installing any after-market radio
communication transmitter, you can
contact a CITROËN dealer for the
specification of transmitters which can
be fitted (frequency, maximum power,
aerial position, specific installation
requirements), in line with the Vehicle
Electromagnetic Compatibility Directive
(2004/104/EC).

The fitting of electrical equipment
or accessories which are not
recommended by CITROËN may result
in a failure of your vehicle's electronic
system and excessive electrical
consumption.
Please note this precaution.
You are advised to contact a CITROËN
representative to be shown the range
of recommended equipment and
accessories.

Depending on the legislation in force
in the country, it may be compulsory
to have a high visibility safety vest,
warning triangle and spare bulbs and
fuses available in the vehicle.

012
Technical data

MODELS:



ENGINES AND GEARBOXES



Model codes:


NX...


5FS0



5FV8/P



5FMA



5FU8



PETROL ENGINES


VTi 120



THP 155



THP 160



THP 200


Cubic capacity (cc)
1 598
1 598
1 598
1 598
Bore x stroke (mm)
77 x 85.8
77 x 85.8
77 x 85.8
77 x 85.8
Max power: EU standard (kW)
88
115
120
147
Max power engine speed (rpm)
6 000
6 000
6 000
5 500
Max torque: EU standard (Nm)
160
240
240
275
Max torque engine speed (rpm)
4 250
1 400
1 400
1 700
Fuel
Unleaded
Unleaded
Unleaded
Unleaded

Catalytic conver ter
yes
yes
yes
yes

GEARBOX

Manual
(5 -speed)


Electronic gearbox system (6 -speed)
Automatic
(6 -speed)
Manual
(6 -speed)

OIL CAPACITIES (in litres)




Engine (with filter replacement)
4.2
4.2
4.2
4.2

283Technical data


WEIGHTS AND TOWED LOADS (in kg)



Petrol engines


VTi 120



THP 155



THP 160



THP 200



Gearboxes


Manual





Electronic gearbox system



Automatic



Manual



Model codes:
NX...


5FS0



5FV8/P



5FMA



5FU8




- Unladen weight
1 205
1 284
1 363
1 316


- Kerb weight
1 280
1 359
1 438
1 391


- Gross vehicle weight (GV W)
1 755
1 795
1 835
1 820


- Gross train weight (GTW)
on a 12 % gradient
2 955
3 195
2 635
2 820


- Braked trailer (within the GTW limit)
on a 12 % gradient
1 200
1 400
800
1 000


- Braked trailer * (with load transfer within the
GTW limit)
1 450
1 650
1 000
1 250


- Unbraked trailer
640
680
715
695


- Recommended nose weight
75
75
75
75

*
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

MODELS:



ENGINES AND GEARBOXES



Model codes:
NX...


9HP0



9HR8

9HR8/S



9HR8/PS



RHH8



RHC8/P



DIESEL ENGINES


HDi 90 PEF



HDi 110 PEF



HDi 160 PEF


Cubic capacity (cc)
1 560
1 560
1 997
Bore x stroke (mm)
75 x 88.3
75 x 88.3
85 x 88
Max power: EU standard (kW)
68
82
120
Max power engine speed (rpm)
4 000
3 600
4 000
Max torque: EU standard (Nm)
230
270
340
Max torque engine speed (rpm)
1 750
1 750
2 000
Fuel
Diesel
Diesel
Diesel
Catalytic conver ter
yes
yes
Ye s

Particle emissions filter (PEF)
yes
yes
Ye s

GEARBOX

Manual
( 5 -speed)
Manual
(6 -speed)


Electronic gearbox system (6 -speed)
Manual
(6 -speed)

Electronic gearbox system (6 -speed)

OIL CAPACITIES (in litres)




Engine (with filter replacement)
3.75
3.75
3.75
-
-

.../S:
e-HDi model fitted with Stop & Star t.

285Technical data


WEIGHTS AND TOWED LOADS (in kg)



Diesel engines


HDi 90 PEF



HDi 110 PEF



e- HDi 110 PEF



HDi 160 PEF



Gearbox


Manual



Manual



Manual





Electronic
gearbox system



Manual




Electronic
gearbox system



Model codes:
NX...


9HP0



9HR8



9HR8/S



9HR8/PS



RHH8



RHC8/P




- Unladen weight
1 205
1 290
1 295
1 300
1 320
1 320


- Kerb weight
1 280
1 365
1 370
1 375
1 395
1 395


- Gross vehicle weight (GV W)
1 765
1 805
1 810
1 815
1 880
1 895


- Gross train weight (GTW)
on a 12 % gradient
2 865
3 105
3 110
3 115
3 180
3 195


- Braked trailer (within GTW limit)
on 12 % gradient
1 100
1 300
1 300
1 300
1 300

1 300


- Braked trailer * (with load transfer with the
GTW limit)
1 350
1 550
1 550
1 550
1 550
1 550


- Unbraked trailer
640
680
680
680
695
695


- Recommended nose weight
75
75
75
75
75
75

*
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Dimensions (in mm)

287Technical data

















Identifi cation markings
Various visible markings for the identification of your vehicle.

A.
Vehicle identification number (VIN) under the bonnet.
This number is engraved on the bodywork near
the engine mounting.

B. Vehicle identification number on the
dashboard.

This number is indicated on a self-adhesive
label which is visible through the windscreen.
D. Tyre/paint label.

This label is affixed to the driver's front pillar. Wheels which are fitted with 225/40 R18
tyres cannot be fitted with snow chains.
For more information, contact a CITROËN
dealer or a qualified workshop.
Low tyre pressures increase fuel
consumption. The tyre pressures must be checked
when the tyres are cold, at least once
a month.
C. Manufacturer's label.

The VIN is indicated on a self-destroying label
affixed to the driver's centre pillar. It bears the following information:


- the tyre pressures, for unladen and laden
conditions,

- the wheel rim and tyre sizes,

- the brands of tyre recommended by the
manufacturer,

- the spare tyre inflation pressure,

- the paint colour code.

013
