USB Citroen DS4 2012 1.G Owner's Guide

04
1
3
2
4
5












CD, USB
AUDIO


PLAYING A COMPILATION

Insert an MP3 compilation in the
CD player or connect a memory stick to the USB port, directly or
via an extension lead.
The s
ystem creates playlists (temporary memory) the creation time
for which can take from a few seconds to several minutes.
The pla
ylists are updated every time the ignition is switched off or aUSB memory stick is connected.
Pla
y starts automatically after a period which depends on the capacity of the USB memory stick.

At a fi rst connection, the order suggested is by folder.When connecting again, the order previously chosen is retained.

To play a disc or memory stick whichhas already been inserted, press
SOURCE
or SRC
several times insuccession and select " CD" or "USB".
Pr
ess one of the buttons to select the next or previous track.

Pr
ess one of the buttons to select the next or previous folder in the order chosen.

Pr
ess and hold one of the buttons for
fast forwards or backwards.

Press LISTto display the menu of folders in the compilation.

359
7
6
8
9
2
1
04
Select a line in the list.
Select a track or a folder.
Jump a pa
ge. Up a level in the menu.
AUDIO









USB MEMORY STICK - FILE
CLASSIFICATION

Having selected the desired classifi cation (" By folders", " By artists", " By genres", " Byplaylists
") press OK.

Then confi rm OKto save the modifi cations.


-
By folders: all folders containing audiofi les recognised on the peripheral device, in alphabetical order without following the folder structure.

-
By artists
: all of the artist names defi ned in the ID3 Tags, in alphabetical order.
-By genres
: all of the genres defi ned in the ID3 Tags.

-
By playlists
: if playlists have been saved.


Make a long press on LISTor press
MENU , select " Multimedia
", then
" Media parameters" and fi nally "Choice of track listing
" to display the differentclassifi cations.

04AUDIO

APPLE ®
PLAYERS or PORTABLE PLAYER
Management of the device is via the audio system controls.
The audio
fi les on a Mass Storage portable player *
can
be heard through the vehicle's speakers by connectingit to the USB port (cable not supplied).
If the portable pla
yer is not recognised by the USB port,connect it to the auxiliary Jack socket.The Apple
Æ player must be updated regularly for the bestÆ
connection.
The pla
ylists are those defi ned in the Apple Æplayer.
The Apple
Æplayer must be generation 5 or later.

*

Check your player's manual.

361
3
2
4
04
1
AUDIO















AUXILIARY SOCKET (AUX)


AUXILIARY JACK SOCKET
Do not connect a device to the USB port and to the auxiliar
yJack socket at the same time. The auxiliar
y Jack socket permits the connection of a portable
non-mass storage device or an Apple® player if not recognised ®
by the USB port.
Connect the portable device to the auxiliary Jack socket using a suitable cable (not supplied). Pr
ess the SOURCEor SRCbutton several times in succession and select "AUX".


First adjust the volume on your portable device.
Then ad
just the volume of the audio
system.

The displa
y and management of controls is on theportable device.

377
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
The CD is ejected
automatically or is not played by the player. The CD is inserted upside down, is unpla
yable, does not contain any audio data or contains an audio format which the player cannot play.
The
CD is protected by an anti-pirating protection system which is not recognised by the audio equipment.
- Check that the CD is inserted in the pla
yer the
right way up.

-
Check the condition of the CD: the CD cannot
be played if it is too damaged.

-
Check the content in the case of a recordedCD: consult the advice in the "Audio" section.

- The audio equipment's CD pla
yer does not
play DVDs.

-
Due to their quality level, certain writeableCDs will not be played by the audio system.
The CD pla
yer sound ispoor.The CD used is scratched or of poor quality. Insert good quality CDs and store them in suitable conditions.
The audio settin
gs (bass, treble, ambience) are unsuitable. Set the treble or bass level to 0, without selectingan ambience.
Th
e Bluetooth connectionis cut. The battery of the peripheral may not be suffi ciently charged. Recharge the battery of the peripheral device.
The messa
ge "USB
device error" is displayed
on the screen.The U
SB memory stick is not recognised.
The memory stick may be corrupt. Reformat the memory stick (FAT 3 2).

QUESTIONANSWER SOLUTION
A telephone connects
automatically,
disconnecting another
telephone. Automatic connection overrides manual connection. Modify the telephone settings to remove automatic connection.

The Apple ®
player is®
not recognised whenconnecting to the USB port.
The Apple ®player is of a generation that is not compatible with the USB. Connect the Apple ®player to the AUX Jack socket using a suitable cable (not supplied).
Th
e hard disk or deviceis not recognised whenconnecting to the USBport. Some hard disks and devices need a power suppl
y greater than is
provided by the audio system. Connect the device to the 230 V socket, the 12 V socket or an external power supply.
Caution
:
ensure that the device does not transmit
a voltage greater than 5 V (risk of destruction of
the system).
When streamin
g, the sound cuts momentarily. Some telephones prioritise connection of the "hands-free" profi le. Delete the "hands-free" connection profi le toimprove streaming.
In "Random all" pla
y,not all of the tracks areplayed.In "Random all" pla
y, the system can only take into account up to 999
tracks.
With the en
gine off, the
audio system switches off after a few minutes of use. When the en
gine is switched off, the audio system operating timedepends on the battery charge.
The switch-o
ff is normal: the audio system switches to economy mode and switches off to prevent discharging the vehicle's battery. Start the vehicle's en
gine to increase the batterycharge.
The messa
ge "the audio system is overheated"
appears on the display. In order to protect the installation if the surroundin
g temperature is too
high, the audio system switches to an automatic thermal protection mode leading to a reduction of the volume or stopping of the playing of the CD. Switch the audio s
ystem off for a few minutes to
allow the system to cool.

