271Practical information








Load reduction mode
System which manages the use of cer tain
functions according to the level of charge
remaining in the battery.
When the vehicle is being driven, the load
reduction function temporarily deactivates
cer tain functions, such as the air conditioning,
the heated rear screen...
The deactivated functions are reactivated
automatically as soon as conditions permit. Do not disconnect the terminals while the engine is running.
Do not charge the batteries without disconnecting the terminals first.
Do not push the vehicle to star t the engine if it is fitted with the 6 -speed electronic
gearbox system.

Before disconnecting the
battery
Wait 2 minutes after switching off the
ignition before disconnecting the battery.
Close the windows and the doors before
disconnecting the battery.


Following reconnection
of the battery
Following reconnection of the battery,
switch on the ignition and wait 1 minute
before star ting to permit initialisation of the
electronic systems. However, if problems
are encountered following this operation,
contact a CITROËN dealer or a qualified
workshop.
Referring to the corresponding section,
you must yourself reinitialise:


- the remote control key,

- the GPS satellite navigation system.

Accessories
A wide range of accessories and genuine par ts is available from the CITROËN dealer network.
These accessories and par ts have been tested and approved for reliability and safety.
They are all adapted to your vehicle and benefit from CITROËN's recommendation and warranty.



"Comfort":

door deflectors, side window blinds, rear
screen blind, isotherm module, coat hanger
fixed to head restraint, mobile reading lamp,
mirror for caravan, parking sensors...


"Transport systems":

child seats and booster cushions, boot carpet,
boot liner, boot net, boot spacers, transverse
roof bars, bicycle carrier, ski carrier, roof boxes,
towbars, wiring harnesses...

"Styling":

gear lever knobs, aluminium foot rest, alloy
wheels, chrome mirror shells, chrome door
aperture finishers...


"Security and safety":

anti-intrusion alarm, anti-tilt unit, stolen vehicle
tracking system, child seats and booster cushions,
breathalyser, first aid kit, fire extinguisher, warning
triangle, high visibility vest, wheel security bolts,
snow chains, non-slip covers...
If a towbar and wiring harness are fitted
outside the CITROËN dealer network,
the installation must be done following
the manufacturer's recommendations.
* To avoid any risk of jamming the pedals:


- ensure that mats are correctly positioned
and secured,

- never fit one mat on top of another.



"Protection":

mats * , seat covers compatible with lateral
airbags, mud flaps, door protective mouldings,
bumper protection strips, vehicle cover...

297
03

For a detailed global view of the menus available, refer to the
"Screen menu map" section.

For cleaning the screen, the use of a soft, non-abrasive cloth
(spectacles cloth) is recommended, with no additional product.
" RADIO / MEDIA
"

" TELEPHONE
"
(If conversation in progress)


SETUP :
PARAMETERS



date and time, display parameters, sound.
Changing the audio source:
RADIO
:
radio broadcasts.

MUSIC
: playing MEDIA.






Press the MODE
button several times in succession for access to the following displays:

GENERAL OPERATION


" FULL SCREEN MAP
"

" MAP IN WINDOW
"

298
03
A press on the OK dial gives access to
short-cut menus according to the display
in the screen.

GENERAL OPERATION







DISPLAY ACCORDING TO CONTEXT

RADIO:


Activate/Deactivate TA

Activate/Deactivate RDS



MUSIC MEDIA PLAYERS,
CD or USB
(according to media):
Play modes:

Normal

Random

Random on all media

Repetition



TELEPHONE
(call in progress):

Private mode

FULL SCREEN MAP OR
IN A NEW WINDOW:

Stop/Restore guidance
Select destination

Enter an address


Directory


GPS coordinates



Divert route


Move the map

Info. on location


Select as destination


Select as stage


Save this place (contacts)


Quit map mode




Guidance criteria


Put call on hold

DTMF ring tones

Hang up

1
1
1
1
1
1
1
1
2
2
2
2
2
1
2
2
2
1
1
1
1
1
1

340
FREQUENTLY ASKED QUESTIONS



QUESTION



ANSWER



SOLUTION


Certain traffi c jams
along the route are not
indicated in real time. On starting, it is several minutes before the system begins to receive the
traffi c information. Wait until the traffi c information is being received
correctly (display of the traffi c information icons on
the map).
The fi lters are too restrictive. Modify the "Geographic fi lter" settings.
In certain countries, only major routes (motorways...) are listed for the
traffi c information. This phenomenon is normal. The system is
dependent on the traffi c information available.
The altitude is not
displayed. On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 4 satellites correctly. Wait until the system has started up completely.
Check that there is a GPS coverage of at least
4 satellites (long press on the SETUP button, then
select "GPS coverage").
Depending on the geographical environment (tunnel...) or the weather,
the conditions of reception of the GPS signal may vary. This phenomenon is normal. The system
is dependent on the GPS signal reception
conditions.
I cannot connect my
Bluetooth telephone. The telephone's Bluetooth function may be switched off or the telephone
may not be visible.

