169Child safety










ISOFIX child seat recommended by CITROËN and approved for
your vehicle
This child seat can also be used on seats which are not fitted with ISOFIX mountings. In this case, it must be attached to the vehicle seat using the three point seat belt.Follow the instructions for fitting the child seat given in the seat manufacturer's installation guide.
"

RÖMERDuo Plus ISOFIX"(size category B1)
Group 1: from 9 to 18 kg


Installed only in the forwards-facing position.Fitted with an upper strap to be secured on the upper ring B, referred to as the TOP TETHER.
Three seat body angles: sitting, reclining, lying.
) Adjust the front seat of the vehicle so that the child's feet do not touch the back of the seat.

Locations for ISOFIX child seats In accordance with European Regulations, this table indicates the options for installing ISOFIX child seats on seats in the vehicle fitted with ISOFIXmountings.
In the case o
f universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from Ato G , is indicated on the childseat next to the ISOFIX logo.
IUF:seat suitable for the installation of an I sofix U
niversal seat, "F
orward facing" secured using the upper strap.IL- SU:
seat suitable for the installation of an I sofix S emi-U
niversal seat either:
- "rear facing" fitted with an upper strap or a stay,
- "forward facing" fitted with a stay,
- an infant car seat fitted with an upper strap or a stay.
For advice on securing of the upper strap, refer to the paragraph "ISOFIX mountings".
* Infant car seats and "car cots" cannot be installed on the front passenger seat.
** The ISOFIX infant car seat, secured on the lower rings of a vehicle ISOFIX seat, occupies two rear seats.
Weight of the child
/indicative age
Less than 10 kg(group 0)Up to approx. 6 months
Less than 10 kg(group 0)
Less than 13 kg(group 0+)Up to approx. 1 year
From 9 to 18 kg (group 1)From approx. 1 to 3 years
Type of ISOFIX child seatInfant car seat

*"rear facing""rear facing""for ward facing"
ISOFIX size categoryFGCDECDABB1
ISOFIX child seats universal and semi-universalwhich can be installed on the rear outer seatsIL-SU**IL-SUIL-SUIUFIL- SU

171Child safety








Manual child lock
Mechanical system to prevent opening of the rear door using its interior control.
The control is located on the edge of each rear door.


Locking
)Using the ignition key, turn the red controlas far as it will go:
- to the left on the left-hand rear door,
- to the right on the right-hand rear door.


Unlocking
)
Using the ignition key, turn the red control
as far as it will go:


- to the right on the left-hand rear door,

- to the left on the right-hand rear door.

008
Safety

Direction indicators
)Left: lower the lighting stalk passing thepoint of resistance.)Right: raise the lighting stalk passing the point of resistance.
"Motorway" function
)
Press briefly upwards or downwards,
without going beyond the point of
resistance; the direction indicators will
flash 3 times.










Hazard warning lamps
A visual warning by means of the direction
indicators to alert other road users to a vehicle
breakdown, towing or accident. )Press this button, the direction indicators
fl
ash.
They can operate with the ignition off.

If you forget to cancel the direction indicators for more than twenty seconds, the volume of theaudible signal will increase if the speedis above 40 mph (60 km/h).

175
Safety
Automatic operation of
hazard warnin
g lamps
When braking in an emergency, depending on
the deceleration, the hazard warning lamps come on automatically.
They switch off automatically the first time you accelerate.)You can also switch them off by pressingthe button.






Horn
Audible warning system to alert other roadusers to an imminent danger. )
Press the central part of the mutlifunction steering wheel.
Use the horn moderately and only in the following circumstances: - immediate danger,- approaching a location lacking
visibility.









Emergency or
assistance call
This system allows you to make an emergency or assistance call to the emergency ser vices or
to the dedicated CITROËN ser vice.
F
or more information on the use of this
function, refer to the "Audio and telematics" section.

Ty r e u n d e r - i nfl ation detection
System which automatically and continuously checks the pressure of the tyres while driving.Sensors fitted in each valve trigger a warning
in the event of problem (speed above 12 mph(20 km/h)).

Puncture

The tyre under-inflation detectionsystem is an aid to driving which doesnot replace the need for the driver to bevigilant or to drive responsibly.


Under-infl ated tyre
This warning lamp is displayed on the
instrument panel and/or a message appears
in the screen, accompanied by an audible
si
gnal, to identify the wheel concerned.
The STOPwarning lamp comes on and/or this warning lamp is displayed on
the instrument panel, accompanied by
an audible signal and a message in the
screen identifying the wheel concerned.
)Stop as soon as it is safe to do so, avoiding any sudden movement of the steering
wheel and the brakes.)Repair or change the damaged wheel(punctured or very deflated tyre), and have
the tyre pressure checked as soon as possible.
) Check the tyre pressures as soon as possible.
This check must be carried out when the tyres
are cold.

177Safety

Sensor(s) not detected or faulty
A message appears in the screen,
accompanied by an audible signal, to identify
the wheel or wheels which are not detected or
to indicate a malfunction in the s
ystem.
Contact a CITROËN dealer or a qualified
workshop to replace the
faulty sensor(s).
All repairs and changing of tyres on a wheel fitted with this system must be carried out by a CITROËN dealer or aqualified workshop.
If, when changing a tyre, you install a wheel which is not detected by your vehicle (example: fitting of snow tyres),you must have the system reinitialised by a CITROËN dealer or a qualified workshop.
This system does not avoid the needto have the tyre pressures checkedregularly (refer to the "Identificationmarkings" section) to ensure that
the optimum dynamic performanceof the vehicle is maintained andprevent premature wear of the tyres, particularly in arduous driving conditions (heavy load, high speed). The tyre pressures must be checked cold, at least once a month. Remember to check the pressure of the spare wheel. The tyre under-inflation detection system may experience temporary inter ference due to electro-magnetic emissions on a frequency close to thatused by the system.

This message is also displayed when one of the wheels is away from the vehicle (being repaired) or when oneor more wheels without a sensor are fitted.
If your vehicle is equipped with a spare wheel, this is not fitted with a sensor.

Braking assistance systems
Group of supplementary systems which helpyou to obtain optimum braking in complete safety in emergency situations:
- anti-lock braking system (ABS),
- electronic brake force distribution
(EBFD),
- emergency braking assistance (EBA).

Anti-lock braking system
and electronic brake force
distribution
Linked systems which improve the stability and
manoeuvrability of your vehicle when braking,
in par ticular on poor or slippery surfaces.
Activation
The anti-lock braking system comes into
operation automatically when there is a risk of
wheel lock.
Normal operation of the ABS may make itself
felt by slight vibration of the brake pedal.
When braking in an emergency, pressvery firmly without releasing thepressure.


Operating fault
If this warning lamp comes on,
together with the STOPand ABSwarning lamps, accompanied by an
audible signal and a message in the screen, it
indicates a malfunction of the electronic brake force distribution which could result in loss of control of the vehicle when braking.You must stop as soon as it is safe to do so.

When replacing wheels (tyres andrims), ensure that they conform to themanufacturer's recommendations.
If this warnin
g lamp comes on,
accompanied by an audible signaland a message in the screen, it
indicates a malfunction of the anti-lock brakingsystem which could result in loss of control of
the vehicle when braking.
In either case, contact a CITROËN dealer or a
qualified workshop.