383Visual search
Interior


Boot fittings 155 -15 8


- rear parcel shelf

- hooks

- 12 V socket

- torch

- lashing eyes

- storage compar tment

Rear seats
93-94
Rear armrest/Ski flap 154
IS
OFIX mountings 168 -170

Child seats 162-167
Front seats
88-92
Seat belts 181-184 Airbags 185 -190

Glove box 145
Deactivating the passenger's airbag 187
Interior fittings 144-154
- auxiliary socket/USB por t
- cigarette lighter/12 V socket
- portable ashtray- front armrest
- 230 V/50 Hz socket
- mats


Panoramic windscreen 12


- blind

- sun visor

389Alphabetical index
Paint colour code..........................................291Parcel shelf, rear...........................................r156Parking brake........................................202,242Parking brake, electric ..........................194, 198Parking lamps ...............................................127Parking sensors, front ...................................229Parking sensors, rear....................................r228Parking space sensor ..................................226Particle emission filter..........................r239, 241Passenger compartment filter......................r240Personalisation...............................................60Player, CD MP3.....................................357,358Port, USB ..............................................146, 359Priming the fuel system ................................234
Protecting children .........162, 166, 168-170, 186Puncture........................................................ 246
Removing a wheel........................................254Removing the mat.........................................152Repair kit, puncture .......................................246Replacing bulbs....................................258,263Replacing fuses ............................................265Replacing the air filter...................................r240Replacing the oil filter...................................r240Replacing the passenger compartment filter......................................r240Replacing wiper blades.........................136,275Resetting the service indicator.......................r56Resetting the trip recorder..............................r58Rev counter.........................................r38, 39, 42Reversing lamps ...........................................263Risk areas (update).......................................308Roof bars ....................................................... 276Routine checks.....................................240, 242Running out of fuel (Diesel).......................................................234
Seat, rear bench.............................................93Seat adjustment........................................88, 89Seat belts......................................181, 182, 184Seats, electric .................................................89Seats, rear.......................................................r93Serial number, vehicle ..................................291Ser vice indicator.......................................r55, 57Servicing.........................................................34Setting the clock...................................339,372Short-cut menus...........................................302Sidelamps.............................124, 127, 259, 263Side repeater.................................................261Ski flap..........................................................154Spare wheel ..................................................251Speed limiter.........................................r221, 222Speedometer............................................r38,39Spotlamps, side....................................129, 262Starting the vehicle.......................104,205, 209Steering mounted controls....................300,351Stopping the vehicle.....................104,205, 209Stop & Start.................................74, 83,86, 117, 214, 233,240, 271Storage..................144,145, 147, 149,150, 155Storage compar tments .................................147Storage drawer..............................................153Storage net....................................................155Storing driving positions.................................92Stowing rings................................................155Synchronising the remote control.........................................................105Synthesiser, voice .........................................314System, navigation ........................................304
P
Radio.............................................329, 330, 353Rear screen(demisting)..............................................87,95Recharging the battery.................................271Reduction of electrical load..........................274Regeneration of the par ticleemissions filter............................................r241Reinitialising the electric windows ................ 115Reinitialising the remote control...................105Remote control..............................100, 102, 106Removable screen(snow shield)...............................................275
R
Safety for children.........................................171Satellite navigation system .............................68Screen, colour and
mapping..................................40,68, 301,340Screen, monochrome.............................64, 373Screen, multifunction (with audio equipment)...................64,68, 352Screen menu map .........................340, 373, 374Screenwash, front.........................................135
S

Table of weights....................................286, 288Ta b l e s o f e ngines..................................286,288Tables of fuses ..............................................265Tank, fuel.......................................................119Technical data .......................................286,288Te l e p h o ne.............................................320, 324Te mperature control for heatedseats.............................................................90Temporary tyre repair kit...............................246Ticket holder..................................................r144TMC(Tr a f f i c i n f o).................................................317Tools ..............................................................251Torch .............................................................157Total distance recorder...................................r58To w b a r...........................................................r279Towed loads..........................................286, 288Towing another vehicle.................................277Traction control (ASR)..........................................................179Traffic information(TA) .............................................318, 331, 354Traffic information(TMC) ...................................................317,318Trajectory control systems ............................ 179Tr i p c o m p u t e r......................................r70,72, 74Tr i p d i s t a n c e r e c o r d e r.....................................r58Tyre pressures..............................................291Tyres................................................................34Tyre under-inflation detection ..................57, 176
Under-inflation (detection)............................176Under floor storage.......................................158Unlocking from the inside.............................107Unlocking the boot ................................100,114Unlocking the doors ......................................100Update risk areas ..........................................308Updating the date ..................................339, 372Updating the time..................................339, 372USB Box........................................................146
Vehic le c onfiguration ..........................40, 64, 68Ventilation .................................................78-80
U
V T
Warning lamps..............................43, 46, 51,57Wash-wipe, rear............................................r137Weights.................................................286, 288Welcome lighting ...........................................129Window controls............................................115Wiper, rear.....................................................r137Wiper control stalk........................ 133, 134, 137Wipers .............................................52, 133, 134
W
Xenon headlamps.........................................259
X