- Check that your telephone's Bluetooth
function is switched on.

- Check in the telephone settings that it is
"visible to all".
The Bluetooth telephone is not compatible with the system. A list of compatible Bluetooth mobile telephones is
available from the dealer network.
The volume of the
telephone connected
in Bluetooth mode is
inaudible. The volume depends both on the system and on the telephone. Increase the volume of the audio system,
to maximum if required, and increase the volume
of the telephone if necessary.
The ambient noise level has an infl uence on the quality of telephone
communication. Reduce the ambient noise level (close the windows,
reduce the booster fan speed, slow down, ...).

346
01
1
2
7
45
6
3
8
9
10
13
1112
14
FIRST STEPS



1. On/Off and volume adjustment.

2. CD eject.

3. Selection of the display on the screen from
the following modes:
Full screen: Audio (or if a telephone call is in
progress)/
New window: Audio (or telephone if a call is
in progress) - Time or Trip computer
.
Long press: black screen (DARK).

4. Selection of source:
Radio, CD, AUX, USB, Streaming.
Accept an incoming call.

5. Selection of FM1, FM2, DAB and AM
wavebands.

6. Buttons 1 to 6:
Selection of a preset radio station.
Long press: preset a station.
7. Display the list of stations received,
the CD/MP3 tracks or folders.
Long press: MP3/WMA fi le order/update
the list of stations received.

8. TA (Traffi c Announcement) function on/off.
Long press: access to the type of
information.

9. Confi rmation or display of contextual menu.

10. Abandon current operation.
Up one level (menu or folder).

11 . Automatic search for a lower/higher radio
frequency.
Selection of previous/next CD, USB,
streaming track.
Navigation in a list.
12. Manual step by step search for a lower/
higher radio frequency.
Selection of the previous/next MP3 folder.
Selection of the previous/next USB device
folder/genre/artist/playlist.
Navigation in a list.

13. Main menu.

14. Audio settings:
equalizer, treble, bass, loudness,
distribution, left/right balance, front/rear,
automatic volume.

359
05
1
25
3
4
6
USING THE TELEPHONE










PAIRING A TELEPHONE


The services offered depend on the network, the SIM card and the compatibility of the Bluetooth telephone used.

Consult your telephone's manual and your operator to fi nd out which services are available to you. A list of mobile telephones which offer the best
range of services is available from the CITROËN dealer network.


Activate the telephone's Bluetooth function.

Press MENU
.
A window is displayed " Search in progress…
".

Select the telephone to be connected
from the list. Only one telephone can
be connected at a time.
Select " Search for a device
".
For safety reasons and because they require prolonged attention on the part of the driver, the operations for pairing of the Bluetooth mobile
telephone with the Bluetooth hands-free system of your audio system must be carried out with the vehicle stationary and the ignition on.

Select " Bluetooth connection
" and
confi rm.

Exterior


Remote control 100 -106


- opening/closing

- antitheft protection

- starting

- battery


Lighting c ontrols 12 2-126
Headlamp adjustment 128
Welcome lighting 127
Directional lighting systems 129 -130
Changing bulbs 256 -260


- front lamps

- front foglamps

- side repeaters

Wiper controls 131-135
Changing a wiper blade 273

Door mirrors 95-96
Blind spot sensors 216 -218

Doors 112-113


- opening/closing

- emergency control
Child lock 169
Electric windows 115 -116
Alarm 109-111

F u e l t a n k 117-11 8
Misfuel prevention 119
Accessories 278-279

Braking assistance 176-177
Trajectory control 177-178
Tyre under-inflation detection 174-175
Tyre pressures 248, 287
Boot 114
Temporary puncture repair kit 244-248
Changing a wheel 249 -255


- tools

- removing/refitting


Changing bulbs 261-263


- rear lamps

- 3rd brake lamp

- number plate lamp



Parking sensors 226 -227
Parking space sensors 224-225
Towbar 276-277
Towing 274-275

Instruments and controls

Instrument panels 38 - 40
Warning lamps 41-51
Indicators 52-54
Manual test 55
Setting buttons 56 -59


- trip distance recorder

- lighting dimmer/black panel

- customisation of dials and screens


Stop & Star t 212-214
Lane depar ture warning system 215
Lighting c ontrols 12 2-126
Adjusting headlamps 128

Door mirrors 95 -96
Electric windows 115 -116

Dashboard fuses 263 -266

Opening the bonnet 231

Adjusting the steering wheel 94
Horn 173
Multifunction screens 62- 69
Seat belt and front passenger
airbag warning display screen 180 -181

Manual gearbox 201-202
6 -speed electronic gearbox
system 203-206
Automatic gearbox 207-210
Parking brake 192-199, 200
Rear view mirror 97
Emergency or
assistance call 173, 291
Cour tesy lamps 136
Wiper controls 131-135
Trip computer 70 -74

Ventilation 78 -79
Manual air conditioning 80 - 81, 86
Digital air conditioning 82- 86
Demisting/Defrosting
the rear screen 87
Audio system 345 -377
Setting the date/time 369

eMyWay satellite navigation system 293-344
Setting the date/time 335
Interior mood lighting 137


Hazard warning lamps 172-173
Central locking 107-108
Black panel 58
Memorising speeds 219
Speed limiter 220 -221
Cruise control 222-223

385Alphabetical index
Directional lighting .............................. 129, 130
Direction indicators ..... 125, 172, 257, 258, 261
Doors ........................................................... 112
Doors emergency control ........................... 113
Door trays .................................................... 142
Driving economically .................................... 34
Driving positions (storing) ............................. 92
Dynamic emergency braking ...................... 195
EBA
(Emergency braking assistance) ...... 176, 177
Eco-driving ................................................... 34
Economy mode ........................................... 272
Electric window controls ............................. 115
Electronic brake force distribution
(EBFD) ...................................................... 176
Electronic engine immobiliser ............. 103, 106
Electronic stability control (ESC) ................ 177
Emergency boot release ............................. 114
Emergency braking assistance .................. 177
Emergency call ................................... 173, 292
Emergency warning lamps ................. 172, 173
eMyWay ................................................66, 293
Energy economy mode ............................... 272
Engine, Diesel .....................118, 232, 234, 284
Engine, petrol .............................. 118, 233, 282
Engine compartment ...........................233, 234
Engine compartment fusebox ..................... 267Engine oil level indicator .................52, 55, 235
Engines ...............................................282, 284
Environment ..... 34, 79, 87, 106, 210, 237, 270
Equipment settings ...........................62, 66, 68
ESC/ASR ..................................................... 177
ESP ............................................................. 177
E
Gearbox, electronic.....................203, 212, 239
Gearbox, manual ................ 201, 202, 212, 239
Gear efficiency indicator ............................. 202
Gear lever,
automatic gearbox .................................... 207
Gear lever,
electronic gearbox system ....................... 203
Gear lever, manual gearbox ....................... 201
Glove box .................................................... 143
Guidance .....................................................299
Guide-me-home .......................................... 125
Filling with fuel ......................................117-119
Fitting a wheel .............................................254
Fittings, boot ............................................... 153
Flashing indicators ..............125, 172, 258, 259
Foglamps, rear ............................ 124, 261, 263
Front foglamps .................... 124, 130, 257, 260
Front seats ........................................88, 89, 92
Fuel....................................................... 34, 118
Fuel consumption ......................................... 34
Fuel filler flap ........................................ 117, 119
Fuel gauge ............................................ 23, 117
Fuel tank ............................................... 117, 119
Fusebox, dashboard ................................... 265
Fuses ........................................................... 263
F
G.P.S. ..........................................................299
Gearbox, automatic ............................ 207, 239
G
Halogen headlamps .................................... 257
Hands-free kit...................................... 316, 359
Hazard warning lamps ........................ 172, 173
Headlamp adjustment ................................. 128
Headlamps, directional ............... 128, 129, 257
Headlamp wash .......................................... 133
Head restraints, front .................................... 90
Head restraints, rear ..................................... 94
Heated seats ................................................. 90
Heating ................................................... 34, 80
Height and reach adjustment,
steering wheel ............................................ 94
Hill star t assist ............................................. 211
Hooks .......................................................... 154
H
